MODEL NO. SPA021
BLUETOOTH PA SPEAKER
INSTRUCTION MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
Warnings and Precautions
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
This symbol, located on back or bottom of the unit, is
intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol, located on back or bottom of the unit, is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
This product utilizes a Class 1 laser to read Compact
Discs. This laser Compact Disc Player is equipped with
safety switches to avoid exposure when the CD door
is open and the safety interlocks are defeated. Invisible
laser radiation is present when the CD Player’s lid
is open and the system’s interlock has failed or been
defeated. It is very important that you avoid direct
exposure to the laser beam at all times. Please do not
attempt to defeat or bypass the safety switches.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
To reduce the risk of electric shock, do not remove
cover (or back). There are no user-serviceable parts
inside. Please refer any servicing to qualified service
personnel.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
WARNING: Changes or modifications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
2
Important Safety Instructions
1. Read Instructions - All the safety and
operating instruction should be read before the
product is operated.
2. Retain Instructions - The safety and
operating instruction should be retained for
future reference.
3. Heed Warnings - All warning on the product
and in the operating instructions should be
adhered to.
4. Follow instructions - All operating and use
instructions should be followed.
5. Cleaning - Unplug this product from the
wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Clean only with a
dry cloth.
6. Attachments - Do not use attachments not
recommended by the product manufacturer as
they may cause hazards.
7. Water and Moisture - Do not use this product
near water - for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a wet
basement, or near a swimming pool, and the
like. The apparatus shall not be exposed to
dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on
apparatus.
8. Accessories - Do not place this product on
an unstable cart, stand tripod, bracket, or
table. The product may fall, causing serious
injury to a child or adult, and serious damage
to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer’s instructions, and should use
a mounting accessory recommended by the
manufacturer.
9. A product and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance
and cart combination to overturn.
See figure:
10. Ventilation - Slots and openings in the cabinet
are provided for ventilation and to ensure
reliable operation of the product and to protect
it from overheating, and these openings must
not be blocked or covered. The openings
should never be blocked by placing the
product on a bed, sofa, rug, or other similar
surface. This product should not be placed in a
built-in installation such as a bookcase or rack
unless proper ventilation is provided or the
manufacturer’s instruction have been adhered
to.
11.
Power Sources - This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your home,
consult your product dealer or local power
company. For products intended to operate
from battery power, or other sources, refer to
the operating instruction.
12. Grounding or Polarization - This product
may be equipped with a polarized alternatingcurrent line plug (a plug having one blade
wider than the other). This plug will fit into
the power outlet only one way. This is a safety
feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarizes
plug.
Alternate Warnings - This product is
equipped with a three-wire grounding-type
plug, a plug having a third (grounding) pin.
This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet,
contact your electrician to replace your
obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug.
13. Power-Cord Protection - Power supply cords
should be routed so that they are not likely to
be walked on or pinched by items placed upon
or against them, paying particular attention to
cords at plugs, convenience receptacles, and
point where they exit from the product.
14. Protective Attachment Plug - The product
is equipped with an attachment plug having
overload protection. This is a safety feature.
See Instruction Manual for replacement or
resetting of protective device. If replacement
of the plug is required, be sure the service
technician has used a replacement plug
specified by the manufacturer that has the
same overload protection as the original plug.
15. Outdoor Antenna Grounding - If an
outside antenna is connected to the receiver,
be sure the antenna system is grounded
so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with
regard to proper grounding of the mast and
supporting structure, grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna-discharge unit, size
of grounding conductors, location of antennadischarge unit, connection to grounding
electrodes, and requirements for the grounding
electrode.
See figure:
16. Lightning - For added protection for this
product during a lightning storm, or when it
is left unattended and unused for long periods
of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This
will prevent damage to the product due to
lightning and power-line surges.
17.
Power Lines - An outside antenna system
should not be located in the vicinity of
overhead power lines or other electric light or
power circuits, or where it can fall into such
power lines or circuits. When installing an
outside antenna system, extreme care should
be taken to keep from touching such power
lines or circuits as contact with them might be
fatal.
18. Overloading - Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
19.
Object and Liquid Entry - Never push
objects of any kind into this product through
openings as they may touch dangerous voltage
points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any
kind on the product.
20. Servicing - Do not attempt to service this
product yourself as opening or removing
covers may expose you to dangerous voltage
or other hazards. Refer all servicing to
qualified service personnel.
21. Damage Requiring Service - Unplug
this product from the wall outlet and refer
servicing to qualified service personnel under
the following conditions:
a) When the power-supply cord or plug is
damaged,
b) If liquid has been spilled, or objects have
fallen into the product,
c) If the product has been exposed to rain or
water,
d) If the product does not operate normally
by following the operating instructions.
Adjust only those controls that are covered
by the operating instructions as an improper
adjustment of other controls may result in
damage and will often require extensive work
by a qualified technician to restore the product
to its normal operation.
e) If the product has been dropped or
damaged in any way, and
f) When the product exhibits a distinct change
in performance - this indicates a need for
service.
22.
Replacement Parts - When replacement parts
are required, be sure the service technician
has used replacement parts specified by the
manufacturer or have the same characteristics
as the original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.
23. Safety Check - Upon completion of any
service or repairs to this product, ask the
service technician to perform safety checks
to determine that the product is in proper
operating condition.
24. Wall or Ceiling Mounting - The product
should be mounted to a wall or ceiling only as
recommended by the manufacturer.
25.
Heat - The product should be situated away
from heat sources such as radiators, heat
registers, stoves, or other products (including
amplifiers) that produce heat. Battery shall not
be exposed to excessive heat such as sunshine,
fire, or the like.
26. Main plug is used as disconnect device and
it should remain readily operable during
intended use. In order to disconnect the
apparatus from the mains completely, the
mains plug should be disconnected from the
mains socket outlet completely.
27. Excessive sound pressure from earphones and
headphones can cause hearing loss.
3
LOCATION OF CONTROLS
4
FUNCTION LOCATION
1. ECHO KNOB
- Turn to adjust echo level low and high.
2. MICROPHONE VOLUME KNOB
- Turn to adjust microphone volume.
3. BASS KNOB
- Turn to adjust bass level low and high.
4. TREBLE KNOB
- Turn to adjust treble level low and high.
5. MASTER VOLUME KNOB
- Adjust master volume level low and high.
6. POWER LED INDICATOR
- To indicator unit power on or off.
7. LED DISPLAY
- To indicate status of the unit (FM, BT, AUX IN)
8. DC Jack
- DC jack for input AC adaptor for charging built in battery or unit operation.
9. POWER ON/OFF SWITCH
- To switch on or off the unit.
10. LEFT CHANNEL AUX IN JACK
- Connect RCA cable to playback external deivce (e.g iPod, Cell Phone)
11. RIGHT CHANNEL AUX IN JACK
- Connect RCA cable to playback external deivce (e.g iPod, Cell Phone)
12. MICROPHONE JACK
- For microphone input
13. LOW BATTERY INDICATOR
- When low battery indicator is lit and mean battery only have 10% of the energy left
14. HIGH BATTERY INDICATOR
- When high battery indicator is lit and mean battery have over 90% of the energy available
15. CHARGING INDICATOR
- When charging indicator is lit and mean the battery is recharging.
16. BACK/TUNING DOWN BUTTON
- To skip back track during Bluetooth Mode
- Tuning down radio frequency in FM Radio Mode
17. PAUSE BUTTON
- To pause during Bluetooth Mode
18. FORWARD/TUNING UP BUTTON
- To skip forward track during Bluetooth Mode
- Tuning up radio frequency in FM Radio Mode
19.MODE BUTTON
-To select a mode, follow by is bluetooth mode, FM radio mode, LIN IN mode back to bluetooth mode,
circulation in turn.
20. FM ANTENNA
- Extend the antenna for better receiption
21. ROLLER BAR
- Easier to move the unit
5
POWER SOURCE
Plug the included AC/DC power adapter (120W/60Hz 15V) into the DC POWER INPUT
on the dock and an AC power outlet to power the dock.
RECHARGEABLE BATTERIES
Rechargeable lead-acid batteries are the same type used in automobiles.
As with your car battery, how you use this battery has a significant impact on its lifespan.
With proper use and treatment, a lead-acid battery can last for years. Here are some
recommendations for getting the longest life from the internal battery.
GENERAL USAGE
• FULLY CHARGE THE BATTERY BEFORE USING IT.
• CHARGE THE BATTERY COMPLETELY AFTER EACH USE.
• AVOID COMPLETELY DRAINING THE BATTERY.
• You may leave the unit plugged in for up to two weeks.
• For maximum life, drain the battery 80% once a month.
STORAGE
• Avoid storing in high temperatures and moist places.
• For long-term storage, periodically recharge the battery.
• If you do not charge the battery for six months, it may not charge.
DISPOSAL
• Bring the unit to a recycling center or dispose of in accordance with local ordinances.
6
PAIRING A BLUETOOTH DEVICE
1. Turn on your Bluetooth device.
2. Power on the unit and switch to Bluetooth Mode. It will automatically go into pairing
mode to search for Bluetooth devices. You will know you are in pairing mode when the
LED is blink.
3. If your Bluetooth device is not able to pair to the unit, switch off the unit and switch on
again to break previous Bluetooth connections and reset the Bluetooth module.
4. Navigate to your Bluetooth device’s setup screen, find “SPA021” and connect.
Note: If your Bluetooth device prompts for a pairing code, enter ‘0000’.
5. When LED will light up solid when it is 'paired'.
Note: Users should consider updating their OS if experiencing trouble with pairing
or playing music.
6. To disconnect pairing, switch off the unit.
7. To connect to another Bluetooth device, repeat steps 3-4.
CARE AND MAINTENANCE
1. Clean the unit with a soft, damp (never wet) cloth. Solvent or detergent should never
be used.
2. Avoid operating your unit under direct sunlight or in hot, humid or dusty places to
reduce the risk of fire or electric shock.
3. Keep your unit away from heating appliances and sources of electrical noise such
as fluorescent lamps or motors.
4. Unplug the AC adapter from the unit and the electrical power outlet immediately in
case of malfunction.
TROUBLESHOOTING GUIDE
# If the sound is distorted: Try lowering the volume control of your sound source or
musical instrument. Also, try to reduce the overall volume of the unit.
# If there is too much bass: Try adjusting the bass control on the unit to lower the bass
level. This will allow you to play the music louder before clipping (distortion) occurs.
# If there is a high-pitched whistling noise when using microphones: This is probably
feedback. Point the microphones away from the speaker.
#If you can’t hear the microphone over the music volume: Turn down the music volume
from your source.
SPECIFICATIONS
Frequency:
FM 87.5 - 108 MHz
AC Adapter: Input - 120V~240V ~ 60Hz
Output - DC 15V 1A
Accessiories: AC Adaptor, Microphone x 1, RCA Audio Cable x 1
Rate Power: 10W (RMS: 15W)
Accessories: AC Adaptor, Microphone x 1, RCA Audio Cable x 1, instruction manual
Cabinet dimension: 265(L)*200(W)*370(H)mm
Weight: 11.3kg
7
LIMITED PRODUCT WARRANTY
This quality product is warranted to be free from manufacturer’s defects in material and workman-ship,
provided that the unit is used under the normal operating conditions intended by the manufacturer.
Should you have any problem with this product, please and it is highly recommended to visit our website at
www.curtisint.com before you take any other steps as we have additional copies of instruction manuals,
operating manuals and trouble shooting tips on our website which gives you the answer on most of the
questions you could have in operating the unit.
TERMS OF WARRANTY
C.I. Service Dept. warrants this product to be free from defects in materials and workmanship for 90 days on
parts and 90 days on labor. If you originally purchased your product more than 90 days ago, a repair fee
may apply.
Nothing within this warranty shall imply that C.I. will be responsible or liable for any damage to any items
placed in this product, whether due to any defect of the product, or its use, whether proper or improper.
EXCLUSIONS
Save as herein provided, C.I. Service Dept. (Canada) or C.I. Service Dept. (USA), there are no other
warranties, conditions, representations or guarantees, express or implied, made or intended by C.I. or its
authorized distributors and all other warranties, conditions, representations or guarantees, including any
warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or
statue is hereby expressly excluded. Save as herein provided, C.I. Service Dept. (Canada) or C.I. Service
Dept. (USA), shall not be responsible for any damages to persons or property, including the unit itself,
howsoever caused or any consequential damages arising from the malfunction of the unit and by the
purchase of the unit, the purchaser does hereby agree to indemnify and save harmless C.I. from any claim
for damages to persons or property caused by the unit.
TO OBTAIN REPAIRS UNDER THE TERMS OF THIS WARRANTY
1. The original purchaser must present a copy of the original bill of sale and the service warranty card.
2. Any alterations, abuse, misuse, battery corrosion or accidental damage voids the warranty.
3. The warranty does not cover cabinets and accessories.
4. No warranty or insurance contained or set out shall apply when damage or repair is caused by power
failure; damage in transit or when moving the unit; improper power supply; use for commercial or
industrial purposes; service calls resulting in customer education, etc.
5. The defective product should be mailed to:
Canada U.S.A
C.I. Service Dept.
Curtis International Ltd
315 Attwell Drive
100 Lakeview Parkway
Toronto, Ontario
Vernon Hills, IL
M9W 5C1
60061
For service assistance and product information, please call: 1-800-968-9853.
If mailing the product, the freight must be prepaid and a money order for $7.00 should be included
to cover the cost of insurance and the return of the product.
6. C.I. reserves the right to repair or replace the parts which have become defective.
Model No.
Date Purchased
Serial No.
Loading...
