User Manual
M Series
LED BACKLIGHT Monitor
1. Introduction 6
4. Access Features 9
2. Installation 7
5. Technical Information 14
3. Front Panel overview 8
Content
F.C.C STATEMENT ⁄ IMPORTANT SAFEGUARDS
1.1 Features...........................................................................................................6
1.2 Checking List..................................................................................................6
4.1 Switching the Monitor On/Off...............................................................9
4.2 Power Indicator........................................................................................9
4.3 Menu Features..........................................................................................9
4.4 OSD Functional Control Description.....................................................10
4.5 Preset Modes Timing Chart.....................................................................12
4.6 Plug and Play............................................................................................13
2.1 Install the Pedestal........................................................................................7
2.2 Connect Your Monitor to Computer.............................................................7
5.1 D-SUB Signal Connector Pin Assignment...............................................14
5.2 Visual Inspection....................................................................................16
5.3 Trouble Shooting....................................................................................16
F.C.C STATEMENT
FEDERAL COMMUNICATIONS COMMISSION
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer of an experienced radio/TV technician for help.
CAUTION:
Changes or modications not expressly approved by the manufacturer
responsible for compliance could void the user's authority to operate
the equipment.
NOTE:
The use of a non-shielded interface cable with this equipment is prohibited
IMPORTANT SAFEGUARDS
Warnings:
1. Read all of these instructions Save these instructions for later use,
please.
2. Unplug this monitor from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
3. Do not use attachments not recommended by the monitor manufacturer
as they may cause hazards.
4. Do not use this monitor near water. For example near a bathtub,
washbowl, kitchen sink, or laundry tub, in a wet basement, or near a
swimming pool,etc...
5. Do not place this monitor on an unstable cart, stand, or table. The
monitor may fall, causing serious injury to a child or adult and serious
damage to the appliance. Use only with a cart or stand recommended
by the manufacturer or sold with monitor. Wall or shelf mounting should
follow the manufacturer’s instructions, and should use a mounting kit
approved by the manufacturer.
6. Slots and openings in the cabinet and the back or bottom are provided
for ventilation, and to insure reliable operation of the television receiver
and to protect it from overheating, these openings must not be blocked
or covered. The openings should never be blocked by placing the
monitor on a bed, sofa, rug, or other similar surface. This monitor should
never be placed near or over a radiator or heat register. This monitor
should not be placed in built-in installation such as a bookcase unless
proper ventilation is provided.
7. This monitor should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supplied in your home, consult your monitor dealer or local power
company.
8. Follow all warnings and instructions marked on the monitor.
9. For added protection for this monitor, when it is left unattended and
unused for long periods of time, unplug it from the wall outlet. This will
prevent damage to the monitor due to power-line surges.
10 . Do not overload wall outlets and extension cords as this can result into
re or electric shock.
11 . Never push objects of any kind into this monitor through cabinet slots
as they may touch dangerous voltage points or short out parts that could
result in a re or electric shock. Never spill liquid of any kind on the
monitor.
12 . Do not attempt to service this monitor yourself since opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
13 .Unplug this monitor from the wall outlet and refer servicing to qualied
service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the monitor.
c. If the monitor has been exposed to rain or water.
d. If the monitor does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as improper adjustment of other controls may result in
damage and will often require extensive work by a qualied technician
to restore the monitor to normal operation.
e. If the monitor has been dropped or the cabinet has been damaged.
f. When the monitor exhibits a distinct change in performance this
indicated a need for service.
14 . When replacement parts are required, be sure the service technician
has used replacement parts specied by the manufacturer that have
the same characteristics as the original parts. Unauthorized substitutions
may result in re, electric shock, or other hazards.
15 . Upon completion of any service or repairs to this monitor, ask the service
technician to perform routine safety checks to determine that the
monitor is in safe operating condition.
16 . The socket outlet shall be near the equipment and shall be easily
accessible.
17 . The power cord or the plug portion of the adapter is used as the main
disconnect device.
6
1. Introduction
1.1 Features.
►Microprocessor based with OSD (On Screen Display) control.
►Compatible with standard IBM VGA, extended VGA, super VGA, IBM
XGA, SXGA modes, as well as VESA resolution standards.
►Universal power supply 100-240 Vac, 50/60Hz(Power box)/DC
12V(Monitor)
►Microsoft Windows 95/98/2000/XP/VISTA/WIN7 compatible & VESA
Display
1.2 Checking List
Please make sure the following items are included with your LCD monitor:
Your monitor
AC-DC adapter
Signal cable
If any of these items are missing, please contact with your dealer for
technical support and customer service.
