C-scope CS9000 MK2 User Manual

CS9000 MK2

OPERATING INSTRUCTIONS

CS9000 MK2 - RAPID GET YOU GOING INSTRUCTIONS

Searching for a Metal Object

1. Turn MODE switch to BATT. CHK and check condition of the battery on meter.

2. Set THRESHOLD to the centre of the normal band.

3. Set SIGNAL BALANCE to the centre of the normal band.

4. Set GROUND BALANCE to the centre of the normal band.

5 Set AUTOMATIC THRESHOLD to No Auto.

6 Turn MODE switch to METAL

7. Hold detector with arm extended and raise and lower 6 inches. If the sound level does not
change leave the GROUND BALANCE in NORMAL range. If the sound changes
excessively then adjust as described in the section GROUND BALANCE PROCEDURE.

8. Switch AUTOMATIC THRESHOLD function on and begin search.

Cave or Void Search

1. Set THRESHOLD to the centre of the normal band.

2. Set SIGNAL BALANCE to the centre of the normal band.

3. Set GROUND BALANCE to the centre of the normal band.

4. Set AUTOMATIC THRESHOLD to on.

5. Turn MODE switch to BATT. CHK and check condition of battery on meter.

6. Turn MODE switch to CAVE. Hold the detector with your arm extended and begin to
search, taking care to keep the detector as level as possible and at a constant distance from
the ground.

IF A PROBLEM IS ENCOUNTERED REFER TO THE FULL INSTRUCTIONS.

1

User notes

2

CONTENTS

PAGE

INTRODUCTION 5

ASSEMBLY INSTRUCTIONS 5

BATTERIES 5

CONTROLS 7

Mode Switch 7
Threshold 8
Signal Balance 8
Ground balance 9
Automatic Threshold 9
Headphone Jack Socket 9
Thumb Set 10

FEATURES 10

Automatic Threshold 10
Ground balance 10

CS9000 MK2 OPERATION 10

Ground balancing Metal Mode 10
Pinpointing 11
Locating Caves & Other Voids 12

ACCESSORIES (OPTIONAL) 12

Headphones 12

THE IMPORTANCE OF THE RIGHT APPROACH 13

METAL DETECTING AND THE ENGLISH LAW 14

CODE OF CONDUCT FOR METAL DETECTOR USERS 15

CARE OF YOUR DETECTOR 16

Storage 16
Maintenance 16

DETECTOR NOT OPERATING? 16

Oscillating Signal Accompanied By Slight Meter Fluctuation 16
Intermittent Sound From Speaker 16
The Detector Drifts Out Of Tune 17
Further Information 17

SPECIFICATION 17

3

Controls C-Scope CS9000 MK2

4

INTRODUCTION

To protect your investment complete both sections of the enclosed guarantee card and return the
reply paid portion to C-Scope. This is particularly important in order to obtain the free parts
guarantee. (UK and Eire Only) Please retain the original packing box. In the event that your
detector should ever require to be serviced, this package will be most suitable for postal
protection.

C-Scope detectors are recognised as the finest detectors available. They are designed with lasting
quality, high technology, and above all, value for money. The only way to realise this value is to
carefully study and understand this instruction manual. You will then be able to obtain all the
advantages designed into your detector. It is also strongly recommended that you experiment
with the detector's operation in air using various test samples, in order to learn to identify and
understand the detector's capabilities and responses. Always remember that becoming a good
metal detectorist is like becoming a good photographer or fisherman, that is, although it is an
advantage to buy the best equipment, having bought it, patience and hours of practice are needed
to become proficient.

ASSEMBLY INSTRUCTIONS

After all the parts have been removed from the shipping carton, assemble as shown on page 4.
Be sure to keep all packing materials for future storage or shipping.

BATTERIES

The standard battery holder supplied with the detector holds four “C” size batteries. Alkaline
types are recommended as they can supply consisitent power for longer time periods.

Battery Holder

1. Remove the battery holder lid by applying gentle pressure down on the two locking tab

openings on one side (just enough so that they unlock), flip the pack over and apply gentle
pressure on the other two locking tab openings. The lid will then slip off

5
