MODEL NO. iP205
IPOD CLOCK
OWNER'S MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
1
CA UT IO N: TO RED UC E TH E RI SK O F EL EC TR IC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEA BLE PARTS INSID E. REFER SERVICING TO QUALIFIED SERVICE PERSONN EL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead
symbol, within an equilateral triangle is intended to alert the user to
the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
ATTENTION:
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the
appliance.
FCC WARNING:
This equipment may generate or use
radio frequency energy. Changes or
modifications to this equipment may
cause harmful interference unless the
modifications are expressly approved in
the instruction manual. The user could
lose the au t hority t o oper a te thi s
equipment if an unauthorized change or
modification is made.
SURGE PROTECTORS:
INFORMATION:
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are
des i g ned to pro v ide reas o nable
protection against harmful interference
in a reside n tial inst a llatio n . T his
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
instal lati on. If this eq uipment do es
cause harmful interference to radio or
tel e visi o n re cept i on, w hich can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
* Reorient or rel ocate the receiving
antenna.
* Increase the separation between the
equipment and receiver.
* Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
* Consult the dealer or an experienced
radio/TV technician for help.
SAFETY INSTRUCTIONS
2
Before using the unit, be sure to read all operating instructions carefully . Please note that these
are general precautions and may not pertain to
your unit. For example, this unit may not have
the capability to be connected to an outdoor
antenna.
1. READ INSTRUCTIONS
All the safety and operating instructions should
be read before the product is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be
retained for future reference.
3. HEED WARNINGS
All warnings on the product and in the operating
instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a dry cloth for cleaning.
6. ATTACHMENTS
Do not use attachments not recommended by
the product's manufacturer as they may cause
hazards.
7. WATER AND MOISTURE
Do not use this product near water–for example:
near a bathtub, washbowl, kitchen sink or laundry tub; in a wet basement; or near a swimming
pool.
8. ACCESSORIES
Do not place this product on an unstable cart,
stand, tripod, bracket or table.
The product may fall, causing
serious injury and serious damage to the product. Use only
with a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the
product. Any mounting of the product should follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
8A. An appliance and cart combination should be
moved with care. Quick stops, excessive force
and uneven surfaces may cause the appliance
and cart combination to overturn.
9. VENTIL ATION
Slots and openings in the cabinet and in the
back or bottom are provided for ventilation, to
ensure reliable operation of the product and to
protect it from overheating. These openings
must not be blocked or covered. The openings
should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This
product should never be placed near or over a
radiator or heat source. This product should not
be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is
provided or the manufacturer's instructions have
been adhered to.
10. POWER SOURCES
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your home, consult your appliance
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer to the operating instructions.
11. GROUNDING OR POLARIZ ATION
This product is equipped with a polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
12. POWER-CORD PROTECTION
Power-supply cords should be routed so that
they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from
the appliance.
13. LIGHTNING
To protect your product from a lightning storm,
or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the product due to
lightning and power-line surges.
14. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it
can fall into such power lines or circuits. When
installing an outside antenna system, extreme
care should be taken to keep from touching
such power lines or circuits as contact with them
might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords
as this can result in a risk of fire or electric
shock.
16. OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product
through openings as they may touch dangerous
SAFETY INSTRUCTIONS
PORTABLE CART WARNING
(symbol provided by RETAC)
3
voltage points or short out parts that could result in
fire or electric shock. Never spill or spray any type
of liquid on the product.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna is connected to the product, be sure the antenna system is grounded so
as to provide some protection against voltage
surges and built-up static charges. Section 810
of the National Electric Code, ANSI/NFPA 70,
provides information with respect to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge product, size of grounding conductors,
location of antenna discharge product, connection to grounding electrodes and requirements
for grounding electrodes.
18. SERVICING
Do not attempt to service this product yourself
as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
19. REPLACEMENT P ARTS
When replacement parts are required, be sure
the service technician uses replacement parts
specified by the manufacturer or those that have
the same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.
20. SAFET Y CHECK
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.
21. WAL L OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
22. DAMAGE REQUIRING SERVICE
Unplug the product from the wall outlet and refer
servicing to qualified service personnel under
the following conditions:
a. When the power-supply cord or plug is
damaged.
b. If liquid has been spilled or objects have
fallen into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the product to its
normal operation.
e. If the product has been dropped or the
cabinet has been damaged.
f. When the product exhibits a distinct change
in performance this indicates a need for
service.
23. HEAT
The product should be situated away from heat
sources such as radiators, heat registers, stoves
or other products (including amplifiers) that produce heat.
24. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close to the point of cable
entry as practical.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
SAFETY INSTRUCTIONS
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE
S2898A
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
4
PREPARATION FOR USE
Power Sources
This portable audio system is designed to operate on DC 12V
or AC adapter 120V AC, 60Hz output DC 12V house current.
LOCATION OF CONTROLS
1 2 3
4
1. POWER BUTTON
2. SNOOZE BUTTON
3. SLEEP BUTTON
4. IPOD CONNECTOR
5. IPOD STAND WHEEL
6. LCD DISPLAY
5
6
5
LOCATION OF CONTROLS
7 8 9
10 11 12 13
Bass
Lo Hi
14
Dimmer
7. WAKE TO SWITCH
(BUZZER/IPOD)
8. BATTERY COMPARTMENT
(1.5V AAA X 2pcs not included)
9. DIMMER (LO/HI)
10. ALARM SET BUTTON
11. HOUR BUTTON
12. MINUTES BUTTON
13. ALARM BUTTON
(ON/OFF)
14. VOLUME KNOB
15. BASS KNOB
16. AC ADAPTOR JACK
15 16
6
OPERATION
Setting up Time:
1. Press Hr Button to select HOUR
2. Press Min Button to select MINUTE
Setting up Alarm Time:
1. Hold Alarm Set and press Hr Button to select alarm HOUR
2. Hold Alarm Set and press Min Button to select alarm Minute
3. Press Alarm ON/OFF button to turn on alarm.
4. Slide Wake To switch to choose wake by buzzer or iPod.
5. To delay alarm, press Snooze button. It will come on again approx. 6 minutes.
6. Press Alarm ON/OFF button to turn off alarm.
Charging your iPod:
When you docked your iPod and it recharges (until fully charged).
* iPod only will charge when using AC Adaptor.
* iPod Shuffle is not support
Listening to your iPod:
1. When the iPod is docked
2. Press the Power button turn on the unit and iPod will play it. iPod icon will
appear on the display.
To start Sleep function:
1. Press the SLEEP button and "90" will appear and set the unit to turn off
after 90 minutes.
2. Each time you press the SLEEP button and time will be “90, 60, 30, 10, 0”
3. After five seconds, the Sleep function will activate and the SLEEP
indicator will light solid.
4. Pressing the SLEEP button again unit "OFF" appears and turns off the
sleep function.
Dimmer Switch:
1. Slide the Dimmer Switch to Hi to turn the Display brighter
2. Slide the Dimmer Switch to Lo to turn down the Display brightness.
7
TROUBLESHOOTING GUIDE
PROBLEM SOLUTION
iPod does not
dock properly
iPod does not
respond to the
unit
iPod didn’t
charge up iPod is not installed properly .
iPod didn’t install properly
iPod is not installed properly .
Using 1st or 2nd generation iPod ,
iPod Shuffle or other devices.
POSSIBLE CAUSE
iPod
is locked up.
Make sure the iPod stand choose
.
the correct iPod type to support your
iPod
Remove your iPod from the dock
and check for obstruction on the
connectors in the dock and on your
iPod . Then reseat it in the dock.
Please make sure your iPod is
working properly before docking into
the unit. Please refer to your iPod®
manual for details.
Unit cannot control those iPod or
other devices.
Remove your iPod from the dock
and check for obstruction on the
connectors in the dock and on your
iPod . Then reseat it in the dock.
8
LIMITED PRODUCT WARRANTY
This quality product is warranted to be free from manufacturer’s defects in material and workman-ship,
provided that the unit is used under the normal operating conditions intended by the manufacturer.
Should you have any problem with this product, please and it is highl y recommended to visit our website at
www.curtisint.com
before you take any other steps as we have additional copies of instruction manuals,
operating manuals and trouble shooting tips on our website which gives you the answer on most of the
questions you could have in operating the unit.
TERMS OF WARRANTY
C.I. Service Dept. warrants this product to be free from defects in materials and workmanship for 1 year on
parts and 90 days on labor.
Nothing within this warranty shall imply that C.I. will be responsible or liable for any damage to any items
placed in this product, whether due to any defect of the product, or its use, whether proper or improper.
EXCLUSIONS
Save as herein provided, C.I. Service Dept. (Canada) or C.I. Service Dept. (USA), there are no other
warranties, conditions, representations or guarantees, express or implied, made or intended by C.I. or its
authorized distributors and all other warranties, conditions, representations or guarantees, including any
warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or
statue is hereby expressly excluded. Save as herein provided, C.I. Service Dept. (Canada) or C.I. Service
Dept. (USA), shall not be responsible for any damages to persons or property, including the unit itself,
howsoever caused or any consequential damages arising from the malfunction of the unit and by the
purchase of the unit, the purchaser does hereby agree to indemnify and save harmless C.I. from any claim
for damages to persons or property caused by the unit.
TO OBTAIN REPAIRS UNDER THE TERMS OF THIS WARRANTY
1. The original purchaser must present a copy of the original bill of sale and the service warranty card.
2. Any alterations, abuse, misuse, battery corrosion or accidental damage voids the warranty.
3. The warranty does not cover cabinets and accessories.
4. No warranty or insurance contained or set out shall apply when damage or repair is caused by power
failure; damage in transit or when moving the unit; improper power supply; use for commercial or
industrial purposes; service calls resulting in customer education, etc.
5. The defective product should be mailed to:
For service assistance and product information, please call: 1-800-968-9853.
Canada U.S.A
C.I. Service Dept. C.I. Service Dept.
315 Attwell Dr 181 Cooper Avenue
Unit 104
Toronto, Ontario Tonawanda, N.Y.
M9W 5C1
If mailing the product, the freight must be prepaid and a money order for $7.00 should be included
to cover the cost of insurance and the return of the product.
6. C.I. reserves the right to repair or replace the parts which have become defective.
Model No. Date Purchased Serial No.
14150
Loading...
