C-scope CS6PI User Manual
CS6Pi - RAPID GET YOU GOING INSTRUCTIONS
1. Assemble and adjust for length (twist surplus lead around stem).
2. Insert batteries.
3. Set FREQUENCY to BATT. CHECK position.
4. Turn detector on by setting THRESHOLD to position 1.
The meter needle should be in the green section of the scale if the batteries are OK.
5. Adjust the FREQUENCY to mid scale 4-5.
6. Adjust THRESHOLD to obtain audio threshold then back off slightly so that no
tone is heard.
7. You will find all metals within the search head range including some iron and trash
PROVIDING THE SEARCH HEAD IS SLOWLY MOVING OVER THE
TARGET (not stationary).
IF A PROBLEM IS ENCOUNTERED REFER TO THE FULL INSTRUCTIONS.
1
CONTENTS:
PAGE
INTRODUCTION 4
ASSEMBLY 4
BATTERIES 4
BATTERY CHECK 5
CONTROLS AND WHAT THEY DO 6
OPERATING YOUR CS6Pi 7
IMPORTANT CONSIDERATIONS 7
DETECTION RANGE 7
DETERMINING THE TARGET SIZE AND DEPTH 8
ACCESSORIES (OPTIONAL) AVAILABLE FROM C-SCOPE 8
CHARGING BATTERIES 8
THE IMPORTANCE OF THE RIGHT APPROACH 8
SWEEPING TECHNIQUE 10
METAL DETECTING AND THE ENGLISH LAW 10
CODE OF CONDUCT FOR METAL DETECTOR USERS 11
CARE OF YOUR DETECTOR 11
DETECTOR NOT OPERATING? 12
FURTHER INFORMATION 12
© C-Scope International Limited
The information contained in this manual was correct at the time of going to press. Specifications
and factors outside of the manufacturer’s control are subject to change without notice.
2
Controls C-Scope CS6Pi
I
A
CS6Pi
B
H
C
J
A Battery Compartment
B Upper Stem & Handle Grip
D
C Din Plug & Socket
D Stem Locking Nut
E Cable
E
F Lower Stem
G Search Head Fastener
F
H Power On/Off & Threshold
I Signal Meter
J Frequency
G
3
INTRODUCTION
To protect your investment complete both sections of the enclosed guarantee card and return the
reply paid portion to C-Scope (UK only). This is particularly important in order to obtain the
free second year parts guarantee. Please retain the original packing box. In the event that your
detector should ever require to be serviced, this package will be most suitable for postal
protection.
C-Scope detectors are recognised as the finest detectors available. They are designed with lasting
quality, high technology, and above all, value for money. The only way to realise this value is to
carefully study and understand this instruction manual. You will then be able to obtain all the
advantages designed into your detector. It is also strongly recommended that you experiment
with the detector's operation in air using various test samples, in order to learn to identify and
understand the detector's capabilities and responses. Always remember that becoming a good
metal detectorist is like becoming a good photographer or fisherman, that is, although it is an
advantage to buy the best equipment, having bought it, patience and hours of practice are needed
to become proficient.
ASSEMBLY
Open the carton and remove the main housing assembly. Twist the plastic stem lock located at
the end of the upper stem to allow the lower stem to be inserted. Adjust for length and rotate the
lower stem to wrap the cable around the stems to take up any slack. Turn the stem lock to fix it at
the desired position.
BATTERIES
The CS6Pi is powered by eight AA batteries (not supplied) available from garages, department
stores, etc. or a single 12v rechargeable pack from C-Scope. It is advisable to use standard
batteries to start with. You can then evaluate the sort of use you give the detector and decide
whether the investment in rechargeables is justified.
Battery
Compartment
CHARGER
SOCKET
The batteries should be fitted in the holder which is located in the battery compartment. To fit
new batteries first check the THRESHOLD control on the unit is switched to OFF. Then loosen
HEADPHONE
SOCKET
BATTERY
COMPARTMENT
4
