Page 1
Griddler
®
Setup Instructions Continue Inside
For more helpful hints see Instruction Booklet
QUICK REFERENCE GUIDE
Cleaning and Care
Before the First Use
Setup
PG-28432
IMPORTANT
Do not throw away. Read before operating your new Griddler®. Keep for future reference.
These helpful hints are intended to be a supplement
to the Instruction Booklet. In order to ensure safe operation and optimum performance,
please read the entire Instruction Booklet.
Remove all packaging materials and any promotional
labels or stickers from your grill. Conrm all parts of your
new appliance have been included.
Place Griddler
®
on a clean at surface where you
intend to cook.
1.
1.
To Position Drip Tray: Slide the drip tray into the base
according to the instruction on the tray.
Remove any dust from the unit by wiping the base, cover
and controls with a damp cloth. Thoroughly clean
cooking plates, drip tray and cleaning/scraping tool
(dishwasher safe).
2.
2.
Turn the Selector Dial to the Off position and unplug the
power cord from the wall outlet.
1.
Use the cleaning/scraping tool to remove any leftover
food from the cooking plate. Do not use metallic objects
(such as knives or forks) or a scouring pad for cleaning.
Dispose of grease from the drip tray once cooled.
To Remove Cooking Plates:
With unit in the at position,
press the plate release button
on the right side of the housing
and slide the plate out from
under the metal brackets.
The cooking plates, drip tray, and cleaning/scraping tool
can all be cleaned in the dishwasher or by hand.
The housing base, cover and control can be wiped clean
with a soft, dry cloth.
2.
3.
4.
5.
6.
CAUTION: Before cleaning appliance, make sure it has
cooled down completely (for 30 minutes).
Lower plate
release button
Upper plate
release button
Page 2
Setup
Cooking Options
To Insert Cooking Plates: Adjust to the at position by
lifting the hinge release lever. Slide the plate underneath
the metal brackets of the housing and push down the front
end of the plate. If you require only one plate for cooking, we
recommend using the bottom plate.
Plug the unit into an outlet.
Turn the corresponding temperature dial to desired tem-
perature. For best results, preheat in the closed position.
Once the unit reaches desired temperature, the green
indicator light will illuminate and you’re ready to cook! Do not touch
the cover or plates during operation, as they get very hot.
NOTE: Each temperature dial
controls both top and bottom
plates simultaneously. Top and
bottom plates will cook at the
same set temperature.
3.
4.
6.
Turn the Selector dial to desired function: Grill/Panini or
Griddle. The red indicator light will illuminate to indicate
the power is on.
5.
CONTACT GRILL: To cook burgers,
boneless meats and vegetables by
resting the top cover on top of the
food until it has reached the desired
cooking temperature.
1.
PANINI PRESS: To grill sandwiches,
breads and quesadillas by resting
the top cover on top of the food,
pressing, and heating to your liking.
FULL GRILL: To cook burgers,
steak, poultry, sh and vegetables
in the open, at position.
FULL GRIDDLE: To cook pancakes,
eggs, hash browns and breakfast
meats in the open, at position.
HALF GRILL / HALF GRIDDLE:
To cook full meals like bacon & eggs
and steak & potatoes at the same
time in the open, at position.
2.
3.
4.
5.
Hinge
release
lever
