Crystal XP2i-DP Digital Differential Pressure Gauge User Manual

Operation Manual

for XP2i-DP Digital Test Gauge

Contents

Overview.................................................................1

Introduction ..............................................................1

Operating Instructions .....................................................1

Speciﬁcations ..........................................................2

Power .....................................................................3

Pressure Ranges, Display Scales, and Resolution .............................5

Applications ............................................................6

Dierential Pressure .......................................................6

Continuous Vacuum .......................................................7

Safety & Certiﬁcations...............................................8

Hazardous Locations .......................................................8

Certications ..............................................................8

Support ..................................................................9

Software ..................................................................9

Replacement Parts .........................................................9

Options ...................................................................9

Accessories ..............................................................10

Factory Service .......................................................... 11

Trademarks ............................................................. 11

Warranty ................................................................ 11

Overview

INTRODUCTION

Thank you for choosing the XP2i-DP Digital Test Gauge from Crystal Engineering Corporation. The XP2i-DP is a combination of leading edge

technology, double-sided isolated dierential pressure sensing, and rugged industrial design.

—

Overview  1

Based on the XP2i S

0.1% of reading accuracy wet/wet dierential transducer

•

Excellent performance in long term high vacuum applications

•

OPERATING INSTRUCTIONS

The XP2i-DP operates just like all the XP2i Series products. The uniqueness of the dierential pressure capability comes from the integration of the dieren-

tial sensor and process tting system. The keypad and remote functions are the same as on all XP2i Series products. For further details about these common

—

eatures, refer to the XP2i Operation Manual (P/N 4870).

eries platform, the –DP has all the key features of the product line with additional capabilities that include:

XP2i-DP Operation Manual

Speciﬁcations

Dierential Pressure Accuracy

20 to 100% of Full Scale . . . . . . . . . .± (0.1% of Reading + Static Line Eect).

0 to 20% of Full Scale . . . . . . . . . . . . ± (0.02% of Full Scale + Static Line Eect).

Static Line Eect: 0.0003 psi/psi of lowest static pressure.

Includes all eects of linearity, hysteresis, repeatability, temperature, and stability for one year.

Temperature

Operating . . . . . . . . . . . . . . . . . . . . . . . -10 to 50° C (14 to 122° F).

Non-condensing. No change in accuracy over operating temperature range. Gauge must be zeroed to achieve rated specication.

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . -40 to 75° C (-40 to 167° F).

Battery should be removed if stored for more than one month.

Media Compatibility

Liquids and gases compatible with 300 Series stainless steel and buna-n (o-ring).

Specications  2

Pressure Conversions

1 psi = 27.6806 inches of water column (water at 4° C [39.2° F])

27.7070 inches of water column (water at 15.6° C [60° F])

27.7292 inches of water column (water at 20° C [68° F])

2.03602 inches of mercury (mercury at 0° C [32° F])

51.7149 millimeters of mercury (mercury at 0° C [32° F])

703.087 millimeters of water column (water at 4° C [39.2° F])

0.070307 kilograms per square centimeter

68.948 millibar

6.8948 kilopascals

0.068948 bar

0.006895 megapascals

XP2i-DP Operation Manual

Connections

Pressure Connections . . . . . . . . . . . . 1/8" Female NPT (both + and – ports).

Communication . . . . . . . . . . . . . . . . .DB9, RS-232 (environmentally sealed).

Note: Do not use the RS-232 connector in a hazardous atmosphere.

Display

Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5 digits.

Display Rate . . . . . . . . . . . . . . . . . . . . . 4 readings/second (standard).

8 readings/second (PSV mode).

ical Display Height . . . . . . . . 16.9 mm (0.67") single line display. LCD readable in sunlight with bright backlight.

Numer

Enclosure

(U.S. Patent D612277)

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . 915g (2.0 lbs), including batteries.

Dimensions . . . . . . . . . . . . . . . . . . . . . . 165.1 mm (6.5") H x 112 mm (4.4") W x 33 mm (1.3") D.

Specications  3

Rating . . . . . . . . . . . . . . . . . . . . . . . . . . .IP67.

Housing . . . . . . . . . . . . . . . . . . . . . . . . .Diecast, nickel plating over low copper, marine grade aluminum.

Keypad and Labels . . . . . . . . . . . . . . . UV Resistant Polyester.

Sensor

Permanent ll dual diaphragm seal (lled with Dow Corning 200).

Max Static Line Pressure . . . . . . . . . .100 psi.

POWER

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . Three size AA (LR6) batteries.

—

WARNING: Do not remove or change the batteries in hazardous locations.

XP2i-DP Operation Manual
