F.V/Time
5 MIN
10MIN
15MIN
30MIN
60MIN
90MIN
2HR
3HR
5HR
8HR
10HR
20HR
1.60V
51.2
33.2
23.9
13.9
8.14
5.90
4.69
3.37
2.24
1.45
1.19
0.63
1.67V
48.2
32.0
23.6
13.7
8.12
5.84
4.62
3.35
2.21
1.44
1.18
0.62
1.70V
46.3
31.6
23.3
13.6
8.08
5.82
4.61
3.32
2.18
1.43
1.17
0.61
1.75V
43.3
30.0
22.6
13.4
8.03
5.77
4.57
3.26
2.13
1.40
1.15
0.60
1.80V
38.8
28.0
21.5
13.0
7.81
5.64
4.48
3.17
2.06
1.37
1.14
0.59
1.85V
34.2
25.3
19.8
12.3
7.51
5.41
4.29
3.03
1.97
1.32
1.09
0.57
F.V/Time
5MIN
10MIN
15MIN
30MIN
60MIN
90MIN
2HR
3HR
5HR
8HR
10HR
20HR
1.60V
539
347
268
160
97.9
70.6
55.9
39.6
25.3
16.7
13.8
7.70
1.67V
515
342
265
159
97.7
70.2
55.6
39.3
25.2
16.6
13.7
7.63
1.70V
499
336
262
158
97.0
69.9
55.4
39.0
25.0
16.5
13.6
7.61
1.75V
462
326
256
156
96.1
69.3
54.9
38.5
24.4
16.2
13.4
7.54
1.80V
418
307
243
153
94.8
68.0
53.7
37.7
24.1
15.8
13.1
7.42
1.85V
369
280
221
144
91.6
66.2
52.6
36.3
23.3
15.5
12.7
7.23
Please refer to the official site for the latest rating confirmation. URL:
www.csb-battery.com
Issued:
180205
Tel: +31(0)180-418-140
Tel: +886-2-2880-5600
Fax: +31(0)180-418-327
Fax: +866-2-2888-3300
Tel: +86-10-5820-5336, 5820-5338
Fax: +86-10-5820-3053
GP series
GP 12120
12V12AH
Specification
Constant Current Discharge Characteristics Unit: A (25
℃
, 77℉)
Constant Power Discharge Characteristics Unit: W (25
℃
, 77℉)
Sales Offices
Tel: +86-755-8831-6488, 8831-6775
Tel: +86-21-5046-1622, 5046-0833
Tel: +886-2-2880-5600
Fax: +866-2-2888-3300
USA OFFICE
EUROPE (EMEA) OFFICE
TAIPEI OFFICE
Fax: +86-755-8831-6075
Fax: +86-21-5046-1046
Tel: +1-817-244-7777 / 1-(800)3-CSB-USA (272872)
Fax: +1-817-244-4445
SHENZHEN OFFICE (CHINA)
SHANGHAI OFFICE (CHINA)
Valve Regulated Lead Acid Battery
Maintenance-Free Sealed Lead Acid Battery.
Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99%.
Design for Standby Power Applications
【Design Life】
Up to 5 Years in Standby Service at 25
Eurobat (20℃) : 3-5 years, Standard Commercial 【Equalization Charging Voltage 】
【 Operating Temperature Range】 14.4 ~ 15.0 VDC/Unit at 25℃ (77℉)
Nominal Operating Temperature : 25℃(77℉)
Discharge : -15℃ ~ 50℃ (5℉~122℉)
Charge: -15℃ ~ 40℃ (5℉~104℉)
Storage: -15℃ ~ 40℃ (5℉~104℉) at higher temperature than 25℃ (77℉).
Design according with IEC 61056-1/2: 2012
Nominal Voltage 12V (6 cells per unit)
Nominal Capacity
Weight Approx. 3.67 Kg (8.09 lbs)
Maximum Discharge Current 150/180A (5sec)
Internal Resistance Approx. 16.7mΩ
Short Circuit Current 378A
Maximum Charge Current 3.60A
Terminal types F1/F2 terminal -Faston Tab 187/250
Terminal Breaking Torque
Container Material ABS (UL 94-HB) & Flame Retardant (94-V0) available upon request
Dimensions
12Ah @20hr-rate to 1.75V per cell @25℃ (77℉)
--
Length (L) 151.0±2.0 mm 5.94±0.08 inch
Width (W) 98.0±1.0 mm 3.86±0.04 inch
Container Height (h) 94.1±1.0 mm 3.70±0.04 inch
Overall Height (H) 100.3±1.5 mm 3.95±0.06 inch
【 Float Charging Voltage
13.5 ~ 13.8 VDC/Unit at 25℃ (77℉)
【 Self Discharge
Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉);
Fully recharging is required before usage, and charged sooner if stored
BUSINESS HEADQUARTERS
Recognized under UL 1989,
and certified by ISO 9001, 14001.
