Curtis RCD904 User Manual

RCD904

12

RCD904
MINI HIFI SYSTEM WITH TURNT ABLE, 3-CD CHANGER, AM/FM-STEREO RADIO,
DOUBLE AUTOSTOP CASSETTE AND REMOTE CONTROL.

INSTRUCTION MANUAL

Please read this instruction manual carefully and familiarize yourself with your new Hifi
System before using it for the first time. Please retain this manual for future reference.

RCD904

EnglishEnglish

18

19

20

21

22

23

T ABLE OF CONTENTS

• Location and Controls-------------------------------------------------------- 3

• Connecting to Power----------------------------------------------------------- 4

• Power Supply---------------------------------------------------------------------- 4

• Connections ------------------------------------------------------------------- 4

• Tuner Operation------------------------------------------------------------------ 5

• Cassette Operation ----------------------------------------------------------- 5

• To Record on a Cassette -------------------------------------------------- 6

• Sound adjustments --------------------------------------------------------- 7

• Compact Disc Operation ---------------------------------------------------- 8

• Track Skip ------------------------------------------------------------------- 9-10

• Manual Search ---------------------------------------------------------------- 10

• Repeat -

• Disc programming ----------------------------------------------------11-12

• Turntable --------

• Remote control -------------------------------------------------------------- 13

• Important ------

• Specifications ------------------------------------------------------------------------ 16

----------------------------------------------------------------------- 11

----------------------------------------------------------------- 12

------------------------------------------------------------------------ 14

17
16

15

14

13

12

11

1010

9

3 - 8

2

1

24

25

26

27

28

29

30

31

32

33 - 37

38

39

34

EnglishEnglish

LOCATION OF CONTROLS

1. Mains Lead , Speaker Sockets and FM Antenna wire ( at the rear of the unit )

2. CD Tray

3. RECORD Key

4. PLAY Key

5. REWIND Key

6. FAST FORW ARD Key

7. STOP / EJECT Key

8. PAUSE Key

9. CASSETTE Compartment A

10. DISC SKIP Button

11. CD REPEA T Button

12. PROGRAM Button

13. PHONES Socket

14.. FUNCTION Selector (Phono/Tuner/Tape/CD)

15.. CD STOP Button

16.. STANDBY/ON Button

17.. PRESET EQUALIZER Button

18.. FM-STEREO Indicator

19.. STANDBY/Mute Indicator

20. EQ Indicators

21. LCD Display

22. REMOTE Sensor

23. Turntable (PHONO)

24. VOLUME Up/Down Button

25. DIAL Pointer

26. HIGH SPEED DUBBING/ FM Stereo Selector

27. CD PLAY/P AUSE Button

28. RADIO Band wave selector

29. TUNING Knob

30. CD Skip/Search Forward Button
CD Skip/Search Backward Button

31. INTRO Button

32. CASSETTE Compartment B

33. PL A Y Key

34. REWIND Key

35. FAST FORW ARD Key

36. STOP / EJECT Key

37. PAUSE Key

38. CD OPEN / CLOSE Button

39. CD DIRECT Access - 1, 2, 3

CONNECTING TO POWER

Before switching on make sure that the voltage of your electricity supply is the same as
that indicated on the rating plate.

For your own safety read the following instructions carefully before attempting to connect
this unit to the mains.

MAINS (AC) OPERATION

This unit is designed to operate on AC 120V 60Hz current only. Connecting it to other
power sources may damage the unit.

CAUTION

To prevent electric shock disconnect from the mains before removing cover. No user
serviceable parts inside. Refer servicing to qualified service personnel.

POWER SUPPL Y

Remove the stereo carefully from the box, retaining the packaging for future use.

AC POWER OPERATION

Connect the plug to a mains power inlet 120V AC ~ 60 Hz.

CONNECTIONS

SPEAKER CONNECTION

Connect each speaker to the corresponding speaker terminals on the back of the system.
Ensure that the left speaker is connected to the left connector, and the right speaker to the
right connector.

HEADPHONE

This unit will accept stereo headphones (not included) with a 3.5mm plug and an impedance
of 8 ohms or greater.
The speakers are automatically disconnected when headphones are connected to the
PHONES JACKS (13).
