Crydom DRC Series Dimensional Sheet
www.crydom.com
1.74
44.2
REV. DATE
DRC Series 3 Phase, With Auxiliary Contacts
2.58
65.5
SCREW TRHEAD 3.5mil
(12 PLACES)
3.01
76.5
2.29
58.3
1.23
31.3
05/08/17
For Technical Support:
support@crydom.com
support-europe@crydom.com
3.51
89
1.78
45.3
3.76
95.6
2.91
73.9
3.41
86.7
Tolerances: ± 0.02 in / 0.5 mm. All dimensions are in: inches [millimeters]
U N L E S S O T H E R W I S E S P E C I F I E D, D I M E N S I O N S A R E I N “i n [m m]” I N F O R M A T I O N I N T H I S D R A W I N G I S P R O V I D E D F O R R E F E R E N C E O N L Y A N D I S S U B J E C T T O C H A N G E.
www.crydom.com
1.74
44.2
REV. DATE
DRC Series 3 Phase, Without Auxiliary Contacts
2.58
65.5
SCREW TRHEAD 3.5mil
(8 PLACES)
3.01
76.5
2.29
58.3
1.23
31.3
05/08/17
For Technical Support:
support@crydom.com
support-europe@crydom.com
3.51
89
1.78
45.3
3.76
95.6
2.91
73.9
3.41
86.7
Tolerances: ± 0.02 in / 0.5 mm. All dimensions are in: inches [millimeters]
U N L E S S O T H E R W I S E S P E C I F I E D, D I M E N S I O N S A R E I N “i n [m m]” I N F O R M A T I O N I N T H I S D R A W I N G I S P R O V I D E D F O R R E F E R E N C E O N L Y A N D I S S U B J E C T T O C H A N G E.
