Cuckoo CRP-M10 Fuzzy Series Operating Instructions Manual

CRP-M10 Fuzzy Series
1.8L(2~10 Persons) / 1.8L(2~10 )
Operating Instructions
NO.1 CUCKOO
Electric Pressure Rice cooker/warmer
Read the following instruction manual before use. Save this instruction manual for future reference. This manual will be useful if you have any questions or have problems operating the rice cooker.
Important safeguards
3 4
34~37
38
39~41
42 42
43 43
44
45 46~47 48~50 51~52
53 54~55 56~58
59
59
60~62
72~81
Important safeguards 3 Specifications
4
Safety precautions
5~8
Name of each part
9
How to clean
10~12
Function operating part
13
How to set current time 14 How to set or cancel voice guide function
14
Before cooking rice
15
For the best taste of rice
16
How to cook
17~18
MY MODE (Cuckoo Customized Taste Function)
19~21
How to use
GABA (Brown rice) 21~22
How to cook the MULTI-COOK and NU RUNG JI
24
How to preset timer for cooking
25~26
To keep cooked rice warm and tasty
27~29
How to set lock buttons
30
Night voice volume reduction function
30
Check before asking for service 31~33
Cooking Guide 63~71
CONTENTS
1. Read all instructions before using this appliance.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and / or injury to persons do not immerse cord, plugs, or Pressure Cooker Body in water or any other liquid.
4. Close supervision is necessary when this appliance is used by or near children. This appliance is not intended for use by young children without supervision.
5. Unplug cord from outlet when not in use and before cleaning. Allow appliance to cool before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions, or has been damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock, and / or injury to persons.
8. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or your service agent.
9. Do not use outdoors.
10. Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
11. Do not place on or near a hot gas, electric burner, or in a heated oven.
12. Always attach the plug to the appliance first, then plug the cord into the wall outlet. To disconnect, or
set all control to off , then remove the plug from the wall outlet.
13. Do not use this appliance for other than its intended use.
14. Extreme caution must be used when moving an appliance containing hot oil or any hot liquids.
15. Oversized foods, metal foil packages, or utensils must not be inserted into the appliance as they are a
risk of fire or electric shock.
16. Fire may occur if the appliance is covered or touching flammable material, including curtains, draperies,
walls, etc while in operation.
17. To reduce the risk of electric shock, cook only in the provided removable container.
18. This appliance cooks under pressure. Improper use may result in scalding injury.
Before operating the unit, properly secure and close the unit. See “Operating Instructions.”
19. Do not cook foods such as applesauce, cranberries, cereals, macaroni, spaghetti, or other foods.
These foods tend to foam, froth, and sputter, and may block the pressure releasing device
20. Before use always check the pressure releasing device for clogging.
21. Do not open the pressure cooker until the unit has cooled and internal pressure has been reduced.
See “Operating Instructions.”
22. Do not use this pressure cooker to fry in oil.
WARNING :This appliance generates heat and releases steam during use. Use proper precaution to
prevent risk of burns, fires, other injuries, or damage to property.
1. Keep hands and face away from the Pressure Release Valve when releasing pressure.
2. Take extreme caution when opening the Lid after cooking. Severe burns can result from steam inside.
3. Never open the Lid while the unit is in operation.
4. Do not use without the inner Pot in place.
5. Do not cover the Pressure Valve with anything as an explosion may occur.
6. Do not touch the inner pot nor any heating parts, immediately after use. Allow the unit to cool down completely first.
This appliance is intended to be used in household and similar applications such as :
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
ADDITIONAL IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS
Note:
A. A short power-supply cord (or cord set) is provided to reduce the hazards from entanglement by a longer cord. B. Extension cord should be used properly. C. Extension cord usage for the rice cooker:
(1) The correct rated voltage should be used for the rice cooker. (2) If the appliance is set on the ground, the extension cord should also be set on the ground. (3) The cord wires and extension cord should always be arranged to prevent hazards to children.
This appliance has a polarized plug : (one blade is wider than the other). As a safety feature, this plug will fit in a polarized outlet only one way. If the plug does not properly fit in the outlet, turn the plug over. If it still does not fit, contact a qualified electrician. Please, keep this safety feature.
CRP-M10 Fuzzy Series
AC220~240V, 50Hz
1150W
0.36~1.8L (2~10cups)
0.36~1.44L (2~8cups)
0.36~1.08L (2~6cups)
0.36~0.72L (2~4cups)
0.18~0.36L (1~2cups)
1.0m
78.4KPa(0.8kgf/
cm
2
)
6.9kg
29.4
cm
29cm
HOW TO USE EXTENSION CORD
SPECIFICATIONS /
SAFETY PRECAUTIONS
www.cuckoo.co.kr
Use a single socket with the rated current above 15A.
Using several lines in one socket can cause overheating or fire. Please check the power cord and plug frequently. Use an extension cord with the rated current above 15A.
Do not alter, reassemble, disassemble or repair.
It can cause fire, electric shock or injury. For repair, contact dealer or the service center.
Do not use the cooker near hot things such as stove, gas stove or direct ray of light.
It can cause an electric shock, fire, deformation, malfunction, or discoloration. Please check the power cord and plug frequectly.
Do not cover the automatic steam outlet or pressure weight with your hand or face.
It can cause burns. Especially be careful to keep it out of children’s reach.
Please pay careful attention against water and chemicals
It can cause an electric shock or fire.
Do not use damaged power cord, plug, or loose socket.
Please check the power cord frequently for damage. Serious damage can cause electric shock or fire. If the plug is damaged, contact the dealer or a service center.
Do not use a rice cooker at a place where dust is trapped or chemical material is located.
Do not use any combustible gas or flammable materials nearby a product. It can cause explosion or fire.
Do not clean the product with water or pour water in the product.
It can cause an electric shock or fire. If it contacts water, please separate power cord and contact dealer and service center.
This sign is intended to remind and alert that something may cause problems under the certain situation. Please read and follow the instruction to avoid any harmful situation. Indicates a prohibition
This means that the action it describes may result in death or severe injury.
This means that the action it describes may result in injury or property damage.
Indicates an instruction
Read the following product safety guide carefully to prevent any accidents and/or serious danger. ‘Warning’ and ‘Caution’ are different as follows.
Warning
Caution
Warning Do not
SAFETY PRECAUTIONS
Do not insert metal objects such as pins and wires or any other external substances in the automatic steam exhaust outlet or any other slot.
It can cause an electric shock or fire. Especially be careful to keep it out of reach of children.
Be careful that both the plug and power cord are not to be shocked by animal attack or sharp metal materials.
Damages by impact can cause an electric shock or fire. Please check the power cord and plug frequently.
When separated it, the steam control vent can be damaged.
Do not use pots that are not designed for the cooker. Do not use abnormal pot and do not use without the inner pot.
It can cause an electric shock or fire.
<Inner pot>
Do not cover the automatic steam outlet or pressure weight with a duster, a towel, or apron, etc.
It can cause deformation or a breakdown. It can cause an explosion by pressure.
Don’t spray or put any insecticides or chemicals.
It can cause an electric shock or fire. If cockroaches or any insects get inside the cooker, please call a dealer or a service center.
Don’t let foreign substances such as needle, cleaning pin, or metal get in or block the in let/out let pipe or gape.
Do not turn the Lock/Unlock Handle to
“Unlock” while cooking.
The hot steam or any hot content within the cooker can cause burns. After you finish the cooking do not try to open the cooker by force until the steam is completely exhausted.
It can cause an electric shock or fire. Do not put a cleaning pin in a gap or a hole of the product except when dearing a steam outlet.
Keep the cooker out of reach of children.
It can cause burns, electric shock or injury.
Do not use it without the inner pot.
It can cause electric shock or malfunction. Do not pour rice or water without the inner pot. If rice or water gets in then do not turn the product over or shake it, please contact the dealer or service center.
Remove a foreign substance on the cord and plug with a clean cloth.
It can cause fire. Please check the power cord and plug frequently.
Do not over unplug and plug the power cord over and over.
It can cause an electric shock or fire.
Metal
objects
Steam
plate
It can cause an electric shock or short circuit resulting in fire. Please check the power cord and plug frequently.
Do not bend, tie, or pull the power cord by force.
Do not open the top cover while in heating and cooking.
It can cause burns. If you need to open the lid while cooking, keep pressing the cancel button for 2 seconds and confirm internal steam released completely turning the pressure weight over.
Do not pull out the clean steam vent by force.
If you have any problem with assembly and cleaning of the clean steam vent, please call a dealer or service center. Keep clean the product before and after use.
Please make sure you clean and check the assembly condition of the clean steam vent before and after use.
Warning Do not
SAFETY PRECAUTIONS
www.cuckoo.co.kr
Use product on a flat surface. Do not use on a cushion. Please avoid using it on an unstable location prone to falling down.
It can cause malfunction or a fire. Please check the power cord and plug frequently.
Don’t use the cooker near a magnetic field.
Do not use it on a rice chest or a shelf.
Do not press heavy things on the power cord.
Do not place the power cord between furniture. It can cause an electric shock resulting in fire. Please check the power cord and plug frequently. When using on furniture be cautious of steam release As it can cause damage, fire and and/or electric shock.
It can cause an electric shock or fire. Please check the power cord and plug frequently
Do not change, extend or connect the power cord without the advice of a technical expert
It can cause an electric shock or fire.
It can cause burns or breakdown.
Please pull out the plug when not in use.
It can cause electric shocks or fire.
First pull out the power cord. And contact dealer or the service center.
It can cause overflow or breakdown. Do not cook over stated capacity for cooking of chicken soup and congee.
It can cause burns. Remaining hot steam can cause burns when you tilt the pressure weight while and right after the cooking.
Please contact a dealer or service center when there is a strange smell or smoke.
Do not use over the maximum capacity.
Do not touch the metallic surface of the inner pot and pressure weight after cooking or warming.
Please surely pull out the plug when not in use.
It can cause electric shocks or fire. Use AC 220~240V only.
Don’t use for various purpose for inner pot. And do not heat up the inner pot on the gas stove.
It can cause deformation of the inner pot. It can cause to spill the inner coating.
Do not plug or pull out the power cord with wet hands.
It can cause an electric shock.
Clean any dust or external substances off the temperature sensor and inner pot.
It can cause a system malfunction or fire.
Do not drop or impact the cooker.
It can cause a safety problem.
Please use the cooker for it’ s intended purpose.
It can cause malfunction or smell.
Do not move the product by pulling or using the power cord.
Electric short might cause fire.
Warning Remember
Caution Do not
SAFETY PRECAUTIONS
Please contact dealer or service center when either a button of a product or a product itself is not working properly.
In case of a blackout during cooking, steam from a rice cooker will be released automatically. Thus, the quality of rice is lower than normal.
If possible, only use warming function when cooking white rice. Other foods are easily discolored.
Do not place on rough top or tilted top.
It can cause burns or breakdowns. Be careful to install the power cord to pass without disruption.
Do not hold the cooker by the inner pot handle.
It can cause problems and danger. There are portable handles on the bottom right and left side of the cooker. Hold the handles with both hands and move it carefully.
After you finish cooking, do not try to open the cooker by force until the steam is completely exhausted.
The hot steam or any hot content within the cooker can cause burns.
Cautiously open the top cover after cooking is done to avoid dangerous steam and burns.
Please call customer service if the inner pot coating peels off.
Oven coating may wear away after long use. When cleaning the inner pot, do not use tough scrubber, metallic scrubber, brush, abrasive metallic etc.
Always turn the Lock/Unlock Handle to "Lock" when not in use.
It can cause deformation by remaining pressure.
Wipe off any excessive water on the cooker after cooking.
It can cause odor and discoloration. Wipe off water that is left behind from dew.
Please clean the body and other parts after cooking.
After cooking chicken soup, multi cook dishes, and etc., the smell may be absorbed. Clean the oven packing, top heater plate, and inner pot every time you cook any of those. It can cause alteration or smell. Use dry kitchen cleaner or sponge to clean the inner pot, since rough scrub or metallic ones are abrasive to the coating. Depending on the using methods or user's circumstances inner pot coating might rise. Please call the customer service for those cases. Please, do not pull out the clean steam vent by force.
When you pull out the power plug, don’t pull the power cord. Please, safely pull out the power plug.
If you inflict impact on power cord, it can cause an electric shock or fire.
Be cautious when steam is being released.
When the steam is released don’t be surprised. Please keep the cooker out of reach of children
Caution Do not
Caution Remember
Please start cooking with an indicated amount of rice and water. Water can overflow if the amount of water in a pot exceeds the indicated level of water usage. Please start cooking in a status that steam control cap is installed completely.
Tough crubber
Abrasive
Material Brush
Metallic crubber
NAME OF EACH PART
www.cuckoo.co.kr
Name of each part
Name of each part
Automatic Steam Exhaust Outlet (Solenoid valve)
When finished cooking or during warming, steam is automatically released.
Pressure Weight
Always keep the pressure weight horizontal. It stabilizes steam inside the oven. When the pressure weight is twisted it releases steam.
Soft Steam Cap
Lock/Unlock Handle (Set the handle to lock when cooking or warming the rice)
The handle has to turn to ‘Lock’ for operation.
Clamp Knob
Turn handle to ‘Unlock’, and then press Clamp knob to open.
Control Panel
Dew Dish
Empty the water out of the dew dish after cooking or keeping warm. Leaving water inside the dew dish can result on odor.
The plug type may differ from the actual. (This is only to explain about how it works.)
Power Plug
Power Cord
Temperature Sensor
Rice Scoop holder
Clean Steam Vent
Detachable Cover
Handle
Top Cover Assy
Accessories
Manual &
Cooking Guide
Rice Scoop
Rice Measuring Cup
Steam Plate
Cleaning Pin
(Attached on the
bottom of the unit)
Oven Packing
Place the inner pot Into the body property.
Inner Pot(Oven)
Pot Handle
HOW TO CLEAN
If you pull out the detachable cover indicated by the arrow, it can be easily separated.
Frequetly clean the cover with a sponge using with a neutral detergent.
When cleaning the detachable cover, hold and pull out the both side wing of the cover, then separate the handle and the rubber packing.
When you fix the rubber packing to the detachable cover, hold it between and put it in the edge of the detachable cover by turning it.
Please put the detachable cover. When putting the cover into the lid,
press the cover handle after fitting the handle into the groove indicated by the arrow.
Lid of the inner pot
the back side
the back side
the back side of cover packing
A groove
Correct example
-Clean the detachable cover to prevent odor.
-Clean the body and cover with a dry dish towel. Do not use bentol while using the rice cooker. Starch may be remain, however there is no health risks.
-Do not put materials like screws into holes on the detachable cover. Check the back cover and front cover.
Detachable cover & Pressure packing
After cleaning detachable cover, put it back on the lid
Do not put substances like a screw into hole of detachable cover. Look in the back cover and the front cover.
the front of packing the front of handle
projection presenting the front
no projection
the back of packing
the back of handle
HOW TO CLEAN
www.cuckoo.co.kr
Separate the dew dish.
Separate the drain ditch cap by pushing it down.
Clean the drain ditch cap and dew dish with a neutral detergent.
Securely put in the dew dish after cleaning.
Insert the dew dish firmly by pressing it in direction of the arrow.
Wipe the inner, upper, outer parts of the inner pot of any alien substances. Do not use abrasive materials such as rough scrubbers or metallic scrubbers.
Wipe the top cover with a damp cloth. Be careful when cleaning the top heater
TOP COVER
Check if there is any rice or foreign substances on the oven packing.
OVEN PACKING
Make sure you clean the steam vent before and after use. When cleaning the steam vent, Use extra care; do not pull on the vent. Make sure the steam vent is in place before and after use. If the clean steam vent is not assembled correctly or falls out please call a dealer or service center.
CLEAN STEAM VENT
AND SAFETY PACKING
Wipe the main unit with a damp cloth.
MAIN UNIT
In case the cauldron is stained with cooked rice broth or foreign matter, wipe the cauldron with a damp dish cloth. Using a rough scouring pad or brush etc may damage cauldron surface. If the buttons are functioning correctly please contact our customer care service.
CONTROL
Make sure to clean the steam control vent before and after use.
INNER BODY
INNER POT
How to clean dew dish
How to clean the pressure weight nozzle.
The valve hole of the pressure weight allows steam to release. Check regularly to ensure that it is not blocked. If the valve hole of the pressure weight is blocked, the hot steam and hot content within the cooker can cause serious injury.
Do not use the cleaning pin for any other use except to clean the valve hole of the pressure weight.
Soft steam cap
Cleaning Pin
If the valve hole of the pressure weight part is clogged, puncture it with the cleaning pin
How to disassemble the pressure weight
Under the Lock/Unlock handle is locked(located on “Lock”) turn the pressure weight counter­clockwise while pulling it up, and pull it out.
Puncture the clogged valve hole with the cleaning pin and reassemble it by turning it clockwise. When the pressure weight is properly assembled, it can freely be turned.
Attached on the botton of the unit.
Alien Substance
Pressure Weight
neutral
detergent
HOW TO CLEAN
How to use handle
1. Handle must be turned to “Lock” during Cooking.
When the lamp is turned on it means that it is ready to cook.
2. After cooking, turn the handle from “Lock” to “Unlock” turn the handle to open.
If there is unreleased steam in the Inner pot it might be hard to turn the handle. In this case twist the pressure weight and let the excess steam out. Do not open by force.
3. Handle must be turned to “Unlock” when opening and closing.
If the lamp does not turn on, it would not operate the “Cook” and “Preset” buttons. Make sure the handle is located in “Lock”.
2. To close the top cover turn the handle to unlock, in shown in the picture on the right.
1. Check to make sure the inner pot is place correctly inside the main body.
3. If there is excess steam inside the inner pot it might be difficult to lock the handle. Twist the pressure weight and allow the excess steam to release. Then try to turn the handle again.
When top cover does not close perfectly
How to clean the soft steam cap
Do not touch the surface of the soft steam cap right after cooking. You can get burned.
Do not try to close the top cover by force. It can cause problems.
Take out soft steam cap as in the figure.
When assembling the soft steam cap, match the sill of the below and insert the cap firmly by pressing it in the direction of the arrow.
When installing the soft steam cap, insert the cap firmly by pressing in the direction of the arrow indicated in the figure.
Correct
Wrong
Carefully insert the packing the correct way.
Disassemble soft steam cap in the rear by pressing the hook in direction, at the arrow and wash it frequently with an neutral detergent and sponge.
Disassemble the rubber packing in the direction of the arrow.
When fitting the rubber packing into the plate, please make sure the packing is facing the correct direction.
How to use with the packing
FUNCTION OPERATING PART
www.cuckoo.co.kr
The button has to be pressed until buzzer sounds. There is a chance that the picture may be different with actual one.
Keep Warm /Reheat button
Used to warm or reheat. (Refer to page 27)
Pressure Cook/Turbo Button
Used to start cooking (Refer to page 17)
Cancel button
Used to cancel a selection or release remaining steam inside the inner pot. (Refer to page 33)
Set button
Used to select a function or to buttonlock function. (Refer to page 30)
Preset/Auto Clean button
Used to preset time. (Refer to page 25-26) Also used for automatic steam clean function (Refer to page 18)
Mode button
Used to customize individual cooking preference, time-setting, voice volume setting, keep warm temperature setting, and power saving movement
Menu / Selection button
Used to select glutinous rice, sushi, mixed rice, GABA, rice and beans, old rice, nu rung ji, nutritious rice, nutritious porridge, all­purpose steaming and automatic sterilization (Steam Cleaning), and to modify preset time. See page 25. For mode button and setting Gaba use the multi cook time Seepage 23, 24
Display
When the inner pot is not placed into the unit.
Temperature sensor problem or fan motor problem.
marks blink.
When pressing the Pressure Cook and Timer botton, while the Lock/Unlock handle is on “Unlock” Turn the Lock/Unlock handle “Lock”
When boiling only water.
When setting preset time longer than 13 hours Set the preset time within 13 hours. (Refer to page 25~26)
When the product has any problems or used it inappropriately, you can follw the below marks. If error persistently shows up even in normal using conditions or after taking measure, inquire with customer service .
Error Code and Possible Cause
It appears on the display when you press Start button again, or if the cooking has finished and you’ve never ever turned the handle to ‘Unlock’. It can be solved by turning handle to ‘Unlock’ and then turn to ‘Lock’.
HOW TO SET CURRENT TIME / HOW TO SET OR CANCEL VOICE GUIDE FUNCTION
First hold the mode button for more than 1sec. Then enter this function, press Mode button 2 times.
V oice guide volume contr ol (The function which can control volume and cancel)
Press mode button once.
Press mode button for more than 1sec “Current time mode press yes button” after setting current time with selection button Menu/Selection button blinks and Mode, Set and Cancel buttons turn ON. Colon mark ( ) on the sec. screen is blinking once per second.
1
About Lithium battery
This product contains lithium battery for improving blackout compensation and time. Lithium battery lasts for 3 years. When current time is not displayed on the screen, it means the battery is exhausted. It should be replaced.
What is blackout compensation
This product remembers and maintains previous condition and processes. After finishing a blackout, it operates immediately. If blackout happens during cooking, the cooking time will be delayed depending on blackout time. If the rice became cold because of blackout, warming will be cancelled.
How to set current time during keep warming mode
1. Press Cancel button to cancel keep warm and then press Mode button over 1 time to set current time.
2. After setting time, press keep warm button to re-start keep warm.
ex) 8:25am now
How to set current time
When you finish setting the time you want the press "Set" button.
If it is over 7 sec without yes button, setting time will be canceled with
voice, “it is canceled due to exceeded time limit”.
3
set o'clock and minutes by pressing the menu/selection button.
2
Set to desired voice volume, and press Set button.
‘ ’ sign is displayed when entered volume control mode by pressing Mode button 2 times.
If set value became ‘ ’ by pressing button, voice guide function is off.
Press button to set ‘ ’, that is the maximum volume sound. When finish setting desired volume, press Mode button to store.
1 min up " " button 1 min down " " button 10 min up or down " ", " " keep pressing. Careful of setting am,pm. In case of 12:00 it is 12:00 pm.
<Standby mode>
BEFORE COOKING RICE
www.cuckoo.co.kr
Clean the inner pot with a dry cloth.
Use the soft cloth to wash the inner pot. Tough scrubber can make the coating come off.
Measure the amount of rice you want to cook using the measuring cup.
Make the rice flat to the top of measuring cup and it is serving for 1 person.
(ex: for 3 servings 3 cups, for 6 servings 6 cups)
Wash the rice with another container until the water becomes clear. Put the rinsed rice into the inner pot.
Put the inner pot into the main body and close the topcover.
Put the inner pot correctly.
If there is any external substance on the temperature sensor or the bottom of the inner pot, wipe it off before putting the pot into the main unit. Top cover will not close if the inner pot is not placed correctly in the main body (Place the inner pot to the corresponding parts of the main body)
Connect power plug and turn the handle to “Lock”
According to the menu, adjust the water amount.
For measuring, place the inner pot on a leveled surface and adjust
the amount of water.
The marked line of the inner pot indicates water level when putting
the rice and water into the inner pot together.
About water scale
When you want to cook the old rice or want the soft rice : pour more water than the measured
scale Glutinous Rice for 8 persons (8 cups) : Set the water to scale of
GLUTINOUS
For overcooked rice : pour less water than the measured scale
Rice for 6 persons(6 cups)
• Glutinous rice, mixed rice, nutritious rice and nu rung ji, Washed rice : Adjust water level to the water scale for ‘glutinous rice and mixed rice’. Glutinous rice can be cooked to max 10 servings, mixed rice to max 8 servings, nutritious rice to max 6 servings and nu rung ji to max 4 servings.
• Sushi, Old rice : Adjust water level to the water scale for ‘sushi’. Sushi can be
cooked to max 8 servings, old rice to max 6 servings.
• GABA : Adjust water level to the water scale for ‘GABA’. Can be cooked to
max6 servings.
• Nutritious porridge : Adjust water level to the water scale for ‘nutritious porridge’.
Nutritious porridge can be cooked to max 2 servings
• Mixed Brown Rice : When cooking use a 5:5 ration of Brown and White Rice.
Use the “Mixed Rice” gradient lines when pouring water. For Mixed Rice mode it will only cook up to a maximum of 8 servings.
The lamp turning on means closed perfectly. If you press the cook button without setting the Lock/Unlock handle to “Lock”, the cooker will not operate. You will hear “beep beep beep” sound and “ ” is shown in the LCD.
If you want to select another function while cooking, push cancel button.
If “ ” shows up in other instances, turn cover handle to "Open" direction, and turn it toward "Lock". Then the cooker will work normally. (The operation of cover lock sensing device can be checked.)
Note: This instruction is not applicable if cover handle is turned toward "Open" direction once or more after cooking was completed in previous cooking.
FOR THE BEST TASTE OF RICE
How to store rice
It
s better to set the “warm” time shortly .
Keep the product clean.
When measuring the rice, Use the measuring cup. (The amount of the rice may vary depending on the quality of the rice.)
Place the inner pot on a flat surface and adjust the water to water level in the inner pot.
If possible, buy a small amount of rice and keep the rice some place where it ventilates well and avoids a direct ray of light. It can prevent evaporation of rice moisture.
If the rice has been unsealed for long, rice can be dry and stale. In this case, you should pour the half of water more. It s tastier.
If possible, do not use the preset time function when rice is too dry and pour the half of water more.
It s better to set “warm” less than 12 hours.
Clean the product often. (Especially clean the top of the cover for external substance.)
If the rice is too dry, rice can be crisp even though it is measured properly.
If you set “Preset” over the 10 hours or “Preset” dried rice, rice can be crisp or half cooked. Even worse condition, rice can be cooked different tastes each level.
If the preset time is longer, the melanoizing effect could be increased.
If rice is kept warm for a long period of time, rice color will change, as well as odor.
Wipe the top cover heating part well for any rice or external substance.
For the best taste of rice, check the following points carefully .
Cook tasty rice with Cuckoo pressure rice cooker
Use the measuring cup!
Pour the water until water level marking in the inner pot!
Shorten the duration of the “Present” time for better cooking.
If amount of water and amount of rice is different, rice can be crisp or hard.
HOW TO COOK
www.cuckoo.co.kr
Choose menu with menu selection button
Start cooking by pressing Pressure Cook button.
Select button. Each time “Menu” button is pressed, the selection
switches in the sequential order, glutinous rice turbo glutinous rice sushi GABA old rice mixed rice nutritious rice washed rice NU RUNG JI porridge chicken soup multi cook automatic Sterilization
If the button is pressed, repeatedly, the menu switches continuously in sequential order.
In the cases of sushi, mixed rice, GABA and old rice, the menu remains memorized once each cooking is completed, so for continuous use of the same menu, no selection of menu is required.
You must turn lid handle to lock before cooking. Then press the pressure Cook/Turbo Unless lid handle is not turned to close, you get alarm with “ ” , and sound “turn lid handle to lock”.
The end of cooking
When cooking is completed. warming will start with the voice "cuckoo completed glutinous".
When cooking ends, stir rice equally and immediately. If you don't stir rice at once and keep it stagnant, rice will go bad and smell bad.
If the lid handle is not working well, take out the steam completely out of inner pot by turning over pressure weight.
While cooking, do not press cancel button.
Cooking thoroughly
The cooktime remaining on the display is shown from cooking thoroughly. The cook time is different according to the menu.
Be careful not to burn yourself from the automatic steam outlet.
After cooking chicken soup and multi cook etc, the smell may permeate into the unit, use the Unit after cleaning the rubber packing and lid part according to page 10~12.
Cooking time by menus may vary to some degree depending on the using environment of the product.
Glutinous
Turbo
Glutinous rice
Sushi
Mixed
GABA
Nutritious
Porridge
Old Rice
Chicken
Soup
Nu Rung Ji
Nutritious
rice
All-purpose
steaming
Washed
rice
Automatic Sterilization
(Steam Cleaning)
Cooking
Capacity
Cooking
Time
Menu
Class
HOW TO COOK
The cooked rice can be light yellow at the bottom of the oven, because this product is designed to improve pleasant flavor and taste. Especially, melanoizing is more serious at the
Preset cooking than just Cooking .
It does not mean malfunction.
When mixing other rice with Glutinous, Melanoizing effect could increase more than Glutinous cook setting.
Melanoizing effect
1. Put desired amount of washed rice into the cooker body by measuring it with measuring cup, and pour water to meet glutinous water scale. (Washed rice can be cooked to min 2 servings to max 10 servings.)
2. Stir evenly with scoop so washed rice and water may mix properly, lock the cover, and after selecting washed rice menu
with Menu/Selection button, press Pressure Cook button.
Note: Washed rice is cooked only with water poured with no separate washing, so they may experience the fine scorching phenomenon(melanoizing).
Note: Do not store washed rice in a humid place as it is vulnerable to humidity. In summer or rainy seasons, the rice may go bad or be inhabited by beetles, so when purchasing washed rice in the market, buy it by units of small pack.
How to cook with washed rice
- If you cook long stored rice or dried rice, they could be half-cooked. If using the old rice menu, you can get better taste .
- The taste of rice will be different depending on storage of rice and water state.
you can add the heating time or soaktime (Refer to page19~20).
Old rice cook function
- When cooking nutritious cooked rice, the degree of melanoizing, a phenomenon of finely scorched rice, may vary depending
on the amount or condition of used materials like jujube or fresh ginseng etc. Adjust the amount of material depending on the preference of melanoized degree.
COOKING NUTRITIOUS COOKED RICE
After cooking in white rice turbo mode or cooking of small serving, discard water. In case of small servings white rice turbo cooking, more water may be required than other menu.
Please refer to the cooking guide.
Glutinous
When you want to have sticky and nutritious white rice.
Mixed
/Brown
Porridge
Chicken
Soup
Turbo
function
for
Glutinous
rice
This menu is used to cook by mixing glutinous rice in cereals.
For cooking Porridge.
This menu cooks samgyetang automatically.
Press Pressure Cooking/White Rice Turbo button twice after selecting "White Rice" menu, and the cooker will go for white rice turbo cooking, which will cut rice cooking time. (Two servings of white rice normally takes 17 minutes or so.)
The mode of white rice turbo does not produce cooked rice as good as normal cooking mode. Use white rice turbo mode only for 6 servings or less.
For better taste of cooked rice, cook rice in white rice turbo mode after macerating rice for 20 minutes or so before cooking.
Sushi
When you want to have a little more sticky and nutritious white rice than Glutinous rice.
GABA
Nutritious
Rice
Nu Rung Ji
(Scorched rice)
For cooking germinated brown rice.
This menu is used to cook nutritious rice.
Have scorched rice when cooking done.
How to use the cooking menu
Nutritious
Rice
This menu is used to cook nutritious rice.
Multi cook
For cooking Nutritious Rice.
Washed
Rice
This menu is used to cook washed rice.
Automatic
Sterilization
(Steam
Cleaning)
This menu is used to eliminate smell soaked after cooking or warming.
Put water until water scale 2, make sure to close and lock the cover. Method 1, After choosing automatic cleaning menu by pressing
“Menu/Select” button, and then press “Pressure cook/turbo” button. Method 2. After choosing automatic cleaning function by pressing “Preset” button twice in standby mode, press “Pressure Cook/turbo” button.
HOW TO USE AUTOMATIC STERILIXATION (STEAM CLEANING)
MY MODE (Cuckoo Customized Taste Function)
www.cuckoo.co.kr
Cuckoo’s patented technology based on variable circuit design. User can select the degree of “softness” and “glutinosity & tastiness” to meet a user’s desire.
What is “MY MODE”?
Longer “SOAK” Time : rice becomes soft and glutinous. (selectable in 4 steps) Longer “HEAT” Time : rice becomes tastier(selectable in 4 steps) [melanoizing will occur] Both functions above can be selected simultaneously or separatetly
MY MODE Function
To enter Customized Rice Taste Setting Mode, select desire menu and hold the Mode button once for 1 second or longer.
“MENU”setting screen
To enter “Customized Rice Taste Setting Mode”, select the menu in which Customized Rice Taste is supported such as glutinous rice, mixed rice, GABA, old rice, nurungji and washed rice, and press and hold the mode button for 1second or longer. Then, you are going to enter “Customized Rice Taste Setting Mode. Select the welling and heating stage with the Selection button, and press the Set button”.
The setting of figure below is based onglutinous rice menu.
How to Use “MY MODE”
“MY MODE” setting screen
Set up desired customized rice taste. And press Pressure Cook. (If you press cancel or do not press a button within 7 seconds, the function will deactivate and return to the standby mode.)
Select menu you want with menu/selection button and press the set button.
Soak time control mode
Keep heating fine control mode
Setting the completed screen after
To enter Customized Rice Taste etting Mode, select desire menu and press Mode button once for 1 second or longer
“MENU”setting screen
You can customize your preference for cooked rice by selecting Customized Cooked Rice Taste mode or mode button. Each time you press Mode button, the major cooked rice taste will show up in the sequential order ‘Sticky Cooked Rice Taste–> Soft Cooked Rice Taste -> Soothing Cooked Rice Taste -> Soft and Soothing Cooked Rice Taste’.
The setting in the figure below is based on glutinous rice menu.
How to Use “MY MODE” ll
“MY MODE” setting screen
Press Mode button two times, and the display will change as in the figure. At this time, Soothing Cooked Rice Taste 4th Step will be selected.
Set up desired customized rice taste. And press Pressure Cook. (If you press cancel or do not press a button within 7 seconds, the function will deactivate and return to the standby mode.)
Press Mode button once, and the display will change as shown in the figure. At this time, Soft Cooked Rice Taste 4th Step will be selected.
Select the menu you want with the menu/selection button and press the set button
Soak time control mode
Keep heating fine control mode
Setting completed screen after
Press Mode button three times, and the display will change as in the figure. At this time, Soft, Soothing Cooked Rice Taste will be selected.
Soft and Sweet Rice Mode
Select desired heating extention time
by pressing the button.
For 16 customized rice tastes, refer to the graph for 6 rice tastes. (See page 20)
Select desired swelling time by
pressing the button.
MY MODE (Cuckoo Customized Taste Function)
The display for My Mode
1. ‘MY MODE’ function may influence scorching or cooking quality. Ensure that cooking time is not changed, by children.
Default setting are “SOAK” Time 0 min, “HEAT” Time 0 min.
2. ‘MY MODE’ function may elongate cooking time according to the set-up time.
3. Scorching of rice may occur by longer “HEAT” Time.
Cautions
Shown in the figure above, the stage mark will show up on the display during setting swelling time, heating, and maintenance time. The mark will continue to show up during cooking, reservation, keeping warm, and reheating as well.
Cuckoo customized taste function is applied to glutinous, mixed, GABA, old rice, Nu Rung ji. Set-up times is stored until the next reset. No need to set-up at every cooking. During cooking, warming and preset time cooking modes, “soak” and “heat” time cannot be readjusted.
This is a graph that shows the flavors of 16 types of cuckoo custom-made rice
If you press the mode button 5times, customized cooking function is setup. Select heating power by selection button. You can see all means with cuckoo customized cooking function on the display.
*1. The rice becomes solid and glutinous. *2. The rice becomes soft and well-raised rice. *3. The rice becomes soft and glutinous.
Note: Rice taste number from 1 to 16 will be displayed on the display window.
How to use Cuckoo Customized cooking function
1. ‘Cuckoo customized cooking function’ applies to Glutinous, Turbo cooking, Sushi, Mixed rice/Brown rice, GABA, Nutrition rice, OLDRICE collectively
2. Set up the step of customized cooking function to taste. The scorch can occur when cooking in high level mode.
3. Cook is subject to be set differently depending on the percentage of water content and the condition of rice.
Initialization is set up “ ” get step by step as the case may be.
- High step : for cooking cereals, old rice and soft-boiled rice.
- Low step : for cooking the year’s crop of rice.
While cooking you can control the heating temperature (both high an low) depending on, your prefenence.
Cuckoo customized cooking function
The display Cuckoo customized cooking function
Press the selection button for “High level”mode.
Press the “menu”button to select the desired level or low level mode.
Continuously press the “menu” button
High level mode
Press the “set” button to complete your customized cooking.(If you press cancel or do not press a button within 7 seconds, the function will deactivate and return to the standby mode.)
If the push the button 5 times, the display for customized cooking function will be set up. Initiation is like above picture.
Menu/selection button will blink, and mode, seland Cancel buttons will turn ON.
Setting completed screen after
Low level mode
MY MODE (Cuckoo Customized Taste Function)
www.cuckoo.co.kr
When cooking nu rung ji, please set it up for your taste with function which controls the level of burning nu rung ji. How to set up the enhanced burning nu rung ji (for enhanced burning nu rung ji).
1. If you push mode button 7 times at the waiting state, enhanced burning nu rung ji mode will be set up when pushing mode button more than it will be possible to set up.
2. When enhanced burning nu rung ji mode is set up, it says "after removed or selection of enhanced burning nu rung ji, push the yes button". At this time, Menu/Selection button will blink, and Mode, Set and Cancel buttons will turn ON.
3. If you push the menu/selection button it says "enhanced burning nu rung ji chosen press the yes button after choosing a mode you want. press the yes button".
4. Without any button within 7 seconds or cancel button, enhanced burning nu rung ji mode will be canceled and returned to waiting state.
How to set up the function for burning nu rung ji
How to cancel the enhanced burning nu rung ji
1. If you push mode button 7 times at the waiting state, enhanced burning nu rung ji mode will be set up when pushing mode button more than it will be possible to set up.
2. When enhanced burning nu rung ji mode is set up, it says "after removed or selection of enhanced burning nu rung ji, push the set button". At this time, Menu/Selection button will blink, and Mode, Set and Cancel buttons will turn ON.
3. If you push the menu/selection button it says, "enhanced burning nu rung ji chosen press the yes button after choosing a mode you want. press the set button".
4. Without any button within 7 seconds or cancel button, enhanced burning nu rung ji mode will be canceled and returned to waiting state.
Set up this function as occasion demands because this function is on the condition of cancel for enriched saorch at the first use.
HOW TO USE GABA (Brown rice)
Check the dates of harvest and pounding. The dates should be within 1year from harvest, 3 months from pounding.
Inspect rice with your eyes.
Check too see if the embryo is alive Rice surface should be light yellow and glazing. Whitely stirred up surface, or darkish colored Brown rice is not suitable
for a germination
Avoid fractured, not fully corned, or empty ear’s. Empty ear’s may generate odors during germination and and be
bluish- nor corned Brown rice cannot be germinated.
(Regular brown rice)
< Comparison of Germinated brown rice s nutrition
and Glutinous rice
s (6 hours) nutrition. >
Phytic acid 10.3Times Ferulic acid 1.4Times Gamma-orizanol 23.9Times Gammma-aminobutyric 5Times Inositol 10Times Food fiber 4.3Times
Brown rice has richer nutrients than polished rice. However, brown rice is rather tough and hard to be digested. By germination, the enzymes in the brown rice are activated, generating nutrients and become more digestible.
What is Germinated Brown rice?
Germinated Brown rice increases nutrients and enhances taste which is a weak point of brown rice. Germinated Brown rice also improves digestion.
Taste will be greatly enhanced. Digestive and rich in nutrients.
Diabetic hormone is generated improving digestion.
Good as a health food for children or adults.
- Rich with dietary fiber.
Germinated brown rice has rich GABA (Gamma Aminobutryc Acid)
- GABA promotes metabolism in liver and kidneys, suppresses neutral fat, lowers blood pressure, promotes metabolism in brain cells - these effects have been proven by medical science.
Features of Germinated Brown rice
Tips to Buy Quality Brown Rice
(Poor brown rice
- Empty ear and nit fully corned brown rice)
HOW TO USE GABA (Brown rice)
www.cuckoo.co.kr
Using GABA Menu
Precautions for GABA Cooking
If smaller germ is preferred, omit pre-germination process. Select GABA menu, set-up appropriate germination time, and start cooking (nutrient ingredients do not vary significantly by the size of germ).
During hot seasons, longer germination time may generate odor. Reduce germination time. GABA cooking is allowed up to 6 persons. City water can be used for germination. However, spring water is recommended. Germination may not be properly
performed in hot or boiled water even after cooling.
Germination rate, germ growth may differ by the Brown rice type, condition or period of storing, etc.
- Germinated brown rice is sprouted brown rice. Germination rate and growth may differ by the Brown rice type. The brown rice should be within 1 year from harvest, and not long since pounded.
In GABA mode, preset on 4H, 5H, 6H may not be possible. If you want to preset the GABA, set up ‘OH’.(See the page 25) The taste of rice could be different as depending on a kind of brown rice. Use customized taste function or control the amount of water for your taste. (Refer to page 19~21)
In order to promote germination, soak brown rice for 16 hours in water.
Method of Pre-germination
Put washed brown rice in an appropriate container, pour sufficient water to soak the rice. Pre-germination shall not exceed 16 hours. Make sure to wash rice clean with flowing water before using
GABA menu. Be careful that hard washing may take off embryos which generate the germination. Unique smell may be generated according to the soaking time of pre-germination. When pre-germination has been completed, wash the rice and put in inner pot (Oven). Pour appropriated volume
of water, and use
GABA menu.
In summer or hot temperature environment odor may be generated. Reduce germination time and wash clean
when cooking.
1
Set the Lock/Unlock handle at Lock, press Menu button to select “GABA”.
When the “GABA”is selected, “2H” is indicated in the display. Set button will blink, and Mode, Menu/Selection, Cancel, and Pressure Cook buttons will turn ON.
2
Press “Set” and Menu Selection buttons to set time.
Menu/Selection button will blink, and Mode, Cancel and Pressure Cook buttons will turn ON.
1. Pressing “Menu Selection” button increases germination time by 2hours.
2. Pressing “Menu Selection” button decreases germination time by 2hours.
3. “GABA” time can be set up by 0, 2, 4, 6 hours.
If GABA time is set “0”hours, pressing “Pressure Cook” button will start cooking immediately. To cook without germinated Brown rice, set the time at “0”.
3
Press Pressure Cook button.
Pressing Pressure Cook button will being the GABA process, after which. cooking will begin immediately. During GABA mode, “ ” indicator will show the remaining time and will be displayed in minutes with the 3H mark going around clockwise.
4
HOW TO COOK USING MULTI COOK AND NU RUNG JI
1. Turn the Lock/Unlock handle to Lock and press menu to select the Nu Rung Ji.
2. Press the “Pressure Cook/Turbo” button to start cooking.
3. When cooking is completed, scoop out the boiled rice. The Nu Rung Ji on the bottom of the jar can be prepared for your taste (e.g. scorched rice tea)
Nu Rung Ji can be prepared for up to 4 people For Nu Rung Ji cooking, set the water volume at Glutinous level. Not too much washing rice. If you want enhanced burning nu rung ji, cook after soaking rice in water for 30minutes.
Press “Set”, “Menu/Selection” button to set up the time.
The Menu/Selection button will blink, and the Cancel and Pressure Cooking buttons will turn ON.
2
Use the preset time of Multi -cook as following instruction.
4
How to use Multi-Cook and preset time
How to make Nu rung ji
Turn the top handle to Lock, press menu to select the Multi-cook.
When selecting Multi-cook, the display indicates cooking time to be 20 minutes.
1
Press “Pressure cook/turbo” button.
Pressure Cook button will blink, and Menu/Selection and Cancel buttons will turn ON. Press the Pressure Cook/Turbo button and the Multi-cook will start.If the Multi-cook starts, the display shows the
cooking mark and remaining minutes.
3
1. Check the present time.
2. Turn the Lock/Unlock handle to
Lock and press the “Preset” button.
6. Press the “Set”button, then press the “Pressure cook” to
1.
Each time you press “Selection” button, the time increases 5 minutes.
Press Menu/Selection to choose desired Menu.
3. Press the Menu/Selection or Min/Heat to preset time. Then press the set button.
4. Press menu selection butt on to select the Multi­cook.Then press the set button.
5. Set up the cooking time by pressing selection to increase, and menu to decrease the cooking time.
2.
Each time you press “Menu” button, the time decreases 5 minutes.
Press Menu/Selection to choose desired Menu.
3. Available setting time is 10 ~ 90 minutes. (Please refer to cooking guide for time setting of each menu.)
4. If you press the set button after choosing the time you want, then it says “press cook/Turbo button.”
HOW TO PRESET TIMER FOR COOKING
www.cuckoo.co.kr
Check if the current time and the menu are correct.
Refer to page 14 for the time setting. If the current time is not set correctly, the presetting time will
also be incorrect. Make sure not to confuse AM and PM.
1
Turn the Lock/Unlock handle to the lock position and a lock icon will be displayed on the screen. Then press the “preset” button.
To activate Preset 1, press the “preset” button once. To activate Preset 2, press the “preset/timer” button twice.
Factory Set Configurations- Preset 1: Preset at 6:30am, Preset 2: Preset at 7:00pm. If you want to use these times, select Preset 1 or Preset 2
If the lock/unlock handle is not in the locked position then you will not be able to program or use the preset function
When you press the “preset” button, the preset time will be displayed, and the Preset 1 & Preset 2 signs will be blinking.
Gaba/Mixed Rice menu, you have to select “0H“ in order to use the preset timer function.
When it is in keep warm mode, press cancel to exit keep warm mode, then select your desired preset time.
2
Preset the time.
3
Press “Pressure Cook” button.
It says that preset cook for glutinous is booked Preset cook will be completed at the timer
Once cook is completed with preset time, preset time is stored in the memory.
Don't need to set up time again. If a small amount of rice is cooked, it could be finished earlier than
time you programmed it.
5
4
How to preset timer for cooking
How to use timer function
In case of setting up timer while warming, increases by 10min when you press “ ”button
Please set up timer after canceling warming, decreases by 10min when you press “ ”button.
If you keep on pressing either button, It can be changed continually.
Please be careful not to change from AM to PM.
Then press the “Set”button to program your desired time.
When preset time is set to AM07:40
Select menu with “Menu/Selection” button.
HOW TO PRESET TIMER FOR COOKING
Touch Me
Glutinous
Old Rice
Mixed
Porridge
Multi Cook
Precautions for preset cooking
In case of preset cooking
If the rice is old and dry, the result may not be good If the rice is not well cooked, add more water by about half-scale. If the preset time is longer, melanization could be increased. Rinsed rice adds precipitated starch, Preset Cook may cause scorching To reduce scorching,
cook washed rice by rinsing it in running water or reduce cooking amount.
1
The change of preset time
Press “cancel” button for more than 2 seconds and restart it to change the preset time
2
If the preset time is shorter than cooking time, cooking will immediately begin.
If set time is shorter than preset time, cooking will immediately begin.
3
In case the preset time is over 13 hours.
""
will be displayed and the preset time will be changed to 13 hours automatically.
ex)
If cooking is preset to AM07:00 of the following day at PM5:00 of the day, where preset time is 14 hours, " " will be displayed, and preset time automatically changes to AM06:00. (Preset time is 13 hours)
If the preset time is over 13 hours, it can cause bad smell. The limited preset time is set up less than 13 hours because the rice spoils easily during the summer time
When you want to finish presetting PM 12:00, preset PM 12:00 Use this function when you want to finish cooking between 1 hour to 13 hours based on the preset time If you press the set button to check the present time during the preset cooking function, the preset time will be
displayed for 2 second.
4
Menu
Class
From
(41minutes
+ My mode)
to 13 hours
Possible
time
Setting
Glutinous
From 27minutes to 13 hours
Turbo
Glutinous
Rice
From 49minutes to 13 hours
Sushi
From (57minutes + My mode)
to 13 hours
Mixed
From
(61minutes
+ My mode)
to 13 hours
GABA
From (46minutes + My mode)
to 13 hours
nutritious
rice
From 93minutes to 13 hours
nutritious
Porridge
From (44minutes + My mode)
to 13 hours
Nu Rung ji
From (48minutes + My mode)
to 13 hours
Old Rice
From (setting time + 1 minutes)
to 13 hours
Multi
Cook
From 23minutes to 13 hours
Automatic
Sterilization
(Steam
Cleaning)
From 64minutes to 13 hours
Chicken
soup
From (38minutes + My mode)
to 13 hours
Washed
Rice
TO KEEP COOKED RICE WARM AND TASTY
www.cuckoo.co.kr
It will be hard to open the lid during warming, or right after it has finished cooking, So push the pressure weight to the side and allow the steam to release.
Make sure the handle is in the “Lock” position during warming or reheating.
It is recommended to evenly stir the cooked rice after cooking. The rice taste is improved. (For a small quantity of rice, pile up the rice on the center area of the inner pot to keep warm)
It is recommended to evenly stir the cooked rice after cooking. The rice taste is improved. (For a small quantity of rice, pile up the rice on the center area of the inner pot to keep warm)
Do not keep the scoop inside the pot while warming the rice. When using a wooden scoop it can create serious bacteria and odors.
It would be better to warm the rice for less than 12 hours because of odors and color change. The cooked rice, which cooked by pressure cooker is more prone to changing color than the rice cooked by general cooker. During warm mode, the rice can arise and turn white and rise. In this case, mix the rice.
The mixed and brown rice cannot be in such good condition as white rice while in warm function due to their characteristics. Therefore do not keep mixed and brown rice in function for a long period of time.
Do not mix small amount of rice or leftovers with the rice under keeping warm. Doing so may cause an odor. (Use a microwave oven for the cold rice.)
<Keep warming>
The ' ' of function display indicates 3 hours has passed in heat preservation mode. One press of 'Set' button during heat preservation displays present heat preservation temperature, and another press of 'Set' button present time.
<Finishing reheat>
When the reheat finishes with the beep sound, keep warming function will be operated and, the elasped time will be shown.
Having a meal
If you want to have warm rice, press the “Reheat/keep” warm. Then “Reheat/Keep” warm function will be started and you can eat fresh rice in 9 minutes.
To use reheating in standby status after power is applied, turn lid combining hand grip to Locked" location, press Reheat/Keep button, and the cooker will convert to Heat Preservation mode. Here press Reheat/Keep warm button once more.
Cautions for Keeping Warm
If you change the present time during warming, see the page 14.
The frequent use of the “Reheat” function may cause the cooked rice to be discolored or dried. Use it once or twice per day. If a separate heating appliance or gas burner is used to cook rice, put the cooked rice into the cooker and press the “Keep Warm/Reheat” button to keep the rice warm. At this time, ' ' is shown on the display. (Like this, transferring hot rice to a cold cooker may cause the rice to be discolored or develop an odor) After 24 hours of heat preservation, the lamp of heat preservation time lapse blinks, indicating that long time has passed in heat preservation condition. In case the lid combining hand grip is in open status during heat preservation, the cooker does not go for reheating. For reheating, lock the lid combining hand grip to (Locked) position, and then press Keep warm/reheat button. If the lid combining hand grip is turned to open status during reheating, function display will show " ". At this time, reheating will be cancelled, and heat preservation will proceed.
<Present morning temperature>
<Reheating>
The lamp blinks and indicator will shows the reheat remaining time will be displayed in minutes with the mark going around clockwise.
If you push the “set” button present warming temperature is displayed and push “set” button again. The current time is displayed during warming. Moreover, when you push the button once more, the time elapsed of warming is displayed
There is a difference between the outer temperature and inner temperature because it operates with various users and environment. After cooking rice, temperature is much higher than the warming temperature programmed.
TO KEEP COOKED RICE WARM AND TASTY
Hold the “Mode” button for 1sec during keep warming. stage It display a picture with a buzzer sound. At the time, means current warming temperature.
Press “Selection” button to increase the temperature as
Press “Menu” button to decrease the
temperature as
1. If too much water is spilled out when you open the lid : Press “Menu/Selection” button to raise the setting mode.
2. If the edge of rice is too soft : Press “Menu/Selection” button to reduce the setting mode.
Controlling method of warming temperature
If the temperature in the oven is not proper, it smells bad and changes rice color even though it is cleaned frequently and boiled up. Temperature needs to be set.
Press “Selection” button to change as the picture(up)
Select the menu you want, then the press the “My Mode” button and set-up time will be automatically entered with a buzzer. (If you press the “Cancel” button or do not press a button within 7 seconds, the function will be cancelled and returned to standby mode.)
After setting the temperature, press the “Set” button. Preset temperature will be stored with buzzer sound. (It will be cancelled once press “Cancel” button or after 7 seconds without pressing any button.)
Press “Menu” button as the picture(down)
How to operate My Mode function.
Use it while opening the lid when there is too much water or rice becomes too soft.
Hold on to the “Mode” button for 1sec, then push the “mode” button 4times. The voice says that it is programmed warming mode, control the temperature you want.
1. When you smell bad odors and the rice is too watery: The keep warm temperature is too low. In this case, increase the “Keep Warm” temperature by 1~2 .
2. When the rice has a yellowish color or is too dry: The keep warm temp is too high. In this case decrease the “Keep Warm” temperature by 1~2 .
Device Temperature Control
To raise temperature
To lower temperature
Note: The reference temperature programmed when the product is shipped may differ from the Instruction.
TO KEEP COOKED RICE WARM AND TASTY
www.cuckoo.co.kr
1. Hold “the mode” button for one second, then press the “mode” button 6times to set up sleeping mode. If sleeping mode is not shown, keep on pressing the “mode”button until it is heard or displayed.
2. When you are in sleeping mode, it says “After selecting or canceling sleeping mode, press the set button.” At this time, Menu/Selection will blink, and the Mode, Set, and Cancel will turn on.
3. Press the “Menu/Selection” button until you hear or see “Sleeping mode”, then Press set. You will see nothing surrounding the rice cooker on the screen.
4. This function must be activated by the user depending on necessity.
1. Hold “the mode” button for one second, then press the “mode” button 6times to set up sleeping mode. If sleeping mode is not shown, keep on pressing the “mode”button until it is heard or displayed.
2. When you are in sleeping mode, it says “After selecting or canceling sleeping mode, press the set button.” At this time, Menu/Selection will blink, and the Mode, Set, and Cancel will turn on.
3. Press the “Menu/Selection” button until you hear “Sleeping mode has been canceled”, then Press set. You will see rings around the rice cooker on the screen.
How to activate “Sleeping” mode.
When keeping rice warm for a long time, set up the temperature low to prevent the following quality of rice: smelly, dry, change of color; from PM10:00 ~ AM 04:00.
How to set up
How to release
If you need to keep the rice warm during sleeping, do not use this function. This function makes the rice cooler than normal. In summer, the rice can be spoiled and may smell bad because of high temperature. If possible, do not use the “Custom-made warming” mode while sleeping. This function is set up as cancel state.
When odors are rising during the warming mode
Clean the lid frequently. It can cause bacteria and odors.
Even though exterior looks clean, there might be germs and it can cause odor so please be sure to use automatic sterilization (steam cleaning) menu for cleaning. Clean the inner pot completely after automatic cleaning function is done. (refer to 18)
After you cook soups and steamed dishes, clean the inner pot properly to prevent rice from smelling.
For button locking or night voice volume reduction, proceed with the following procedur e
How to set Lock buttons
Lock can be set for touch button to prevent malfuncion during cleaning with touch button or by children touch.
Setting Method
Setting Method
1. Button will be locked if "Set" button is pressed for 3 seconds or longer during cooking,presetting, warming, reheating, or in standby stage.
2. When button is locked, a voice will sound saying "Button lock is selected." At this time, button lock is displayed on the screen.
1. To cancel button lock, press "Set" button for 3 seconds or longer on locked the button.
2. “Lock” sign on the display disappears when button lock is cancelled, a voice will be saying “Button lock is cancelled.”
Note: Any button other than Set button is pressed while button lock is set, buzzer will sound. Note: Desired function can be set after cancelling button lock by pressing Set button for 3 seconds or longer.
Note: Button lock function is cancelled automatically when the power is off even though the button lock function
is already set.
Night Voice Volume Reduction function
1. Press 'Mode' button in standby status, and the system will enter night voice volume reduction mode. When pressing 'Mode' button for the first time, press the button for 1 second or longer to enter the function.
2. Upon entering the mode of activating 'Night Voice Volume Reduction', you will hear a voice saying "You have entered the Night Voice Volume Reduction Activation mode. Select or inactivate the Night Voice Volume Reduction function with 'Select' button, and press 'Confirm' button."
3. Press Menu/Select button, and as process progress bar changes, voice volume will change. Select the desired volume of voice, and press 'Confirm' button.
4. If you press 'Inactivate' button or no button is pressed for 7 seconds after process progress bar reaches 5th step through adjustment of Menu/Select button, the function will be inactivated while you hear a voice saying "Specified time has passed and the function is inactivated", and the system will return to standby mode.
60% of day time voice volume
Marking of process progress bar by the activation of Night Voice Volume Reduction function.
Night Voice Volume Reduction is the function of reducing voice volume during night hours 10:00PM ~ 05:59AM. Activate this function when necessary. This function works only during night hours.
How to activate or inactivate the function of Night Voice Volume Reduction
No voice 20% of daytime voice volume 40% of daytime voice volume 60% of daytime voice volume 80% of daytime voice volume In case Night Voice Volume Reduction function is inactivated
1st step 2st step 3st step 4st step 5st step
This function remains inactivated when the product is shipped. Activate this function when necessary.
www.cuckoo.co.kr
If there is a problem with your cooker, check the following details before requesting service to your dealer. Sometimes the cooker may not operate as desired if used incorrectly.
Case
When the rice is not cooked.
When the rice is not cooked well.
Rice is too watery or stiff.
When the water overflows.
When you smell odors while warming.
signs show up.
Rice has gotten cold or a lot of water flow during keeping warm
If “ ” sign appears.
Check points
Pressure “Cook/Turbo” button is pressed?
Is there power cut while in cooking?
Did you use the measuring cup for the rice? Did you put proper amount of water? Did you rinse the rice before cooking? Did you put rice in water for a long time? Is the rice old or dry?
Is the menu selected correctly? Did you properly measure water? Did you open the top cover before cooking was finished?
Did you use the measuring cup? Did you use proper amount of water? Is it the menu selected correctly?
Did you close the top cover? Please check it the power cord is plugged. Did it warm over 12 hours? Is there any other substance such as rice scoop or cold rice?
Temperature sensor or fan motor does not work properly.
Keeping warm was set in “Sleeping” mode
It shows on the display when pressing “Start” button again, or when the cooking has finished and you
ve never turned the
handle to ‘Unlock’.
Warming passed time mark blinks during keeping warm
24 hours has not passed yet after keeping warm
Do the following
Keep warm after cancelling or setting “Sleep Keeping Warm” mode depending on the necessity
It can be solved by turning handle to ‘Unlock’
and then turn to ‘Lock’.
This function alarms if the rice remained warm for more than 24 hours.
Unplug the power cord and call the Service center.
Close the top cover perfectly. Always keep the power on while warming. As possible, keep warming time within 12 hours. Don’t warm rice with other substance.
Refer to page 15~16
Select the correct menu. Properly measure water. Open the top cover after cooking finished.
Refer to page 15~16
Add water about half the notch and then cook.
Press the “Pressure Cook” button once. And check “ ”sign on the display.
Blackout backup power source for the Rice Cooker, see page 14.
CHECK BEFORE ASKING
FOR SERVICE
CHECK BEFORE ASKING FOR SERVICE
If there is a problem with your cooker, check the following details before requesting service to your dealer. Sometimes the cooker may not operate as desired if used incorrectly.
Case Check points Do the following
When the Pressure “Cook/Turbo” Timer button does not operate with “ ”
When the rice is badly sticky.
Did you turn the Lock/Unlock Handle to “Lock”
Is “pressure” lamp on?
Is there any rice or any other alien substance on the temperature sensor or the bottom surface of the inner pot?
When the button cannot operate with “ ”
Is the inner pot inserted? Check the rated voltage?
Clean all the alien substance on the temperature sensor or the bottom surface of the inner pot.
Please turn the “Lock/Unlock” handle to “Lock”.
Please insert inner pot. This product is AC 220~240V only.
When the time cannot be preset.
When you smell after and before cooking?
When the top cover cannot be closed.
Is the current time correct? Is AM or PM set properly? Did you set the reservation time over 13 hours?
Did you clean it after cooking?
Is the inner pot correctly inserted in the main body? Is the Lock/Unlock handle on the top cover set to “Lock”? Is there hot food in the inner pot?
Check the rated Voltage?
Cut the power and contact customer service. It is normal to get “ ” when putting only water. This is only for AC 220~240V.
Set the current time. (Refer to page 14) Check the AM and PM. Maximum reservation time is 13 hours.
(Refer to page 25~26)
Please clean it after cooking.
When "tick, tick" sounds occurs while cooking and warming.
Is it the sound of cooking relay?
Did you wipe the moisture of bottom of inner pot?
Please put in the inner pot perfectly.
Please turn the “Lock/Unlock” handle to “Lock”.
Pull the pressure handle to aside once.
When “ ” is showed on the LCD
It is normal that the "tick, tick" sound of relay is an on and off operation. The moisture of the bottom of the inner pot may cause "tick, tick" sound. Please wipe the moisture.
www.cuckoo.co.kr
CHECK BEFORE ASKING
FOR SERVICE
If there is a problem with your cooker, check the following details before requesting service to your dealer. Sometimes the cooker may not operate as desired if used incorrectly.
Case
When cannot turn to “Unlock”.
When the top cover cannot open although the Lock/Unlock handle is turned to "Unlock".
When the steam exhausted between the top cover.
When the “Cancel” button does not operate while cooking.
When you hear weird noises during cooking and warming
Check points
Did you turn the “Lock/Unlock” handle while cooking?
Did you turn the “Lock/Unlock” handle before exhausting steam perfectly?
Is there an external substance on the packing?
Is packing too old?
Is the inner pot hot?
Is there a wind blowing sound when cooking the rice? Is there a “Chi” sound when warming the rice?
Do the following
Don’t open the top cover while cooking. If you want to open top cover while cooking, press the “Cancel” button more than 2 seconds and exhaust the steam. Pull the pressure handle to aside once and exhaust the steam perfectly.
Because of the pressure. Pull the pressure handle to aside once and exhaust the steam perfectly.
Clean the packing throughly. Keep the packing clean. If the steam is exhausted through the top cover, please power off and contact the service center and dealer. Packing life cycle is 12 months, please replace the packing per 1 year.
Keep pressing the “Cancel” button for 2 seconds for safety reason if you want to cancel while cooking. Be careful of hot steam emission or hot contents spattered from the automatic steam outlet during cancellation.
This is the sound of the fan motor to cool the internal parts. This is normal. The “Chi” sound during the warming process is the sound of IH cooker operating. This is normal.
Bean(other grains) is half cooked.
Is bean (other grains) too dry?
Soak or steam beans and other grains before cooking in the pressure cooker in order to avoid partially cooked beans or grains. Beans should be soaked for-2-minutes or steamed for-2-minutes prior to cooking, depending on your taste.
Loading...
