Maintenance-Free Sealed Lead Acid Battery.
Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99%.
Design for Standby Power Applications
【Design Life】 【 Float Charging Voltage】
Up to 8 Years in Standby Service at 25℃
13.5 ~ 13.8 VDC/Unit at 25℃ (77℉)
Eurobat (20℃) : 10/12 YEARS LONG LIFE 【Equalization Charging Voltage 】
【 Operating Temperature Range】 14.4 ~ 15.0 VDC/Unit at 25℃ (77℉)
【 Self Discharge】
Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉);
Fully recharging is required before usage, and charged sooner if stored
Storage: -15℃ ~ 40℃ (5℉~104℉) at higher temperature than 25℃ (77℉).
Design according with IEC 61056-1/2:2012
Nominal Capacity
--
Length (L) 151.0±2.0 mm 5.94±0.08 inch
Width (W) 98.0±1.0 mm 3.86±0.04 inch
Container Height (h) 94.1±1.0 mm 3.70±0.04 inch
Overall Height (H) 100.3±1.5 mm 3.95±0.06 inch
F.V/Time 5 MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR
1.60V 45.7 32.1 23.1 13.5 7.42 5.16 3.99 2.84 1.84 1.25 1.03 0.63
1.67V 44.0 31.4 23.0 13.4 7.32 5.11 3.96 2.81 1.83 1.24 1.01 0.62
1.70V 42.8 30.8 22.6 13.2 7.27 5.08 3.94 2.80 1.81 1.23 1.00 0.61
1.75V 40.3 29.4 21.9 13.0 7.14 5.00 3.88 2.76 1.80 1.22 0.99 0.60
1.80V 37.6 27.5 20.7 12.6 6.92 4.87 3.80 2.70 1.77 1.20 0.97 0.59
1.85V 33.8 24.8 19.0 11.7 6.55 4.64 3.63 2.59 1.70 1.14 0.93 0.56
F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR
1.60V 487 343 258 152 84.6 59.9 46.9 33.4 21.7 14.7 12.2 6.30
1.67V 475 339 255 151 84.5 59.7 46.6 33.2 21.6 14.6 12.1 6.24
1.70V 466 333 252 150 84.1 59.2 46.1 33.1 21.5 14.5 12.0 6.23
1.75V 443 322 246 149 83.5 58.9 46.0 32.9 21.4 14.4 11.8 6.19
1.80V 416 306 235 144 81.0 57.4 44.9 32.0 21.0 14.2 11.6 6.09
1.85V 380 280 217 135 77.0 54.8 43.0 30.7 20.4 13.7 11.2 5.85
Please refer to the official site for the latest rating confirmation. URL: www.csb-battery.com
Issued: 200930
Tel: +31(0)180-418-140 Tel: +886-2-2880-5600
Fax: +31(0)180-418-327
Fax: +866-2-2888-3300
Tel: +86-10-6597-8065/8165/8265
Fax: +86-10-6597-8565
Fax: +86-755-8831-6548
Fax: +86-21-5046-1046
Tel: +1-817-244-7777 / 1-(800)3-CSB-USA (272872)
Fax: +1-817-244-4445
SHENZHEN OFFICE (CHINA)
SHANGHAI OFFICE (CHINA)
BEIJING OFFICE (CHINA)
Tel: +86-755-8831-6488/6775/6075
Tel: +86-21-5046-1622/0833/0094
BUSINESS HEADQUARTERS
Tel: +886-2-2880-5600
Fax: +886-2-2888-3300
USA OFFICE
EUROPE (EMEA) OFFICE
TAIPEI OFFICE
Constant Current Discharge Characteristics Unit: A (25℃, 77℉)
Constant Power Discharge Characteristics Unit: W (25℃, 77℉)
Recognized under UL 1989,
and certified by ISO 9001, 14001, 45001, 50001.
Sales Offices
Terminal tightening torque
Container Material
ABS (UL 94-HB) & Flame Retardant (94-V0) available upon request
Dimensions
Short Circuit Current
458A
Maximum Charge Current
3.60A
Terminal types
F1/F2 Faston Tab Terminal (187/250)
Weight
Approx. 4.10 Kg (9.04 lbs)
Maximum Discharge Current
150/180A (5sec)
Internal Resistance
Approx. 13.2 mΩ
Discharge : -15℃ ~ 50℃ (5℉~122℉)
Charge: -15℃ ~ 40℃ (5℉~104℉)
Specification
Nominal Voltage
12V (6 cells per unit)
12 Ah @20hr-rate to 1.75V per cell @25℃ (77℉)
GPL series
GPL 12120
Valve Regulated Lead Acid Battery
General
Nominal Operating Temperature : 25℃(77℉)
