Curtis SDVD9002 User Manual

SDVD9002

Table Of Contents

Safety Precaution 1
Package 3
Main Features 3
Main Unit Controls 4
System Connection 5
The Remote Control 10
Basic operation 12
System Setup 22
Specification 24
Troubleshooting 25

Safety Precaution

Thank you for choosing our portable DVD player. It includes a 7” wide screen and a DVD
player. The unit applies the latest state of art electronics and is designed for use at home,
in hotels and in offices etc for relaxation. The compact size makes carrying easier as
well as installation. Please read the manual carefully prior to use and keep it well for later
consultation.

Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture.

1) Please read the instruction manual carefully and follow all the requirements of safe
operation to operate the device.

2) Do not use this unit near water. Do not place over the unit any container with liquid
inside.

3) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

4) Unplug this unit during lightning storms or when unused for long time.

5) About Cleaning: Unplug the system, use only wet cloth to clean. Do not use liquid
detergent or aerosol.

6) Only use accessories specified by the manufacturer.

7) Refer all servicing to qualified service personnel, servicing is required when the unit
has been damaged in any way, such as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the unit, exposed to moisture, does not
operate normally. Don't try to repair the machine by yourself because of the danger of
high voltage and electric shock.

8) Do not use irregular shaped discs such as heart or star-shaped discs as they may
cause the unit to malfunction.

1

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Package

9 '' LCD Monitor & DVD Player
Remote Control with battery
Audio/Video Cable

AC/DC Power Adapter
Cigarette Lighter Adapter
User Manual

Earphone
DC+Audio/Video Cable

Carry Bag
Mounting Straps

Main Features

High brightness color 9” LCD screen

Compatible with disc of DVD, VCD, MP3, MPEG4, CD, JPEG, etc.
Built-in stereo speaker
Support PAL or NTSC system
Support Multi-language OSD, speed forward/backward, repeat function
Zoom in/out function

1
1

1
1
1
1
2

1
1

2

32

Main Unit Controls

System Connection

ON OFF

1 2

OK

4 5 6 7 8

3

1. Open knob

2. Power ON/OFF switch

3. SETUP button

4. MODE button

5.

6. OK button(Function same as
ENTER on remote control)

7. Play/Pause

8. STOP button

Monitor View

ON OFF

1

2
3

4
5

9

DC OUT

10

AV OUT

11

12
13

14

15

16

CLOSE

9. DC IN 9-12V

10. DC OUT

11. AV OUT

12. Earphone jack

13. Volume knob

14. SD card slot

15. USB Port

16. Rating Label Position

Powering and installation

Plug one end of the AC/DC power adaptor into the DC IN 9-12V jack on the right of the
main unit, then plug the other end into the AC power receptacle. Please refer to the
following illustration.

DC OUT

AV OUT

If using car cigarette lighter adaptor to connect to the power:
Plug one end of the cigarette lighter adaptor into the DC IN 9-12V jack on the unit, plug
the other end into the car cigarette lighter socket. See illustration below.

DC OUT

AV OUT

Note

Car cigarette lighter adaptor is available to use only when the car cigarette lighter with DC

12V negative grounding.

The mains plug is used as the disconnect device, the disconnect device should remain

readily operable.

BRIGHTNESS

1. Power ON/OFF

2. Volume knob

3. Earphone jack

DC OUT

AV OUT

CLOSE

6

4. AV I N

5. DC IN 9-12V

6. LCD Monitor

4

DC OUT

AV OUT

5

Connecting to the monitor

In Car Installation

The unit can also be connected to the external LCD monitor.
Connect the unit to power by AC/DC adapter or cigarette lighter adapter.
Then connect the unit DC OUT jack to DC IN 9-12V Jack of the LCD Monitor by a DC/AV
cable. Also use this DC/AV cable to connect the AV OUT jack of the unit to AV IN
jack of the Monitor.
Please refer to the illustration below.

DC OUT

AV OUT

ON OFF

BRIGHTNESS

1. Fit the headrest mount to the DVD Player / Monitor as required.

C1

A

C2

The DVD player will fit to the mount

D1

in this position, as shown below.

B

D2

Turn the headrest and player around so the backs are facing you.

E1 F1

Slide the vertical straps A and B through the
strap lock upon the back of the DVD player,
or monitor, as shown.
Fold and secure the horizontal straps on to
the back of the mount until the velcro attaches.

A B

Ensure the DVD player or monitor is mounted
centrally.

E2

F2

Turn the headrest and player around so the front is facing you.

Bring straps C1, C2, D1 &D2 in front of the DVD Player and attach
to the velcro as shown.

OK

Note: You're advised to supply both units the power by the cigarette lighter adapter
only. The AC/DC adapter is used to supply power of one unit only and as the charger
to charge the main unit if it's with built-in battery.

C1

OK

C2

D1

D2

NOTE: Both the headrest mounts are the same, there is no difference for
DVD Player or Monitor.

76
