C-scope CS1MX User Manual
C.Scope CS1MX MOTION Metal Detector
CS1MX_Manual.indd 1 10/5/07 11:07:18
1. Control box
2. Main stem
3. Hand grip
4. Armrest/detector stand
5. Lower stem
6. Twistlock stem adjuster
7. Search-head
8. Search-head retaining screw, washers, nut
9. Search-head lead
10. Loudspeaker
11. Headphone socket (rear of control box)
12. Battery compartment
13. Battery compartment cover
14. On/off/sensitivity control
15. Variable discrimination control.
14
15
11
6
2
1
8
7
9
10
3
5
naming of the parts
The CS1MX is a lightweight professional metal detector
operating on the ‘MOTION’ principle. Optimum performance
is achieved by keeping the search-head in motion.
The discrimination system can ignore the signals from some
types of metal which are likely to be worthless. The CS1MX
is extremely easy to use but you will be a better treasure
hunter if you take the time to read this manual carefully and
understand what the controls are doing.
CS1MX - Rapid get you going instructions
Assemble and adjust for length. Twist surplus lead around the stem.
Insert battery so that the terminals line up easily with the contacts in the battery compartment.
(9volt MN1604, PP3 type )
Switch on and rotate Sensitivity Control (15) to the start of the green section on the scale.
Rotate the Discrimination Control (16) to the middle of the green area on the scale.
Start searching using a relaxed motion swinging the search-head from side to side as close to
the ground as possible.
You are now searching in discrimination mode. The presence of a metal target will be indicated
by the increasing intensity of the tone. Signals from small ferrous rubbish will be ignored.
C.Scope CS1MX MOTION Metal Detector
4
12
13
CS1MX_Manual.indd 2 10/5/07 11:07:19
