Crouzet 87623573 Data Sheet

Electronic multifunction counters without preselection

➜ Multifunction counter with 2 totalizers (total and partial function) with common input - LED 24 x 48 - CTR24L

Scale factor 1 ➞ 99.9999 (separate for A and B)
Scaling factor 1
Decimal point 0

➞ 99.9999 (separate for A and B)

0.0

0.00

0.000

Maximum counting frequency 50 k Hz

■ High brightness display: 6-digit LED, height 8 mm

■ Maximum input frequency 50 k Hz

■ Counter with 2 separate totalizers and a common input

(INPA)

■ Reset on panel or external with inhibition option

■ Supply: 10 ➞ 30 V

c

■ Easy to program

■ Scaling factor

■ Decimal point

■ Accessories for 50 x 25 mm cut-out

Part numbers

Type Functions Code

CTR24L - 2514 Counter with 2 separate totalizers and a common input

87623573

Accessories

Description Code

Adaptor for 50 x 25 mm cut-out - Fixed with screws
Adaptor for 50 x 25 mm cut-out - Fixed with clips
DIN rail adaptor
Clip-fixing kit (supplied with the product)

26546843
26546844
26546840
26546848

General characteristics

Environmental characteristics

Consumption
Connection by 5 screw terminals at rear of casing
Terminal capacity
Fixed using bracket

10

✓

1.5 mm

✓

Degree of protection front face IP 65
Data memory EEPROM
Temperature limits use (°C) -20
Temperature limits stored (°C) -25
Breakdown voltage Selon EN 61010-1: 2000 V / 50 Hz / 1 min
Conformity to standards EN 61000-6-2 - EN 55011 class B
Altitude 2000 m
Certifications UL - cULus (pending) - CE
Weight (g) 50

Operating characteristics

Functions Counter with 2 separate totalizers and a common input
Display 6-digit LED
Height digits (mm) 8

Input characteristics

Inputs 1 counter input (INPA), 1 reset input
Low level

High level
Cyclical ratio Any (maximum frequency given for a cyclical ratio = 1/1)

0

0.6 x Ub

Schmitt trigger input
Polarity NPN or PNP for all inputs (programming)
Minimum impulse duration for reset 5 ms
Frequency of filtered input Filter active: 30 Hz

Filter disabled: maximum frequency (programming)
Input impedance (kΩ) Appr. 5

Impulse counter (Partial - Totalizer)

Display details 0
Display When the buttons are pressed, the counter displays the following values:

Elimination of non-significant zeros

Total 1

Total 2

✓

Counting input mode INPA input counting
Input INPA Dynamic
Reset input (terminal 5) Dynamic Reset input connected in parallel with the red SET/RESET button
Reset to zero - Panel If not locked during programming
Remise à zéro - Externe (borne 5) If not locked during programming

c

➞ 30 V

2

➞ +55
➞ +70

➞ 0.2 x Ub V

➞ 30 V

➞ 999 999

max 55 mA with protection against polarity reversal

c

c

Dimensions (mm)

CTR24L - 2514 Fixing strip with clip-on yoke Panel cut-out

48

24

CTR24L

19,3

22x45

4

59

6,5

Seal

1

Fixing yoke

2

4 appliances 26546843 - Adaptor for 50 x 25 mm cut-out -

+ 0,6

3045

+ 0,3

20 22,2

Fixed with screws

40

32

1

2

26546844 - Adaptor for 50 x 25 mm cut-out ­Fixed with clips

56

28

25X50

1

4

Accessory supplied with the counter

26546840 - DIN rail adaptor

101

45

45

75

83

50,4 x 25,4

70

Connections

1 2 3 4 5

Supply: 10

1

Supply: GND (0 Vc)

2

INPA

3

NC

4

SET/RESET

5

➞ 30 V

c

+0,3

- 0

22,2

53

+0,6

45

25X50

1

4

44
