7.2AH
Maintenance-Free Sealed Lead Acid Battery.
Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99%.
【Design Life】 【 Float Charging Voltage】
Up to 5 Years in Standby Service at 25℃
13.5 ~ 13.8 VDC/Unit at 25℃ (77℉)
Eurobat (20℃) : 3-5 years, Standard Commercial 【Equalization Charging Voltage 】
【 Operating Temperature Range】 14.4 ~ 15.0 VDC/Unit at 25℃ (77℉)
【 Self Discharge】
Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉);
Fully recharging is required before usage, and charged sooner if stored
Storage: -15℃ ~ 40℃ (5℉~104℉) at higher temperature than 25℃ (77℉).
Design according with IEC 61056-1/2: 2012
Nominal Capacity
Terminal Breaking Torque
Length (L) 150.9±2.0 mm 5.94±0.08 inch
Width (W) 64.8±1.0 mm 2.55±0.04 inch
Container Height (h) 94.3±1.0 mm 3.71±0.04 inch
Overall Height (H) 98.6±1.0 mm 3.88±0.04 inch
F.V/Time 5 MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR
1.60V 34.3 21.1 15.4 8.89 5.15 3.74 2.97 2.15 1.42 0.940 0.774 0.416
1.67V 32.8 20.8 15.3 8.87 5.14 3.73 2.96 2.14 1.41 0.937 0.771 0.415
1.70V 31.9 20.5 15.1 8.83 5.13 3.72 2.95 2.13 1.40 0.936 0.770 0.414
1.75V 30.0 19.8 14.8 8.72 5.09 3.71 2.94 2.12 1.39 0.932 0.767 0.412
1.80V 27.6 18.6 14.2 8.49 4.99 3.66 2.91 2.10 1.38 0.921 0.758 0.407
1.85V 24.4 16.9 13.1 8.06 4.80 3.54 2.81 2.04 1.33 0.892 0.734 0.393
F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR
1.60V 362 233 174 104 60.4 44.1 35.1 25.4 17.1 11.5 9.45 5.04
1.67V 352 230 172 103 60.2 44.0 35.0 25.3 17.0 11.4 9.43 5.03
1.70V 345 227 171 102 60.1 43.9 34.9 25.2 16.9 11.3 9.42 5.02
1.75V 329 219 168 101 59.8 43.8 34.8 25.1 16.8 11.2 9.39 5.01
1.80V 304 207 162 100 58.9 43.3 34.5 25.0 16.7 11.1 9.31 4.95
1.85V 273 192 151 95.5 56.9 42.0 33.5 24.4 16.3 11.0 9.06 4.80
Issued: 180326
Tel: +31(0)180-418-140
Tel: +886-2-2880-5600
Fax: +31(0)180-418-327 Fax: +866-2-2888-3300
Tel: +86-10-5820-5336, 5820-5338
Fax: +86-10-5820-3053
Fax: +86-755-8831-6075
Fax: +86-21-5046-1046
Tel: +1-817-244-7777 / 1-(800)3-CSB-USA (272872)
Fax: +1-817-244-4445
SHENZHEN OFFICE (CHINA)
SHANGHAI OFFICE (CHINA)
BEIJING OFFICE (CHINA)
Tel: +86-755-8831-6488, 8831-6775
Tel: +86-21-5046-1622, 5046-0833
BUSINESS HEADQUARTERS
Tel: +886-2-2880-5600
Fax: +866-2-2888-3300
USA OFFICE
EUROPE (EMEA) OFFICE
TAIPEI OFFICE
Constant Current Discharge Characteristics Unit: A (25℃, 77℉)
Constant Power Discharge Characteristics Unit: W (25℃, 77℉)
Recognized under UL 1989,
and certified by ISO 9001, 14001.
Sales Offices
--
Container Material
ABS (UL 94-HB) & Flame Retardant (94-V0) available upon request
Dimensions
Short Circuit Current
276A
Maximum Charge Current
2.16A
Terminal types
F1/F2 terminal -Faston Tab 187/250
7.2Ah @20hr-rate to 1.75V per cell @25℃ (77℉)
Weight
Approx. 2.40 Kg (5.29 lbs)
Maximum Discharge Current
100/130A (5sec)
Internal Resistance
Approx. 23.0mΩ
Discharge : -15℃ ~ 50℃ (5℉~122℉)
Charge: -15℃ ~ 40℃ (5℉~104℉)
Specification
Nominal Voltage
12V (6 cells per unit)
GP series
GP 1272
12V 7.2AH
Valve Regulated Lead Acid Battery
Design for Standby Power Applications
Nominal Operating Temperature : 25℃(77℉)
