CTI Products NCB-IM with Internal PSTN Modem User Manual

Download

Model NCB/IM

Network Combiner Module

with Internal Modem

Wide Area Router for LONWORKS® Networks

User Guide # S2-60419-310

68-10822-310

CTI Products, Inc. NCB/IM User Guide

Standard Limited Hardware Warranty

LIMITED WARRANTY. Equipment manufactured by CTI Products, Inc. is warranted to be free from defects in material and workmanship for

a period of ONE (1) YEAR from date of shipment to original purchaser. Under this warranty, our obligation is limited to repairing or replacing any equipment proved to be defective by our inspection within one year of sale to the original purchaser. This warranty shall not apply to equipment which has been repaired outside our plant in any way, so as to, in the judgment of CTI Products, Inc. affect its stability or reliability, nor which has been operated in a manner exceeding its specifications, nor which has been altered, defaced, or damaged by lightning.

CUSTOMER REMEDIES. In the event of a defect, malfunction, or failure to conform to specifications established by the seller during the period shown, the customer shall call CTI Products, Inc. to obtain a Return Authorization Number and return the product or module, shipping and insurance prepaid. CTI Products, Inc., will then at its option, either repair or replace the product or module and return it, shipping prepaid, or refund the purchase price thereof. On-site labor at the purchaser's location is not included in this warranty.

EQUIPMENT NOT MANUFACTURED BY CTI Products, Inc. Equipment not manufactured by CTI Products, Inc. is excluded from this warranty, but is subject to the warranty provided by its manufacturer, a copy of which will be supplied to you upon specific written request.

NO OTHER WARRANTIES. The foregoing constitutes the sole and exclusive remedy of the buyer and exclusive liability of CTI Products, Inc., AND IS IN LIEU OF ANY AND ALL OTHER WARRANTIES EXPRESSED OR IMPLIED OR STATUTORY AS TO MERCHANTABILITY, FITNESS FOR PURPOSE SOLD, DESCRIPTION, QUALITY, PRODUCTIVENESS OR ANY OTHER MATTER.

NO LIABILITY FOR CONSEQUENTIAL DAMAGES. WITHOUT LIMITING THE FOREGOING, IN NO EVENT SHALL CTI PRODUCTS, INC. OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE CTI PRODUCTS, INC. EQUIPMENT BY PURCHASER OR OTHER THIRD PARTY, WHETHER UNDER THEORY OF CONTRACT, TORT (INCLUDING NEGLIGENCE), INDEMNITY, PRODUCT LIABILITY OR OTHERWISE, EVEN IF CTI PRODUCTS, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSSES. IN NO EVENT SHALL CTI PRODUCTS, INC.’S, LIABILITY EXCEED THE TOTAL AMOUNT PAID BY PURCHASER FOR THE EQUIPMENT GIVING RISE TO SUCH LIABILITY.

Location: CTI Products, Inc

Phone: +1.513.595.5900 Fax: +1.513.595.5983 Web: www.ctiproducts.com E-mail, Sales: info@ctiproducts.com

Technical Support: lwsupport@ctiproducts.com

1211 West Sharon Road Cincinnati, OH 45240 USA

CTI Products, Inc. NCB/IM User Guide

This manual covers NCB units of Revision 300 or higher and NCB/Plug software revision

1.00 or higher. The NCB Unit Revision can be found on the rear of the unit following the

letter “U”. The NCB/Plug software revision can be found on the Help/About screen of the

program. If the revision of the product in hand is greater than that shown above, there may be additional features supported by the product that are not covered in this manual.

Information contained in this document is subject to change without notice and does not represent a commitment on the part of CTI Products, Inc.

No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the written permission of CTI Products, Inc.

This manual describes products which include copyrighted CTI Products, Inc. computer programs in semiconductor memory. CTI Products, Inc. reserves all rights for these programs, including the exclusive right to copy or reproduce the copyrighted computer programs in any form. No copyrighted computer program contained in products described in this manual may be copied, reproduced, decompiled, disassembled, or reversed engineered in any manner without express written permission of CTI Products, Inc. The purchase of products from CTI Products, Inc. shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of CTI Products, Inc., except for the normal non-exclusive, royalty fee license to use that arises by operation of law in the sale of the product.

Echelon, LON, LONWORKS, LONTALK, and Neuron are U.S. registered trademarks of Echelon Corporation.

CTI Products, Inc. NCB/IM User Guide

Radio Frequency Emissions and Immunity

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Limits specified in the standards listed below are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

UNITED STATES: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. CANADA: This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

EUROPE: This equipment has been tested and found to comform with the following standards: EN60950, EN50082-1, IEC801-2, IEC801-3, IEC801-4, and EN55022. This equipment complies with the requirements of the following directives: Low Voltage Directive 73/23/EEC, EMC Directive 89/336/EEC, and 93/68/EEC Harmonization of CE Marking

FCC Notices:

1. The Federal Communications Commission (FCC) has established Rules which permit this device to be directly connected to the telephone network. Standardized jacks are used for these connections. This equipment should not be used on party lines or coin lines.

2. If this device is malfunctioning, it may also be causing harm to the telephone network; this device should be disconnected until the source of the problem can be determined and until repair has been made. If this is not done, the telephone company may temporarily disconnect service.

3. The telephone company may make changes in its technical operations and procedures; if such changes affect the compatibility or use of this device, the telephone company is required to give adequate notice of the changes. You will be advised of your right to file a complaint with the FCC.

4. If the telephone company requests information on what equipment is connected to their lines, inform them of:

a. The telephone number this unit is connected to c. The USOC jack required b. The ringer equivalence number d. The FCC Registration Number Items ‘b’ and ‘d’ are indicated on the label. The Ringer Equivalence Number (REN) is used to determine how many devices can be connected to your telephone line. In most areas, the

sum of the RENs of all devices on any one line should not exceed five (5.0). If too many devices are attached, they may not ring properly.

WARNING: This device must only be attached to a private line using a JM8 connector.

Industry Canada (IC) Notices:

EQUIPMENT ATTACHMENT LIMITATIONS

 NOTICE: The Canadian Industry Canada label identifies certified equipment. This certification means that the equipment meets

certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfaction.

 Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local

telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

 Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any

repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

 Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal

metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate. The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device, to prevent overloading. The termination on a loop may consist of any combination of devices subject only to the requirement that the total of the Load Numbers of all the devices does not exceed 100.

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

CAUTIONS:

- Never install telephone wiring during a lightning storm.

- Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

- Never touch uninsulated telephone wiring or terminals unless the telephone line has been disconnected at the network interface.

- Use caution when installing or modifying telephone lines.

BABT Notice:

Although this equipment can use either loop disconnect or DTMF signalling, only the performance of the DTMF signalling is subject to regulatory requirements for correct operation. It is therefore strongly recommended that the equipment is set to use DTMF signalling for access to public or private emergency services. DTMF signalling also provides faster call set up.

iii

CTI Products, Inc. NCB/IM User Guide

TABLE OF CONTENTS

QUICK-START GUIDE ............................................................................................................................................. 1

1. INTRODUCTION ................................................................................................................................................... 3

WHAT IS AN NCB/IM UNIT? ...................................................................................................................................... 3

REFERENCE DOCUMENTS ........................................................................................................................................... 5

FRONT PANEL ............................................................................................................................................................. 6

2. SETUP AND OPERATION .................................................................................................................................... 9

STEP 1. MOUNTING .................................................................................................................................................... 9

STEP 2. SWITCH SETUP .............................................................................................................................................. 9

STEP 3. ELECTRICAL CONNECTIONS ........................................................................................................................ 11

STEP 4. IMPLEMENTATION IN A NETWORK ............................................................................................................... 13

STEP 5. CONTROLLING THE WAN CONNECTION...................................................................................................... 16

3. NETWORK VARIABLE (NV) CONTROL ....................................................................................................... 17

TYPICAL NV BINDINGS ............................................................................................................................................ 17

MODEM CONTROLLER OBJECT ................................................................................................................................. 18

TELEPHONE DIRECTORY OBJECT .............................................................................................................................. 24

GLOBAL CONTROL OBJECT ...................................................................................................................................... 25

4. NCB/PLUG CONFIGURATION PLUG-IN ....................................................................................................... 27

INSTALLATION .......................................................................................................................................................... 27

ACCESSING NCB/PLUG .......................................................................................................................................... 28

USAGE ................................................................ ................................ ................................................................ ...... 28

APPENDIX ................................................................................................................................................................ 31

APPENDIX A. FACTORY DEFAULT CONFIGURATION ................................................................................................. 31

APPENDIX B. MOUNTING OPTIONS ........................................................................................................................... 33

APPENDIX C. CONNECTOR DETAILS ......................................................................................................................... 36

APPENDIX D. NCB VERSION COMPARISON .............................................................................................................. 39

APPENDIX E. TROUBLESHOOTING ................................................................ ............................................................ 40

APPENDIX F. SPECIFICATIONS .................................................................................................................................. 45

APPENDIX G. MODEM NOTES ................................................................................................................................... 46

INDEX ........................................................................................................................................................................ 49

CTI Products, Inc. NCB/IM User Guide

QUICK-START GUIDE

This Quick Start Guide provides a concise series of steps to get a pair of the NCB modules “up and running”

quickly so that initial operation may be confirmed. It is important that all LONWORKS devices attached to the “NETWORK” connector of any one NCB module

use the same network transceiver . See “LONWORKS NETWORK TRANSCEIVERS” in section “1. INTRODUCTION”.

In the following steps, identify the two units as “NCB Unit 1” and “NCB Unit 2”.

Switch Settings

 For use in Dial-up mode, set the OPTION A switches on both NCB units as follows:

Switches 1 through 4 and 6 through 8 : UP Switch 5 : DOWN

 For use in 2-wire Leased-Line mode, set the OPTION A switches as follows:

Switch 1 : DOWN on NCB Unit 1 and UP on NCB Unit 2 Switches 2, 5 and 7 : DOWN Switches 3, 4, 6 and 8 : UP

Module Connection

 Connect LONWORKS network devices to the “NETWORK” connectors of each NCB unit (both RJ45s

and the terminal strip are in parallel). If using the RJ45 connector(s), connect to pins 1 & 2 (the rightmost two pins) and use caution, as other pins on these connectors carry DC power.

 If using Dial-up mode, connect the “LINE” connector of each NCB unit to a standard analog

telephone line using the telephone cables supplied with the NCB modules. If using Leased-Line mode, connect the “LINE” connectors on each NCB together using one of the telephone cords provided with the NCB modules.

 If optional handsets were included with the NCB units, connect one to the “AUDIO” connector of each

NCB.

 Connect power to the NCB units via the front panel “DC IN” connector.

 If using dial-up mode, the NCB units are ready to be given a dialing command. Proceed directly to

“Step 4. Implementation in a Network”in section “2. SETUP AND OPERATION”.

 If using Leased-Line mode, the “OH“ LED will light on both NCB units and the modems will

automatically begin the training sequence. If optional handsets are connected, the training process can be monitored with them. Within 10 seconds, the “CD” LEDs on both NCB units will light, indicating a successful connection. The modules are now ready for use. Any LonTalk packets entering one NCB unit will exit the other and vice-versa. Disconnecting, then re-connecting the telephone cable will cause the connection to be dropped, then automatically re-established.

NOTE: If using Leased-Line mode, this quickstart setup includes connecting the NCBs

“back-to-back” using 2 wire mode and a reduced transmit level. In an actual leased-line installation involving longer telephone cable lengths, change OPTION A Switch 7 to UP to configure the NCB’s modem to output full transmit power, and set OPTION A Switch 8 UP for 2-wire mode or DOWN for 4-wire mode.

Quick-Start Guide 1

CTI Products, Inc. NCB/IM User Guide

Quick-Start Guide 2

CTI Products, Inc. NCB/IM User Guide

CA-80070-100

LONWORKS

NODE

LONWORKS

NODE

LONWORKS

NODE

LONWORKS

NODE

NCB

LONWORKS

NODE

LONWORKS

NODE

LONWORKS

NODE

LONWORKS

NODE

NCB

STANDARD

VOICE GRADE

CIRCUIT

BUILDING 1

BUILDING 2

Read this section to learn the general function and capabilities of an NCB Router

1. INTRODUCTION

WHAT IS AN NCB/IM UNIT?

The Network Combiner NCB/IMTM Module is a wide-area router with an internal modem for LonWorks networks. The NCB/IM unit is used in pairs to connect

LONWORKS networks real-time, spanning distances from building-wide to

worldwide. The communication channel spanning the distance between local networks can be any analog or digitized analog channel that is capable of carrying V.32 terbo standard modem signaling, including standard dial-up Public Switched Telephone Network (PSTN) circuits, 2-wire or 4-wire leased lines, microwave channels, PBX circuits, etc. Data transfer between distant networks via an NCB module pair is "live", delayed only by the transit time through the routers and modem connections.

The NCB module uses router technology so that no custom coding or additional hardware is necessary to seamlessly connect multiple networks across very large distances. The NCB module is self-contained, easily configured with standard network management tools, and requires no custom programming or coding changes in system nodes.

The NCB/IM unit contains Modem Controller and Telephone Directory objects.

Basic Application

A basic application of the NCB module is where two multi-node LONWORKS networks, separated by a distance beyond the reach of conventional wired media, need to be interconnected, as in Figure 1. This distance could be across a large building, business campus, city, etc. Using the NCB module, this interconnection is accomplished using one NCB module local to each network site and a single voice-grade telephone circuit connecting the two NCB modules. Additional networks can be added to this unified network by simply adding an NCB module pair per network.

Figure 1 Networks in two buildings connected with NCB modules

LONWORKS Network Transceivers

The local LONWORKS networks at different sites do not need to use the same network transceiver type. For example, an FTT-10A network, a TPT/XF-78 network, and a PLT-22 network can all be interconnected by using pairs of NCB modules with network transceivers matching the local network at each site.

1. Introduction 3

CTI Products, Inc. NCB/IM User Guide

LONWORKS

NETWORK

Side

ROUTER

LONWORKS

TRANSCEIVER

“DC IN”

Connector

“NETWORK”

Connector

“AUDIO”

Connector

“LINE”

Connector

To TELCO

CIRCUIT

Side

SMX

TRANSCEIVER

POWER SUPPLY

CONTROL

NEURON

PROCESSOR

INTERNAL

MODEM

HANDSET



NCB units are available with an option for LONWORKS network transceiver type. The ordering code on the rear of the NCB lists the installed options. This ordering code is of the form: NCB/IM-Txxx-xx, where ‘T’ indicates the transceiver type.

The following LONWORKS network transceiver options are available: A = FTT-10A K = SMX RS485 B = TPT/XF-78 M = SMX PL22 C = TPT/XF-1250 X = None (SMX ready)

Line Port

The internal modem in the NCB/IM module uses proven V.32 terbo modulation, transferring data at 19,200 bits per second. Dial-up as well as 2-wire and 4-wire leased lines are supported.

The internal modem is unique in its ability to transfer voice simultaneous to data using only a single voice-grade circuit between two NCB modules. This bidirectional voice channel exists between each NCB module pair and is accessible via the “AUDIO” connector on the NCB module. This live voice feature can be used in any application that requires live data as well as voice communication between personnel or equipment at separate sites.

Data Flow

There are three sources of message packets within the NCB module. The first source is the LONWORKS NETWORK connector on the front of the unit. The second is the Telco “LINE” connector on the front of the

unit. The third source is the Control Neuron Processor. Message packets originating from any of these sources are sent to the other two. This message packet flow is shown in the block diagram of Figure 2.

Figure 2 NCB Network Combiner Block Diagram

The “NETWORK” connector attaches to the local LONWORKS network using a compatible transceiver

internal to the NCB module and is associated with Side B of the internal router.

The “LINE” connector attaches to the telephone circuit as the link to the NCB unit at the other network site

and is associated with Side A of the internal router.

The Control Neuron Processor allows network management messages to be sent to the NCB module for

connection control and status monitoring and is associated with Side A of the internal router.

1. Introduction 4

CTI Products, Inc. NCB/IM User Guide

Document

Source

Reference Number

Message Buffer Configuration

CD ROM or www.ctiproducts.com

Technical Note TN010

Using Explicit Messages to Configure and Monitor Dialing Parameters of an NCB

CD ROM or www.ctiproducts.com

Technical Note TN022

Using NCBCON to Configure and Monitor Dialing Parameters of an NCB

CD ROM or www.ctiproducts.com

Technical Note TN023 Setting the PCNSS Card to Network Interface Mode

CD ROM or www.ctiproducts.com

Technical Note TN024 SMX Transceiver Installation

CD ROM or www.ctiproducts.com

Technical Note TN025

NCB Installation with Network Management Tools

CD ROM or www.ctiproducts.com

Technical Note TN026

LONWORKS Router User’s Guide

Echelon

078-0018-01B

Router Function

The router contained in each NCB module may be configured as a repeater, bridge, or configured router. The easiest configuration is as a repeater, where all messages which enter the NCB module (via any of the three data sources described above) are simply passed to the other two sources, regardless of the domain, subnet/node, or group destination address. A bridge only passes messages that match one of the two domain IDs configured on the router. A configured router only passes messages that match a domain ID as well as a set of subnet or group numbers. The proper choice of router mode depends on desired simplicity of installation versus required system performance.

REFERENCE DOCUMENTS

The following additional information is available from the sources indicated.

1. Introduction 5

CTI Products, Inc. NCB/IM User Guide

1234567

OPTION A

DC IN

ERR

ACT

PWR

NETWORK

OUT

RSVC

CSVC

AUDIO

LINECDOH

RESET

CMD

NCB

NETWORK COMBINER

NETWORK

PWR LED Indicates correct input power ERR LED Indicates an error condition ACT LED Indicates LonWorks packet

activity in router

LonWorks NETWORK Connections

RJ45 and Screw Terminal

DC IN Connector for input power

AUDIO Connector Simultaneous Voice/Data CD LED Carrier Detected and

training sequence completed

OH LED Off Hook condition LINE Connector Telco connection

RESET Button

CMD Button Temporarily enables Auto-

Answer mode (see below)

CSVC Button Initiates Service Request

from Control Neuron

RSVC Button Initiates Service Request

from Router

OPTION A Switches

Selects Internal Modem

and LonWorks Addressing parameters. (See Setup and Operation for more detail)

FRONT PANEL

Figure 3 NCB/IM Module Front Panel

Front Panel Indicators and Buttons

PWR LED (Green) - Indicates condition of DC input power or a “Wink” command.

 Always On: Correct DC input power is present.

 Flashing Continuously: DC input to module is below minimum required voltage.

 Flashes for 2 Seconds: A “Wink” network management command has been sent to the Control

Neuron Processor.

ERR LED (Red) – Indicates a possible error condition.

 Always On: A diagnostic error has been detected. Press the “RESET” button. If the “ERR” LED now

stays off, the EEPROM contained invalid data and has been reinitialized. Any non-volatile information must be re-entered by using the NCB/Plug configuration plug-in or the DOS NCBCON program. If the LED stays on solid, a hardware problem is indicated. Contact technical support for assistance.

 Slow Flash: (once per second) LONWORKS configuration information is insufficient. Using a

Network Management Tool, re-commission the internal router nodes (and optionally, the Control Neuron Processor node).

ACT LED (Yellow) - Indicates a packet has been passed by the NCB router. OH LED (Green) - Indicates the modem is OffHook. CD LED (Yellow) - Indicates the modem has detected carrier and completed the training sequence with the

distant modem.

1. Introduction 6

CTI Products, Inc. NCB/IM User Guide

CMD Button

This button can be used to temporarily enable the Auto Answer function in Dial-up mode. This is useful if Auto Answer mode has been inadvertently disabled on a remote NCB. When this occurs, and a connection with this remote unit is broken, it will no longer automatically answer an incoming call. To re-enable Auto Answer mode, proceed as follows:

 Press and hold the “CMD” button on the remote NCB

 Press and release the “RESET” button on the remote NCB.

 Wait until the “PWR” LED begins to flash on the remote NCB, then release the “CMD” button.

These steps will temporarily enable Auto Answer mode for the remote NCB for one incoming call. Use the NCB/Plug configuration plug-in, NCBCON, or explicit messages to re-enable Auto Answer mode for future connections.

1. Introduction 7

CTI Products, Inc. NCB/IM User Guide

1. Introduction 8

CTI Products, Inc. NCB/IM User Guide

1234567

3. Not Used

4. Not Used

5. Control Neuron Addressing Method....... Hardware Network Management Tool

6. Control Neuron Hardware Subnet/Node 255/2 255/1

7. Leased-Line Transmit Level .................. -10dBm (Normal) -16dBm (Back-to-back)

8. Leased-Line Wiring................................2-Wire 4-Wire

UP DOWN

Modem Mode

Modem Mode Switch: 1 2

Dial-up: Auto Answer Enabled UP UP Dial-up: Auto Answer Disabled DN UP Leased-Line: Answer UP DN Leased-Line: Originate DN DN

See Appendix B for Mounting Option details.

Follow the steps in this section to setup an NCB Router for the first time

2. SETUP AND OPERATION

STEP 1. MOUNTING

Non-slip rubber feet are included on all NCB modules to allow them to conveniently rest on any horizontal surface. Four 6-32 threaded holes are also available on the bottom of the module to allow bolting of the module in any convenient orientation. WARNING: Care should be taken to limit protrusion of the screw into the module to no more than 0.125 inch from the module bottom surface!

Mounting kits are available as options to allow wall or rack (19” EIA) mounting of the NCB module.

When wall or rack mounting the NCB, a suitable safety and protective earth ground should be provided to the metal enclosure. The protective earth ground provides a path to ground for electrostatic discharge (ESD) energy. This connection is most conveniently made directly to the wall mount bracket or rack plate.

STEP 2. SWITCH SETUP

OPTION A Switches

OPTION A switches set the internal modem configuration (switches 1, 2, 7, and 8), and LONWORKS addressing parameters (switches 5 and 6). Leave the unused switches (3 and 4) in the UP position. The

position of the OPTION A switches are read by the NCB at module power-up or after pressing the “RESET” button on the front panel.

2. Setup and Operation 9

CTI Products, Inc. NCB/IM User Guide

Which Modem Mode should be used?

Leased-Line Mode

This is the simplest mode as long as a permanently connected (non-switched) leased telephone line is available. After power-

up or reset, an NCB in ‘Leased-Line: Originate’ mode will immediately attempt to connect with an NCB in ‘Leased-

Line:Answer’ mode on the line. If the connection is lost, the

process repeats.

Manual Dial-Up Mode

This mode uses a switched telephone line and requires command information be sent to the NCB that will initiate a dial sequence. This command information is sent in the form of Network Variables or Explicit Messages. After receipt of a dialing command, the NCB will attempt to connect with the NCB connected to the specified phone number. When the NCB being dialed detects an incoming ring, a connection will be established. Command information must also be sent to disconnect after transmission of all messages is complete.

Perpetual Dial-Up Mode

This mode simulates the constant connection of a Leased-Line, but uses a switched Dial-Up line. The NCB initiating a call must have the phone number of another NCB stored internally. This can be accomplished with the NCB/Plug plug-in or the DOS NCBCON program. The connection will be attempted whenever the link does not exist.

See “APPENDIX G. MODEM NOTES” for more details.

Tutorial . . .

Setting the Internal Modem Configuration (Switches 1, 2, 7, and 8)

Will a Dial-Up line be used for this Network?

 If Manual or Perpetual

Dial-up Mode is required, see “DIAL-UP CIRCUITS” following in

this section.

 If using a leased

telephone line, see “LEASED-LINE CIRCUITS” following in this section.

Dial-Up Circuits (OPTION A Switch 2, UP)

1) OPTION A Switch 2 must be in the UP position for dial-up operation (Manual or Perpetual

mode). In dial-up mode, switches 7 and 8 are ignored.

2) For an NCB to be capable of both originating and answering a call, Auto-Answer must be

enabled (OPTION A Switch 1, UP). To only originate calls, Auto-Answer should be disabled (OPTION A, Switch 1, DOWN).

Note: with OPTION A Switch 5 DOWN (see below), OPTION A Switch 1 is ignored. In this case, Auto-Answer mode is enabled/disabled by Network Variables or the NCB/Plug plug-in.

Leased-Line Circuits (OPTION A Switch 2, DOWN)

1) When using Leased-Line circuits, one NCB must be in ‘Leased-Line: Originate’ mode, and

the other NCB must be in ‘Leased-Line: Answer’ mode. (It does not matter which NCB

module is in which mode).

Note: With OPTION A Switch 2 DOWN (to enable Leased-Line modem mode), the AutoAnswer enable/disable setting using Network Variables or the NCB/Plug plug-in is ignored.

2. Setup and Operation 10

CTI Products, Inc. NCB/IM User Guide

NETWORK

OUT

NETWORK

See Appendix C for Connector Details

2) OPTION A Switch 7 is used to set the transmit level from the modem and should be normally

left in the UP position. If two NCB units are to be connected “back-to-back” in Leased-Line

mode with only a short cable between the “LINE” connector on each unit (in lab test

situations, for instance), Switch 7 must be set to the DOWN position in order for the two modems to connect properly.

3) OPTION A Switch 8 should be set to match the type of leased telephone line being connected

: 2-wire or 4-wire.

Setting the LONWORKS Addressing Parameters (Switches 5 and 6)

Switches 5 and 6 provide a simple (but very limited) method of setting the LONWORKS domain/subnet/node address of the internal Control Neuron Processor. This method is useful for systems with two NCB modules, but does not provide enough flexibility for larger systems. (Standard Network Management Tools are a much better choice.) For more information on setting this address, see “STEP 4. IMPLEMENTATION IN A NETWORK” for a tutorial on network management tools.

 If OPTION A Switch 5 is UP, Switch 6 determines a static subnet/node address for the Control Neuron

Processor: Switch 6 DOWN fixes the Control Neuron Processor subnet/node address at 255/1 in the zero-length domain, while Switch 6 UP fixes the subnet/node address at 255/2 in the zero-length domain. This setting allows for a quick evaluation of the NCB modules, requiring minimal user setup.

 If OPTION A Switch 5 is DOWN, dynamic determination of the domain/subnet/node number by a

Network Management Tool is allowed.

STEP 3. ELECTRICAL CONNECTIONS

LONWORKS Network Connection

The local LONWORKS network must be attached to the NCB module via the “NETWORK” connector following standard Echelon guidelines as to cable type, cable length, and termination appropriate for the selected transceiver.

The dual RJ45 “NETWORK” connector allows a daisy-chained network connection method, as the network pins of the two RJ45 connector are directly paralleled. Note that other pins on the RJ45 are connected to circuit ground and DC power.

The 2 pin removable terminal strip is wired in parallel with the network connections on the dual RJ45 connector.

NOTE: If your NCB module was purchased without a LONWORKS transceiver (SMX-ready), refer to Technical Note TN025 to install your SMX transceiver.

2. Setup and Operation 11

CTI Products, Inc. NCB/IM User Guide

LINE

See APPENDIX G for 4-Wire Leased-Line pinouts and wire

AUDIO

See APPENDIX C for connector type and pinout.

Telephone Line Connection

The telephone circuit connection must be made using the “LINE” connector

Dial-Up

A dial-up connection uses a 2-wire connection scheme to a standard telephone circuit. A standard telephone cord can be used.

Leased-Line

A leased-line connection can use either a 2-wire or 4-wire scheme to a dedicated leased-line circuit:

2-Wire Leased-Line

In 2-wire Leased-Line mode, the audio circuit must pass audio simultaneously in both directions. For this mode, use pins 3 & 4 (red and green) of the “LINE” connector (see “APPENDIX C. CONNECTOR DETAILS”). Pins 2 and 5 are unused in 2-wire mode.

For testing “on the bench” in 2-wire Leased-Line mode, two NCB units may be connected “back-to-back” using the standard modular telephone cable provided with each NCB unit. For this short cable back-to-back

connection, however, the OPTION A Switch 7 must be placed in the DOWN position (followed by resetting the NCB unit) on BOTH NCB units. This lowers the transmit level to prevent clipping of the signal due to the

short (near lossless) cable. Be sure to return OPTION A Switch 7 to the UP position before installing the NCB unit in the field.

4-Wire Leased-Line

In 4-wire Leased-Line mode, two pairs are used, one for Transmitting to the other NCB and one for Receiving from the other NCB. For this mode, pins 3 & 4 (red

and green) of the “LINE” connector carries ‘transmit audio’ from this unit to the other unit and pins 2 & 5 (black and yellow) carries ‘receive audio’ to this unit

from the other unit. A 4-wire leased-line telephone circuit has two channels and each channel carries audio in only one direction.

For testing “on the bench” in 4-wire Leased-Line mode, two NCB units must be connected “back-to-back” by connecting the transmit pair of each unit to the receive pair of the opposite unit. This cannot be done with the telephone cable having modular connectors on both ends, as this cable is wired “straight through”. Instead, use the modular plug to spade lug cables provided. Also, for this short cable back-to-back connection, the

OPTION A Switch 7 must be placed in the DOWN position (followed by resetting the NCB unit) on BOTH NCB units. This lowers the transmit level to prevent clipping of the signal due to the short (near lossless) cable.

Be sure to return OPTION A Switch 7 to the UP position before installing the NCB unit in the field.

Handset Connection

A standard telephone handset or other audio input and output device may be

connected to the "AUDIO" connector to allow use of the simultaneous voice/data feature of the NCB module. Audio directly from the telephone circuit is routed to this connector during modem dialing and training to permit monitoring of call establishment (as typical modems provide via an internal speaker). After training is

completed (when the CD LED turns on), bidirectional audio from the simultaneous voice/data system is available at this connector. The audio on this connector is digitized and transferred across the modem link by

2. Setup and Operation 12

CTI Products, Inc. NCB/IM User Guide

Why is a Network Management Tool needed?

Factory Default Settings

An NCB could be placed in a network using the configuration as it was shipped from the factory (Repeater Mode, fixed Subnet/Node address). All messages would simply be passed through the NCB. This may suffice for small networks where channel bandwidth and message timing issues are of no concern.

Use of a Network Management Tool

If a larger network is planned, and channel bandwidth limitations require segmentation of message traffic, then a Network Management Tool should be used to perform some or all of the following functions:

 Assign unique addresses to each NCB Router

and Control Neuron

 Configure domain address tables in routers  Optimally set Transaction Timers based on

Channel Delays

 Configure forwarding tables in routers for traffic

segmentation

Tutorial . . .

DC IN

utilizing a portion of the connection bandwidth. This utilization is dynamic and only consumes bandwidth when audio is detected into the “AUDIO” connector.

NOTE: Data throughput across the modem channel is decreased by 7200 bits-per-second when audio input is detected at either handset. To maximize data throughput, handsets should normally remain disconnected or the input audio be kept muted on any NCB that may be installed where normal background noise could be detected by the handset. Audio input is automatically un-muted when a connection is established.

DC Power Connection

DC power must be attached to the NCB module via the DC IN connector (see

“APPENDIX C. CONNECTOR DETAILS”). Apply DC power to the NCB module only after all other connections have been made. A wall plug-in style power

supply designed for the NCB module is an available option.

STEP 4. IMPLEMENTATION IN A NETWORK

Will a Network Management Tool Be Used?

 If NO, and the NCB will be used

with its factory default settings (Repeater Mode), skip the rest of this section. The NCB is ready to function in a network.

 If NO, and the DOS NCBCON

program will be used to access and configure the Control Neuron Processor, then see Technical Note TN023.

 If YES, and LonMaker For

Windows will be used, be certain

2. Setup and Operation 13

that ‘OPTION A Switch 5 is in

the DOWN position, and see

Commissioning the NCB with LonMaker for Windows later in

this section.

 If YES, and another Network

Management Tool will be used, be

certain that ‘OPTION A Switch 5

is in the DOWN position, then see Technical Note TN026.

CTI Products, Inc. NCB/IM User Guide

Commissioning the NCB with LonMaker for Windows

Commissioning each NCB in a network with LonMaker for Windows involves commissioning two different network devices, both contained in the single NCB enclosure: a standard LONWORKS router, and the control neuron.

Since the standard LONWORKS router portion of an NCB router interfaces a LONWORKS channel to a Telephone (WAN) channel, it requires connection to two channels on the LonMaker drawing. A standard LONWORKS channel will be connected to Side B of the router shape, and a CUSTOM (Telephone, WAN) Channel will be connected to Side A of the router shape.

Commissioning the NCB control neuron requires that the .XIF file be available. The simplest way to do this is to install the NCB/Plug configuration plug-in, as this process copies the required .XIF file to the proper directory.

Installing NCB/Plug Plug-in

A) Install the NCB/Plug plug-in on your PC:

 Insert the NCB/Plug CD into your CD-ROM drive.  Click the Windows Start button, choose Run..., click Browse… , select the Setup application on the

NCB/Plug CD, and click Open .

 Follow the instructions displayed by the Setup application.  Restart your computer when the Setup application is complete.

NOTE: Two External Interface Files (.XIF) are automatically transferred to the hard drive when NCB/Plug plug-in is installed. NCBTLC30.XIF should be used for the Control Neuron Processor of an NCB of Version 3. NCBTLC20.XIF should be used for the Control Neuron Processor of an NCB of Version 2.

B) Register NCB/Plug with LonMaker for Windows:

 Click the Windows Start button, choose Programs, then NCBPlug, and click on NCBPlug.  Click Register Plug-In .  Click Exit .

C) Register NCB/Plug with the desired LonMaker for Windows network:

 Start LonMaker for Windows and open the desired network (be sure to checkmark the “Show all

Network Option Screens” box). When the “Plugin Registration” window within the Network

Wizard appears, highlight the “NCB_Plug” under “To Be Registered” and click Finish.

After installing and registering the NCB/Plug plugin, commission the “local NCB” (the one whose “NETWORK” port is connected to the NSI attached to LonMaker for Windows) using the following steps:

Commisioning the NCB Unit

A) Add a CUSTOM channel to the network drawing (this will be the WAN channel):

 Drag the Channel shape to the drawing. The “Channel Definition” window will be displayed.  Specify an appropriate Channel Name.  In the “Transceiver Type” field, click the down arrow and select CUSTOM.  In the “Delay” section, choose “Specify”, and enter a value of 150ms.  Enter a Channel Description, if desired.  Click OK to continue.

B) Add the standard LONWORKS router portion of the NCB to the network drawing:

 Drag the Router shape to the drawing. The “New Router Wizard” window will be displayed.  Specify the desired router name.  Click NEXT to continue.  In the “Channel A” Name field, choose the custom channel created in Step a.  In the “Channel B” Name field, choose the standard LONWORKS channel connected to the

“NETWORK” connector on the NCB.

 Click NEXT to continue.

2. Setup and Operation 14

CTI Products, Inc. NCB/IM User Guide

 Specify a Location string and Description, if desired. “Ping Interval” can be set as desired,

however should be set to “never” for remote NCB routers which are not connected full-time (for

example, those connected via dial-up telephone lines).

 Click NEXT to continue.  Specify desired advanced router properties. Router Type : Configured is recommended.  Click FINISH to complete the “New Router Wizard”.

C) Add the Control Neuron Processor to the network drawing:

 Drag the Device shape to the drawing. The “New Device Wizard” window will be displayed.  Specify the desired Device Name.  Click NEXT to continue.  In the “External Interface Definition” section, choose ‘Existing Template’, click the down arrow

and choose the appropriate template as follows: NCBTLC30.XIF should be used for the Control Neuron Processor of an NCB of Version 3, NCBTLC20.XIF should be used for the Control Neuron Processor of an NCB of Version 2.

 Click NEXT to continue.  In the “Channel: Name:” section, choose the custom channel connected to Side A of the router that

was created in Step a.

 Click NEXT to continue  Specify a Location string and Description, if desired. “Ping Interval” can be set as desired,

however should be set to “never” for remote NCBs which are not connected full-time (for example, those connected via dial-up telephone lines).

 Click FINISH to complete the “New Device Wizard”.

D) Commission the LONWORKS router:

 Right-click on the router shape added in step b.  Click on the Commission function  Select the Online state.  Click FINISH to commission the router.

E) Commission the Control Neuron:

 Right-click on the Control Neuron device shape added in step c.  Click on the Commission function  Select the Online state and Current Values in Database for Source of Configuration Property

Values.

 Click FINISH to commission the Control Neuron.

Figure 4 LonMaker NCB Diagram

2. Setup and Operation 15

CTI Products, Inc. NCB/IM User Guide

NCB/Plug

LNS plug-ins are applications that can be started from within an LNS application (such as the LonMaker tool) to perform a specialized task. The NCB/Plug plug-In implements configuration and query commands for the NCB. The NCB/Plug plug-In and Network Variables can be used simultaneously. The following functions are available if the NCB/Plug plug-In is installed:

 Send a dial string to a modem  Send a ‘Call Cancel’ command to a modem  Configure the NCB Telephone Directory  A window displays ‘Connect Status’  Select Dial Mode (Manual Dial or Perpetual

Connect)

 Select Auto Answer Enabled Mode  Request a soft reboot of NCB

Tutorial . . .

Network Variables

Network Variable Bindings allow a device to send and receive messages to and from other devices on the network. All configuration and status commands sent to the NCB module are carried on the LonTalk network in the form of Network Variables bound to the Control Neuron Processor inside the NCB module. The following functions are available if Network Variable bindings are made:

 Send a dial string to a modem  Send a ‘Call Cancel’ command to a modem  Request ‘Connect Status’ from a modem  Request a ‘Connect String’ output from a

modem

 Select Dial Mode (Manual Dial or Perpetual

Connect)

 Select Auto Answer Enabled Mode  Request a soft reboot of NCB  Request Product Name Output from NCB

Tutorial . . .

STEP 5. CONTROLLING THE WAN CONNECTION

At this point, the “local” NCB (the one connected to the LonMaker for Windows NSI) has been configured and fully commissioned for use. This last step involves making a connection to the “remote” NCB via the

Telephone (WAN) channel. If a leased-line connection has been made to the remote NCB (via the actual leased-line to be used, or via a

back-to-back test phone cable) and the remote NCB has been configured properly, the “CD” LED on both units should be on and message packets will flow between them across the Telephone circuit. To commission the remote NCB router and control neuron, repeat B through E of Commisioning the Router in Step 4 above.

If a dial-up circuit is being used between the local and remote NCB’s, then the local NCB must be commanded to dial into the remote NCB in order to commission it. The simplest way to command this dialing to occur is to use the NCB/Plug plugin. Alternatively, the Network Variable interface can be used. See the following tutorial. Once the dial-up connection is established with the remote NCB, message packets will flow between them. To commision the remote NCB router and control neuron, repeat B through E of Commissioning the Router in Step 4 above.

Network Variables and the NCB/Plug Plug-In

Will bindings be made to any Network Variables?

 If NO, you may wish to use the NCB/Plug

Plug-In (See ‘Tutorial: NCB/Plug’ above).

 If YES, see SECTION 3, NETWORK VARIABLE

(NV) CONTROL. You may also wish to use the NCB/Plug plug-in (See ‘Tutorial: NCB/Plug’ above).

2. Setup and Operation 16

Will NCB/Plug be used?

 If NO, you may wish to make Network

Variable bindings (See ‘Tutorial: Network Variables’ above).

 If YES, see SECTION 4, NCB/PLUG. You may

also wish to make Network Variable bindings (See ‘Tutorial: Network Variables’ above).

CTI Products, Inc. NCB/IM User Guide

This Section contains details of Network Variables and Bindings

Phone Book

Object

Some Alarm

Device

nviReqDialStr

nvoDialStr

Modem

Controller

Object

nviDialStr

nviCallCancel

nvoConnectStat

nvoCallCancel

nvoReqDialStr

nviConnectStat

3. NETWORK VARIABLE (NV) CONTROL

TYPICAL NV BINDINGS

All commands sent to the NCB module are carried on the LonTalk network in the form of Network Variables bound to the Control Neuron processor inside the NCB module (connected to Side A of the internal router). This section details the Functional Blocks (objects) and the network variables of each.

The Modem Controller Object is typically used in conjunction with the Directory Object and some other event-generating object which causes connection control information to be given to the Modem Controller Object. This information initiates modem dialing so that, once a connection is established, transfer of data can be accomplished via the modem.

Figure 5 is an example of typical network variable bindings.

Figure 5 Typical Network Variable Bindings

3. Network Variable Control 17

CTI Products, Inc. NCB/IM User Guide

Phone Book

Object 1

Some Alarm

Device

nviReqDialStr1

nvoDialStr1

Modem

Controller

Object 1

nviDialStr1

nviCallCancel1

nvoConnectStat1

nvoCallCancel1

nvoReqDialStr1

nviConnectStat1

Phone Book

Object 2

Modem

Controller

Object 2

nvoCallCancel2

nvoReqDialStr2

nviConnectStat2

nviReqDialStr2

nvoDialStr2

nviDialStr2

nviCallCancel2

nvoConnectStat2

The example in Figure 6 uses multiple Directory Objects with multiple Modem Controller Objects.

Figure 6 Multiple Directory Objects with Multiple Modem Controller Objects

MODEM CONTROLLER OBJECT

The Modem Controller Object is used to control the functions of the NCB Module’s data modem. These functions include configuration, connection control, and connection status. Two Modem Controller Objects are available, depending on the NCB model being used. ‘Internal Modem’ is for use with the NCB/IM. ‘External Modem 1’ and ‘External Modem 2’ are for use with the NCB-EM and NCB-IS. The Modem Controller Objects have identical network variable inputs and outputs.

3. Network Variable Control 18

CTI Products, Inc. NCB/IM User Guide

Value

Call Cancel

Off

No Action

Modem goes On-Hook

Network Variables

Dial String (Input)

C Language Syntax

network input SNVT_str_asc nviDialStr1; network input SNVT_str_asc nviDialStr2;

Usage

 A non-null string sent to this input network variable while the current modem connection state

is TEL_NOTINUSE causes the modem to go off hook, wait for a dial tone, then perform a dialing sequence using the provided character string.

 A non-null string sent to this input network variable while the current modem connection state

is other than TEL_NOTINUSE has no effect on the modem connection state or action.

 A null string sent to this input regardless of current modem connection state has no effect on

the modem connection state or action.

Valid Range

 A NULL terminated ASCII string up to 31 bytes in length.  All ASCII characters are valid, with specific support for the following:

 Letter P (upper or lower case, first character in string only) – Pulse Dial.  Digits (0-9,*,#) – Dials digit directly.  Comma (,) – Pauses 2 seconds for each comma encountered.  Letter W (upper or lower case) – Pauses until a dial tone is detected.  Exclamation Point (!) – Hookflash, go onhook for 0.5 seconds, then back offhook.  Punctuation (space, dash, left and right parentheses) – Valid in string, but ignored.

Call Cancel (Input)

C Language Syntax

network input SNVT_switch nviCallCancel1; network input SNVT_switch nviCallCancel2;

Usage

 An input value of ON to this network variable causes the modem to immediately go onhook,

terminating the connection attempt in progress or breaking the existing connection to the distant modem. The modem returns to the TEL_NOTINUSE state.

Valid Range

Default Value

Off

3. Network Variable Control 19

CTI Products, Inc. NCB/IM User Guide

Value

Output String

Description

TEL_NOTINUSE

Modem onhook and idle

TEL_OFFHOOK

Modem waiting for dialtone

TEL_DIALING

Modem dialing (and training for NCB/EM)

TEL_DIALCOMP

Modem executing mid dial pause (NCB/IM only)

TEL_ANSWERED

Modem training (NCB/IM only)

TEL_TALKING

Modem connected and online with distant modem, ready to send data

TEL_HOLD

Modem retraining (NCB/IM only)

TEL_ERROR

Modem initializing, not present, or port diabled

Connect Status (Output)

C Language Syntax

network output SNVT_telcom nvoCnctStat1; network output SNVT_telcom nvoCnctStat2;

Usage

 This output network variable provides the current state of the modem connection process.

Valid Range

When Transmitted

The output is updated upon each change in modem connection state.

Update Rate

The output is updated only once per change in modem connection state.

Connect String (Output)

C Language Syntax

network output SNVT_str_asc nvoCnctStr1; network output SNVT_str_asc nvoCnctStr2;

Usage

 This output network variable provides detail in text format of the connection parameters

established after the modem connection has reached the TEL_TALKING state. These parameters include connect speed, protocol, error correction, etc.

Valid Range

A NULL terminated ASCII string up to 31 bytes in length.

When Transmitted

The output is updated when the modem connection state reaches TEL_TALKING or TEL_NOTINUSE.

Update Rate

This network variable is updated once after the modem has entered the TEL_TALKING state and once after the modem has entered the TEL_NOTINUSE state.

3. Network Variable Control 20

CTI Products, Inc. NCB/IM User Guide

Request Dial String (Output)

C Language Syntax

network output SNVT_char_ascii nvoReqDialStr1; network output SNVT_char_ascii nvoReqDialStr2;

Usage

 This output network variable is associated with Perpetual Dial-Up Mode (see Tutorial

“Which Modem Mode Should Be Used” in section “2. SETUP AND OPERATION”) and is used when the Directory Object storing the telephone number (to be dialed) belongs to a node other than the call-originating NCB.

Valid Range

0-F (Hex)

When Transmitted

Transmitted when the Modem Controller Object senses that a connection is not made.

Perpetual Dial-up Mode The NCB module can be configured to provide a “perpetual” connection using the ‘dial-up’ mode

of the modem, with no runtime user or application intervention required to initiate or maintain a

constant modem connection. See “APPENDIX G. MODEM NOTES” for more details of Perpetual Dial-up Mode.

There are two methods available for implementing a “perpetual” connection using Dial-up mode:

1) The first method uses only configuration properties. This method is useful when the Directory

Object storing the telephone number (to be dialed) belongs to the dialing NCB module. a) Specify an entry in an NCB’s Directory that contains the phone number to be dialed.

This can be accomplished using either the NCB/Plug configuration plug-in (discussed in “Section 4. NCB/Plug” or using the “Dial Mode” Configuration Property (discussed later in this section).

b) Set the “Dial Mode” (for the call-originating NCB) to “Perpetual”. This can be

accomplished most easily with the NCB/Plug configuration plug-in (discussed in “Section “4. NCB/Plug” by accessing Dial Mode choices under the Modem Options menu item. Changing the Dial Mode to Perpetual may also be accomplished by using the “Dial Mode” Configuration Property (discussed later in this section).

2) The second method uses a combination of configuration properties and network variable

bindings. This method is useful when the Directory Object storing the telephone number (to be dialed) belongs to a node other than the call-originating NCB.

a) Specify an entry in an NCB’s Directory that contains the phone number to be dialed.

This can be accomplished using either the NCB/Plug configuration plug-in (discussed in “Section 4. NCB/Plug” or using the “Dial Mode” Configuration Property (discussed later in this section). This step is the same as in the first method.

b) Set the “Dial Mode” to “Manual” mode (the default setting). c) Make network variable bindings as shown in Figure 7.

3. Network Variable Control 21

CTI Products, Inc. NCB/IM User Guide

Phone Book

Object

nviReqDialStr

nvoDialStr

Modem

Controller

Object

nviDialStr

nvoReqDialStr

Why are Configuration Properties important?

Configuration Properties of an object (such as the Telephone Directory Object or Modem Controller Object) are used to alter the operation of a device. These properties are normally setup parameters that are accessed just once for purposes of initialization. However, they may be altered at any subsequent time. Configuration Properties may need to be changed from default values if any of the following is required:

 Perpetual Connect mode enabled (in Modem

Controller Object).

 Auto Answer mode disabled (in Modem

Controller Object).

 Dial string entry (in Telephone Directory Object),  Ring Mode enabled and parameters initialized

(in Global Control Object).

Accessing Configuration Properties

Alternative methods of accessing Configuration Properties are available:

 Direct access by either Network Variable

bindings or File Transfer (if a large amount of data is involved).

 Indirect access when a plug-in is used, such as

the NCB/Plug plug-in.

Tutorial . . .

Figure 7 Perpetual Dial-up Mode using NV Bindings

Configuration Properties

Will Configuration Properties be modified?

 If NO, and the NCB objects

(functional blocks) will be used with factory default settings (Manual Dial-Up or Leased-Line modes, Auto Answer mode Enabled, Ring Mode disabled), skip to Directory Object, later in this section.

 If YES, but the NCB/Plug

configuration plug-in will be used to modify the Configuration Properties, skip to Directory Object, later in this sections and also section “4. NCB/PLUG”.

 If YES, then the information

3. Network Variable Control 22

following is this section will be useful.

CTI Products, Inc. NCB/IM User Guide

Mode:

Value

Dial-up Mode

Index: 0-F hex

0 Manual

Perpetual

Dial Mode

C Language Syntax

Typedef struct UCPT_DialMode { unsigned char Mode; unsigned char Index; } network input config SCPTdialMode UCPT_DialMode1; network input config SCPTdialMode UCPT_DialMode2;

Usage

 This input configuration network variable allows the modem dialing Mode (Manual or

Perpetual) to be set, as well as the Directory entry Index number (0 through 15) that should be used when dialing in Perpetual mode. These configuration properties can also be modified using the NCB/Plug configuration plug-in as described in section “4. NCB/PLUG” and “APPENDIX G. MODEM NOTES”

 Manual dial mode requires either of the following for dialing to take place:

 A string should be sent to nviDialStr input network variable of the Modem

Controller Object.

 Or, a character representing the entry Index number should be sent to nviReqDialStr

input network variable of the Directory Object. In addition, a binding is need between nvoDialStr of the Directory Object and nviDialStr of the Modem Controller Object.

 Perpetual mode causes the modem to automatically dial a number stored in the specified

Index entry of the local Directory Object amd requires the following:

 The Dial Mode configuration property should be used to set the Mode to Manual,

and the Index to a Directory entry that will be used when dialing. In addition, the Directory’s configuration property Dial String should be used to add the dial string to the proper Index of the Directory. (See Directory Configuration Properties later in this section.)

 If the modem is currently connected to another NCB, the Dial Mode will not change until

the current call is cancelled.

Valid Range

Default Value

Mode: 0 Index: 0

Auto Answer Enable/Disable

C Language Syntax

network input config snvt_switch UCPT_AutoAnswer1; network input config snvt_switch UCPT_AutoAnswer2;

Usage

 This input configuration network variable provides a mechanism to enable or disable the

‘Auto Answer’ modem function.

3. Network Variable Control 23

Valid Range

CTI Products, Inc. NCB/IM User Guide

Value

Auto Answer Mode

Off

Disabled

Enabled

Default State

On (Enabled)

TELEPHONE DIRECTORY OBJECT

A Telephone Directory Object is used to store and retrieve arrays of ASCII strings that are characterized as telephone numbers (including characters used for control) used in dialing a data modem. The ASCII arrays are configured using data file transfer or configuration network variables and are retrieved in real-time using an index value passed via a network variable.

The output of a Directory Object (which emits telephone numbers) is typically bound to a Modem Controller Object. The input to a Directory Object is typically driven by an object requiring the services of the Modem Controller Object to accomplish some connectivity task, e.g. notification of an alarm to a remote site. Usage of a Directory Object allows the alerting object to initiate dialing of the Modem Controller Object to a specific telephone number by simply emitting an array index from 0 to 15.

Two Directory Objects are available, for independently sending a distinct dial string to each Modem Controller Object. All Directory Objects use the same configuration data (all contain the same dial string data).

Network Variables

Request Dial String (Input)

C Language Syntax

network input SNVT_char_ascii nviReqDialStr1; network input SNVT_char_ascii nviReqDialStr2;

Usage

Two variables are available, one for each of the Directory Objects. These input network variables request the output of a telephone number, from the requested index.

Valid Range

0-15

Dial String (Output)

C Language Syntax

network output SNVT_str_asc nvoDialStr1; network output SNVT_str_asc nvoDialStr2;

Usage

Two variables are available, one for each of the Directory Objects. These output network variables provide the phone number string from the Directory entry corresponding to the index number received on nviReqDialStrx.

Valid Range

A NULL terminated ASCII string up to 31 bytes in length (including the NULL). All ASCII characters are valid, with specific support for the following:

Letter P (upper or lower case, first character in string only) – Pulse Dial. Digits (0-9,*,#) – Dials digit directly. Comma (,) – Pauses 2 seconds for each comma encountered. Letter W (upper or lower case) – Pauses until a dial tone is detected. Exclamation Point (!) – Hookflash, go onhook for 0.5 seconds, then back offhook. Punctuation (space, dash, left and right parentheses) – Valid in string, but ignored.

3. Network Variable Control 24

CTI Products, Inc. NCB/IM User Guide

When Transmitted

Transmitted upon receipt of a valid nviReqDialStr input, unless requested entry index is not supported or entry is blank (first character of entry is a NULL), in which case this variable is not transmitted.

Receipt of another nviReqDialStr input causes this output to be transmitted, containing the phone number string from the Directory entry corresponding to the index received on nviReqDialStr, even if the index received is the same index as received on the previous update to nviReqDialStr.

Update Rate

Updated only on an update to nviReqDialStr input.

Configuration Properties

Dial String

C Language Syntax

network input config SNVT_str_asc nciSetPhoneNum;

Usage

The first byte (character) specifies the Index entry (0-F hex) of the Directory Object. Up to 29 additional bytes (characters) can be used to specify the dial string.

Valid Range

A NULL terminated ASCII string up to 31 bytes in length (including the NULL). All ASCII characters are valid, with specific support for the following:

Default Value

The NULL character.

The File Transfer method of communications can also be used to configure the Dial String(s) in a Directory Object. A Dial String Array (nciDialStr[16]) can be loaded with the desired dial strings. This array holds data of type SNVT_str_asc.

GLOBAL CONTROL OBJECT

The following network variables pertain to the entire NCB, and not just to a single Modem Controller object or Directory Object.

Product Name (Output)

C Language Syntax

network output SNVT_str_asc nvoProductName;

Usage

This output network variable contains an ascii string identifying the product.

When Transmitted

Unsolicited at power-up and reset, or when polled.

3. Network Variable Control 25

CTI Products, Inc. NCB/IM User Guide

3. Network Variable Control 26

CTI Products, Inc. NCB/IM User Guide

4. NCB/PLUG CONFIGURATION PLUG-IN

LNS plug-ins are applications that can be started from within an LNS application (such as LonMaker for Windows) to perform a specialized task. The NCB/Plug configuration plug-in implements configuration and query commands for the NCB. The NCB/Plug plug-in and Network Variables can be used simultaneously. The following functions are available if NCB/Plug is installed:

 Pulse router service pin

 Request a soft reboot of NCB

The following function (for models NCB-EM, NCB-IS, and NCB-AY) will also be displayed, but will have no effect when using NCB/IM and NCB-RF models:

 Configure Ring Mode parameters The following functions (for models NCB/IM, NCB-EM, and NCB-IS) will also be displayed, but will have no

effect when using NCB-AY, and NCB-RF models:

 Send a dial string to a modem

 Send a ‘Call Cancel’ command to a modem

 Configure the NCB Directory

 A window displays ‘Connect Status’

 Select Dial Mode (Manual or Perpetual)

 Select Auto Answer Enabled Mode

INSTALLATION

NOTE: If you have already performed these steps as detailed in Section 2 “Setup and Operation”, they do NOT

need to be repeated here. In this case, skip directly to “Accessing NCB/Plug” below.

1. Install the NCB/Plug plug-in on your PC: a) Insert the NCB/Plug CD into your CD-ROM drive. b) Click the Windows Start button, choose Run..., click Browse… , select the Setup application on

the NCB/Plug CD, and click Open .

c) Follow the instructions displayed by the Setup application. d) Restart your computer when the Setup application is complete.

2. Register NCB/Plug with LonMaker for Windows: a) Click the Windows Start button, choose Programs, then NCBPlug, and click on NCBPlug. b) Click Register Plug-In . c) Click Exit .

3. Register NCB/Plug with the desired LonMaker for Windows network: a) Start LonMaker for Windows and open the desired network (be sure to checkmark the “Show all

Network Option Screens” box). When the “Plugin Registration” window within the Network

Wizard appears, highlight the “NCB_Plug” under “To Be Registered” and click Finish.

Two External Interface Files (.XIF) are automatically transferred to the hard drive when NCB/Plug plug-in is installed. NCBTLC30.XIF should be used for the Control Neuron Processor of an NCB of Version 3. NCBTLC20.XIF should be used for the Control Neuron Processor of an NCB of Version 2.

4. NCB Plug-In 27

CTI Products, Inc. NCB/IM User Guide

ACCESSING NCB/PLUG

a) Bring NCB/Plug to the desktop: b) Right click on the Control Neuron Functional

Block to be configured (Modem, Directory, Globals). In the drop-down list, click

“Configure”. The Plugin will appear as

shown here.

c) Alternatively, right click on the Control

Neuron Processor device shape. In the dropdown list, click “Plug-Ins…”, and select NCB/Plug. Click OK to continue. The Plugin will appear as shown here.

USAGE

Starting NCB/Plug from a Modem or Global Functional block shows the main NCB/Plug window from which both modem and Directory configurations and operations may be performed. Starting NCB/Plug from a Directory functional block shows only the Directory window from which only Directory information may be configured or printed.

If LonMaker is currently in “Offnet” mode, only the configuration functions of NCB/Plug (including Directory

and certain Modem and NCB Options) will be available, and “<OFFNET>” will appear in the Message Box.

If the Control Neuron device being configured is not currently attached to the network, NCB/Plug will display a “Connection Error”.

 “Yes” may be clicked to retry communication with the device after reconnecting it.  “No” may be clicked to ignore the error and enter NCB/Plug to perform configuration functions only.

In this case, “No response from <device name>” will be shown in the Message box.

 “Cancel” may be clicked to abort the load of NCB/Plug.

Manual Dialing

A dial string can be entered directly into the Phone Number box of the main NCB/Plug window. The Dial button can then be used to initiate a call. The Call Cancel button can be used to terminate a call. Connect Strings are displayed in the Message window. Connect Status is also displayed.

Directory Menu Item

The Phonebook menu item accesses the Directory and is used to edit a list of 16 phone numbers (dial strings). A Description field is available for each of the 16 Number entries. Any entry in the Directory can be accessed for dialing by using the pulldown button of the Phone Number box on the main NCB/Plug window. File -> Print to File pastes the current Directory information to Windows Notepad from where it may be saved, printed, pasted, etc.

NCB Options Menu Item

The NCB Options menu item provides access to the following functions:

Pulse Router Service Pin

This is equivalent to pressing the “RSVC” button on the NCB’s front panel.

4. NCB Plug-In 28

CTI Products, Inc. NCB/IM User Guide

See Appendix G for Modem Dialup modes.

Soft Reboot

This is equivalent to pressing the “RESET” button on the NCB’s front panel.

Modem Options Menu Item

The Modem Options menu item provides access to the following functions for an NCB/IM:

Auto Answer (Dial-Up only)

This option allows enabling or disabling the Auto Answer function in Dial-up mode. A check next to the menu item indicates Auto Answer is currently enabled. Be careful when disabling Auto Answer mode on a remote NCB, as once connection with this unit is broken, it will no longer automatically answer an incoming call. To re-enable Auto Answer mode, proceed as follows:

 Press and hold the “CMD” button on the remote NCB  Press and release the “RESET” button on the remote NCB.  Wait until the “PWR” LED begins to flash on the remote NCB, then release the “CMD” button.

These steps will temporarily enable Auto Answer mode for the remote NCB for one incoming call. Use NCB/Plug, NCBCON, or explicit messages to re-enable Auto Answer mode for future connections.

Mute Input Audio

To maximize data throughput, handsets should normally remain disconnected or the input audio be kept muted on any NCB that may be installed where normal background noise could be detected by the handset. Audio input is automatically un-muted when a connection is established

Dial Mode (Dial-Up only)

Manual or Perpetual dialing modes are supported. If the modem is currently connected to another NCB, the Dial Mode will not change until the current call is cancelled.

Connection Statistics

The Connection Statistics window appears to the right.

4. NCB Plug-In 29

CTI Products, Inc. NCB/IM User Guide

4. NCB Plug-In 30

CTI Products, Inc. NCB/IM User Guide

APPENDIX

APPENDIX A. FACTORY DEFAULT CONFIGURATION

Control Neuron Processor

Restoring Factory Default Parameters

Should the Control Neuron Processor communication parameters be overwritten incorrectly by a network management tool, they can be restored as follows:

 Press the “RESET” button on the front of the NCB unit  After the “ERR” LED goes off, press the “RESET” button a second time.

The Control Neuron communication parameters are now restored to factory defaults.

Router

The router portion of the NCB module may be configured for various operational characteristics. The factory default configuration is as a repeater, where all messages entering the NCB module (via any of the three data ports described in section “1. INTRODUCTION” are simply passed through, regardless of the domain, subnet/node, or group destination address of the message. Other algorithms, as described in section “1. INTRODUCTION”, can be selected using standard LONWORKS Network Management Tools such as the LonBuilder, LonMaker, or LNS.

The communication parameters for sides A and B of the router are forced to their proper settings via NCB hardware and need not be set (nor can they be changed) by the Network Management Tool.

Further details of router operation and configuration are contained in the Echelon document entitled "LONWORKS Router User's Guide", Echelon part number 078-0018-01B.

Address Assignments

The router inside the NCB module contains two Neuron chips, each with its’ own subnet/node number assignment. The default factory configuration of the router Neurons is subnet 255 node 126 and subnet 255 node 127. If any other nodes in the system to which the NCB is connected are configured with either of these subnet/node addresses, the router should be reconfigured to different addresses using any standard Network Management Tool.

Buffer Configuration

The NCB module utilizes buffers to store incoming messages and route them out to other ports. The configuration of these buffers (the number of bytes in each buffer as well as the number of buffers) determine the maximum size message that can be passed and the performance of the NCB module under conditions of bursty traffic. In the standard configuration, the NCB router restricts the maximum size message that can be passed to a length of 40 to 50 bytes of user data, depending on the addressing overhead in the packet.

Technical Note TN010 covers the topic of buffers and buffer sizes in detail and should be referenced if messages to be passed through the NCB module could exceed the maximum default size.

Querying, Defaulting, and Unconfiguring Router Configuration using SETRTR.EXE

The SETRTR.EXE DOS utility provided with each NCB can be used to query the router for its current configuration, force the router to certain default states, or force the router to unconfigured mode. If the router will be installed with the configured router algorithm, it is highly recommended that the router module is set to

Appendix A. Factory Default Configuration 31

CTI Products, Inc. NCB/IM User Guide

unconfigured mode before being installed into the system (this step is mandatory if redundant routers are to be configured).

Refer to Technical Note TN025 for more information on configuration of the router with standard network management tools such as LonBuilder, LonMaker, LNS, and others.

The SETRTR program requires a network interface to be connected to the personal computer. This network interface can be an Echelon SLTA, PCLTA, PCNSS, or any other device conforming to Echelon network interface standards. Network interface driver software must be loaded in the personal computer and configured with a device name (typically "LONn" where n is a number). Documentation provided with the network interface device details how to install the unit and driver software. The network interface device must contain a network transceiver compatible with the network transceiver in the NCB module to be controlled.

NOTE: If you are using the PCLTA card as a network interface and the NCB is not performing the commands as expected, the PCNSS has probably not been configured for network interface mode. See Technical Note TN024 for information on configuring the PCNSS card into network interface mode.

After the network interface and its software driver are properly configured on the personal computer, connect its’ network port to the front panel “NETWORK” connector on the NCB.

Querying an NCB’s Router for its Current Configuration

Start the SETRTR program with the following command line: SETRTR [-ddevicename] -L <cr>

where devicename is the name assigned to the network interface on the command line of the device driver (typically "LON1" or "LON2"). If this parameter is omitted, the default name of LON1 is used.

The -L parameter instructs SETRTR to List the current configuration of the router module.

After the signon message appears, press the “RSVC” button on the front of the connected NCB module.

SETRTR will report the current router configuration to the screen.

Returning an NCB’s Router to Factory Default Configuration

Start the SETRTR program with the following command line: SETRTR [-ddevicename] -F <cr>

where devicename is the name assigned to the network interface on the command line of the device driver (typically "LON1" or "LON2"). If this parameter is omitted, the default name of LON1 is used.

The -F parameter instructs SETRTR to set the RTR-10 to full Factory defaults, including router algorithm, domain tables, and buffer settings.

After the signon message appears, press the “RSVC” button on the front of the connected NCB module.

SETRTR will send the required messages to the router and exit. Press the “RESET” button on the front of the

NCB module to complete the reconfiguration.

Setting an NCB’s Router to Unconfigured Mode

Start the SETRTR program with the following command line: SETRTR [-ddevicename] -U <cr>

The -U parameter instructs SETRTR to set both sides of the NCB’s router to Unconfigured mode. After the signon message appears, press the “RSVC” button on the front of the connected NCB module.

SETRTR will send the required messages to the router and exit.

Appendix A. Factory Default Configuration 32

CTI Products, Inc. NCB/IM User Guide

CA-80113-100

1 2 3 4 5 6 7 8

OPTION A

DC IN

ERR

ACT

PWR

RSVCCSVC

AUDIO

LINECD OH

RESET

CMD

NCB

NETWORK COMBINER

NETWOR K

FACEPLATE

SPACER

APPENDIX B. MOUNTING OPTIONS

Wall mount and EIA 19” rack mount kits are available as options for the NCB from CTI Products, Inc. The wall mount kit includes brackets to allow a single NCB module to be mounted to any flat surface. The rack mount kit includes an adaptor allowing up to three NCB modules to be mounted in a single rack unit height.

Rack Mount Option

The rack mount option allows up to three NCB modules to be mounted in a one rack unit height (1.75 inches) of

a standard 19 inch rack. The modules are mounted in the rack plate by removing its’ front bezel and

remounting the module into the rack plate. Figure 8 shows an exploded view of the rack mount installation. The top diagram shows the front view of the bracket with one module installed. The bottom two diagrams show a side view of the module installation into the rack adaptor and rack adaptor installation into the rack, respectively.

Figure 8 NCB Module Rack Mounting

Appendix B. Mounting Options 33

CTI Products, Inc. NCB/IM User Guide

Step

Operation

Remove the front panel from the module, including the bezel, by removing the two Philips head screws in the faceplate. The bezel is not used when rack mounting the module.

Position the module behind the rack adaptor, lining up the holes in the rack adaptor with the front panel screw holes on the module.

Position the front panel in front of the rack adaptor, lining up the front panel with the module.

Fasten the front panel and module to the rack adaptor with the Philips head screws that were previously removed.

Position the rack adaptor into your rack, lining up the four mounting holes of the rack adaptor with mounting holes in the rack frame.

Position the two spacers in the front of the rack adaptor, aligning the cutouts in the spacers with the holes of the adaptor.

Install mounting screws (customer provided) into the rack.

Step

Operation

From the front of the module, slide the PC board out of the housing.

Remove the back panel of the module.

From the rear of the module, slide the PC board back into the housing (there are markings on the PC board to indicate which edge to insert into the rear of the housing first).

Install the back panel of the module.

To attach a module to the rack adaptor, and then mount the rack adaptor into the rack, follow the steps below.

WARNING

Do not allow the PC board to slide out of the housing when the front panel is removed. If it does, DO NOT slide the PC board back into the housing from the front of the module. Doing so may damage the unit, causing the unit to malfunction when powered on. Doing so will void the unit’s warranty.

Rack Mounting Instructions

When the module’s front panel is removed, do not allow the PC board to slide out of the housing. If the PC board does slide out of the housing, you must follow the steps below to replace the PC board in the housing. DO NOT RE-INSTALL THE PC BOARD FROM THE FRONT OF THE HOUSING !

Re-Installing a PC Board in its housing

Appendix B. Mounting Options 34

CTI Products, Inc. NCB/IM User Guide

Industry Canada

NOTE: THE NUMBE RS ON THIS DRAWING REFER TO THE ITEM NUMBERS

ON THE CORRES PONDING B ILLS OF MATERIAL FOR THIS ASSE MBLY.

24 VDC 100 m A

BOTTOM VIEW

US E O N LY 6- 3 2 X 1 /4 " LO N G

FL A T H EA D S CR E W S TO AT T AC H T HE

W A LL M O UN T B RA C KE T T O T HI S U N IT .

TO P R EV E NT D A M A G E T O T HE C I RC U I T B O A RD .

C A U T IO N !

US E O N LY 6- 3 2 X 1 /4 " LO N G

FL AT HE A D S CR EW S T O A TT AC H T H E

W A L L M O UN T B R AC K ET T O T HI S U NI T .

TO P R EV E NT D A M A G E T O T HE C I RC U I T B O A RD .

CAUTI O N!

Products Inc.

ETL APPRO

3.500

1.980

6.130

6.700

1.642

TOP VIEW

Provided by installer.

Allow ro om on ends

for connector s.

Allow ro om on ends

for connector s.

SIDE VIEW

1.980

QTY 2

QTY 4

QTY 4 NO . 8 SCR EW S OR OTHE R AP PR OP RIATE HA RDW A RE.

DRAWN BY

APPROVED BY

SCALE

DATE

SHEET OF

TITLE

DRAWING NUMBER

1 1

NONE

APPLICATION

CFA

11-22-96

WON PRODUCTS

RKK

WON NC B S IZE "B " WA LL MOUNT K IT

OPTIO N A

DC I N

ERR

ACT

PWR

RSVC

CSVC

AUDIO

LINE

RESET

CMD

NCB

NETWORK COM BINER

NETWORK

Wall Mount Option

The wall mount option allows an NCB module to be mounted to any flat surface. The NCB module has four screw holes on the bottom. Simply attach the two mounting plates to the bottom of the module using the four flat-head screws provided with the wall mount kit. This assembly is then attached to the flat surface with userprovided fasteners. Figure 9 shows a dimensioned view of the wall mount installation.

Be sure to use the flat head screws provided with the wall mount kit. If you are not using the wall mount kit from CTI Products, Inc., make sure that the screws do not protrude into the enclosure more than 0.125 inches from the bottom surface of the module.

Using a longer screw that touches the PC board inside the module may damage the module. Doing so will void the unit’s warranty.

Appendix B. Mounting Options 35

Figure 9 NCB Module Wall Mounting

CAUTION

CTI Products, Inc. NCB/IM User Guide

Function

Notes

Network

Network connection is NOT polarity sensitive

Network

Pins 1,2 of IN and OUT connectors tied parallel

+ DC Power

In on IN connector, Out on OUT connector

No Connection

5 No Connection

6 - DC Power

In on IN connector, Out on OUT connector

- DC Power

In on IN connector, Out on OUT connector

+ DC Power

In on IN connector, Out on OUT connector

Function

Network

Polarity

DC IN

Front View

NETWORK

OUTIN1234567

NETWORK

APPENDIX C. CONNECTOR DETAILS

DC IN Connector

Connector type: 2.5 x 5.5 mm coaxial Mating Connector: Switchcraft 760 or equivalent Connector pinout: CTI Products, Inc. standard power

supply wired with center pin positive, NCB module can accept either pin positive, polarity routing is provided internal.

NETWORK Connectors

RJ45 Connectors:

Pins 1 and 2 of both RJ45 connectors as well as the terminal strip pins are all wired in parallel. The dual RJ45 connector designates "IN" and "OUT". These designations apply only to DC power that is passed down unused pairs of the 4 pair network cable. The two pins carrying the network pair are straight-through.

Connector Type: Standard RJ45 telephone connector, 8 position 8

contact.

2 Pin Terminal Strip style:

Mating Connector: Weidmuller 128176

Appendix C. Connector Details 36

CTI Products, Inc. NCB/IM User Guide

Function

Network

Shield (RS-485 only)

Standard

Color

Function

Notes

No Connection

2 Black

4 wire receive tip

Used for 4-wire channels only

Red

2 wire tip / 4 wire transmit tip

4 Green

2 wire ring / 4 wire transmit ring

5 Yellow

4 wire receive ring

Used for 4-wire channels only

No Connection

NETWORK

1 2 3

C A - 8 0 0 8 5 - 10 0

NETWORK

LINE

12345

3 Pin Terminal Strip style:

Mating Connector: Weidmuller 128186

SMX Transceiver units:

SMX network connections are described in the documentation with the SMX transceiver.

Telco LINE Connector

Connector type: Standard RJ11 telephone style, 6 position 4 contact. For Dial-Up operation: Use pins 3 and 4 (standard telephone wiring) For 2-wire Leased-Line operation:

Connect pins 3 and 4 from each NCB module to each end of the bidirectional leased-line circuit.

For 4 wire Leased-Line operation:

Connect pins 3 and 4 of NCB module 1 to the circuit carrying audio from NCB1 to NCB2, terminate this circuit to pins 2 and 5 of NCB2. Connect pins 2 and 5 of NCB module 1 to the circuit carrying audio from NCB2 to NCB1, terminate this circuit to pins 3 and 4 of NCB2.

Appendix C. Connector Details 37

CTI Products, Inc. NCB/IM User Guide

Function

Notes

audio in

Inactive during training, simultaneous voice audio in after training

audio out

Line audio during training, simultaneous voice audio out after training

audio ground

8 audio ground

AUDIO

123

AUDIO Connector

Connection point for a telephone style handset or other audio device to make use of the simultaneous voice/data feature

Connector type: Standard RJ11 telephone type, 4 position 4 contact

Appendix C. Connector Details 38

CTI Products, Inc. NCB/IM User Guide

Feature

Version 3 Operation

Version 2 Operation

Auto-Answer Mode

(using OPTION A Switch 1)

OPTION A Switch 1 determines the AutoAnswer capability for dial-up operation. In Dial-up Auto-Answer Enabled mode, an NCB can originate and answer a call. In Dial-up Auto-Answer Disabled mode, an NCB can only originate a call.

OPTION A Switch 1 determines the Answer/Originate mode for Dial-Up operation. In Answer mode, an NCB can not originate a call. In Originate mode, an NCB can not answer a call.

Perpetual Dial-up Mode

requirements for OPTION A Switch 1

Perpetual Dial-up Mode will function when OPTION A Switch 1 is in either position.

Perpetual Dial-up Mode requires that OPTION A Switch 1 be in the DOWN position.

Using a Network

Management Tool (with OPTION A Switch 5 in the DOWN position)

When OPTION A Switch 5 is in the DOWN position, the Auto-Answer Enabled/Disabled setting due to NCB/Plug or Network Variables is non-volatile. (The setting of OPTION A Switch 1 will be ignored.)

Regardless of the setting of OPTION A Switch 5, the Auto-Answer Enabled/Disabled setting in NCB/Plug is volatile. Following a power cycle or reset, the setting of OPTION A Switch 1 will determine the Answer/Originate mode.

(When using NCB/Plug to control the Answer/Originate mode of the NCB,

NCB/Plug’s reference to ‘Auto-Answer Enabled’ is equivalent to Answer mode. ‘Auto-Answer Disabled’ is equivalent to

Originate mode.)

CMD Button operation

Holding the CMD Button depressed during a power cycle or reset will temporarily enable Auto-Answer mode. This feature is useful if an NCB that must answer calls is inadvertently placed in Auto-Answer Disabled mode. When this feature is utilized, the NCB will answer a single call before reverting back to Auto-Answer Disabled mode. During this single answered call, NCB/Plug may be used to change the mode to Auto-Answer Enabled so that future calls may be answered.

CMD Button has no function.

APPENDIX D. NCB VERSION COMPARISON

Appendix D. NCB Version Comparison 39

CTI Products, Inc. NCB/IM User Guide

If the PWR LED . . .

REASON

CORRECTIVE ACTION

Is always illuminated.

Normal operation indicating that NCB unit

is receiving proper DC input power.

Go to next Table.

Flashes for 2 seconds.

Normal operation when WINK command is

being executed.

Go to next Table.

Flashes continuously.

DC input to unit is below minimum required

voltage.

Check for proper voltage at “DC IN”

connector (10-32VDC).

Does not illuminate.

NCB unit is not receiving DC input power.

Check for proper voltage at “DC IN”

connector (10-32VDC).

If the ERR LED . . .

REASON

CORRECTIVE ACTION

Is always off.

Normal operation indicating no error

condition was detected.

Goto next Table.

Occasionally blinks on, then

off.

Normal operation when “CSVC” button or

“RSVC” button is pressed.

Go to next Table.

Flashes slowly, at a rate of

once every 2 seconds.

The Router Neurons are unconfigured.

Use a Network Management Tool to

‘Replace’ or ‘Commission’ router, or Use NODEUTIL to change the

mode/state to ‘Configured’ and ‘Online’,

or Use SETRTR –F to configure the router to Factory default conditions (Repeater Mode).

Is always illuminated.

Router module, or Control Neuron

Processor, or Microprocessor is not functioning.

Call CTI Products, Customer Support (+1-

513-595-5900), to arrange to return unit for evaluation/repair.

If the OH LED . . .

REASON

CORRECTIVE ACTION

Is always illuminated in

Leased-Line mode.

Normal operation indicating the modem is in

the ‘Off-Hook’ condition.

Go to next Table.

Illuminates immediately when

a connection is attempted in Dial-up mode.

Normal operation indicating the modem is in

the ‘Off-Hook’ condition.

Go to next Table.

Is not illuminated when using

a Leased-Line.

1. OPTION A Switch is not set correctly.

2. Defective modem.

1. Verify OPTION A Switch 2 is down (Leased-Line mode), then press “RESET”.

2. If “OH” LED does not illuminate, call CTI Products, Customer Support (+1513-595-5900), to arrange to return unit for evaluation/repair.

Is always illuminated when

using a Dial-Up line, but a connection is not made.

OPTION A Switch is not set correctly.

Verify OPTION A Switch 2 is up (Dial-up

mode), then press “RESET”.

APPENDIX E. TROUBLESHOOTING

Table E1

Table E2

Table E3

Table E3 continued on next page 

Appendix E. Troubleshooting 40

CTI Products, Inc. NCB/IM User Guide

Does not illuminate on

originating NCB when using a Dial-Up line and a connection is attempted.

1. DIAL command is not being sent

correctly to originating NCB.

2. Defective modem.

1. Verify that the originating NCB is receiving a proper DIAL command.

2. If “OH” LED does not illuminate, call CTI Products, Customer Support (+1513-595-5900), to arrange to return unit for evaluation/repair.

Illuminates only briefly (less

than 5 seconds) on originating NCB when using a Dial-Up line and a connection is required.

Dial-up line is not operating to the telco

switching equipment. (While initiating a dial-up connection, and with a handset connected to the AUDIO connector of the originating NCB, the dial tone can not be heard.)

Contact dial-up line provider for line status.

If the CD LED . . .

REASON

CORRECTIVE ACTION

Illuminates within 45 seconds

of resetting (“OH” LED is

already illuminated) when using a Leased-Line.

Normal operation indicating the modem is

connected to another NCB’s modem.

Go to next Table.

Illuminates within 45 seconds

of illumination of “OH”

LED on originating NCB when using a Dial-Up line.

Normal operation indicating the modem is

connected to another NCB’s modem.

Go to next Table.

Does not illuminate within 45

seconds of resetting (“OH”

LED is already illuminated) when using a Leased-Line.

1. OPTION A Switch is not set correctly.

2. Incorrect 4-wire leased-line connections.

3. Leased-line is not operating.

4. Defective modem.

1a. Verify OPTION A Switch 1 is down

for the originating NCB, and up for the answering NCB.

b. Verify OPTION A Switch 7 is up (-

10dBm transmit level) for normal operation, or down (-16 dBm transmit level) for back-to-back operation (on both NCB’s)

2. See “Appendix G. Modem Notes”.

3. Contact leased-line provider for line status.

4. Call CTI Products, Customer Support (+1-513-595-5900), to arrange to return unit for evaluation/repair.

Table E4

Table E4 continued on next page 

Appendix E. Troubleshooting 41

CTI Products, Inc. NCB/IM User Guide

Does not illuminate within 45

seconds of illumination of “OH” LED on originating NCB when using a Dial- Up Line.

1. OPTION A Switch 1 is not set correctly.

2. Incorrect dial string is being used by

originating NCB. (While initiating a dial-up connection, and with a handset connected to the AUDIO connector of the originating NCB, the dial tone, followed by the dial sequence, followed by the repeating busy signal, can be heard.)

3. Dial-up line is not operating from the

telco switching equipment to the answering NCB. (While initiating a dialup connection, and with a handset connected to the AUDIO connector of the originating NCB, the dial tone, followed by the dial sequence, followed by the repeating ringing signal, can be heard.)

4. Defective modem.

1. Verify answering NCB’s OPTION A Switch 1is up (Auto Answer Enabled), then press “RESET”.

2. Verify dial string.

3. Contact dial-up line provider for line status.

4. Call CTI Products, Customer Support (+1-513-595-5900), to arrange to return unit for evaluation/repair.

Appendix E. Troubleshooting 42

CTI Products, Inc. NCB/IM User Guide

If the ACT LED (on local

NCB) . . .

REASON

CORRECTIVE ACTION

Occasionally blinks on, then

off.

Normal operation indicating a message

packet has passed through the router module of the NCB.

Go to next Table.

Does not illluminate when

“RSVC” button on remote

NCB is pressed.

1. LONWORKS Service Pin message from

remote NCB is not reaching the local NCB.

2. LONWORKS Service Pin message from

remote NCB is not passing through the local router module.

1a. Verify that “ACT” and “ERR” LED’s

on remote NCB flash once. If not, return remote unit for evaluation/repair.

b. Verify that “OH” and “CD” LED’s are

both illuminated on the local and remote NCB’s. (See above)

2a. Place the remote router in Repeater

mode and verify that the local “ACT”

LED illuminates when “RSVC” button

on remote NCB is pressed.

b. If ‘2a’ is ok, re-commission the local

NCB router.

c. If ‘2a’ is not ok, swap either the local

or remote unit with a known-good-unit to determine the faulty unit.

Does not illuminate when

local LONWORKS nodes are transmitting messages.

1. LONWORKS message packets from

local nodes are not passing through the local router module.

1a. Verify the connection between the

local LONWORKS nodes and the local NCB.

b. Place the local router in Repeater mode

and verify that its “ACT” LED

illuminates when local LONWORKS nodes are transmitting messages.

c. If ‘1b’ is ok, re-Commission the local

NCB.

d. If ‘1b’ is not ok, return the local NCB

unit for evaluation/repair.

Does not illuminate when

remote LONWORKS nodes are transmitting messages.

1. LONWORKS message packets from

remote nodes are not passing through the remote router module.

2. LONWORKS message packets from

remote nodes are not reaching the local NCB.

3. LONWORKS message packets from

remote nodes are not passing through the local router module.

1a. Verify the connection between the

remote LONWORKS nodes and the remote NCB.

b. Verify that “ACT” LED on remote

NCB illuminates when remote

LONWORKS nodes are transmitting

messages.

c. Place the remote router in Repeater

mode and verify that its “ACT” LED

illuminates when remote LONWORKS nodes are transmitting messages.

d. If ‘1c’ is ok, re-comminssion the

remote router.

e. If ‘1c’ is not ok, return unit for

evaluation/repair.

2. See this Table above and verify that the

“ACT” LED “Does not illluminate

when “RSVC” button on remote NCB is pressed”.

3. See this Table above and verify that the

“ACT” LED “Does not illluminate

when “RSVC” button on remote NCB is pressed”.

Table E5

Appendix E. Troubleshooting 43

CTI Products, Inc. NCB/IM User Guide

Miscellaneous:

REASON

CORRECTIVE ACTION

Cannot communicate with

Control Neuron Processor of local NCB when using NODEUTIL.

1. In Bridge or Configured modes, router

neurons and network interface are not in the same domain.

2. In Repeater mode, the network interface

may be defective.

1. Verify that Nodeutil can communicate with another LONWORKS node.

2a. Place the local router in Repeater mode

and verify that communications is possible, or

b. Use Nodeutil to change the network

interface Domain to match the router neurons’ domains.

Cannot communicate with the

Control Neuron Processor of local NCB when using NCBCON.

1. In Bridge or Configured modes, the

Control Neuron, the router neurons, and the network interface are not all in the same domain. (2)

2. In Repeater mode, the Control Neuron

and network interface are not in the same domain. (1)

1. Place the local router neurons in Repeater mode.

2. Use NCBCON to change the network interface Domain to match the Control Neuron domain.

Cannot commission the

Control Neuron Processor when using LonMaker for Windows.

Incorrect external interface definition

(.xfb or .xif file) was specified when commissioning node.

Use NCBTLC30 for Version 3 NCB’s.

Use NCBTLC20 for NCB’s prior

to Version 3.

Table E6

Appendix E. Troubleshooting 44

CTI Products, Inc. NCB/IM User Guide

APPENDIX F. SPECIFICATIONS

NCB/IM Unit

Power: 10 to 30 VDC, Negative Ground, Externally Current Limited

5 watts max. without SMX transceiver

10 watts max. with SMX power line transceiver North American and International Power Supplies available Size: 7.5" D x 5.6" W x 1.6" H Mounting: Desktop with integral non-slip feet

Wall mount or 19" rack mount with optional adapters Temperature: 0-60C Humidity: 10-95% non-condensing Listings: UL1459, CSA C22.2, EC EN60950 Telco Approvals FCC Part 68 (U.S.), IC CS02 & CS03 (Canada),

BABT NTR2 & NTR3 (UK) EMI: Complies with: FCC part 15 Class A

Industry Canada (IC) Class A

EN55022 (European Union) Class A EMC: Complies with EN50082-1 (European Union) European: Carries the CE Mark Modem: Internal V.32 turbo 19.2 Kbps, 2 wire dial-up, 2/4 wire leased line

Simultaneous Voice plus Data.

Transceivers Supported: FTT-10A, TPT/XF-78, TPT/XF-1250, SMX, RS485, PLT22

Maximum packet size: 66 bytes (factory default router configuration)

255 bytes (maximum with software re-configuration)

Dialing: Modem Controller and Telephone Directory

SNVTs or Explicit messages

Configuration: Router set as a repeater by factory default.

Bridge, Configured, or Learning type set using standard LONWORKS

network management tools capable of configuring routers.

LNS plug-in provided for configuration of telephone parameters. Installation: Can be done with Standard Network Tools

Appendix F. Specifications 45

CTI Products, Inc. NCB/IM User Guide

APPENDIX G. MODEM NOTES

Manual Dial-Up Mode (PSTN)

Manual dial-up mode requires command information be sent to the originating NCB unit to cause it to dial the answering NCB unit. This command information is sent in the form of Network Variables bound to function blocks (objects) of the control Neuron processor inside the NCB module. The detail of these function blocks and network variables is provided in the SECTION 3, NETWORK VARIABLE CONTROL

This command information can be sent by any LonTalk node connected to the “NETWORK” port of the NCB

unit to be dialed. Additionally, a DOS utility program called NCBCON.EXE, included with each NCB unit, can be used to send this command from a simple menu. See Technical Note TN023 for more information on this program.

After receipt of a dialing command, the originating NCB module will go offhook and perform the dialing sequence. If a dial-tone is not detected within 4 seconds after going offhook, the NCB module will return onhook and await a new dialing command. Once the dialing sequence is complete, it begins the training sequence, waiting for an answer tone from the distant NCB module.

The NCB module configured in the Dial-Up ‘Auto Answer Enabled’ mode (the one being dialed) will detect the incoming ring on the telephone “LINE” connection. At the end of the first ring, it will go offhook and respond with an answer tone after a 2 second period of silence. The training sequence determines telephone circuit characteristics, sets appropriate equalization parameters and other housekeeping items, and concludes with the "CD" (carrier detect) LED illuminating. Within 2 seconds after this LED lights, data packets can flow across the modem connection and the simultaneous voice/data facility is enabled on the “AUDIO” connector.

The elapsed time between training sequence start (the end of the dialing sequence at the originating NCB module) and training sequence completion (carrier detected) is tracked by a timer inside each NCB unit. If the time reaches 60 seconds and training has not concluded, the NCB units will go onhook. The originating NCB module will await a new dialing command and the answering NCB module will wait for another ring. When configured for manual dialing mode, no automatic redialing is performed. Once a connection is established between the two NCB modems, any loss of carrier will be detected by both NCB modules and cause them to go onhook and await new commands/rings. Data entering the NCB module from the “NETWORK” or control Neuron processor ports while the modem is not in the connected state is not buffered.

Perpetual Dial-up Mode

The NCB module can be configured to provide a “perpetual” connection using the ‘dial-up’ mode of the modem, with no runtime user or application intervention required to initiate or maintain a constant modem

connection. This closely approximates the operation of Leased-Line mode, but uses dial-up mode. Operationally, the NCB unit used in Perpetual mode is configured with the telephone number of the remote NCB unit. (The remote NCB unit must have Auto-Answer mode enabled.) When powered on, the unit in Perpetual mode automatically dials the remote unit and the connection occurs without user or application intervention. Should the link between the two modems not connect or be broken for any reason, the unit in Perpetual mode will automatically redial the remote unit and re-establish the connection.

Note that NCB modules configured with the modem approved for use in the United Kingdom do not include this perpetual dial-up feature.

The NCB/Plug plug-in can be used to configure the NCB for Perpetual Dial-Up Mode. (See section “4. NCB/PLUG”.)

Leased-Line Mode

Leased-Line mode is the simplest operational mode of the NCB module. After power-up or reset, an NCB

module set to ‘Leased-Line: Originate’ mode will immediately go offhook and emit a cyclic calling tone to the telephone circuit. An NCB module set to ‘Leased-Line: Answer’ mode will go offhook and wait for detection

of the calling tone from the distant end. When this calling tone is detected, the modem training sequence begins. This training sequence determines telephone circuit characteristics, sets appropriately equalization

Appendix G. Modem Notes 46

CTI Products, Inc. NCB/IM User Guide

Telco Connector

Color / Pins

Function

Connect to NCB LINE Pins:

42A Block

Red & Green

Yellow & Black

Transmit Receive

3 & 4 (Red & Green) 2 & 5 (Yellow & Black)

66 Block

(Punch Block)

Top-most pair

Bottom-most pair

Transmit Receive

3 & 4 (Red & Green) 2 & 5 (Yellow & Black)

RJ45 (8 Pin)

Pins 1 & 2 Pins 7 & 8

Transmit Receive

3 & 4 (Red & Green) 2 & 5 (Yellow & Black)

parameters and other housekeeping items, and concludes with the "CD" (carrier detect) LED illuminating. Within 2 seconds after this LED lights, data packets can flow across the modem connection and the simultaneous voice/data facility is enabled to the “AUDIO” connector.

The elapsed time between training sequence start and end (carrier detect) is tracked by a timer inside each NCB unit. If the time reaches 20 seconds and training has not concluded, the NCB units will automatically restart the calling tone sequence. Once a connection is established between the two NCB modems, any loss of carrier will be detected by both NCB modules and cause them to automatically restart the calling tone sequence. Data entering the NCB module while the modem is in the calling tone or training sequence is not buffered.

4-wire Leased-Line Wire-color/Connection Method

For actual connection to the telephone circuits in the field, the following table shows typical telephone circuit connector schemes and functions:

The above data is typical in most situations, but sometimes wire pairs get flipped, causing this information to be incorrect. If the modem units do not properly communicate after connecting the pairs as above, use the following procedure to determine proper wire pairs:

1. Disconnect all four wires between both NCB units and their associated telephone circuit wiring.

2. At the site containing the NCB unit in originate mode, connect pins 3 & 4 (Red & Green) from this

NCB to either telephone circuit pair (use the pair you suspect is the transmit pair that carries audio from the originate mode NCB to the answer mode NCB, if you believe you know which one this is).

3. Be sure this originate mode unit has OPTION 1 switches set correctly (positions 1, 2, 8 DOWN and all

others UP), and that this NCB unit was reset or power-cycled after any switches were changed.

4. At the site containing the NCB unit in answer mode, connect pins 2 & 5 (Yellow & Black) from this

NCB to either telephone circuit pair.

5. Connect a standard telephone handset into the “AUDIO” connector of this answer-mode NCB.

6. Be sure this answer mode unit has OPTION 1 switches set correctly (positions 2 and 8 DOWN and all

others UP), and that this NCB unit was reset or power-cycled after any switches were changed.

7. Listen in the earpiece of the handset for a periodic single tone with about a four second repitition rate.

This is a tone from the originate NCB to the answer NCB.

8. If you hear this tone you have correctly chosen the transmit telephone pair. Proceed by connnecting

the remaining pair from each NCB unit to each remaining telephone circuit pair at each site. Reset both NCB units (or wait for them to timeout and recycle, approximately 60 seconds) and they should complete the modem training process and turn on their “CD” LEDs within 30 seconds.

9. If you do not hear this periodic tone on the handset connected to the answer-mode NCB, try changing

the connection of pins 2 & 5 (Yellow & Black) of this answer-mode NCB to the other telephone circuit pair at this site. Reset both NCB units and again listen for the periodic tone in the earpiece of the handset connected to the answer-mode NCB unit.

10. If step 9 still does not result in a periodic tone in the handset, go back to the site of the originate-mode

NCB unit and change the connection of pins 3 & 4 (Red & Green) of this originate-mode NCB to the other telephone circuit pair at this site. Reset both NCB units and return to the site of the answermode NCB and listen for the periodic tone.

11. If the actions of step 9 and/or 10 still do not result in a periodic tone in the handset, either the telephone

circuit or the NCB unit(s) must be defective. Have the telephone company installer check the telephone circuit for proper operation and labeling of the transmit and receive channels at both sites.

Appendix G. Modem Notes 47

CTI Products, Inc. NCB/IM User Guide

12. If the actions of step 9 or 10 do result in a periodic tone, proceed by connnecting the remaining pair

from each NCB unit to each remaining telephone circuit pair at each site. Reset both NCB units (or wait for them to timeout and recycle, approximately 60 seconds) and they should complete the modem

training process and turn on their “CD” LEDs within 30 seconds.

See text in section “2. SETUP AND OPERATION”, “STEP 3. ELECTRICAL CONNECTIONS” for important information when connecting two NCB units “back-to-back” in Leased-Line mode with a short phone cable.

Certain leased-line audio circuits (most notably microwave RF channels) provide a 4-wire circuit made up of a Transmit pair and a Receive pair. Use the 4-Wire mode in these situations. Be sure to provide proper wiring in 4-Wire mode.

Appendix G. Modem Notes 48

CTI Products, Inc. NCB/IM User Guide

INDEX

ACT LED .................................................................. 6

AUDIO connector.......................................... 4, 13, 47

Auto Answer Mode ....................................... 7, 29, 46

Back-to-back ................................................ 11, 12, 48

Bridge ........................................................................ 5

Buffer Configuration ............................................... 31

Call Cancel .............................................................. 19

CD LED ............................................................... 6, 12

CMD Button .................................................. 7, 29, 39

Commisioning the NCB .......................................... 14

Configuration Properties .................................. 22, 25

Configured router ................................................ 5, 31

Connection Statistics ............................................... 29

Connector ................................................................ 36

Control Neuron Processor.................... 4, 6, 11, 15, 31

Dial String ............................................................... 25

Dial-Up .................................................................... 46

Domain .......................................................... 5, 31, 32

ERR LED............................................................. 6, 31

Error ..................................................................... 6, 20

Explicit Messages ...................................................... 5

Factory Default Parameters ..................................... 31

Front Panel ............................................................... 6

Functional Block...................................................... 17

Message Buffer .......................................................... 5

Modem Controller object ................. 17, 18, 21, 24, 25

Mounting Kit ............................................................. 9

Mute Input Audio .................................................... 29

NCB/Plug -- Installation .......................................... 14

NCB/Plug Configuration Plug-In ..................ii, 16, 27

NCBCON ...................................................... 5, 13, 46

NETWORK connector .................................. 4, 11, 32

Network Management Tool ..................... 6, 11, 13, 31

Network Variables ...................................... 16, 19, 24

Object -- Modem Controller ............ 17, 18, 21, 24, 25

Object -- Telephone Directory ............... 17, 24, 25, 28

Objects -- Global Control ...................................... 25

OffHook ..................................................................... 6

OH LED..................................................................... 6

OPTION A Switches ................................................. 9

PCNSS Card .............................................................. 5

Perpetual Dial Mode ............................................... 21

Perpetual Dial-Up Mode .......................................... 46

Plug-In ..................................................................... 27

Power Connection ................................................... 13

PSTN ............................................................. 3, 37, 46

Pulse Router Service Pin ......................................... 28

PWR LED .................................................................. 6

Repeater ............................................................... 5, 31

RJ45 ............................................................. 11, 36, 47

Handset Connection ............................................... 12

Internal modem ................................ ...................... 4, 9

Internal router ............................................ 4, 6, 17, 31

Leased-Line ........................................... 10, 12, 46, 47

LINE connector ................................................... 4, 12

LNS Plug-In ............................................................. 27

LONWORKS ......................................................... 4, 14

Appendix G. Modem Notes 49

SETRTR.EXE ......................................................... 31

Soft Reboot .............................................................. 29

Subnet/node ................................................... 5, 11, 31

Telephone Directory object ................... 17, 24, 25, 28

Transmit level .................................................... 11, 12

Wink ................................................................ .......... 6

CTI Products NCB-IM with Internal PSTN Modem User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
