DIN Rail Mount
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
SeriesOne DR Series
AC
ATEX
• Ratings of 6 & 12 Amps
• Load voltage ratings of 1-60VDC, 1-100VDC, 24-280VAC and 48-600VAC
• Fits standard 35mm DIN Rail
• LED input status indicator
• AC or DC control
• Zero Voltage (resistive loads) or Instantaneous (inductive loads) turn-on output
• UL and cUL Listed, HP Rated CE & RoHS Compliant
• UL 508 Endurance Rating for Enhanced Reliability
• UL Class I and II, Division 2, for Hazardous Locations
PRODUCT SELECTION
Control Voltage 280, 6 A 280 V, 12 A 600 V, 6 A 600 V, 12 A 60 V, 6 A 60 V, 12 A 100 V, 6 A 100 V, 12 A
4-32 VDC DR24D06X DR10D12X
90-140 VAC DR24B06X
200-280 VAC DR24A06X
18-36 VAC
DR24E06X DR24E12X
AVAILABLE OPTIONS
Operating Voltage
06: 1-60 VDC
10: 1-100 VDC
Series
24: 24-280 VAC
48: 48-600 VAC
DR24D12X
DR24B12X
DR24A12X
DR48D06X
Rated Load Current
06: 6 Amps
12: 12 Amps
DR48D12X DR06D06X DR06D12X DR10D06X
DR48B12X
DR48A12X
DR48E12X
Switching Type
Blank: Zero Voltage Turn-On
(AC Output Only)
R: Instantaneous Turn-On
(AC Output, D suffix Only)
DC
Control Voltage
D: 4-32 VDC
A: 200-265 VAC
B: 90-140 VAC
E: 18-36 VAC (1)
Required for valid part number
For options only and not required for valid part number
OUTPUT SPECIFICATIONS AC Output
1206 DDR
(2)
X
Agency Approvals
X: ATEX II 3G Ex nA IIC T4 Gc
approved
AC
Output
Only
R
Description DR24x06X DR24x12X DR48x06X DR48X12X
Operating Voltage Range (47-63Hz) [Vrms] 24-280 24-280 48-600 48-600
Transient Overvoltage [Vpk] 600 600 1200 1200
Maximum Load Current, resistive [Arms] (3) 6 12 6 12
Minimum Load Current [mArms]
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/
Maximum On-State Voltage Drop @ Rated Current [Vrms]
Maximum Surge Current (50/60Hz, 1 cycle) [Apk]
Maximum I²t for Fusing (50/60 Hz, 1/2 cycle) [A² sec]
HP Rating UL 508/IEC60947 [HP (KW)] @ 240V
HP Rating UL 508/IEC60947 [HP (KW)] @ 380V
HP Rating UL 508/IEC60947 [HP (KW)] @ 480V
Minimum Power Factor (at Maximum Load)
Min/Max stranded wire
Min/Max solid wire
Weight (Typical)
µsec] (4)
150 150 150 150
0.1 0.1 0.1 0.1
500 500 500 500
1.3 1.3 1.3 1.3
285/300 715/750 285/300 715/750
400/375 2560/2330 410/375 2560/2330
1/2 (.37) 1 (.75) 1/2 (.37) 1 (.75)
N/A N/A 1 (1.5) 2 (1.5)
N/A 2 (1.5)N/A 3 (2.2)
0.5 0.5 0.5 0.5
22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG
22/14 AWG22/14 AWG 22/14 AWG 22/14 AWG
1.76 oz. (50g) 1.76 oz. (50g)3.17 oz. (90g) 3.17 oz. (90g)
DIN Rail Mount
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
OUTPUT SPECIFICATIONS DC Output
(2)
Description DR06D06X DR10D06X DR06D12X DR10D12X
Operating Voltage [VDC] 1-60 1-100 1-60 1-100
Maximum Load Current [Adc] (3) 6 6 12 12
Minimum Load Current [mAdc] 2.5 2.5 2.5 2.5
Maximum Off-State Leakage Current @ Rated Voltage [mA]
Maximum On-State Voltage Drop @ Rated Current [Vpk]
Maximum Surge Current (10ms) [Apk]
On-State resistance at rated current [Ohms]
Min/Max stranded wire
Min/Max solid wire
Weight (typical)
INPUT SPECIFICATIONS
Control Voltage Range (5) 4-32 VDC 200-265 Vrms 18-36 Vrms (1)
Minimum Turn-On Voltage 4.0 VDC 200 Vrms 18 Vrms
Must Turn-Off Voltage 1.0 VDC 40 Vrms 4 Vrms
Minimum Input Current for [mA] (6) 9 2.5 3.5
Maximum Input Current for [mA] (6) 11 3.3 8
Maximum Turn-on Time [msec] (7) (8)
Maximum Turn-off Time [msec] (9)
Min/Max stranded/solid wire
GENERAL SPECIFICATIONS
(2)
1/2 Cycle 20 msec 20 msec
1/2 Cycle 30 msec 30 msec
22/16 AWG 22/16 AWG 22/16 AWG
(2)
0.1 0.1 0.1 0.1
0.6 0.6 0.6 0.6
60 60
0.1 0.1
22/14 AWG 22/14 AWG
22/14 AWG 22/14 AWG
1.94 oz. (55g) 1.76 oz. (50g)
DRxxAxxX
90-140 Vrms
90 Vrms
10 Vrms
3
5
20 msec
30 msec
22/16 AWG
100 100
0.45
22/14 AWG
22/14 AWG
3.17 oz (90g)
DRxxExxXDRxxBxxXDRxxDxxXDescription
0.45
22/14 AWG
22/14 AWG
3.17 oz.(90g)
Description Parameters
Dielectric Strength, Input/Output/Base (50/60Hz) 4000 Vrms (10)
Minimum Insulation Resistance (@ 500 VDC)
Maximum Capacitance, Input/Output 10 pF
Ambient Operating Temperature Range -20 to 40 °C
Ambient Storage Temperature Range -30 to 100 °C
Recommended Terminal Screw Torque Range
9
10
Ohm
4.4-7.0 in-lb (0.5-0.8Nm)
GENERAL NOTES
(1) E option is UL certified for AC control voltage, but it works also with 18-36 VDC input range.
(2) All parameters at 25°C unless otherwise specified.
(3) See Derating curves
(4) Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
(5) DC control includes reverse polarity protection.
(6) Input circuitry incorporates active current limiter.
(7) Turn-on time for DC control random turn-on versions is 0.1 msec.
(8) Turn-on time for DC output 600
(9) Turn-off time for DC output 300
(10) 2500Vrms for DC output.
µsec.
µsec.
Standards of Compliance
IEC 62314
LC A, Resistive or Slightly Inductive Load Ratings: 12 A @40°C ambient for DR24x12X, 12 A @ 40°C ambient for DR48x12X
LC A, Resistive or Slightly Inductive Load Ratings: 6 A @ 40°C ambient for DR24x06X, 6 A @ 40°C ambient for DR48x06X
LC B, Motor Loads Ratings: 0.75KW @ 240 VAC for DR24x06X and 2.2KW @ 480 VAC DR48x12X
LC B, Motor Loads Ratings: 0.375KW @ 240 VAC for DR24x06X and 1.5KW @ 480 VAC DR48x12X
Shock and Vibration (Applies to all part numbers)
Vibration Resistence according to IEC 60068-2-6: 0.35mm and 0.75mm Amplitude over 10-55 Hz
Shock Resistance according to IEC 60068-2-27: 15g/11ms
EMC (Applies to all part numbers)
IEC 61000-4-2: Electrostatic Discharge- Level 3
IEC 61000-4-4: Electrically Fast Transients- Level 3
IEC 61000-4-5: Electrical Surges- Level 3
ANSI / ISA 12.12.01-2013
Nonincendive Electrical Equipment for Use in Class I and II, Division 2 and Class III, Division 1 and 2 Hazadous (classified) locations
This equipment is open-type device and is meant to be installed in an enclosure suitable for the enviroment such that the equipment is only accesible with the use of a tool
suitable for use in Class 1, Division 2, Group A,B,C and Hazardous locations, or Nonhazardous locations only
WARNING-Explosion Hazard- Do not disconnect equipment while the circuit is live or unless the area is known to be free of ignitable concentrations
WARNING-Explosion Hazard- Substitution of any component may impair suitability for Class I, Division 2
ATEX
Compliance with Essential Health and Safety Requirements has been assessed by reference to Standards EN 60079-0:2012+A11:2013
and EN 60079-15-:2010
DIN Rail Mount
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
MECHANICAL SPECIFICATIONS
(2)
EQUIVALENT CIRCUIT BLOCK DIAGRAMS/WIRING DIAGRAMS
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
THERMAL DERATE INFORMATION
Derating Curves are not approved for the ATEX Certification
DRxxx06X
6
5
4
3
2
Load Current (Amps)
1
0
100 20 30 40 50 60 70 80
Ambient Temperature (ºC)
DRxxx12X
12
DIN Rail Mount
DataSheet
10
8
6
4
Load Current (Amps)
2
0
100 20 30 40 50 60 70 80
Ambient Temperature (ºC)
Multiple units, no minimum spacing between components
AGENCY APPROVALS
IND CONT EQ
4WB8
Agency Approvals
II 3G Ex nA IIC T4 GcE364559
Rev 052516
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
ACCESORIES
DIN Rail Mount
DataSheet
DIN Rail Mount
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
DANGER / PELIGRO / DANGER /GEFAHR / PERICOLO / 危险
HAZARD OF
ELECTRIC
SHOCK,
EXPLOSION,
OR ARC FLASH.
• Disconnect all
power before
installing or
working with
this equipment.
• Verify all
connections
and replace all
covers before
turning on
power.
Failure to follow
these
instructions will
result in death
or serious injury.
RIESGO DE
DESCARGA
ELECTRICA O
EXPLOSION.
• Desconectar
todos los
suministros de
energia a este
equipo antes
de trabajar
con este equipo.
• Verificar todas
las
conexiones
y colocar todas
las ta
pas antes
de energizer
el equipo.
El
incumplimiento
de estas
instrucciones
puede provocar
la muerte o
lesiones serias.
RISQUE DE
DESCHARGE
ELECTRIQUE
OU EXPLOSION
• Eteindre
toutes les
sources
d'énergie de
cet appareil
avant de
travailler
dessus de cet
appareil
• Vérifier tous
connections, et
remettre tous
couverts en
olace avant de
mettre sous
De non-suivi de
ces instructions
provoquera la
mort ou des
lésions sérieuses
sérieuses.
GEFAHR EINES
ELEKTRISCHE
N SCHLAGES
ODER EINER
EXPLOSION.
• Stellen Sie
jeglichen
Strom ab, der
d
ieses Gerät
versorgt, bevor
Sie an dem
Gerät Arbeiten
durchführen
• Vor dem
Drehen auf
Energie alle
Anschlüsse
überprüfen
und alle
Abdeckungen
ersetzen.
Unterlassung
dieser
Anweisungen
können zum
Tode oder zu
schweren
Verletzungen
führen.
RISCHIO DI
SCOSSA
ELETTRICA O
DELL’ESPLOSIONE.
• Spenga tutta
l'alimentazione
che fornisce
questa
apparecchiatura
prima di lavorare
a questa
apparecchiatura
• Verificare tutti
i collegamenti
e sostituire
tte le coperture
tu
prima
dell’accensione
L'omissione di
queste istruzioni
provocherà la
morte o
lesioni serie
存在电击、
爆炸或电弧
闪烁危险
•
在操作此设
备之前请先
关闭电源。
若不遵守这些说明，
可能会导致严重的
人身伤害甚至死亡。
WARNING / AVERTISSEMENT / WARNUNG /ADVERTENCIA / AVVERTENZA / 警告
RISK OF MATERIAL DAMAGE AND HOT
ENCLOSURE
• The product's side panels may be hot, allow
the product to cool before touching.
• Follow proper mounting instructions including
torque values.
• Do not allow liquids or foreign objects to enter
this product.
Failure to follow these instructions can result in
serious injury, or equipment damage.
RIESGO DE DAÑOS MATERIALES Y DE
SOBRECALENTAMIENTO DE LA UNIDAD
• Los paneles laterales del producto pueden
estar calientes. Esperar que el producto se
enfríe antes de tocarlo.
• Respetar las instrucciones de montaje, y en
particular los pares de apretado.
• No dejar que penetren líquidos o cuerpos
extraños en el producto.
Si no se respetan estas precauciones pueden
producirse graves lesiones, daños materiales.
RISQUE DE DOMMAGE MATERIEL ET DE
SURCHAUFFE DU BOITIER
• Les panneaux latéraux du produit peuvent être
chauds. Laisser le produit refroidir avant de le
toucher.
• Respecter les consignes de montage, et
notamment les couples de serrage.
• Ne pas laisser pénétrer de liquide ni de corps
étrangers à l'intérieur du produit.
Le non-respect de cette directive peut entraîner,
des lésions corporelles graves ou des
dommages matériels.
RISCHIO DI DANNI MATERIALI E D'INVOLUCRO
CALDO
• I pannelli laterali dell'apparecchio possono
scottare; lasciar quindi raffreddare il prodotto
prima di toccarlo.
• Seguire le istruzioni di montaggio corrette.
• Non far entrare liquidi o oggetti estranei in questo
apparecchio.
La mancata osservanza di questa precauzione può
causare gravi rischi per l'incolumità personale o
danni alle apparecchiature.
GEFAHR VON MATERIALSCHÄDEN UND
GEHÄUSEERHITZUNG
• Die Seitenwände können heiß sein. Lassen Sie
das Produkt abkühlen, bevor Sie es berühren.
• Beachten Sie die Montageanweisungen,
• Führen Sie keine Flüssigkeiten oder
Fremdkörper in das Produkt ein.
Die Nichtbeachtung dieser Anweisung kann
Körperverletzung oder Materialschäden
zur Folge haben.
材料损坏和高温外壳的危险性
• 产品的一侧面板可能很热 在其冷却前请
不要触碰。
• 遵照正确的安装说明 包括扭矩值。
• 请勿让液体及其他异物进入本产品。
如不能正确执行这些操作说明，
极有可能造成严重人体伤害或者设备的损坏。
DIN Rail Mount
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
ANNEX - ENVIROMENTAL INFORMATION
The environmental information disclosed in this annex including the EIP Pollution logo are in compliance with People’s Republic of China
Electronic Industry Standard SJ/T11364 – 2006, Marking for Control of Pollution Caused by Electronic Information Products.
Part
Name
Semiconductor die
Solder
附件 - 环保信息
此附件所标示的包括电子信息产品污染图标的环保信息符合中华人民共和国电子行业标准 SJ/T11364 2006,
电子信息产品污染控制标识要求。
名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚
半导体芯片
焊接点
Toxic or hazardous Substance and Elements
Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated
(Pb) (Hg) (Cd)
(Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE)
Chromium
(Cr (VI))
有毒有害物质或元素件部
biphenyls
(PBB)
diphenyl ethers
(PBDE)
50
Loading...
