INSTRUCTION AND RECIPE BOOKLET
Combo Juice Extractor / Citrus Juicer
For your safety and continued enjoyment of this product, always read the instruction book carefully before using.
CJE-2000 Series
IMPORTANT
SAFEGUARDS
When using any electrical appliance, basic safety
precautions should always be followed, including
the following:
1. Read instructions thoroughly.
2. Turn the appliance OFF (O), then unplug
from the outlet when not in use, before
assembling or disassembling parts and
before cleaning. To unplug, grasp the plug
and pull from the outlet. Never pull the
power cord.
3. To protect against electrical shock, do not
immerse the juice Extractor / Citrus juicer
motor housing in water or other liquids.
4. This appliance is not intended for use by
children or by persons with reduced physical,
sensory, or mental capabilities, or lack of
experience and knowledge. Close
supervision is necessary when any appliance
is used near children. Children should be
supervised to ensure that they do not play
with the appliance.
5. Avoid contact with moving parts.
6. Do not operate any appliance with a
damaged cord or plug or after the appliance
malfunctions, or is dropped or damaged in
any manner. Contact our Customer Service
Center to return for examination, repair or
electrical or mechanical adjustment.
7. Using accessory attachments not sold or
recommended by the manufacturer can
cause fire, electric shock or injury.
8. Do not allow the power cord to come into
contact with any hot surfaces, including
stove, or to hang over table edge or counter.
9. Switch to OFF (O) position after each use
and be sure the motor stops completely
before disassembling.
10. Do not put fingers or other objects into the
juice extractor feed tube or on the citrus
reamer while they are in operation. If food
becomes stuck in the opening of the feed
tube, use the food pusher or a piece of fruit
or vegetable to push it down or turn the
motor off and disassemble the unit to remove
the trapped food.
11. If the mesh filter-basket/blade is damaged,
do not use.
Always make sure the juice extractor and
12.
citrus juicer attachment is properly positioned
and secured before motor is turned on. If it is
not, the safety interlock will not operate.
Do not loosen attachments while the juice
Extractor / Citrus juicer is in use.
13. Not designed for outdoor use.
14. Appliance should be plugged into a 120V
household outlet only.
15. The appliance is wired for domestic use only.
16. Do not use the appliance for anything other
than the intended purpose, as outlined in the
instruction booklet.
17. Never juice with the spout in the closed
position.
18. This unit comes with a resettable thermal
device to prevent damage to the motor in the
case of extreme overload. Simply unplug the
unit, rest it for 30 minutes and continue.
19. Do not operate without the juice pitcher in
place.
20. Do not operate your appliance in an
appliance garage or under a wall cabinet.
When storing in an appliance garage
always unplug the unit from the electrical
outlet. Not doing so could create a risk of
fire, especially if the appliance touches the
walls of the garage or the door touches the
unit as it closes.
SAVE THESE
INSTRUCTIONS
HOUSEHOLD USE
ONLY
No user-serviceable parts are inside. Do not
attempt to service this product.
Maximum rating is 220 watts.
A short power supply cord is provided to
reduce the risk of entanglement or tripping.
AN EXTENSION CORD WITH A MARKED
ELECTRICAL RATING AT LEAST AS GREAT
AS THE ELECTRICAL RATING OF THE JUICER
MAY BE USED WITH CARE.
The extension cord should not be allowed to
drape over the countertop or tabletop, where it
can be pulled on by children or tripped over.
2
POLARIZED PLUG
This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of electric
shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully
into the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not attempt
to modify the plug in any way. If the plug fits
loosely into the AC outlet or if the AC outlet feels
warm, do not use that outlet.
CONTENTS
Important Safeguards.................. 2
Parts and Features.................... 3
Before First Use ...................... 4
Assembly Instructions ................. 4
Disassembly Instructions ............... 5
Operating Instructions ................. 5
Cleaning and Maintenance . . . . . . . . . . . . . 6
Tips and Hints ....................... 6
Approximate Yield Juicing Chart . . . . . . . . . 8
Troubleshooting ......................9
Warranty ........................... 11
Recipes............................ 12
PARTS AND FEATURES
Items in pictures may be slightly different than
those in the final product.
1. Main Housing
2. Food Pusher
3. Juice Extractor Cover with Feed Tube
4. Micro-Mesh Juice Filter Basket and Cutting
Disc
5. Filter Housing/Juice Container
Adjustable Citrus Juicing Basket and Reamer
6.
7. Juice Pitcher
8. High/Low/Off Rocker Switch
II = high speed
I = low speed
O = off
9. Nonslip Rubber Feet (not shown)
10. Cleaning Brush
11. BPA Free
All materials that come in contact with food
and / or liquid are BPA free.
2
3
4
7
6
10
5
1
8
3
BEFORE FIRST USE
• Remove all packaging materials and any
promotional labels or stickers from your
Cuisinart
Juicer. Be sure all parts (listed in Parts and
Features) of your new appliance have been
included before discarding any packaging
materials.
• You may wish to save the box and packing
materials for use at a later date.
• Before using your Cuisinart
Extractor / Citrus Juicer for the first time,
®
Combo Juice Extractor / Citrus
®
Combo Juice
• Thoroughly clean juice extractor cover, food
pusher, juice pitcher, micro-mesh juice filter
basket assembly, filter housing/juice container,
and citrus juicing basket and reamer by hand
or on top rack of dishwasher.
• Never place the motor housing in the
dishwasher, nor immerse it in water. Always
use a damp cloth to wipe it clean.
• Make sure rubber feet are gripping the counter
before using your Cuisinart
Extractor / Citrus Juicer to avoid the unit from
falling off the counter.
remove any dust from shipping by wiping the
base with a damp cloth.
ASSEMBLY INSTRUCTIONS
Assembling the Juice Extractor
To use the Juice Extractor and Citrus Juicer
attachments, begin by setting the motor base on
a clean, flat surface. Make sure the motor base is
unplugged from the power outlet (not shown).
1. Place filter housing on top of motor base. Once
done, turn housing clockwise until it locks into
place.
2. Insert the micro-mesh filter with cutting disc
into the filter housing, pressing firmly down on
rim of the filter basket so it locks securely in
place.
Be careful not to touch the blades on the bot-
tom of the filter basket and be sure this part is
inserted before every use.
3. Place the pulp sealing ring on top of micromesh filter basket.
4. Place the juice extractor cover on top of filter
housing and twist into place, making sure to
align locking marks.
5. Place juice pitcher in the front center of
the unit.
6. Insert the food pusher into the feed tube.
7. Make sure the flow spout is in the open
position. Never juice with the spout in the
closed position.
®
Combo Juice
4
Assembling the Citrus Juicer
1. Place the filter housing on top of the motor
base. Place the citrus juicing basket and
reamer on the spindle in the filter housing.
2. Place juice pitcher in the front center of the
unit. Make sure the flow spout is in the open
position. Never juice with the spout in the
closed position.
3. Plug in power cord. Your citrus juicer is now
ready to be used.
DISASSEMBLY
INSTRUCTIONS
Disassembling the Juice Extractor
1. Unplug the Combo Juice Extractor / Citrus
Juicer
2. Remove the food pusher from cover.
3. Lift and remove cover from filter housing.
4. Carefully remove the micro-mesh filter
basket from filter housing by pulling up
on the sides of the rim. Be careful not to
touch the blades in the bottom of the
basket. DO NOT touch the metal shaft in
the center of the micro-mash filter basket
as it may be hot after using.
5. Make sure the flow spout is in the closed
position. Remove the juice pitcher.
Disassembling the Citrus Juicer
1. Unplug the Combo Juice Extractor / Citrus
Juicer
2. Rotate the Citrus Juicing Basket and Reamer
assembly counterclockwise until it releases.
3. Remove the reamer from the basket by
placing one hand on the basket and the other
on the reamer and gently pulling to apart.
OPERATING INSTRUCTIONS
1. Make sure your Combo Juice Extractor /
Juicer is properly assembled. (See
Citrus
Assembly Instructions, pages 4 and 5.)
2. Plug the power cord into a 120V electrical
outlet.
3. Make sure that the spout is in the open
position. NEVER JUICE WITH THE SPOUT
IN THE CLOSED POSITION.
4. Wash all selected fruits or vegetables.
Operating the Juice Extractor
1. Select high speed (II) when using the juice
extractor.
2. Lift the food pusher out of the feed tube and
put your food into the opening. Push through
by inserting the food pusher and pressing
firmly.
3. Juice will begin to flow into the juice pitcher.
4. When juice is fully extracted, move the switch
into the Off position.
5. Lift the spout to the closed position before
removing the juice pitcher to prevent juice
from dripping on the counter.
Operating the Citrus Juicer
1. Select low, medium, or high pulp setting on
the Citrus Juicing Basket and Reamer
assembly by rotating the reamer according
to the arrows.
Low speed (I) is the recommended speed for
best results.
2. Slice fruit horizontally.
3. Place center of citrus fruit on the center
of the juicing reamer.
5
4. Place your palm over the fruit and press it
firmly against the reamer using steady
pressure.
5. Once you feel the ribs of the reamer through
the citrus rind, remove it from reamer and
begin juicing the next piece of fruit.
6. After approximately 1 lb. of fruit has been
juiced, the juicing basket will appear to
be full.
7. Place drip spout in the closed position and
remove the juice pitcher.
8. Turn the juicing basket all the way to the left
to release and remove it.
9. Separate the reamer and the juicing basket
by pulling gently with one hand.
CLEANING AND
MAINTENANCE
Do not immerse the motor housing in water or
spray it with water. Clean only by wiping with
a damp sponge, cloth or paper towel. Use any
liquid dishwashing detergent, but do not use
any products containing ammonia or scouring
powders, as these products will dull, scratch or
mar the finish.
For easy cleanup, use the cleaning brush to
remove excess pulp from the micro-mesh juice
filter basket and citrus juicing basket after each
use. Vegetable and fruit residue will harden if left
to dry on the unit parts, making them more difficult to clean. One side of the provided cleaning
brush is designed to scrape the pulp out of the
filter basket and the other side is used to brush
the basket clean.
1. Unplug juicer and carefully take it apart, following Disassembly Instructions on page 5.
WARNING: Be careful when handling the
mesh filter basket/blade, as blades are
very sharp.
2. Rinse all removable parts with cold water.
3. Wash the juice extractor cover, food pusher,
juice pitcher, micro-mesh juice filter basket
assembly, filter housing/juice container, and
citrus juicing basket and reamer in hot, sudsy
water on top rack of dishwasher.
NOTE: For best juicing results, the mesh
filter basket must always be thoroughly
cleaned after each use.
4. Towel dry all parts.
5. Any other servicing should be performed by
an authorized service representative.
TIPS AND HINTS
Juice Extractor
•
Extracted juice captures about 95% of the
nutrients from fresh fruits and vegetables.
Drinking extracted juice is a fast and efficient way
for your body to digest and absorb all of those
nutrients. Digesting whole fruits can take about
an hour; extracted juices take only 15 minutes.
• Freshly extracted juices are an excellent aid
in weight management and in cleanses, which
rid the body of toxins.
• Always use fresh, organic and seasonal pro-
duce. Organic produce is grown without synthetic fertilizers and chemicals, which is very
important when juicing whole foods. Buying
foods in season is considerably less expensive than purchasing off-season, and flavors
are much better.
• Wash all fruits and vegetables immediately
after purchasing and store them in the refrigerator.
This way they are ready to juice at any time.
• Always juice fresh fruits and vegetables as
soon as possible after purchasing. The longer
produce is held, the more nutrients it loses.
• Fresh juices should be consumed immediately.
They lose nutrients as they sit.
•
Certain fruits should be peeled before juice
extracting. Examples are pineapples, melons,
mangoes, papayas, citrus – any fruit with skin
that you cannot eat. Also remove all pits and
hard seeds from peaches, cherries, mangoes,
etc.
•
If cucumbers are waxy, peel them before juicing.
• Juice the softer ingredients before the
harder ones.
•
When juicing herbs or leafy greens, juice them
in the middle of a combination of ingredients in
order to extract the greatest amount of juice.
6
6
Loading...
