Curtis KCR2620DUK User Manual

Operation Instruction

MODEL NO.: KCR2620DUK

Multi-media Digital TV Receiver

for Kitchen

2

Table of Contents

I Precautions

II Accessories

III Description of Appearance

IV Description of Remote Controller

V Basic port Connect

VI Operation Instruction for Alarm Clock
Radio System

VII DVB-T Digital TV Receiver Instruction

VIII Analog TV receiving operation

IX DVD Operation Instruction

X Troubleshooting

XI Technical Parameters

1

2

3

6

9

10

12

14

17

24

25

I Precautions

Storage

1. Keep this product away from extremely hot or cold places. The
storage temperature ranges from -20 to 60 and the working
temperature from -5 to 40 .

2. Do not use this product at damp environment like bathtubs, wash
basins, washtubs, as well as basements, swimming pools or similar
places

Protect TFT Display from bumping.

3.

4. Do not push on or scrub this product with sharp objects.

Maintenance

1. Disconnect all cables of this device at first before cleaning.

2. Wipe the enclosure, screen and keys using soft cloth with a little
soft detergent on.

3. Do not use polishing cloth, abstergent, and all types of propellants
or chemical detergents like alcohol and benzene to clean your device.

Special Notice

Bright spots or dark spots may appear on the screen. This is a
normal phenomenon associated with the active matrix display
technology and is not a sign of malfunction. Do not attempt to
maintain. For any failures, please turn off your TV set immediately
and contact us or your dealer. This device integrates a great deal of
fine electronic components. Disassembly or alternation may result in
damages or breaks.

-1-

II Accessories

Knighthead

Remote control

2 UM4 Batteries

Screws

O

p

e

r

a

t

i

o

n

In

s

t

r

u

ct

i

o

n

MO

D

E
L

M

N

u

O

l

.

t

:

i

-

K

m

C

e

R

di

2

6

a

2

D

0

f

D

i

o

g

U

r

i

K

t

K

a

l

i

t

T

c

V

h

e

R

n

e

c

e

2

i

v

e

r

Operation
Instructions

Installation
manual

-2-

III Description of Appearance

1. DVD/TV/AUX: Mode Switch key. In power-on state,
press this key to switch between DTV/ATV/DVD/AUX.

2. FM/AM: Radio Mode key. In power-on state, press this
key to enter the FM/AM Mode Switch of RADIO system.

3. MEMORY/CARD/USB: In the radio state, press this key to enter
Channel Storage State, then press "SKIP+/TUNE+" and "SKIP-/
TUNE-" or "CH+"/"CH-" key to select a Channel Saving number,
and press again to confirm it; in DVD state, it is the CARD/USB
Mode Switch Menu Key - DISC/CARD/USB menu will appear when
you press this key, then select by Up and Down key, press OK key
to confirm.

4. CLOCK/ALARM: Time Show key. In power-on or standby state,
press shortly to display the time of current alarm1, alarm2 and the
clock; long press to respectively enter the setting state of hours and
minutes of the current time, AL1, AL2 (the number of current hour or
minute will flash), then press "SKIP+/TUNE+" or "SKIP-/TUNE-" to
adjust. When these two alarms are set at the same time, alarm 1 is
effective but alarm 2 isn't.

5. SLEEP/SNOOZE: Sleep/Snooze key. In power-on state, press this
key repeatedly to set the system to sleep and shut down after 90/80
/70/60/50/40/30/20/10 minutes, then press this key to exit the Sleep

-3-

Power-off Setting function. Press this key in sleep state to cancel
this state; in alarm state, press this key to start snooze function
(interval time is 8 minutes), and the screen will show "SNOOZE"
symbol.

6. EQ: Sound Effect key. Press this key in power-on state, you can set
the sound effect as Rock Jazz Popular Classical Normal in
turns.

7. TIMER: Timer Setting key. In power-on or standby state, press this
key to enter the state of clockwise time setting from1 to 90 minutes,
then press "SKIP+/TUNE+" or "SKIP-/TUNE-" to adjust minutes,
and press again to confirm the set time.

8. SKIP-/TUNE-: Radio Tuner/ Time Adjust key. In radio state, press
this key shortly to tune radio downwards, long press to search
channels downwards, it will stop automatically until it gets the
channel; in clock adjusting state, press this key shortly to adjust
backwards the number of hours or minutes in steps, long press this
key to fast adjust downwards the number of corresponding hours or
minutes, you can select the channel in descending order when you
enter Channel Saving state; in DVD state, press this key to select
previous song in playing; in DTV state, it means turn page
downwards.

9. SKIP+/TUNE+: Radio Tuner/ Time Adjust key. In radio state, press
this key shortly to tune radio upwards, long press to search
channels upwards, it will stop automatically until it gets the channel;
in clock adjusting state, press this key shortly to adjust forward the
number of corresponding hours or minutes in steps, long press this
key to fast adjust upwards the number of hours or minutes, you can
select the channel in ascending order when you enter Channel
Saving state; in DVD state, press this key to select previous song
when it is playing; in DTV state, it means turn page downwards.

10. : Eject key. In DVD state, press this key to eject the disc.

11. : Stop key (Only in DVD state).

12. : Play/ Pause key. In DVD playing, press this key to pause,
press again to resume playing.

-4-

13. OK: OK key. In the DTV and DVD state, press this key to confirm
the selected item.

14. VOL-: Volume Decreasing key. In power-on state, press this key to
decrease volume; when entering analogue adjusting menu, press
this key to adjust analogue decrease; in the DTV and DVD state,
press this key to select left.

15. VOL+: Volume Increasing key. In power-on state, press this key to
increase volume; when entering analogue adjusting menu, press
this key to adjust analogue increase; in the DTV and DVD state,
press this key to select right.

16. STANDBY: Power-on/Standby/Cancel Alarm key.

17. Loudspeaker.

18. TFT LCD Screen.

19. Power Indicator.

20. Remote Controller Receiving Window.

21. CH-: Channel Decreasing/Alarm 2 Mode Setting key. In radio
state, press this key to select the stored channels in descending
order; in Channel Saving state, press this key to select the location
to store radio channel in descending order; in standby state, you
can set the Alarm 2 mode as Alarm 2/ Radio 2/ TV2; in TV state,
press this key to select channel in descending order; when
entering DVD/DTV/ATV/AUX menu state, press this key to select
the item downwards.

22. CH+: Channel Increasing/ Alarm 1 Mode Setting key. In radio
state, press this key to select the stored channels in ascending
order; in memory state, press this key to select the location to
store radio in ascending order; in standby state, you can set the
Alarm 1 mode as Alarm 1/ Radio 1/ TV 1; in TV state, press this
key to select channel in ascending order; when entering DVD/DTV
/ATV/AUX menu state, press this key to select the item upwards.

23. MENU: Menu key. In FM Radio state, press this key to select
Mono and Stereo mode, in DTV/ATV/AUX state, press this key to
enter menu; in DVD state, it can play menu.

24. USB connector/ Three-in-one card connector.

-5-

25. TV Antenna Input.

26. External video Input.

27. External Audio Left Channel Input.

28. External Audio Right Channel Input.

29. External DC Power socket (Optional).

30. Power Cable.

31. FM Antenna.

IV Description of Remote Controller

1. POWER: Standby/ Power off key.
Press it to switch between Power-on
and Standby, when the alarm sounds,

2
4

press this key to close alarm.

2. FM/AM: FM/AM switch key. In power-on
state, press this key to enter the FM/AM
Mode Switch of RADIO system.

3. DVD/TV/AUX: TV system working mode
key. In power-on state, press it to switch
between DTV/ATV/DVD/AUX.

4. SNOOZE: Snooze key. When the
alarm rings, press SNOOZE key,
the alarm will ring again in 8 minutes.

5. CLOCK: Time Show Key. In power-on
or standby state, press shortly to
display the time of current alarm1,

10

13
15
17
19

11
12

14
16
18
20

alarm2 and the clock; long press to
respectively enter the setting state of hours

-6-

1

3
5

6

7

8

9

21
23

25

26
27

28

29

30

31

32
34
36
38

22
24

33
35
37

and minutes of the current time, AL1, AL2(the number of current
hour or minute will flash), then press "SKIP/TUNER" key to adjust.
When these two alarms are set at the same time, alarm 1 is
effective but alarm 2 isn't.

6. 0-9, -/--: Number key, Channel Directly Selecting key. In TV mode,
press these keys to select preset TV programs.

7. MENU: Menu key. Press this key to enter the corresponding main
menu.

8. VOL+/ /VOL-/ : Volume Adjusting Direction key. You can press
this key to adjust volume; in system menu, this key is Left and
Right key.

9. P.ADJ: Image Adjusting Menu key. In DVD/DTV/ATV/AUX state,
press this key to make adjustment such as brightness, contrast,
chroma, hue (applicable for N system only), flip horizontally and
vertically, 4:3/16:9 and resetting.

10. (PAUSE): Pause key. In DVD state, press this key to enable
the screen in pause state, then press again to exit pause state.

11. SKIP/TUNER: Radio Tuner/ Time Adjust key. In FM state, press
this key shortly to tune radio, long press to search channels, it will
stop automatically until it gets the channel; in clock adjusting state,
press this key shortly to adjust forwards the number of hours or
minutes in steps, long press this key to fast adjust upwards the
number of hours or minutes, you can select the channel number
when you enter Channel Saving state.
/ : Next song/ Previous song (Only in DVD state), in DTV
menu it is Page Up/ Page Down key.

12. (STOP): Stop key (Only in DVD state).

13. CLEAR/Green: In DVD state, it is Delete key; in DTV state, you
should operate by system prompt.

14. PROGRAM/Red: In DVD state, it is Programming key; in DTV
state, you should operate by system prompt.

15. PR LIST/TITLE: In DTV state, it shows program list. Press this key
to enter program guide state; in DVD state, it is Title Back key.

16. FAVOR/REPEAT: In DTV state, it is the favorite program list switch
key. In DTV state, you can switch between the favorite program
lists then press OK key to open the list; in DVD state, it is Repeat
key.

17. SEARCH: Search key. In ATV state, long press for 3 seconds to
enter Automatic Search; in DVD state, it has Title/Chapter/Song/
Time/ Search function.

-7-

18. A-B: A-B Screen Repeat key.

19. SLOW: Slow key (Only in DVD state).

20. SLEEP: Sleep Timing Power off key. Press this key to set the
system power-off at different times.

21. OPEN: Eject key.

22. CARD/USB/MEMORY: In the radio state, press this key to enter
Channel Saving State, then press "SKIP+/TUNE+" and "SKIP-/
TUNE-" or "CH+"/"CH-" key to select the stored channel, and press
again to confirm it; in DVD state, it is the CARD/USB Mode Switch
Menu Key, DISC/CARD/USB menu will appear when you press this
key, then select by Up and Down key, press OK key to confirm.

23. MUTE: Mute key. Each time you press it, it will switch between
Mute and Unmute.

24. MONO: FM Stereo Switch key. In FM state, press this key to set
the sound as stereo or mono.

25. EQ: Sound Effect key. You can set the sound effect as ROCK
JAZZ POP CLASSIC NORMAL in turns.

26. : Back key. In ATV state, you can switch between the current
program and the previous program; in DTV and DVD menu state,
press this key to exit menu.

27. CH+/ /CH-/ : Channel Switch Up and Down key. In FM/DTV/
ATV state, press this key to switch program channels; when
entering system menu, this key will become Up and Down key .

28. AUDIO: Audio Switch key. In DTV state, press this key to display
the audio information of the current program, then press direction
key to switch audio channel; in DVD state, press this key to switch
audio channel.

29. OK: OK key.

30. SETUP: Set up key. In DVD state, it is the Menu on/ off key.

31. AL.SET/ALARM SET1/ALARM SET2: Alarm State Setting key.
You can set the state of alarm 1, alarm 2 as BUZZER/RADIO/TV.

32. / /Yellow/Blue: In DVD state, it is Fast Backward/ Fast
Forward key; in DTV state, you should operate by system prompt.

33. DTV MODE/ZOOM: In DTV state, it is the switch key of radio and
TV program. Press this key to switch between TV program and
radio program; in DVD state, it is the Zoom In key.

-8-

34. EPG/ANGLE: In DTV state, it is the Electronic Program Menu key.
Press this key to enter electronic program menu interface; in DVD
state, it is Angle Switch key.

35. TEXT: Text Information key. In DTV state, press this key to start
text function to check the text information.

36. INFO: Program Information Display key. In DTV state, press this
key to display the current program information.

37. SUBTITLE: Subtitle key. In DTV/DVD state, press this key to open
subtitle language menu to select the subtitle language you need
and display subtitle (Requiring program support).

38. TIMER: Timer Setting key. Press once to enter timer adjusting
state, you can use "SKIP/TUNER" to adjust time, and then press
this key to confirm it and enter timer countdown state.

V Basic port Connect

Connect to USB and CARD: Set the player in DVD state and connect
the USB device or Card to corresponding interface.

-9-

VI Operation Instruction for Alarm Clock Radio

System

1 .Time setting

( on remote)CLOCK

Press for 3 seconds

( on remote)CLOCK

Press one time Minute setting

( on remote)CLOCK

Press one time

( on remote)CLOCK

Press one time

Hour setting

Alarm 1 hour setting

Alarm 1 minute setting

( on remote)CLOCK

Press one time

( on remote)CLOCK

Press one time

Alarm 2 hour setting

Alarm 2 minute setting

2. Alarm setting (standby status)

a " " (AL1.SET key on remote) press to choose Alarm/Radio/TV.
b " " (AL2.SET key on remote) press to choose Alarm/Radio/TV.

-10-

3. Snooze/Turn off alarm

While the alarm ring, press SNOOZE to pause, it will ring again

after 8 minutes.

While the alarm ring, press POWER to stop, it will ring at this time

next day.

4. Sleep time setting

Press SLEEP key to choose sleep time to be (90, 80, . ..... 10) minutes.

5. Calculagraph

Press TIMER key, then press SKIP+/-(TUNE+/-) to adjust time of
calculargraph:

Then press TIMER key to confirm.

6. Radio

a. Press FM key to switch to the radio state.
b. Hold on SKIP+/- key to search channel manually.
c. Press SKIP+/- (TUNE+/-) key to select channel.
Press MEMORY key;

Press CH+/- key to select location to save channel:

Then press MEMORY key to confirm the saving of the current radio
manually.
d. Press CH+/- key to select the stored channel.
e. AM can store 10 radio channels, FM can store 20.

-11-

VII DVB-T Digital TV Receiver Instruction

1. Automatic installation guide
For first use or when the program list doesn't exist, system will
implement quick installation guide after connecting power. Please
follow the screen prompt, press "OK" key to scan automatically as
shown in the following picture:

2. TEXT(Text Information)
When playing program, press "TEXT" to open text information
(Requiring program support)

3. EPG ( program navigation function)
In program playing process, press "EPG" to open program navigation
function, this time you can check program information quickly. Select
channel by Up and Down key, then press OK key to play.

4. Menu Operation Instruction
Press the remote controller or "MENU" key to enter menu interface,
use to select menu function, then press "OK" key to enter
submenu, in submenu state, press "MENU" to back to menu function.

-12-

Menu Function

Organiser

Favourltes

Timer
Programming

Setup

Languages

TV Setup

Parental
Control

Service
Setup

Check For
Download

Technical
Information

Submenu

Subtitles
Data Service
Audio

On Screen
Display

Television

Please enter PIN
to access menu

Full Scan Add
New Services

Full Scan Replace
Exlsting Services

Manual Scan
Full Scan Setup
First Time Setup

Update by
USB/Card Reader
Update by CAD

off
English
English

English

16:9

Censorship
Change PIN
Lock/Un lock
Services

Operation Instruction

"Program information list": Enter "Service
Organiser", press to browse program
information, following the prompt, you can
press the red key to delete the program in
channel list, press green key to move current
program order in channel list, press to
move; press yellow key to edit the current
program name, press direction key to select
keyboard letter and number, press "ENTER"
key to complete input, after editing, press
green key to save it and back to channel list.

"Favorite Channel": Enter favorite channel,
following the prompt, press red key to delete
the channel in favorite channel list, press
green key to add channel in favorite channel
list; press yellow key to edit, press to
select a channel in the list and press
"ENTER" to start playing.

User can set alert function to watch specific
program in specified time, the start time and
end time depend on current system time.
Before setting alert function please check
system time first.

Subtitle Language
Data Information Language
Audio Language

Screen Display Language

TV Display Mode: 16:9

Child lock: Lock programs according to age
brackets; change password: first enter old
password then set the new password;
channel lock; press OK key to enter this item,
select channel then press OK key to lock.
When you want to watch the locked program,
you should input preset password.

Search new-added program based
on original programs.

Delete original program then re­search new one.

Search program manually

Parameter setting of automatic program search

Restore factory default setting

Only for factory debugging

Only for factory debugging

System information

-13-

VIII Analog TV receiving operation

Press DVD/TV/AUX to enter ATV mode, display options as follows:
PICTURE SYSTEM
PRESET

MAIN MENU


SYSTEM

PRESET

1. PICTURE

Press to select Picture item. Press , Bright, Contrast,

Saturation and Reset displays on the screen as illustrated below:


BRIGHT 50

CONTRAST 50

SATURATION

RESET

Press to select the Bright item. Press to adjust the analog
quantity of Bright. Press in turn to select Contrast, Saturation and
also can adjust the analog quantity of Contrast and Saturation. Press
to select the Reset item. Press to reset the quantity of Bright,
Contrast, Saturation to 50.

50

-14-

2. STSTEN

Press to select System item, press then (language),
(picture mode), (Image Flip) and Blue back displays on the
screen as illustrated below:

SYSTEM

ENGLISH

16:9

1

BLUE BACK ON

Use direction key to adjust selected item.

3. PRESET

Press to select Preset item, Position, Remember, Auto search,
Swap, Fine, Search, Sound-sys and Color-sys as illustrated below:

PRESET

PROGRAM 1

REMEMBER ON
AUTO SEARCH
SWAP 1
FINE 0
MANUAL SEARCH 551MHz
SOUND-SYS DK
COLOR-SYS PAL

-15-

Note

1. Auto Search Start from Program No. 0.

2. When receive signal under Manul Search, the indication frequency stop
means the optimum position for signal storage. If channel under wea k
signal is received, the channel storage system will a utomati cally
identify it as no signal.

3. You can press and hold SEARCH key for 3 seconds on remote
control to enter Auto Search.

4. Notes on Sound System: 6.0M means I, 6.5M stands for DK(L),

5.5M is BG, please set the Sound System at local one.

5. Color system
A. While sound system is I, color system is PAL-I;
B. While sound system is DK, color system is PAL-DK or
SECAM-DK;
C. While sound system is BG, color system is PAL-BG or
SECAM-BG;
D. While sound system is L, color system is SECAM-L;

6. In case with picture while without sound or with noise, please check
the Sound System for correct setup first.

-16-

IX DVD Operation Instruction

1. Instruction for basic operation

>

1 Play/Pause

1) After the disc be read, the disc types information of DVD, VCR or CD
could be displayed on TFT screen.

2) Some disc will play automatically when tray is in.

3) When playing DVD or some VCD2.0 disc, the menu will emerge, you
could select the option by pressing direction key or digital keys, then
press OK to confirm. Finally the player will play according to your
selections.
Notice: If playing some VCD disc, you should press Menu to turn off the
PBC function, then use digit key (0-9) to select desired track.

4) While playing, press one time to pause, press one more time to
continue normal playback.

>

2 Fast Forward/Backward playback

While playing, press or to play the disc fast forward or backward at a
certain multiple speeds.
DVD/VCD: 2 , 4 , 8 and 20 times speeds.
Note: when play some disc menu or title, the Forward/Backward function
is not available.

3>

Slow playing

If you want to enjoy a specific portion, slow playing function can be use.
The player provides six slow speeds. Press SLOW key continuously to
shift slow speeds in order of 1/2 1/3 1/4 1/5 1/6 1/7 normal.
During slow playing, press to return normal playback.
Note: The slow playing function is not available while playing the menu
and title.

>

4 Last/Next track search&play

While playing, you could select and play the last or next track/chapter by
pressing or .
Notice: when play some disc menu or title, the last/next search&play
function is not available.

>

5 Stop playing

While playing, press STOP key one time, the player will be to Memory
Stop, and OSD will be displayed on screen. Press , the player will start
play from the Memory Stop point. Press STOP two times continuously, the
screen will also display OSD, disc will stop playing totally. Now press
key once more, the player will play disc from very beginning.

-17-

2. Special function operation instruction

>

1 Selection of caption language

While playing, you could select your favor caption language by press
SUBTITLE key directly or pressing SETUP key to enter system menu
to change caption language. Please refer to system menu operations.
Note:

1) Some disc only contain one language.

2) If you cannot find your favor caption
language by pressing SUBTITLE key
continually, that means the disc does
not contain such caption language at all.

2>Select Audio language

When playing DVD disc, you could
select your favor dub language by pressing the AUDIO key.
When playing some VCD disc, you also could switch the audio output
mode: Stereo left sound channel right sound channel Mix mono.
You can select audio language in system menu.
Note: Some discs only contain one audio language. How many audio
language can be use is depend on information on the disc.

3> Zoom

While playing a video disc, press ZOOM, player will zoom in the image
under play/pause status.
Press ZOOM to zoom in 2 3 4 1/2 1/3 1/4 zoom
off.
Press to see other parts of the picture.

4>Different video angle play (ANGLE)

During playback of DVD disc press ANGLE to display the available video
angles for disc contain multi-angle. Press one time to change an angle,
how much angle is depend on information on the disc.

5>Title

Some DVD discs have a title menu recorded within them to use for
selecting titles for play. This feature will only work with these discs.

1) Press TITLE key during playback to enter the title menu.

2) Use keys to control the direction and press OK or PLAY to
select the preferred title or directly press the numeric keys to select the
title.
Note: DVD disc are divided into units referred to as titles are divided into
chapters. A disc that contains a movie may have only one title with many
chapter divisions.

-18-

6>Menu

Some DVD discs have complex contents such as multi-subtitle, multi­audio, or multi-angle. In these cases, you can use the DVD menu to
select audio language, subtitle language, and video angle.

1) Press MENU during playback to display the DVD menu.

2) Press MENU again resumes to normal playback of the scene when
MENU key was first pressed.

3) Use the arrow keys to select favor item, then press OK or to confirm.
Or directly press the numeric keys to select the item.

7>System select (NTSC/PAL/AUTO)

Press SETUP to enter setup menu. Use direction key to select submenu
of System setup, choose TV System item, then press OK to change the
NTSC/PAL/AUTO output mode.

8>Repeat play

During playing DVD disc, press REPEAT continually in order to select:
repeat off repeat chapter repeat title repeat off. Repeat a specific
portion from point A to point B of the disc. Press A-B first time to set point
A, press second time to set point B, press the third time to cancel A-B
repeat function and return to normal playback.
Notice: 1. For VCD2.0 or above , the repeat function will not work till the
PBC have be set off.

2. After power off or open the disc cover, the repeat function will
be turned off.

9>Program play

You must create your program in the Edit Program menu before you can
access the Program Playback. By selecting Program Playback in the Play
Mode menu, you are telling the DVD player to play the disc in the order
you created in the Edit Program menu.
Program edit

1) While playing a DVD disc, press PROGRAM to enter the program menu.

2) Use the digital key to enter desired title/chapter,

3) High light PLAY item, press OK or to program play. High light CLEAR
and press OK to eliminate the program list.

4) To exit PROGRAM playback, press key two times.

Note: After power off or open disk cover, the program play will be turned off.

10>Search play

During playback , press SEARCH to display title, chapter, play time,
subtitle, audio, angle information of the disc as follows:

-19-

DVD disc Info Display

CD disc Info Display

VCD disc Info Display

Title selecting

If the disc include many Title or chapter, press "SEARCH" use direction
key or digit number key to select title, chapter and time.

Play CD

CD track select
Playing CD, all track can be select and play:

1. Use the number keys on remote control to enter the number of the
track while playing.

2. For example, to select track 12, press -/--, then 2.

Play Mp3

MP3 music list

Current playing music

Folder list

Music list of current folder

MP3 music list will appear automatically while playing MP3.
Use direction key to select music, then press "OK" key to play.

-20-

Viewing JPEG files

JPEG files list

Current selected file

Preview picture

JPEG file list in the current folder

The operation method of viewing JPEG files is similar as the operation
method of playing MP3, the above picture will appear after insert JPEG
disc.

1. The image zoom function is available while displaying JPEG file.

2. Press Left arrow, the picture rotate 90 at anti-clockwise, press Right
arrow, the picture rotate 90 at clockwise. Press Up arrow, the picture
flip vertically, press Down arrow, the picture flip horizontally.

11> Storage equipment(USB and Card)

The player support playing of USB storage equipment and Multi Media
Card (MMC), SD, Memory Stick (MS).
(The capability of the USB or card must less than 2G).
All kind of storage equipment can be use as same as disc to play MP3/
JPEG/AVI etc. media files.
Disc, USB and Card can be inside the player at the same time. Press
USB/SD/MS key to select desired media equipment.
Tip: When playing USB storage device or CARD individually, you should
cover the disc cover, this machine can recognize and play. It can't play
any media when the disc cover is opened; in MP3/PHOTO/MOVIE
switching, please press Stop key, then press Left or Right direction key to
select.

-21-

3. System menu setup

To setup the mainframe system, Press SETUP to enter system menu.

Then you could setup the DVD player for Lock, Display, Audio,
Language and Default etc.

1. Use left/right key to select item on the main option list. The item list
appear.

2. Use up/down key to select desired item, then press OK to enter.
Press left/right key to set the value. Press OK to return option list.

3. After setup, press SETUP key or key to exit system setup menu.

System setup menu as below

Main option list

Item list

Parameter list

-22-

The default of this DVD player

MENU

SYSTEM
SETUP

LANGUAGE
SETUP

AUDIO SETUP

VIDEO
SETUP

DIGITAL
SETUP

ITEM

TV SYSTEM
TV TYPE

PASSWORD

RATING
DEFAULT

OSD
LANGUAGE

AUDIO LANG

SUBTITLE
LANG

MENU LANG

KEY
BRIGHTNESS
CONTRAST
HUE
SATURATION

SHARPNESS

DYNAMIC
RANGE

DUAL MONO STEREO/MONO L/MONO R/MIX MONO

NTSC/PAL/AUTO
4:3PS/4:3LB/16:9
USE NUMBER KEYS TO ENTER A NEW PIN,

THEN SYSTEM WILL START LOCK FUNCTION.
(DEFAULT PIN IS 9999)

KID SAFE/G/PG/PG13/PG-R/R/NC-17/ADULT

RESTORE
ENGLISH/CHINESE/GERMAN/SPANISH/

FRENCH/PORTUGUESE
CHINESE/ENGLISH/JAPANESE/FRENCH/

SPANISH/PORTUGUESE/LATIN/GERMAN
CHINESE/ENGLISH/JAPANESE/FRENCH/

SPANISH/PORTUGUESE/GERMAN/OFF
CHINESE/ENGLISH/JAPANESE

SPANISH/PORTUGUESE GERMAN/

#/+4/+2/0/-2/-4/b

12/10/8/6/4/2/0
12/10/8/6/4/2/0
+6/+4/+2/0/-2/-4/-6
12/10/8/6/4/2/0
0/2/4/6/8
FULL

6/8
4/8
2/8
OFF

DEFAULT

/FRENCH/

/ LATIN

-23-

X Troubleshooting

The following phenomenon does not indicate failures. Before you
contact us for repair, please check your device according to the
approaches below.

Problems

No picture or sound

No signal

No sound

Mosaic images

Signal search failure

Too-dark images

Causes

Power wire is not properly connected;
the functioning power source is not
recognized; or there're breaks in the
power wire.

Check whether the antenna is located
well; Check the parameter of image or
region is set correctly; if not, please set
or search again.

If the volume is turned down to the
minimum; single is too weak, and Silence
function is active.

The signal strength is too weak.

Check whether the country and region
is set right;
Maybe the signal intensity is too poor.

Check whether the brightness and
contrast of your display is adjusted well;
if not, readjust it.

-24-

XI Technical Parameters

DVD Technical parameters

Laser wave length: DVD 650nm; CD 780nm

Optical pickup: DV34 (SANYO)

Compatible disc: MPEG-4, DVD, VCD, CD, MP3, WMA, JPEG CD, CD-R,

CD-R/W, DVD+R/-R(nonsupport DIVX 3.11 version)

Other Compatible media:

USB/Multi Media Card(MMC)/SD/Memory Stick(MS)

Shockproof: DVD 3seconds; VCD/CD 10seconds; MP3 90seconds

Frequency response: 20Hz-20KHz

Audio signal-noise ratio(S/N): 60dB

Dynamic scope: 60dB

TV system: PAL/NTSC/AUTO

Menu language: Chinese/English/Japanese/French/Spanish/Portuguese/

German/Latin

Radio Receiving Frequency Range: AM522KHz-1620KHz

Radio Receiving Frequency Range: FM87.5MHz-108MHz

Radio Adjustment Step: AM: 9KHz FM: 50KHz

Radio Sensitivity: AM 90dBuV FM 15dBuV

Radio Signal-to-noise ratio: AM 30dB FM 40dB

DTV Receiving Frequency: 474MHz - 858MHz

DTV Receiving Input Power: 85dBm - 0dBm

ATV Receiving Frequency: 48.25MHz - 863.25MHz

LCD Size: 8.5 inch

LCD Aspect Ratio: 16:9
LCD Resolution: 480 RGB 234

LCD Light Source: CCFL

Power Supply: AC INPUT 230V 50Hz

DC INPUT 12V/2A

-25-

Speaker Output Power: more than1.2W 2CH(when Distortion is less
than 10%)
Power Consumption: less than 20W
Dimensions: 360mm 290mm 78mm
Weight: about 2900g

Note:

Batteries only power the system clock. When main power is off, clock
and memory remains the same and the TV receiver stops playing.
Because system clock is powered by batteries, the time display will be
still correct when the TV receiver is reconnected to main power and
begins to play.

-26-

Warning

This operation instruction is only intended for reference. No further
notice is available to any modification of all information contained
therein. Due to continuing improvements, the features and design
are subject to change without notice.

Warning

No repairable components exist in the machine. Don't try to dismantle
and improve the monitor, and the high voltage in the machine may
cause danger. Maintenance and adjustment of the monitor is subject
to professionals.

after some items in this manual means it is available with this

function.

-27-
