Cuisinart CTG-00-SPI4 Instruction And Recipe Booklet

Instruction and Recipe Booklet

CTG-00-SPI4

FOOD SPIRALIZER

For your safety and continued enjoyment of this product,

always read the instruction book carefully before using.

2

CONTENTS

Important Safeguards......................................... 3

Assembly.................................................... 4

Using the Spiralizer ........................................... 5

Cutting Options .............................................. 6

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Recipes .................................................. 8–11

Product Registration ...................................... 12–15

3

IMPORTANT SAFEGUARDS

SAVE AND READ THESE

INSTRUCTIONS

CAUTION: THE CUTTING

BLADES HAVE VERY SHARP

EDGES.

Basic safety precautions should always be taken, including the
following:

1.

READ ALL INSTRUCTIONS, including these
important safeguards.

2. Close supervision is necessary when this spiralizer is used by or
near children or individuals with certain disabilities.

3. Blades are extremely sharp. Handle carefully when in use or
cleaning.

4. Be certain clear protective cover is securely locked in place before
using.

FOR HOUSEHOLD USE ONLY

BEFORE USING

Wash all parts of the spiralizer with warm, soapy water, rinse, and wipe
dry. Use caution when handling the cutting table where the blades are
located – the blades are sharp!

4

ASSEMBLY

1. Insert the shaft into the hole of the protective cover. Screw the

handle clockwise onto the stainless steel shaft to tighten

2. Screw the food holder to the bottom of the stainless steel shaft so

that the teeth are pointed downward.

3. Set the cutting surface on the collection bowl (as shown in diagram)

and turn clockwise to lock into collection bowl.

Handle knob

Stainless steel sha

Center pin

Ribbon blade dial

Collection bowl

Julienne blade

dial

Food holder

Handle

Protective cover

Cutting surface

Collection bowl

5

USING THE SPIRALIZER

1. Begin by cutting your fresh, raw food (vegetable/fruit) at least 1" in

diameter and 1" to 3.5" in length. Make sure the top and bottom
ends of your food pieces are cut straight and flat so that they can
be held firmly in place by the teeth on the holder and the center pin
on the cutting surface.

2. Move the Julienne blade dial from “Safe” position to the desired

thick or thin julienne (refer to Cutting Options on page 6). Turn the
Ribbon blade dial marked “Cut” out of safe mode, into the cut mode,
where the blade will be visible.

3. Position one of the flat ends of the food on the center pin of the

cutting surface. Apply enough pressure to stabilize the food item on
the center pin.

4. The center pin keeps your food in place while you adjust the shaft

and position the Cuisinart

®

Food Spiralizer’s food holder so it is
centered over the food item. As you turn the protective cover
clockwise, the teeth of the holder will grip the food, holding it
securely. Turn clockwise until protective cover locks into place.

5. Your food is now securely held in place between the teeth of the
holder and the center pin on the cutting surface.

6. To start using your Cuisinart

®

Food Spiralizer, rotate the handle
clockwise while applying downward pressure with the palm of your
hand.

WARNING

Please remember to set all blades to the SAFE position (no blades or
teeth will be visible on the cutting surface) before unlocking the
collection bowl to retrieve food or before cleaning the unit.

The Cuisinart

®

Food Spiralizer is not recommended for harder foods,

e.g., butternut squash. Keep food spiralizer blades away from children.

6

CUTTING OPTIONS

Ribbon Slice (Figure 1) – Only the flat blade is being used. Adjust the
Ribbon blade dial to Cut. Turn the Julienne blade dial to the Safe
position, so that no julienne blade will be visible.

Thin Julienne (Figure 2) – Turn the Ribbon blade to the cut position.
Turn the Julienne blade dial so that the thinly spaced blades (teeth) are
visible.

Thick Julienne (Figure 3) – Turn the Ribbon blade to the cut position.
Turn the Julienne blade dial so that the widely spaced blades (teeth)
are visible.

2 3

Closed
julienne
blade
dial

Open thin
julienne
blade
dial

Open thick
julienne
blade
dial

Open ribbon

blade dial

Open ribbon

blade dial

Open ribbon

blade dial

Ribbon Slice Thin Julienne Thick Julienne

USE AND CARE

Dishwasher-safe unit and parts.

1

7

WARRANTY

LIFETIME WARRANTY (U.S. and Canada ONLY)
Cuisinart

®

Tools & Gadgets are warranted to be free of defects in
material and workmanship under normal home use from the date of
original purchase throughout the original purchaser’s lifetime. If your
tool/gadget should prove to be defective within your lifetime, we will
repair it (or, if we think it necessary, replace it) without charge to you,
except for shipping and handling. To obtain warranty service, please
call our Consumer Service Center toll-free at 1-800-726-0190, or write
to Consumer Service Center, Cuisinart, 150 Milford Road, East Windsor,
NJ 08520. To facilitate the speed and accuracy of your return, please
enclose $4.00 for shipping and handling of the product. Be sure to
include a return address, description of the product problem, phone
number, and any other information pertinent to the product’s return.
Please pay by check or money order made payable to Cuisinart. This
warranty excludes damage caused by accident, misuse or abuse,
including damage caused by overheating, and it does not apply to
scratches, stains, discoloration or other damage to external or internal
surfaces that does not impair the functional utility of the tool/gadget.
This warranty also expressly excludes all incidental or consequential
damages. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the foregoing limitation or
exclusion may not apply to you. This warranty gives you specific legal
rights, and you may also have other rights, which vary from state to
state.

CALIFORNIA RESIDENTS ONLY
California residents should call 1-800-726-0190 for shipping
instructions. Cuisinart will be responsible for the cost of the repair,
replacement, and shipping and handling of such nonconforming
products under warranty.

8

RECIPES

Cucumber Salad with Asian-Style Dressing

The thin and thick julienne settings are perfect for enjoying your favorite

vegetables raw in a delicate salad like this one.

Makes 3 cups

Dressing:
2 tablespoons rice vinegar
2 teaspoons reduced-sodium soy sauce
¼ teaspoon fish sauce (optional)
1 teaspoon packed light brown sugar
1 1-inch piece fresh ginger, peeled and grated
1 small garlic clove, grated

1

⁄3 cup grapeseed oil
Salad:
2 tablespoons packed fresh cilantro leaves, roughly chopped
2 large carrots
3 medium radishes
1 large seedless cucumber
Pinch of salt, for serving

1. Prepare dressing by combining all the ingredients in a large bowl. Fold in the

cilantro. Set aside.

2. Trim vegetables to fit into spiralizer. Prepare carrots and radishes by

spiralizing on the thin julienne setting. Add to the large bowl with the
dressing.

3. Prepare cucumber by spiralizing on the thick julienne setting. Add to the

large bowl with the carrots, radishes and dressing. Toss gently. Sprinkle with
salt before serving.

4. Serve immediately.

Nutritional information per serving (1 cup):

Calories 152 (70% from fat) • carb. 11g • pro. 1g • fat 12g • sat. fat 1g

chol. 0mg • sod. 108mg • calc. 39mg • fiber 2g

9

Crispy Potatoes and Frizzled Onions

This spiralizer isn’t just for the healthy—after all, doesn’t almost everything

taste better fried?

Serves 4 to 6 people

1 russet potato
1 sweet potato
1 medium onion
4 cups vegetable or canola oil, for frying
¾ teaspoon salt, divided

1. Trim vegetables to fit into spiralizer. Prepare vegetables by spiralizing each

on the thick julienne setting. Set aside.

2. Put vegetable oil in a medium saucepan*. Heat until oil reaches 375º F. Add

russet potato to oil in two batches. Fry until golden brown, adjusting the
heat as necessary, about 4 minutes per batch. Remove from oil and drain on
a plate lined with paper towels. Sprinkle with a pinch of the salt.

3. When the oil reaches 375º F again, add the sweet potato. Fry until golden

brown, about 4 minutes. Remove from oil and drain alongside fried russet
potato. Sprinkle with a pinch of salt. Repeat with onion. Taste and adjust
seasoning as desired.

4. Serve immediately.

*Note: When frying, oil should be several inches deep to prevent crowding.
There should also be at least 3 to 4 inches of clearance from the top of the pot
to prevent splattering.

Nutritional information per serving (1 cup):

Calories 333 (73% from fat) • carb. 22g • pro. 2g • fat 28g • sat. fat 48g

chol. 0mg • sod. 327mg • calc. 29mg • fiber 3g

10

Fresh Summer “Spaghetti”

This light, stovetop dish is full of bright flavors and couldn’t be easier to make.

Makes 5 cups

2 medium zucchini, about 1 pound total
1 large carrot (only use wide end of carrot)
2 tablespoons extra virgin olive oil
2 garlic cloves, smashed
¼ teaspoon crushed red pepper

1 pint grape tomatoes, halved
¾ teaspoon salt
¼ cup packed fresh basil leaves, sliced very thin

1. Trim vegetables to fit into spiralizer. Prepare zucchini by spiralizing on the

thick julienne or ribbon setting. Set aside. Prepare carrot by spiralizing on
the thick julienne setting. Set aside with zucchini.

2. In a large skillet, heat olive oil, garlic and crushed red pepper over medium-

high heat until hot and fragrant, about 5 minutes.

3. Add tomatoes and ¼ teaspoon salt; cook until blistered, about 6 to 8

minutes.

4. Remove skillet from heat. Remove garlic cloves. Stir in zucchini, carrot, basil

and remaining salt. Taste and adjust seasoning as desired.

5. Serve immediately.

Nutritional information per serving (1 cup):

Calories 81 (62% from fat) • carb. 7g • pro. 2g • fat 6g • sat. fat 1g

chol. 0mg • sod. 338mg • calc. 29mg • fiber 2g

11

Pear Chips

With just the right amount of sweetness, these pear chips make the perfect snack.

Makes about 50 chips

1 pear, firm
2 teaspoons ground cinnamon
1 teaspoon brown sugar
1 teaspoon granulated sugar

1. Trim pear to fit into spiralizer*. Preheat oven to 300º F. Prepare 2 baking

trays with parchment paper. Set aside. Combine cinnamon and sugars in a
small bowl. Set aside.

2. Prepare pear by spiralizing on ribbon setting. Break large pieces into single

layer rounds and place on prepared baking trays. Sprinkle pears evenly with
2 teaspoons of cinnamon sugar mixture. Turn pears over and sprinkle with
remaining cinnamon sugar.

3. Bake for 45 minutes, rotating pans halfway through baking. Remove from

oven and let pears cool so they become crunchy, at least 5 minutes.

*Note: To make fruit or vegetable chips, trim both ends of the fruit or vegetable,
making sure they are flat and even. Position tip of sharp knife over middle of
top of core and cut straight down (leaving ¼" from the bottom uncut) on one
side only. As food spiralizes, chips are pre-cut – there’s no long spiral that
needs to be cut into pieces.

Nutritional information per serving (10 chips):

Calories 56 (2% from fat) • carb. 14g • pro. 0g • fat 0g • sat. fat 0g

chol. 0mg • sod. 1mg • calc. 8mg • fiber 2g

12

REGISTER YOUR PRODUCT NOW!

Complete the two easy steps to register your product and receive

premium customer service, special offers and more!

Take a photo of your Photoregister Code below including the points

STEP 1

TAKE A PHOTO

13

SMARTPHONE US/CANADA

Text photo to 71403

EMAIL

WORLDWIDE

[e-mail]

ONLINE

WORLDWIDE

register.cuisinart.com

STEP 2

SEND IT IN

OR

OR

Need help? Visit Photoregister.com/help or text HELP to 71403.

W-9/026-ESP-C

14

¡REGISTRA TU PRODUCTO AHORA!

¡Completa dos pasos sencillos para registrar el proucto recibe

servicio de alta calidad, ofertas especiales y mucho más!

Saca una foto del código PhotoregisterSM debajo, incluyendo los puntos

PASO 1

SACA UNA FOTO

15

TELÉFONO MÓVIL EE. UU./CANADÁ

Envía la foto a 71403

CORREO ELECTRÓNICO

DESDE CUALQUIER PARTE DEL MUNDO

[e-mail]

EN LÍNEA

DESDE CUALQUIER PARTE DEL MUNDO

register.cuisinart.com

PASO 2

ENVÍALA

O

OR

¿Necesitas ayuda? Visita Photoregister.com/help o envía AYUDA a 71403.

W-9/026-ESP-C

©2017 Cuisinart

150 Milford Road, East Windsor, NJ 08520

Printed in China

17CT028218

Cuisinart offers an extensive assortment of top quality products to

make life in the kitchen easier than ever. Try some of our other

countertop appliances and cookware, and Savor the Good Life

®

.

www.cuisinart.com

IB-15006
