INSTALLATION AND USER GUIDE

Rev.3T08MV

TECHNICAL CHARACTERISTICS

alarm shop

Wall mount D
Microwave frequency 24.125 GHz
Microprocessor technology DSP ( Digital Signal Processing )
Detection length From 0.30 to 12m

Detection area

Horizontal detection area IR = 7.5° - MW = 32°
Vertical detection area IR = 90° - MW = 80°
Curtain area characteristics (2­10m)
Installation height 2.1m (wall or windows mount)
Detection technology Adjustable : AND - OR
Power supply 10 -15 Vcc
Maximum consumption 25mA
Minimum consumption 11mA
Alarm relay time 5sec commutation

Antimasking relay time

TAMPER relay Open relay when cover removed.
Sensitivity Adjustable through trimmer
Microwave sensitivity Adjustable through trimmer
Max. detection length Adjustable through dip switch
Led indicator Enabled/disable through DIP Switch
Alarm memory Yes
RF interference No Alarm up to 2GHz
Led indicator purpose MW > yellow ; PIR > green; Alarm > red
Operating temperature Auto compensation
Cover color Art.9452 -> white - Art. 9454 ->brown
Dimension 37 x 125 x 40m

etection length 12m, 7.5°

Single curtain area (7.5° see chart on page

5)

25cm - 130cm

5sec commutation after 25sec of masking
time.

WARNING!!!! : To avoid the risk of damaging the
product, never touch the PIR sensor with hands. Use a clean
and soft cloth to clean the sensor.

2

alarm shop

GENERAL DESCRIPTION

Remove screw plastic protection, in the upper side of detector, using a screw
driver.

ANGULAR BRACKET WALL MOUNTING

Staffa di montaggio angolare reversibile

Angular reversible mounting bracket Wall mounting bracket

Staffa di montaggio a parete

3

WIRING

alarm shop

Clamp description and purpose :

12V = Positive 12Vcc.
GND = GND ( negative)
AMK = Antimasking Output N.C.
AS = TAMPER (N.C.)
MEM = Inhibition input and alarm memory enabling

(positive)

AL = Alarm output N.C.

LED indicator

LD4 = Red Led (alarm)
LD5 = Yellow Led (microwave)
LD6 = Green Led (IR)

Trimmer

IR Range = IR range adjustment
MW Range = MW range adjustment

DIP Switch SW1

DIP

ON

OFF

JUMPER JP1

It is possible to set up detector for external or internal use using ’JP1’Jumper ‘’ as described
in the following chart:

JP1 plugged in
JP1 plugged out

1 2 3 4

Antimask

Enabled

Antimask

Disabled

AND

IR ANTIMASK

IR ANTIMASK

OR

ENABLED

DISABLED

External use setup: more stability, more power consumption
Internal use setup: more sensitivity, less power consumption

Led

Enabled

Led

Disabled

DETECTION LENGTH CHART

4

alarm shop

Lateral view

Top view

LED indicator

MEM input:

In case of alarm or masking attempt, a positive signal on this clamp shows the
following events:

LIGHTED ON FLASHING

GREEN LED

YELLOW LED

RED + GREEN LED

RED + YELLOW LED

RED + GREEN + YELLOW

LED

GREEN and RED LED

RED + YELLOW LED

RED + YELLOW + GREEN

LED

IR detection (no

alarm)

MW detection

(no alarm)

IR detection

(alarm)

MW detection

(alarm)

IR + MW detection

(alarm)

/////////////////

/////////////////

/////////////////

/////////////////

/////////////////

/////////////////

IR antimask detection
(enabled AMK output)

MW antimask detection

(enabled AMK output)

IR+MW antimask detection

(enabled AMK output)

5

N.B. In case both masking and alarm condition occur, first LED will light on, then they

alarm shop

will start flashing.

GENERAL INSTALLATION GUIDE

Perimeter
protection

Windows and door protection

Windows
protection

6

Installation

alarm shop

To avoid troubles on the detector, it is necessary to check what follows:

When the detector is powered on, LED indicator will flash alternatively
(stabilization time). After that GREEN LED will flash fast and in the end
YELLOW LED will flash fast.

GREEN LED flashing fast means that detector is acknowledging environmental
conditions necessary for “Beam antimask” function.

YELLOW LED flashing fast means that detector is acknowledging conditions
necessary for “MW antimask” function.

This acknowledging phase is necessary to evalue default conditions (no
masking condition), so that any other condition can be considered as a
masking attempt.

During this procedure do not stay in front of detector and do not put any
obstacle between detector and covered area.
When detector will stop flashing, it will start working normally.

• GREEN LED will show pre alarm condition (IR).

• YELLOW LED will show pre alarm condition (MW).

• RED LED will show detector alarm condition (IR).

When a positive signal is present on MEM clamp, usually connected to +Off
clamp of some control panels, LED indicator are always lighted off and
detector will be not working.

If an alarm occurs, alarm memory will be shown as described in the above
chart. When control panel will be activated again, detector will start working
normally.

If a masking alarm occurs, detector will repeat acknowledgment of
environmental conditions, when control panel will be activated again.

7

DETECTION OPTIONS

alarm shop

• Mw antimask

When this function is enabled, AMK output activates if an obstacle remains in
front of detector about 25sec.

• IR antimask

When this function is enabled, AMK output activates if an obstacle remains in
front of detector. A IR active signal will be checked out to verify this condition.

IMPORTANT NOTICE:

We suggest to do not activate “Mw Antimask” function if detector is installed
outside where it can be exposed to rain, snow etc..

- AND

Detector will be in alarm only if MW and IR are both in pre alarm condition.

- OR

Detector will be in alarm if MW or IR are in pre alarm condition.

8
