Cuisinart CSB-44 Instruction And Recipe Booklet

B

LENDER

CSB-44N

INSTRUCTION AND

RECIPE BOOKLET

4. Do not operate in the presence of explosive and/or flammable fumes.

5. To avoid possibility of personal injury, always detach the charger

handle from the motor body before attaching or removing
blades and/or attachments.

6. Unplug charger handle from outlet when not in use, before putting
on or taking off parts and before cleaning.

7. Avoid contacting moving parts. Keep hands, hair, clothing, as well
as spatulas and other utensils away from attachments and mixing
container during operation to reduce risk of injury to persons,
and/or damage to the appliance. A spatula may be used, but must
be used only when the unit is not operating.

8. Remove detachable shaft from the blender before washing the
blades or shaft.

9. Blades and accessory attachments are SHARP. Handle carefully.

10. When mixing liquids, use a tall container or make small quantities
at a time to reduce spillage and possibility of injury.

11. Charger handle should be plugged into an electrical outlet away

from sink or hot surfaces.

12. Do not use an extension cord. Plug charger handle directly into an

electrical outlet.

13. Do not attempt to use this charger handle with any other product.

Also, do not attempt to charge the batteries with any other charger.

14. Do not use appliance for other than intended use.

15. Do not charge batteries with handle charger plugged into an

outdoor outlet.

16. Do not operate any appliance with a damaged cord or plug, or

after the appliance has malfunctioned or has been dropped or
damaged in any way, or is not operating properly. Return the
appliance to the nearest Cuisinart Repair Center for examination,
repair, or mechanical or electrical adjustment.

17. The use of attachments or accessories not recommended by

Cuisinart may cause fire, electrical shock or risk of injury.

18. Make sure the appliance is "OFF" and the motor has stopped

completely before putting on or taking off attachments, and
before cleaning.

3

INTRODUCTION

Blending has never been easier! Now you can bring your blender to
the food, rather than taking your food to the blender.

The Cuisinart

®

Cordless Rechargeable Hand Blender may be the most
convenient stick blender you ever own. Built with the same expertise
that made the Cuisinart

®

Food Processor a legend, it delivers up to

15 continuous minutes of powerful blending, without a cord.

Consider the possibilities. Take it to the stovetop to purée a pot of
simmering split pea soup or to blend pasta sauce just before serving.
Bring it out on the patio to mix up a pitcher of margaritas. Take it
to an out-of-the-way corner of the kitchen to quickly whip up a dip.
Wherever it goes, you get the perfect blend. And this hand blender is
comfortable. The handle is contoured to fit like your favorite kitchen
utensil. The rubberized grip won’t slip, even when hands are wet.
And we put the power button right on top, within easy reach of
your thumb.

As with all Cuisinart products, the Cordless Rechargeable Hand
Blender is designed to be easy to use. Prongs slide out of the charger
handle and into any wall outlet to recharge the batteries. The charger
handle can be left in the outlet whenever the blender is not in use to
guarantee up to 15 minutes of run time whenever you need it. The
Cordless Rechargeable Hand Blender is engineered to let the batteries
remain on continuous charge and to draw very little power while
connected.

Cuisinart is famous for easy cleanups, too, and this hand blender is no
exception. The detachable shaft is dishwasher safe, and the handle
wipes clean in seconds.

Enjoy the perfect blend with Cuisinart, wherever life takes you!

3.Batteries with Long Run Time Recharge Easily:

Runs up to 15 minutes under normal use (depending on specific
uses) and regains over half of full power within 3 hours. Full
charge in 12 to 24 hours. Normal time required for a blending
task is 10 seconds to 2 minutes.

4.Maximum Comfort Handle:

The hand blender handle and power button are designed around
the way you actually hold a stirring utensil. The shape of this handle
gives you comfortable control and easy access to the power button.
Rubberized handle gives better grip, especially when your hands
are wet.

5.One Step ON/OFF
(Power) Button:

Press and hold the
rubberized power
button to operate
blender. Release
button to stop motor.

6.Plug-In Charger with Charging Light:

Plugs into wall outlet to recharge the batteries. Charging light
is on to let you know the outlet is in operation and batteries are
recharging. Light remains on when charging is completed.
Detach charger handle from motor body with release button,
slide wall plug out of housing, and plug directly into wall outlet.
No cords necessary.

7.Detachable Shaft:

Easy to use, easy to clean and easy to store. Detach from motor
body by pressing release button. Rinse under faucet or put in top
shelf of dishwasher to clean.

8.Long Running Time:

The Cordless Rechargeable Hand Blender runs for 10 to 15 minutes
during normal use with a full charge. Maximum usage time for
most applications is only 1 to 2 minutes!

5

BEFORE YOU BEGIN

Place the package containing the Cuisinart®Cordless Rechargeable
Hand Blender on a sturdy surface. Unpack the hand blender from
its box by removing the upper protective insert. Carefully remove
each piece from the box.

Note: The blending blade is extremely sharp. Use caution when
removing and unpacking the storage stand. The blending blade
is stored in the storage stand.

Remove all support materials from the box and replace the upper
insert. Save packaging for possible repacking of the unit.

Before using the Cuisinart

®

Cordless Rechargeable Hand Blender
for the first time, we recommend that you wipe the unit with a clean,
damp cloth to remove any dirt or dust. Dry it thoroughly with a soft,
absorbent cloth. Handle carefully. Wash the blending blade, whipping
disc, mixing beaker and detachable shaft by hand or in the dishwasher
(upper rack only). Dry thoroughly before use. Read all instructions
completely for detailed operating procedures.

The batteries in your
Cuisinart

®

Cordless
Rechargeable Hand Blender
have not been charged. Before
the first use of this appliance,
the batteries must be charged
for 24 hours! See Charging and
Battery Life on page 7.

ASSEMBLY

Note: To avoid possibility of
personal injury, always detach
the charger handle from the
motor body before attaching or
removing blades and/or attachments.

1. Attach blade or whipping disc

to blender shaft.

For your safety, always detach the shaft from the motor body.
To insert the blade or whipping disc, hold the stem of the
blade/disc between your fingers. Match the raised notches
on the shaft to the open slots on the stem.

OPERATION

Turning Cordless Rechargeable Hand Blender ON/OFF:

Keep hands, hair, clothing and other utensils away from blending blade.

Press and hold rubberized ON/OFF button on top of handle to turn
motor ON. The ON/OFF button is marked “PRESS”. The hand
blender will continue to run as long as the switch is pressed in. To turn
hand blender off, release ON/OFF button and the motor will stop.

Helpful Hints:

1. Cut most solid foods into 1/2" cubes for easy blending.

2. Pour liquid ingredients into the mixing container first, unless
recipe instructs otherwise.

3. To avoid splashing, do not pull the hand blender out of the
mixture while blender is running.

4. Do not let hand blender stand in a hot pot on stove while not
in use.

5. To prevent splashing, don't turn the hand blender ON until the
blade is beneath the surface of the mixture.

6. Do not put fruit pits, bones, or other hard material into the
blending mixture, as these are liable to damage the blade.

7. Do not fill mixing containers too full. The level of mixture will
rise when blending, and can overflow.

8. Adding liquids that are warm, not cold, facilitates blending solids
with liquids.

9. For recipes calling for ice, use crushed ice (not whole cubes) for
best results.

Press
release
button to
separate
or attach

Push
Thumb
Grip In

Thumb
Grip

7

Continuous Charging

The unit is designed so that the batteries may remain on continuous
charge. It is recommended that the Cuisinart

®

Cordless Rechargeable
Hand Blender charger be kept plugged into a wall socket to charge, so
that it will always be ready to use. Leaving the unit on continuous charge
is very inexpensive in terms of the amount of electricity
being used.

Holding the Charge

The batteries will keep their charge even when not plugged in. The
batteries will lose approximately 1% of their total charge per month,
if they are not plugged in and charging.

Short Run Times

If after repeated use the run time seems to get shorter and the hand
blender has less power, it may not be the result of a faulty unit.
This condition can be remedied by allowing the Cuisinart

®

Cordless
Rechargeable Hand Blender to run until it stops. Then recharge the unit
for 24 hours for a new charge. This procedure improves the batteries’
capacity. You may need to repeat this a few times for the best results.

Charging Light

The charging light on the tip of the handle glows when the unit is
charging. This light will be illuminated even when the batteries are
fully charged. If the unit does not function, make sure that the charger
handle is securely plugged into the outlet, and check to see if the
outlet is controlled by a wall switch. Also, check for a blown house
fuse. Note that if this light is on, the charger is operating.

Push
thumb
grip out

Thumb
Grip

®

Cordless

(B) WHIPPING DISC ATTACHMENT

The Whipping Attachment is specially designed to add air and
volume to mixtures. Perfect for aerating egg whites, cream and
mayonnaise, this attachment makes mixtures light, frothy and thick.

When using this attachment, make sure there is extra room in the
mixing container for the recipe to grow! For most recipes such as
mayonnaise, beaten egg whites and whipped cream, hold the end of the
hand blender in the bottom of the container and turn it on for about
15 seconds. Then continue to process, lifting the hand blender almost to
the top of the liquid until mixture is thick.

STORAGE STAND / WALL BRACKETS

The Cuisinart®Cordless Rechargeable Hand Blender
includes a two part storage stand that can be assembled
into a single piece for countertop use. You can also separate
the stand into two pieces, and mount one of the pieces to
your wall to use as a wall storage bracket.

Storage stand kit consists of six (6) pieces: two anchor
bolts, two plastic wall anchors, and two storage pieces that
can fit together for countertop, or be separated for wall
mount.

Countertop Option

The two storage pieces fit together. (See diagram below.)

Align the two pieces back to back on a flat surface, with the
ring-shaped reservoirs facing right and left. The raised walls should
be in the middle. Lift up the right piece; align the two tabs in the back

9

®

place. Mark the wall with a pencil in the locations indicated for screw
holes by the template. Remove the template.

With a drill, make a 3/16" starter hole for each screw. Place the plastic
anchor in each hole. Push completely into the hole with fingers, or
tap in gently with a hammer. Screw a mounting screw into each hole,
leaving 1/8" to 1/4" of the head and screw exposed.

Position the two mounting holes of the wall bracket over the screw
heads, and slide wall bracket down the wall until the bracket is resting
against the screw head, and will not slide any further. If the wall bracket
feels too loose against the wall, remove bracket, put screws further into
wall, and replace bracket.

Place the assembled hand blender into the wall bracket. The unit will
hang from the bracket, held in place by the motor body width.

The charger handle can be attached to the motor body when you store
the unit. This is especially helpful when you want the hand blender
close at hand during a heavy use period. At other times, you probably
will want to keep the charger handle plugged into the electrical
socket to assure the battery is always 100% charged.

RECIPE TABLE OF CONTENTS

BEVERAGES

Mochaccino Shake . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 11

Strawberry-Banana Breakfast Shake . . . . . . . . . . . . . . Page 11

Mangolada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 11

Frothy Café Au Lait . . . . . . . . . . . . . . . . . . . . . . . . . . Page 12

SAUCES/SOUPS/DRESSINGS

Basic Vinaigrette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 12

Blue Cheese Dip/Dressing . . . . . . . . . . . . . . . . . . . . . Page 12

Rustic Tomato Sauce . . . . . . . . . . . . . . . . . . . . . . . . . . Page 13

Yukon Bold Potato and Roasted Garlic Soup . . . . . . . Page 13

Provencal White Bean Soup . . . . . . . . . . . . . . . . . . . . Page 14

Fast and Fresh Applesauce . . . . . . . . . . . . . . . . . . . . . Page 14

DESSERTS

Sweetened Whipped Cream . . . . . . . . . . . . . . . . . . . . Page 15

ABOUT THE RECIPES

Nutritional analysis are based on number of servings indicated. If a
recipe produces a range of servings, analysis are based on the highest
serving yield for that particular recipe.

11

Place all ingredients in mixing beaker in order listed. Insert the hand
blender fitted with the metal blending blade. Turn the blender ON
and process using a gentle up-and-down motion until smooth, about
20 to 30 seconds. Remove the charger handle from the hand blender.
Serve immediately.

Nutritional information per serving:

Calories 156 (5% from fat) • carb. 34g • pro. 5g • fat 1g • sat. fat 0g •

chol. 1mg • sod. 34mg • calc. 115mg • fiber 3g

MANGOLADA

A twist on the traditional piña colada, combining mango with the
tropical flavors of pineapple, coconut and rum.

Makes 2 servings

3/4 cup chilled pineapple juice
1 cup mango cubes (1/2 - inch), chilled
1/4 cup unsweetened “lite” coconut milk
3 ounces rum

Place ingredients in mixing beaker in order listed. Place the hand
blender, fitted with the metal mixing blade, into the beaker. Turn the
blender ON and process using a gentle up-and-down motion until
smooth, about 20 to 30 seconds. Remove the charger handle from
the hand blender. Serve immediately over crushed ice.

Nutritional information per serving:

Calories 218 (7% from fat) • carb. 27g • pro. 1g • fat 2g •

sat. fat 1g • chol. 0mg • sod. 5mg • calc. 19mg • fiber 2g

Place all ingredients in the mixing container. Place hand blender,
fitted with the metal blending blade, into the beaker. Turn On and
blend using a gentle up-and-down motion until combined, about
10 to 15 seconds. Remove charger handle from hand blender. Keep
unused portions in an airtight container in the refrigerator up to
2 weeks.

Nutritional analysis per tablespoon:

Calories 91 (98% from fat) • carb. 0g • pro. 0g • fat 10g •

sat. fat 1g • chol. 0mg • sod. 23mg • calc. 0mg • fiber 0g

BLUE CHEESE DIP/DRESSING

Use as a dressing for crispy, chilled greens or as a dip for celery when
serving “Buffalo Wings.”

Makes about 1 cup

1/2 cup lowfat mayonnaise
1/3 cup fat free plain yogurt
1/2 cup crumbled blue cheese (about 2 ounces)
1 tablespoon dehydrated onion flakes
1 teaspoon cider vinegar
1/4 teaspoon kosher salt
1/4 teaspoon freshly ground black pepper

Place all ingredients in the mixing beaker. Place hand blender, fitted
with the metal blending blade, into the beaker. Turn ON and blend
using a gentle up-and-down motion until blended and creamy, about
20 to 30 seconds. Remove charger handle from hand blender. Cover
and chill for 30 minutes before serving to allow flavors to blend.

Nutritional information per tablespoon:

Calories 37 (78% from fat) • carb. 1g • pro. 1g • fat 3g •

sat. fat 1g • chol. 6mg • sod. 116mg • calc. 27mg • fiber 0g

13

YUKON GOLD POTATO AND

ROASTED GARLIC SOUP

Makes eight cups (8 servings)

1 ounce peeled garlic cloves (8 – 12 cloves)
2 teaspoons extra virgin olive oil
1/2 tablespoon unsalted butter
1 medium onion (5 ounces), peeled, cut in 1/2-inch pieces
1 carrot (2 ounces), peeled, cut in 1/2-inch pieces
1 rib celery (2 ounces), peeled, cut in 1/2-inch pieces
3-1/2 cups fat free, low-sodium chicken or vegetable stock
2 cups water
2 pounds Yukon gold potatoes*, peeled, cut in 1/2 -inch slices
1 teaspoon herbs de Provence
1/2 cup evaporated fat free milk or half-and-half
1 teaspoon kosher salt
1/2 teaspoon ground white pepper

Preheat oven to 375°F. Place cloves of garlic in the center of a
12-inch square of foil, drizzle with 1 teaspoon of the olive oil and
toss to coat. Wrap the foil around the garlic and fold or crimp to
seal. Roast until garlic is tender, about 1 hour. Cool slightly before
using. (Garlic may be done ahead, and will keep in a resealable
container for 5 days in the refrigerator.)

While the garlic is roasting, heat remaining olive oil with butter in
a Cuisinart

®

3-3/4 quart Saucepan over medium heat. Add the onion,
carrot, and celery. Reduce heat to low, cover loosely and cook until
vegetables are tender but not browned, 8 to 10 minutes. Stir in the
stock, water, potatoes, herbs de Provence, and roasted garlic. Raise
heat and bring to a boil. Reduce heat to medium low and simmer,
loosely covered, until potatoes are tender, about 20 minutes. Turn
off heat and let sit for 2 to 3 minutes.

Insert the hand blender and process using a gentle up-and-down
motion, moving the blender slowly throughout the saucepan until
well combined, smooth, and without any visible pieces of vegetables
remaining, about 1 to 2 minutes. Add half-and half, salt and pepper.

using a gentle up-and-down motion, blend until smooth and creamy,
about 1 to 1-1/2 minutes. Remove charger handle from hand blender.
Season with salt and pepper.

Serve the soup hot. Soup may be garnished with a sprinkling of
chopped fresh parsley and diced cooked bacon or ham.

Nutritional analysis per serving (without garnish):

Calories 182 (9% from fat) • carb 30g • pro. 12g • fat 2g •

sat. fat 0g • chol. 0mg • sod. 221mg • calc. 111mg • fiber 7g

FAST & FRESH APPLESAUCE

One pan, no fuss applesauce – make it as you like it, chunky or smooth.

Makes 3 cups

2 pounds apples (your favorite, Red Delicious not

recommended), peeled, cored and cut into eighths
1/4 cup water
1 tablespoon fresh lemon juice

Combine all ingredients in a Cuisinart

®

2-quart Saucepan. Bring to a
boil over high heat, then reduce heat to low, cover and simmer until
apples are fork tender, 12 to 15 minutes. Remove from heat and let
sit 5 minutes, still covered. Uncover and insert hand blender fitted
with the metal blending blade. Process using a gentle up-and down
motion until desired consistency is reached, using less time for a
chunkier sauce, about 20 to 60 seconds. Remove the charger handle
from the hand blender. Serve applesauce warm or chilled. Keeps
covered and refrigerated for 3 days.

Nutritional analysis per serving (1/2 cup):

Calories 81 (5% from fat) • carb. 21g • pro. 0g • fat 1g •

sat. fat 0g • chol. 0mg • sod 2mg • calc. 8mg • fiber 4g

Variations: Cinnamon Applesauce: add a cinnamon stick when
cooking the apples. Remove before processing.

Cranberry Applesauce: Substitute cranberry or cranapple juice for
the water and add 1/3 to 1/2 cup dried cranberries to the apples
before cooking.

15

We suggest you complete and return the enclosed warranty registration
card promptly. However, return of the card is not a condition of this
warranty and does not eliminate the need for the consumer to maintain
the original receipt of purchase.

If your unit should prove to be defective within the warranty period,
we will repair or replace it at our option without charge to you.
To obtain warranty service, simply send the defective product to:
Cuisinart, 150 Milford Road, E. Windsor, NJ 08520 or call
toll-free 800-726-0190.

To facilitate the speed and accuracy of your return, please also enclose
$7.00 for shipping and handling of the product. CA residents need
only provide proof of purchase. Please be sure to include a return
address, daytime phone number, description of the product defect,
product serial number and any other information pertinent to the
product's return. Please pay by check or money order.

Your Cuisinart

®

Cordless Rechargeable Hand Blender has been
manufactured to the strictest specifications and has been designed for
use with authorized Cuisinart

®

accessories and replacement parts.
This warranty expressly excludes any defects or damages caused by
accessories, replacement parts or repair service other than those which
have been authorized by Cuisinart. This limited warranty does not
cover any damage caused by accident, misuse, shipment or other than
ordinary household use.

THIS WARRANTY EXCLUDES ALL INCIDENTAL OR
CONSEQUENTIAL DAMAGES. SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF THESE
DAMAGES, SO THESE EXCLUSIONS MAY NOT APPLY TO
YOU. ALL APPLICABLE IMPLIED WARRANTIES, INCLUD­ING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, GIVEN TO
YOU BY LAW ARE HEREBY LIMITED IN DURATION TO
THIS WARRANTY.

This warranty gives you specific legal rights, and you may have other
rights which vary from state to state.

If you have any questions about the safety features of your Cuisinart

®

Cordless Rechargeable Hand Blender, please call us, toll-free,
at 1-800-726-0190.

© 2003 Cuisinart

Cuisinart

®

is a registered trademark of

Cuisinart

150 Milford Road

East Windsor, NJ 08520

Printed in China

02CU13103

IB-4130
