User’s Manual

MPK1066UKAB

MPK2066UKA

MPK4066UKA

TABLE OF CONTENTS

Introduction .......................................................................................................................................................................................................................................1

Important Safety Precautions...........................................................................................................................................................................................................2

Features .............................................................................................................................................................................................................................................3

Location of Controls .........................................................................................................................................................................................................................4

Connecting with Computer...............................................................................................................................................................................................................5

System requirements......................................................................................................................................................................................................................5

Installing the drive for windows 98 SE............................................................................................................................................................................................5

Connecting player to computer.......................................................................................................................................................................................................6

Loading files to the player...............................................................................................................................................................................................................6

Disconnecting the USB cable......................................................................................................................................................................................................... 7

Charging the battery....................................................................................................................................................................................................................... 8

Basic Operation.................................................................................................................................................................................................................................9

Turning on/off the player................................................................................................................................................................................................................. 9

Adjusting the volume......................................................................................................................................................................................................................9

Resetting the player........................................................................................................................................................................................................................9

Hold function ..................................................................................................................................................................................................................................9

Selecting main menu or mode........................................................................................................................................................................................................9

Listening to Music........................................................................................................................................................................................................................... 11

Turning on and playing................................................................................................................................................................................................................. 11

Display .........................................................................................................................................................................................................................................11

Pausing playback .........................................................................................................................................................................................................................12

Stopping playback and escape Music mode.................................................................................................................................................................................12

Skipping tracks............................................................................................................................................................................................................................. 12

Searching backward or forward within a track ..............................................................................................................................................................................12

A-B function.................................................................................................................................................................................................................................. 12

Using the music menu.................................................................................................................................................................................................................. 13

Displaying lyric synchronously......................................................................................................................................................................................................17

Viewing Picture................................................................................................................................................................................................................................18

Watching Video................................................................................................................................................................................................................................19

Skipping video files.......................................................................................................................................................................................................................19

Searching backward or forward....................................................................................................................................................................................................19

Setting video repeat mode............................................................................................................................................................................................................20

Recording Voice..............................................................................................................................................................................................................................21

Listening to Recordings .................................................................................................................................................................................................................22

Reading E-book...............................................................................................................................................................................................................................23

Moving to previous/next page.......................................................................................................................................................................................................23

Skipping to next page automatically............................................................................................................................................................................................. 23

Settings............................................................................................................................................................................................................................................24

Navigating the settings menu.......................................................................................................................................................................................................24

Setting language ..........................................................................................................................................................................................................................25

Setting play mode.........................................................................................................................................................................................................................25

Setting record quality....................................................................................................................................................................................................................26

Setting contrast ............................................................................................................................................................................................................................26

Setting time off .............................................................................................................................................................................................................................27

Reset settings...............................................................................................................................................................................................................................27

Deleting Files................................................................................................................................................................................................................................... 28

About................................................................................................................................................................................................................................................ 28

Converting Video to MTV Format...................................................................................................................................................................................................29

Troubleshooting.............................................................................................................................................................................................................................. 31

Specifications.................................................................................................................................................................................................................................. 32

iii

Introduction

Congratulations on purchasing the MP3 Player.

Before using the player, read this manual thoroughly and keep it for future reference. This manual will help you use all of the exiting features to make

your player view more enjoyable.

This manual contains important safety information and correct operation instructions. Read the manual carefully before you use the player in order to

avoid any confusion.

We have done our best to produce a complete and accurate manual; however, we cannot ensure that there are no errors or

omissions. We have no responsibility for damages or loss of data caused by improper operation.

The instruction manual is subject to change for improvement without notice.

The player may power off if suffers in lightning strikes or certain static electricity. You can turn on the player again or press the

RESET hole to re-initialize the system of your player.

Trademarks and trade names used in this instruction manual are owned by their respective companies or organizations.

Important Safety Precautions

Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury.

y Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel.

y Do not dispose of the player in fire to avoid explosion because the player has built-in battery.

y Do not touch the player with bare hands if the built-in battery is leaking. In this case, contact service center for help since the liquid may

remain in the player. If your body or clothes has contacted with the battery liquid, wash it off thoroughly with water. Also, if some of liquid gets

into your eyes, do not rub your eyes but immediately wash them with clean water, and consult a doctor.

y Keep the player away from direct sunlight and heat source.

y Do not expose the unit to rain or moisture to avoid any malfunction.

y Do not use the player in rather dry environment to avoid static.

y Never apply heavy impact on the player like dropping it or placing it on the magnet.

y Route USB cable so that people and pets are not likely to trip over or accidentally pull on them as they move around or walk through the area.

y Disconnect the USB cable from the computer when you do not use the player for a long time.

y Clean only with dry cloth. Make sure the player is turned off before cleaning. Do not use liquid cleanser.

y Be sure to back up your files. We will not be liable for the loss of data due to improper operation, repair or other causes.

Precautions in using the earphone

y Do not use the earphone while driving an automobile or riding a bicycle. It is not only dangerous, but also

against the law. To avoid an accident, do not turn up the volume of the earphones too high while walking.

y It’s not recommended that you use the earphones at a high volume for an extended time as this may

cause hearing damage.

Features

y 1.44 inch 65K color CSTN with 128*128 resolution

y Built-in rechargeable Li-polymer battery

y USB 2.0 high speed transmission

y Supports playback of MP3, WMA and WAV files

y Supports multiple equalizer (EQ) and 3D sound effects

y Supports multiple playback mode: section repeat, file repeat, folder repeat and random

y Supports the basic information of titles, artists and albums of music files(ID3 tag) or lyrics synchronization show while music is playing

y Supports browse of JPEG and BMP picture files

y Supports converted MTV video format (file transformation tool included)

y Supports browse of e-book in TXT format

y Supports Voice recording via the build-in microphone

y Multiple language user’s interface

Location of Controls

1. Earphone jack

2. USB cable connection port

3. A-B/REC

4. [

5. RESET hole

6. Screen display

7. [

8. [

9. [VOL®] Volume up

10. [

11. [VOL−] Volume down

12. Hold switch

13. Microphone

] Power on/off; Stop; Open sub-menu; Return to

previous menu.

] Next, Fast Forward

] Enter main menu, Play/Pause, Confirm

] Previous, Fast Rewind

Connecting with Computer

System requirements

You computer system must meet the following specifications:

y Pentium 200MHz or above

y Microsoft Windows 98SE/2000/ME/XP/Vista

y 120MB of available hard disk space

y USB port supported

y CD-ROM drive

Installing the drive for windows 98 SE

If your computer is running Windows ME/2000/XP/Vista, no driver is required to install.

If your computer is running Windows 98 SE, you must install the drive provided on the CD before connecting the player to your computer.

1. Insert the installation CD into the CD-ROM driver.

2. Execute the “USB Disk Win98 Driver Version xxx.exe” file in the CD and follow the instructions in window to complete the installation.

3. Restart the computer.

Note: Make sure the player is disconnected from the computer when installing the drive.

Connecting player to computer

Files can be transferred directly into the player using the USB data cable. Make sure that your computer is powered on. Below is the procedure of

connecting with computer:

1. Plug the larger USB connector of the USB cable into the USB port on the computer.

2. Plug the other end (the smaller end) of the USB cable to the player.

3. The computer system detects “New hardware” and starts to install the driver automatically. Wait for the system to finish the installation.

When it has finished, a new “Removable Disk” will be created in “My Computer”.

Loading files to the player

To download the files from your computer, perform the following steps:

1. Open the Windows Explorer or My computer.

“Removable Disk” is displayed.

2. Select the files on your computer and simply move it into the “Removable Disk” in the usual way (drag and drop, copy and paste). After

copying is completed, the data will be available on the MP3 player.

Note:

y Please do not disconnect the USB cable during loading. It may cause malfunction of the player and the files.

Disconnecting the USB cable

After completing the file transfer, please disconnect the USB cable as the following way:

1 Double click the green arrow “Safely Remove Hardware” in the taskbar on the bottom right of the window.

2 Select “USB Device” and click “Stop”.

3 When the “Stop a Hardware device” appears, click “OK” to disconnect the USB mass storage device. Then you can unplug the player safely.
