Cuisinart CWC-1200 User Manual
INSTRUCTION
BOOKLET
Private Reserve™ Wine Cellar
For your safety and continued enjoyment of this product, always read the instruction book carefully before using.
CWC-1200
IMPORTANT
SAVE THESE
SAFEGUARDS
When using an electrical appliance, basic
precautions should always be followed to reduce
the risk of re, electric shock, and personal injury,
including the following:
1. Use this appliance only as described in this
manual. Other uses not recommended may
cause re, electric shock or personal injury.
2. This product is intended for household use
only.
3. To protect against electric shock, do not
immerse unit, plug or cord in water or spray
with liquids.
4. Close supervision is necessary when any
appliance is used by or near children.
5. Unplug from the outlet when not in use when
moving from one location to another, and
before cleaning.
6. To disconnect the appliance, grip the plug
and pull it from the wall outlet. Never pull
by the cord.
7. Do not operate the appliance in the presence
of explosives and/or ammable fumes.
8. Do not place the appliance or any of its parts
near an open ame, cooking or other heating
appliance.
9. Do not operate the appliance with a damaged
cord or plug, if the product malfunctions, or
if it is dropped or damaged in any manner.
10. The use of attachments not recommended
by the manufacturer may be hazardous.
11. Place the unit on a dry level surface.
12. Do not operate if the housing is removed
or damaged.
13. A loose t between the AC outlet (receptacle)
and plug may cause overheating and a
distortion of the plug. Contact a qualied
electrician to replace loose or worn outlet.
14. This appliance is designed to be freestanding
only, and should not be recessed or built in
(fully recessed.)
15. Locate the unit away from direct sunlight and
sources of heat (stove, heater, radiator, etc.).
Direct sunlight will affect/alter the outside
color of the appliance.
WARNING: To reduce the risk of fire, electric
shock or personal injury, unplug or disconnect
the appliance from the power supply before
servicing.
INSTRUCTIONS
FOR HOUSEHOLD USE
ONLY
SPECIAL CORD SET
INSTRUCTIONS
NOTICE
For your protection, this unit is equipped with
a 3-conductor cord set that has a molded
3-prong grounding-type plug, and should be
used in combination with a properly connected
grounding-type outlet as shown in gure A.
If a grounding-type outlet is not available, an
adapter, shown in Figure B, may be obtained
so that a 2-slot wall outlet can be used with
a 3-prong plug. As shown in Figure C, the
adapter must be grounded by attaching its
grounding lug under
the screw of the
outlet cover plate.
NOTE: Do not
remove the
grounding prong.
CAUTION: Before
using an adapter,
it must be
determined that
the outlet cover
plate screw is
properly grounded.
If in doubt, consult
a licensed
electrician. Never
use an adapter
unless you are
sure it is properly
grounded.
Note: Use of an
adapter is not
permitted in
Canada.
2
CONTENTS
Important Safeguards . . . . . . . . . . . . . 2
Special Cord Set Instructions . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . 3
Parts . . . . . . . . . . . . . . . . . . . . . . 3
Using Your Wine Cellar . . . . . . . . . . . . 3
Operating Instructions . . . . . . . . . . . . 4
Temperature Control . . . . . . . . . . . . . 4
Mode Selection Procedure . . . . . . . . . . 5
Storing Wines/Temperature Chart . . . . . . 6
Interior Light Control . . . . . . . . . . . . . 7
Cleaning and Care . . . . . . . . . . . . . . 7
Wine Tips and Hints . . . . . . . . . . . . . . 7
Wine and Food Pairing Guide . . . . . . . . . 8
Troubleshooting . . . . . . . . . . . . . . . . 9
Warranty . . . . . . . . . . . . . . . . . . . 10
USING YOUR WINE CELLAR
Remove all packaging and any promotional
labels or stickers from your wine cellar.
Be sure that all parts (listed above) of your
new wine cellar have been included before
discarding any packaging materials. You may
want to keep the box and packing materials
for use at a later date.
Before using your Cuisinart™ Private Reserve™
Wine Cellar for the rst time, remove all
protective paper and wrapping. Wipe housing
and internal chamber with a damp cloth to
remove any dust from the warehouse or
shipping.
3
INTRODUCTION
Different wines must be served at different
temperatures to optimize avor. Your Private
Reserve™ Wine Cellar has 8 convenient
presets to keep each type of wine at the
temperature recommended by experts.
You’ll love the way this traditionally styled
countertop wine cellar looks in your kitchen.
With its smooth brushed stainless steel door,
tinted glass window, and soft interior lighting
that you can leave on or turn off, it’s an elegant
way to ensure that your favorite wines and
champagnes are beautifully displayed and
ready to serve.
PARTS
1. Stainless steel veneered door with handle
2. Tinted double-pane window
3. LED display
4. Cabinet
5. Control panel
6. 3 removable chrome wine racks
7. Interior light control
8. Circulating fan
1
2
4
8
5
7
6
3
OPERATING INSTRUCTIONS
1. Place your wine cellar on a at surface
that is strong enough to support it when
fully loaded.
2. Allow 3" (76mm) of space on both sides
and rear of the wine cellar to allow proper
ventilation.
3. This wine cellar is designed to be
freestanding only, and should not be
recessed or built in (fully recessed).
4. Do not place heavy objects on top of the
unit.
5. Do not locate the unit in a moist place or
display in direct sunlight.
6. Do not place the unit next to a major
appliance that emits large amounts of
heat, such as a dishwasher, microwave,
toaster oven, oven or barbecue, etc.
7. Do not plug unit into the same outlet as a
refrigerator or microwave.
8. The unit’s cooling system operates
efciently with an ambient temperature of
less than 70°F (21°C).
9. Gently place/slide the racks in the wine
cooler.
10. Determine the best setting to use: refer to
the temperature guide for appropriate
serving presets (see page 6).
11. Place bottles inside the cooler.
12. Plug the power cord into a standard
electrical outlet.
Important: When using the wine cellar for
the first time, allow at least 24 hours for the
internal temperature to adjust properly.
Make sure there are at least 3 to 5 bottles in
the unit.
ALWAYS REMOVE ALL BOTTLES BEFORE
MOVING THE WINE CELLAR
TEMPERATURE CONTROL
Impor tant note: In order to operate
efficiently, thermoelectric products should
be in an environment with an ambient
temperature of less than 70°F (21°C).
Setting the temperature control (presets):
For your convenience, the Cuisinart™ Private
Reserve™ Wine Cellar is programmed with
eight presets, to accommodate any variety
of wine.
To change the preset temperature in the wine
cooler, simply press the Preset button until
the desired preset number (1 to 8) appears.
The following section about storing wines
(see page 6) will advise the optimal settings
for your wine.
4
