Outdoor Grilling Pro ducts
MODEL: CGG-220
Everyday Portable LP Gas Grill
ASSEMBLY AND OPERATING INSTRUCTIONS
m WARNING: FOR OUTDOOR USE ONLY
m This instruction manual contains important information necessary for the
proper assembly and safe use of the appliance
m Read and follow all warnings and instructions before
assembling and using the appliance
m Follow all warnings and instructions when using the appliance
m Keep this manual for future reference
Note to installer: Leave this Owner’s Manual with the consumer after delivery and/or installation.
Note to customer: Leave this Owner’s Manual in a convenient place for future reference.
m DANGER
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
m DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your fire
department.
Failure to follow these instructions could
result in fire, explosion or burn hazard,
which could cause property damage,
personal injury or death.
m DANGER
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3.05m) of any other gas cylinder.
3. Never operate this appliance with 25 feet (7.5m) of any flammable liquid.
4. lf a fire should occur, keep away from the appliance and immediately call your fire
department . Do not attempt to extinguish an oil or grease fire with water.
5. Heated liquids remain at scalding temperatures long after the cooking process.
Never touch cooking appliance until liquids have cooled to 115oF (45oC) or less.
Failure to follow these instructions could result in fire, explosion or burn hazard,
which could cause property damage, personal injury or death.
1
1. Warnings and Safety Instructions y Instructions
If these instructions are ignored, there is a possibility of a hazardous fire or explosion which
could result in physical injury or property damage! It is your responsibility to assemble,
operate and maintain your gas grill properly.
READ ALL WARNINGS AND INSTRUCTIONS PRIOR TO ASSEMBLING AND
OPERATING YOUR GRILL
WARNINGS:
m This grill is for outdoor use only. It should NOT be used in a building, garage or any other
enclosed area.
m The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability
to properly assemble or safely operate this appliance.
m Do not leave the grill unattended. Keep children and pets away from the grill all the times.
m Do not use the grill in high wind.
m This grill must be used with propane gas only. Liquid propane is not natural gas. The
conversion or attempted use of natural gas in a liquid propane grill is dangerous and will void
your warranty.
m Do not attempt to attach this grill to the self-contained propane system of a camper, trailer,
motor home or house.
m Do not use charcoal or lighter uid.
m Do not use gasoline, kerosene or alcohol for lighting .The LP-gas cylinder must be con-
structed and marked in accordance with the specications for propane gas cylinder of the
U.S. Department of Transportation (DOT).
m Do not attempt to move the grill when in use.
m Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened
and tightened .if there are any missing or damaged parts, contact customer service for a
replacement.
m Do not alter the grill in any manner.
m Do not operate the grill if there is gas leak present.
m The use and installation of this product must conform to local codes. In the absence of
local codes, use the National Fuel Gas Code: ANSI Z223.1/NFPA54, Storage and Handling
of Liqueed Petroleum Gases, ANSI.NFPA 58 or Natural Gas and Propane Installation Code,
CSA B149.1; Propane Storage and Handling, CSA B149.2.
m This appliance is not intended to be installed in or on a boat or recreational vehicle.
m Locate the grill away from any combustible or non-combustible materials or construction by
at least 24 inches (61cm) from the back and sides.
m The appliance shall not be located usdunder overhead unprotected combustible construction.
m When cooking with oil or grease, have a type BC or ABC re extinguisher readily available.In
the event of an oil or grease re do not attempt to extinguish with water. Immediatelycall the re
department. A Type BC or ABC re extinguisher may, in some circumstancescontain the re.
m The appliance shall not be located used under overhead unprotected combustible construction.
m This appliance is not intended for and should never be used as a heater.
m This appliance will be hot during and after use. Use insulated oven mitts or gloves for
protection from hot surfaces or splatter from cooking liquids.
m This appliance is not intended for commercial use.
m The pressure regulator supplied with the Cuisinart Gas Grill must be used.
Table of Contents
1. Warnings and Safety Instructions 3
2. Illustrated Parts List 4
3. Exploded View 5
4. Assembly Instructions 6
5. Operating Your Grill
5.1 Choosing a location for installation 7
5.2 Special Instructions for Use of Regulator and Cylinder 8
5.3 Installing the LP gas cylinder 8
5.4 Checking for Leaks 9
5.5 Lighting Instructions 9
5.6 Match lighting 10
5.7 Using the Grill 10
6. Care and Maintenance 10
7. Frequently Asked Questions 11
8. Troubleshooting 11
9. Warranty Program and Replacement Parts 12
2
3
1. Lid & Firebox 1 pc
2. Grill Leg Assembly 1 pc
3. Cooking Grate 1 pc
4. Flame Tamer 1 pc
5. Drip Tray 1 pc
6. Side Table Assembly 2 pcs
Hardware List
A. Wing Nut Screw 2pcs
B. Wing Nut 2 pcs
C. Black Washer 6 pcs
D. White Washer with Adhesive Tape 2 pcs
2. Illustrated Parts List 3. Exploded View
4 5
1
Decoration Panel Assembly
10
Carry Handle Assembly
19
Electrode
2
Thermometer
11
Left Front Support Bracket
20
Tube Burner Assembly
3
Thermometer Bezel
12
Drip Pan Assembly
21
Cooking Grid
4
Logo
13
Leg Assembly
22
Flame Tamer
5
Lid
14
Rubber Foot
23
Gas Valve Assembly
6
Lid Handle
15
Upper Part Lid Hinge
24
Gas Valve Support
7
Side Table (2)
16
Lower Part Lid Hinge
25
Control Panel
8
Table Support Bracket
17
Lid Axle
26
Knob
9
Rear Support Bracket
18
Firebox Assembly
