CU Medical Systems iNF1200 Service Manual
i-PAD NF1200
Service Manual
CU Medical Systems, Inc.
1
i-PAD NF1200
Quick Reference Card
Rescue Steps
1. Connect the defibrillator pads to the i-PAD and then place on patient.
2. Stand clear and press the SHOCK button if instructed.
3. Administer CPR
2
Notice
i-P AD NF 1200 Service Manual
CU Medical Systems, Inc. reserves the right to make changes on the device specifications contained in this manual
at any time without prior notice or obligation to customers.
Printed in the Republic of Korea
Publication Date: March 2007
Service Manual Part No.:
© 2007 CU Medical Systems, Inc.
No part of this manual may be reproduced without the permission of CU Medical Systems, Inc.
3
Table of Contents
Table of Contents ...................................................................................................................4
1. Introduction........................................................................................................................5
1.1 The i-PAD NF1200.......................................................................................................................................... 5
1.2 Service Manual Overview ...............................................................................................................................5
1.3 Warnings, Cautions, and Notes........................................................................................................................ 5
1.4 i-PAD NF1200 Device Details ........................................................................................................................ 5
1.4.1 Operating Controls, Indicators and Accessories ...................................................................................7
1.4.1.1 Device Parts Illustration .............................................................................................................. 7
1.4.1.2 Accessories ................................................................................................................................10
1.4.2 Voice and Text Prompts .......................................................................................................................11
2. Routine Maintenance ....................................................................................................... 13
2.1 Overview........................................................................................................................................................13
2.2 Cleaning the i-PAD NF1200..........................................................................................................................13
2.3 Periodic Safety and Functional Checks ......................................................................................................... 14
2.4 Batteries .........................................................................................................................................................16
3 Performance Verification .................................................................................................. 17
3.1 Self-Tests........................................................................................................................................................17
3.2 Automatic Self-Tests...................................................................................................................................... 18
3.3 Battery Insertion Test..................................................................................................................................... 18
3.4 Self Test Results.............................................................................................................................................18
3.4.1 Automatic Self Tests ............................................................................................................................ 18
3.4.2 Battery Insertion Test...........................................................................................................................18
3.5 Shock Waveform Verification Test................................................................................................................20
3.6 Data Transmission Test..................................................................................................................................22
3.7 Impedance Measurement Test .......................................................................................................................23
3.8 Voice and Text Prompt Testing......................................................................................................................24
4 Troubleshooting ................................................................................................................ 26
4.1 How to Use This Section ...............................................................................................................................26
4.2 Who Must Perform Repairs ........................................................................................................................... 26
4.3 Replacement Level Supported....................................................................................................................... 26
4.4 Troubleshooting Guide .................................................................................................................................. 26
5 Disassembly and Repair....................................................................................................33
5.1 Disassembly ................................................................................................................................................... 34
5.2 Reassembly ....................................................................................................................................................40
6 Assembly Diagram............................................................................................................41
Technical Specifications ......................................................................................................43
Electromagnetic Compatibility ............................................................................................49
4
1. Introduction
1.1 The i-PAD NF1200
The i-PAD is a semi-automated external defibrillator designed for minimally trained individuals. It provides
simple and direct voice prompts and indications for a straightforward rescue operation. It is lightweight and
battery powered for maximum portability.
1.2 Service Manual Overview
This Service Manual contains service information and instructions intended for qualified service personnel who
will repair and service the i-PAD NF1200.
1.3 Warnings, Cautions, and Notes
“WARNING” – used to denote conditions, hazards, or unsafe practices that can result in serious personal injury or
death.
“CAUTIONS” – used to denote conditions, hazards, or unsafe practices that can result in minor personal injury,
damage to the i-PAD NF1200, or loss of data stored in it.
“NOTES” – used to denote items that are important during installation, operation, or maintenance of the i-PAD
NF1200.
1.4 i-PAD NF1200 Device Details
The following description and diagrams show the details of the i-PAD NF1200.
5
Data Storage and Backup Subsystem
To External
Device
Data Storage and
Backup
Subsystem
Analog Front-end
Patient
Analog Front-end Subsystem
ECG and
impedance
signals
Analog to Digital
Converter
Internal Disarm
Resistor
Switches
H-Bridge
Therapy Capacitor
ECG and
impedance
data
High Voltage Subsystem
High Voltage
Electrical
energy
High Voltage
Electrical
energy
Main Digital Subsystem
Main
Microprocessor and
Memory
Defibrillation
Control Signals
Defib Control
Microprocessor and
Memory
High Voltage Power
Supply
12V
Electrical
energy
General Power
Supply
15V, 5V, 3.3V, -3.3V, 1.8V
To various parts
of the device
Battery Pack
Power Supply Subsystem
i-PAD NF1200 Functional Block Diagram
6
1.4.1 Operating Controls, Indicators and Accessories
1.4.1.1 Device Parts Illustration
Top View of the i-PAD NF1200 with its cover closed
7
Perspective view of the i-PAD NF1200 with its cover open
8
Power ON/OFF
Button
i-Button Press this button to:
State LED Indicates the status of the i-PAD
Handle An easy-grip carrying handle for increased portability of the i-PAD.
Cover Covers the front panel of the i-PAD and retains the defibrillator electrode pads package.
SHOCK button Press this button when the i-PAD prompts you to “Press the flashing orange button now”.
AED electrode
pads connector
port
Graphical Rescue
Guide
Quick Reference
Guide
Battery Pack Provides power to the i-PAD.
IrDA
Communication
Port
Press this button to turn the i-PAD ON or OFF.
• Get information regarding the i-PAD’s last usage (usage time and number of
shocks delivered.)
• Get information regarding errors that were detected during self-tests.
• Toggle between compression-to-breathing ratios during CPR (30:2 and 15:2)
• blinking green: the i-PAD is in standby mode and ready for a rescue operation
• solid green: the i-PAD is in rescue mode.
• blinking red: the i-PAD detected a system error or low battery level during a self-
test.
• solid blue: the i-PAD is conducting a self-test.
• solid white: the i-PAD is in administration mode. It announces last use
information and it senses and waits for a possible data
transfer to a personal computer.
Pressing this button delivers a defibrillation shock to the patient.
Plug the connector of the AED electrode pads into this port
Guides you by indicating the current step in the rescue process.
A printed card that summarizes the steps of a rescue process using the i-PAD.
Initiates a self-test upon insertion.
Port for sending and receiving data to and from a personal computer.
9
1.4.1.2 Accessories
Only parts and accessories approved by CU Medical Systems, Inc. must be used with the i-PAD NF1200. Using
parts and accessories that are not approved by CU Medical Systems, Inc. may degrade performance.
Using accessories and cables other than the ones specified in this manual may result in increased
ELECTROMAGNETIC EMISSIONS or may decrease the ELECTROMAGNETIC IMMUNITY of the
i-P AD NF 1200
Replacement accessories and consumables must be sourced only from CU Medical Systems, Inc. or its
authorized representatives.
Standard Accessories
Defibrillator Electrode Pads and
Connector Assembly
Disposable, non-rechargeable, LiMnO2
battery pack
Optional Accessory
Self adhesive, pre-gelled defibrillator electrode pads used to
acquire the ECG signal from the patient and to deliver the
defibrillation shock to the patient.
Power source of the i-PAD NF1200. This battery is inside the
case of the device. RETURN the i-PAD NF1200 to an
authorized service representative in case the battery pack needs
to be replaced.
Used to store the i-PAD NF1200 and the accessories needed for
a rescue operation.
Carrying Case
10
1.4.2 Voice and Text Prompts
Prompts
The i-PAD NF1200 guides you throughout a rescue operation using voice prompts and other audio-visual
indicators. The following table lists the voice prompts of the i-PAD NF1200.
Table: Voice prompts and their meanings.
Prompt Meaning/Definition
Attach pads
Do not touch the patient
Analyzing heart rhythm
Shock advised
Stand clear
Press the flashing orange button, now.
Deliver shock, now.
Shock delivered
Begin CPR, now
Push the chest down, fast, two inches
Give two breaths. Breath, breath
The shock button was not pressed
No shock advised
Check pulse
If no pulse, begin CPR
System shutting down
Press the flashing orange button, now
Press the flashing blue i-Button
Administration mode
• Indicates that you have to attach the defibrillator electrode
pads to the bare chest of the patient and to the i-PAD
NF1200
• Indicates that you or any bystander must not touch the
patient.
• Indicates that the i-PAD NF1200 is analyzing the ECG of
the patient. Nobody must touch the patient.
• Indicates that a shockable ECG rhythm has been detected
and the i-PAD NF1200 is preparing for a shock delivery.
• Emphasizes the need to stay clear of the patient. Given just
before the prompt to deliver shock is given.
• Indicates that you have to press the shock button in order
for the shock to be delivered. The shock will only be
delivered if you press the shock button.
• Indicates that a shock has been delivered to the patient.
• Indicates the start of CPR.
• You may touch the patient after this prompt is given.
• Indicates that you have to push the chest down for about
two inches during CPR. The chest has to be pushed down
fast.
• Indicates that you have to give artificial breaths to the
patient. Time the breaths with the breathing guide.
• Indicates that you did not press the shock button within 15
seconds when the i-PAD NF1200 prompted you to do so.
• Indicates that the i-PAD NF1200 detected a nonshockable
rhythm.
• Indicates that you have to check the pulse of the patient.
• Indicates that if there is no pulse, you have to begin CPR.
• Indicates that the ON/OFF button of the i-PAD NF1200
has been pressed to turn it OFF.
• Given during battery insertion test. Indicates that you have
to press the SHOCK button so that the i-PAD NF1200 can
test its functionality.
• Given during battery insertion test. Indicates that you have
to press the i-Button button so that the i-PAD NF1200 can
test its functionality.
• Indicates that the i-PAD NF1200 is in administration mode
11
Table: Voice prompts and their meanings, continued
Prompt Meaning/Definition
Device usage time is 10 minutes
Shock delivery is 4 times
• Given during administration mode. Indicates the duration
(in minutes) that the i-PAD NF1200 was ON. In this case,
the i-PAD NF1200 was ON for 10 minutes during its
previous usage.
• Given during administration mode. Indicates the number
of shocks that the i-PAD NF1200 delivered. In this case,
the i-PAD NF1200 delivered four shocks during its
previous usage.
12
2. Routine Maintenance
2.1 Overview
The i-PAD NF1200 does not need any routine maintenance or calibration of its internal electronic subsystems.
Whenever service is necessary, please contact CU Medical Systems, Inc. or any of its authorized representatives.
2.2 Cleaning the i-PAD NF1200
After each use, clean the i-PAD NF1200 using a soft, damp cloth moistened with any of the following solvents:
Soap and water
70% solution isopropyl alcohol
Chlorine bleach and water mixture (30 ml bleach/liter of water)
Ammonia-based cleaners
Hydrogen peroxide
Do not immerse any part of the i-PAD NF1200 in fluids
Do not let any fluid enter the case of the device.
Do not spill liquids on the case of the device.
Do not use strong, acetone-based cleaners in cleaning the device.
Do not use abrasive materials in cleaning the unit, especially on the LCD display and the infrared
filter on the IrDA port.
Do not sterilize the i-PAD NF1200.
13
2.3 Periodic Safety and Functional Checks
It is recommended that the following periodic checks be performed to ensure that the device and its accessories are
in good condition and ready for any emergency.
Maintenance Activities
Frequency Activity Actions to be T aken
Daily
Monthly and after
each use
Check the i-PAD NF1200 for any error
messages that might have been
generated during the Daily Periodic
Self-Test.
Check supplies, accessories, and spare
parts for damage and expiration.
Initiate complete self-test by doing a
Manual Self-Test.
Check the case of the i-PAD NF1200
and the accessories for any sign of
apparent damage.
Check for dirt contamination.
If a message that the battery is low is
displayed, recharge the battery. For any other
error messages, please call the manufacturer
or its designated service center.
If any supplies have expired, replace them
immediately.
If the self test detects any problem, see the
chapter on Troubleshooting.
If there is any apparent damage to the case of
the device, consult the manufacturer.
If there is dirt contamination, clean the case as
suggested in the section on Cleaning.
After each use.
Ensure that the connector of the
defibrillator pad assembly is
disconnected from the ECG-DEFIB
port of the i-PAD NF1200.
Disconnect the pad assembly from the ECG-
DEFIB port
14
MAINTENANCE CHECKLIST
i-P AD NF 1200
Serial Number __________________ Location/Vehicle ID _________________
Date
Scheduled Frequency
i-PAD NF1200:
Clean, no signs of damage, free of
excessive wear
Supplies Available
-2 sets of defibrillator electrode pads,
undamaged, sealed, within expiration
date
-supplementary supplies (razor,
scissors, gloves, gauze)
Remarks, Problems, Corrective
Actions
Inspected by
Signature of operator doing the
inspection
15
g
2.4 Batteries
The i-PAD NF1200 is equipped with LiMnO2 battery cells. These batteries are nonrechargeable. The status of the
battery charge is monitored by periodic tests (daily, weekly, monthly), power ON test, run-time test, and battery
insertion test. The i-PAD NF1200 indicates through the State LED and the i-Button if the battery pack needs to be
replaced.
If the voltage level of the internal Battery pack falls below the minimum tolerable level, the i-PAD NF1200 is
going to be inoperative.
If this is detected during automatic self-test, the i-PAD NF1200:
a. Flashes the State LED in red
b. Emits a burst of beeps every minute.
When the i-PAD NF1200 is turned ON after a low battery condition is detected, the i-PAD NF1200:
a. Turns the State LED momentarily in blue.
b. Then turns the State LED in solid red.
c. Flashes .the i-Button in red
d. Gives the prompt: “Press the flashing red i-Button”.
e. After the i-Button is pressed, the i-PAD NF1200 gives the prompt: “Low battery. Replace the battery with a
new one.”
The sequence of indications from a to e above is also given when the low battery level is detected during battery
insertion test.
• Do not charge the battery pack
• Do not open the case of the battery pack. Do not saw off or break apart the case of the battery pack.
• Do not let the battery pack come into contact with open flames and other hot objects. Do not dispose
of in fire
• Do not short-circuit the terminals of the battery pack.
• Do not subject the battery pack to serious physical impact. Do not hit it with a hammer.
• In case of leaka
• Keep the battery pack out of children’s reach.
• If the battery pack, leaks and the leaked liquid gets in the eyes, wash them with clean water and
consult a physician immediately.
• Do not leave the battery pack in direct sunlight or in high temperature areas.
• Do not have the battery pack in contact with water.
• Keep the battery pack away from direct sunlight, high temperature, and humidity.
• Follow local regulations when disposing of the battery pack.
• Do not subject the battery pack to conditions beyon d the safe environmental conditio ns for the i-PAD
NF1200.
e or strange smell, keep away from fire to prevent ignition of any leaked electrolyte.
16
Loading...
