3-10
A
m
p
• 0-60, 0-
S
eries
100, 0-200 V
C
M
d
c
• DC OUTPUT SI
X
P
CURRENT DERATING CURVES
7.0
1.00
MAX.
(25.4)
.300 TYP.
(7.6)
.200
(5.1)
6.0
5.0
CMX60D5
4.0
3.0
CMX200D3
2.0
LOAD CURRENT [AMPS]
1.0
0
12.0
10.0
8.0
6.0
4.0
LOAD CURRENT [AMPS]
2.0
0
CONTROL LOAD
All dimensions are in inches (millimeters)
20 40 60 80
AMBIENT TEMPERATURE [˚C]
20 40 60 80
AMBIENT TEMPERATURE [˚C]
Max. Load Current vs. Temp.
43 2
.700
(17.8)
1.100
(27.9)
1.70
(43.1)
CMX100D6
CMX60D10
.300 (7.6)
1
.050
TYP.
(1.3)
.040 (1.0) DIA.
(4 PLACES)
PIN 1: +DC LOAD
PIN 2: ---DC LOAD
PIN 3: +DC CONTROL
PIN 4: --DC CONTROL
APPROVALS
UL E116950 (3 Amp, 6 Amp and 10 Amp Models)
FastFax Document No. 109
SERIES CMX
Rev. 031704
PAGE 1 OF 1
• MOSFET Output
• Extra Low On-State
Resistance
DC output SPST-NO solid state relays
use MOSFET output for high switching
capabilities in a PC-mount air-cooled
package. Pinouts are compatible with
Series 6 and ODC type I/O modules.
Manufactured in Crydom’s ISO 9001
Certified facility for optimum product
performance and reliability.
MODEL NO. CMX60D5 CMX60D10 CMX100D6 CMX200D3
INPUT SPECIFICATIONS
Control Voltage Range 3.0-10.0 Vdc
Nominal Input Impedance 300 Ohm
Typical Input Current @ 5 Vdc 15 mAdc
Must Turn On Voltage 3.0 Vdc
Must Turn Off Voltage 1.0 Vdc
OUTPUT SPECIFICATIONS ➀
Operating Voltage Range 0-60 Vdc 0-60 Vdc 0-100 Vdc
Load Current Range 0-5 Adc 0-10 Adc 0-6 Adc
Max. Surge Current, (10 msec) 60 Apk 100 Apk 100 Apk
Max.Off-State Leakage
@ Rated Voltage
Max. On-State Resistance
@ Rated Current (R
Max. On-State Voltage Drop
@ Rated Current
Max.Turn-On Time @ 10Vdc Control 1.0 msec
Max. Turn-Off TIme @ 10Vdc Control 300 µsec
DS-ON
)
GENERAL SPECIFICATIONS
Dielectric Strength➁ 2500 Vrms
Insulation Resistance (Min.) @ 500 Vdc
Max. Capacitance (Input/Output) 15 pF
Ambient Operating Temperature Range -30 to 80˚C
.100
Ambient Storage Temperature Range -30 to 125˚C
(2.5)
MECHANICAL SPECIFICATIONS
Weight: (typical) 0.4 oz. (11 g)
Encapsulation: Thermally Conductive Epoxy
GENERAL NOTES
➀
All parameters at 25ºC unless otherwise specified.
Dielectric and insulation resistance are
➁
measured between input and output.
➂ Inductive loads should be diode suppressed.
➃ At 55 Vdc.
For recommended applications and more information contact:
USA: Sales Support (877) 502-5500 Tech Support (877) 702-7700 FAX (619) 710-8540
Crydom Corp, 2320 Paseo de las Americas, Ste. 201, San Diego, CA 92154
Email: sales@crydom.com
UK: +44 (0)1202 365070 FAX +44 (0)1202 365090 Crydom International Ltd., 7 Cobham
Road, Ferndown Industrial Estate, Ferndown, Dorset BH21 7PE, Email: intsales@crydom.com.
GERMANY: +49 (0)180 3000 506
➀
3.0-10.0 Vdc
300 Ohm
15 mAdc
3.0 Vdc
1.0 Vdc
3.0-10.0 Vdc
300 Ohm
15 mAdc
3.0 Vdc
1.0 Vdc
➂
100 µAdc 100 µAdc
100 µAdc
.10 Ohm .018 Ohm .040 Ohm
0.5V 0.18V 0.24V
1.0 msec
300 µsec
➁
© 2004 CRYDOM CORP, Specifications subject to change without notice.
WEB SITE: http://www.crydom.com
➃
1.0 msec
300 µsec
109Ohm
4.0-10.0 Vdc
300 Ohm
15 mAdc
4.0 Vdc
1.0 Vdc
0-200 Vdc
0-3 Adc
30 Apk
100 µAdc
.20 Ohm
0.6 V
1.0 msec
300 µsec
