3-4
A
m
p
•
120/240 Vac (AC OUTPUT) • 60
S
eries
V
d
M
c
(DC OUTPUT) • SI
P
P
• H
igh
P
ackaging Density
•
C
ompatible with
olt
L
ogi
c
V
• O
pto-Is
•
Z
ero Voltage
C
)
(A
MODEL NUMBER
AC OUTPUT SPECIFICATIONS
Operating Voltage Range (47-63 Hz) [Vrms] 12-140 24-280 24-280
Load Current Range [Arms] .02-3 .02-3 .02-4
Transient Overvoltage [Vpk] 400 600 600
Max. Surge Current, (16.6ms) [Apk] 90 90 130
Max. On-State Voltage Drop @ Rated Current [Vpk] 1.6 1.6 1.6
Maximum I2t for Fusing, (8.3 msec.) [A2sec] 36 36 72
Max. Off-State Leakage Current @ Rated Voltage [mArms] 5.0 5.0 5.0
Min. Off-State dv/dt @ Max. Rated Voltage [V/µsec] ➁ 200 200 200
Max. Turn-On Time 1/2 Cycle 1/2 Cycle 1/2 Cycle
Max. Turn-Off Time 1/2 Cycle 1/2 Cycle 1/2 Cycle
Power Factor (Min.) with Max. Load 0.5 0.5 0.5
➀
S
olated
5, 15 & 24
ystem
MP120D3 MP240D3 MP240D4
s
4000 V
S
witching
rm
s
Available in 3Arms and 4Arms ratings,
all are SPST-NO PC-mount relays that
provide greater packaging density and
compatibility with pin out of Series 6 and
OAC output modules. Internal snubber
included for high dv/dt applications (AC).
Manufactured in Crydom's ISO 9001
Certified facility for optimum product
performance and reliability.
DC OUTPUT SPECIFICATIONS
Operating Voltage Range [Vdc] 3-60
Load Current Range [Adc] 0.02-3.0
Max. Over Current (non-repetative) 1sec [A] 5.0
Max. On-State Voltage Drop @ Rated Current [Vdc] 1.5
Max. Turn-On time (T
Max. Turn-Off time (T
Max. Off-State Leakage Current @ Rated Voltage [mA] 1.0
INPUT
Control Voltage Range [Vdc] 3-32
Must Turn-On Voltage [Vdc] 3.0
Must Turn-Off Voltage [Vdc] 1.0
Typical Input Current @ 5Vdc [mA] 2.6
Nominal Input Impedance [Ohms] 1500
GENERAL
➀ All parameters at 25˚C unless otherwise specified.
➁ Off-State dv/dt test method per EIA/NARM standard
➂ Inductive loads should be diode suppressed.
FastFax Document No. 111
SERIES MP
Rev. 111303
PAGE 1 OF 2
SPECIFICATIONS
NOTES
RS-343, paragraph 13.11.1
delay
delay
+ T
) [µs] 100
rise
+ T
) [µs] 100
fall
➀
➀
©2003 CRYDOM CORP, Specifications subject to change without notice.
For recommended applications and more information contact:
USA: Sales Support (877) 502-5500 Tech Support (877) 702-7700 FAX (619) 710-8540
Crydom Corp, 2320 Paseo de las Americas, Ste. 201, San Diego, CA 92154
Email: sales@crydom.com
UK: +44 (0)1202 365070 • FAX +44 (0)1202 365090 Crydom International Ltd., 7 Cobham
Road, Ferndown Industrial Estate, Ferndown, Dorset BH21 7PE, Email: intsales@crydom.com.
GERMANY: +49 (0)180 3000 506
WEB SITE: http://www.crydom.com
MPDCD3
All M
odel
➂
s
3-4
A
m
p
•
120/240 Vac (AC OUTPUT) • 60
S
eries
V
d
M
c
(DC OUTPUT) • SI
P
P
CURRENT DERATING CURVES
4.0
3.0
2.0
LOAD CURRENT (AMPS)
1.0
0
20 40 60 80
AMBIENT TEMPERATURE (ûC)
GENERAL SPECIFICATION
Dielectric Strength 50/60Hz Input/Output/Base 4000 Vrms
Insulation Resistance (Min.) @ 500 Vdc 10
Max. Capacitance Input/Output
Ambient Operating Temperature Range
Ambient Storage Temperature Range -40 to 125˚C
MEC
HANICAL
Weight: (typical) 0.7 oz. (20g)
Encapsulation:
MP240D4
MP120D3
MP240D3
MPDCD3
.25 TYP. (6.35)
.040 (1.0) DIA.
(4 PLACES)
SPECIFICATION
BOTT
1.00
(25.4)
12 34
All dimensions are in inches (millimeters)
OM VIEW
1.10
(27.9)
S
S
CONTROLLOAD
.70
(17.8)
1.70
(43.1)
-40 to 80˚C
Thermally Conductive Epoxy
.025
(.64)
.20
(5.1)
.30
(7.6)
9
Ohm
8 pF
top to base
.16
(4.1)
AC O
PIN 1: AC LOAD
PIN 2: AC LOAD
PIN 3: +DC CONTROL
PIN 4: -DC CONTROL
DC O
PIN 1: +DC LOAD
PIN 2: -DC LOAD
PIN 3: +DC CONTROL
PIN 4: -DC CONTROL
1û draft
.40
(10.2)
utput
utput
APPR
OVALS
UL E116950
VDE 5900 UG (AC Output Only)
CSA LR81689 (AC Output Only)
FastFax Document No. 111
SERIES MP
Rev. 111303
PAGE 2 OF 2
