Speed control
HSV
Part numbers
Product adaptations
Accessories
General characteristics
➜ Speed control relay - 35 mm
■ Control of overspeed, underspeed, operating rate,
stopping
■ Measurement via discrete sensors - 3-wire PNP or
NPN, Namur, voltage 0-30V or volt-free contact type
■ Works with either NO or NC sensors
■ Time between pulses adjustable from 0.05 s to 10 min.
■ Power-on inhibit time, adjustable from 0.6 to 60 s
■ Inhibit time can be managed via an external contact
Type Nominal voltage (V) Code
HSV
24
➞ 240 V
z
■ Customisable colours and labels
■ Possible to delete settings
■ Fixed threshold in the generic measurement range
■ Fixed or adjustable time delay
84874320
Description Code
Removable sealable cover for 35 mm casing
Supply
Supply voltage Un
Voltage supply tolerance -15% / +10%
Operating range
Polarity with DC voltage No
a
supply voltage frequency
Galvanic isolation of power supply/measurement Yes
Power consumption at Un
Immunity from micro power cuts 50 ms
Inputs and measuring cicuit
Input circuit 3-wire sensors PNP or NPN, 12V, 50 mA max.
Input circuit NAMUR sensor 12 V / 1.5 KΩ *
Input circuit Contact 12 V / 9.5 KΩ
Input circuit Voltage input 0 V min. /30 V max. /9.5 KΩ
Minimum pulse time 5 ms in high and low state
Frequency of measured signal 1.5 m Hz minimum, 22 Hz maximum
Measurement ranges 0.5 s - 1 s - 5 s - 10 s - 1 mn - 5 mn - 10 mn
Threshold adjustment 10
Fixed hysteresis 5% of displayed threshold
Display precision ±10% of full scale
Repetition accuracy with constant parameters ± 0.5%
Measuring error with voltage drift < 1% across the whole range
Measuring error with temperature drift ± 0.1% / °C max.
Timing
Maximum threshold crossing response time 15 ms
Reset time S2 50 ms minimum (in memory mode)
Reset time In memory mode (power break) : 1500 ms minimum
Inhibit time delay On energisation: 0.6
Repetition accuracy with constant parameters ± 0.5%
Delay on pick-up 50 ms
Display precision ±10% of full scale
24 V
20.4 V
50 / 60 Hz ±10%
5 VA in
High state 4.5 V min.
Low state 1 V max.
➞ 100% of the range
➞ 240 V
➞ 264 V
a
/3 W in
z
z
c
➞ 60 s (0, +10% of full scale)
84800001
56
www.crouzet.com
General characteristics
Output
Type of output 1 single pole changeover relay
Type of contacts No cadmium
Maximum breaking voltage
Max. breaking current
Min. breaking current
Electrical life (number of operations)
Breaking capacity (resistive)
Maximum rate 360 operations/hour at full load
Operating categories acc. to IEC 60947-5-1 AC 12, AC 13, AC 14, AC 15, DC 12, DC 13, DC 14
Mechanical life (operations)
Insulation
Nominal insulation voltage IEC 60664-1 250 V
Insulation coordination (IEC 60664-1 / 60255-5) Overvoltage category III: degree of pollution 3
Rated impulse withstand voltage IEC 60664-1/60255-5 4 KV (1.2 / 50 µs)
Dielectric strength IEC 60664-1/60255-5 2 kV AC 50 Hz 1 min
Insulation resistance IEC 60664-1 / 60255-5
General characteristics
Display power supply Green LED
Display relay Yellow LED
Inhibit display Yellow LED
Casing 35 mm
Mounting On 35 mm symmetrical DIN rail, IEC/EN 60715
Mounting position All positions
Material: enclosure plastic type VO to UL94 standard Incandescent wire test according to IEC 60695-2-11 & NF EN 60695-2-11
Protection (IEC 60529) Terminal block: IP20
Weight 120 g
Connecting capacity IEC 60947-1
Max. tightening torques IEC 60947-1 0.6
Operating temperature IEC 60068-2 -20
Storage temperature IEC 60068-2 -40
Humidity IEC 60068-2-30 2 x 24 hr cycle 95% RH max. without condensation 55°C
Vibrations according to IEC/EN60068-2-6 10
Shocks IEC 60068-2-6 5 g
Standards
Marking CE (LVD) 73/23/EEC - EMC 89/336/EEC
Product standard NF EN 60255-6 / IEC 60255-6 / UL 508 / CSA C22.2 N°14
Electromagnetic compatibility Immunity EN 61000-6-2/IEC 61000-6-2
Certifications UL, CSA, GL
Conformity with environmental directives RoHS, WEEE
Comments
The IEC 60947-5-6/1999-12 NAMUR standard does not impose the operating voltage (open circuit voltage) or the load resistance (source resistance of the
control amplifier), but it defines the test conditions for which, using the sensor voltage/current characteristics with high and low impedance, the normal
operating zones are specified. The great majority of NAMUR sensors use a 12 V supply voltage. Matching the load resistance to the operating voltage allows
the nominal switching distance to be maintained.
a/ c
250 V
z
5A
10 mA / 5 V
1 x 10
1250 VA
30 x 10
> 500 MΩ / 500 V
c
5
a
6
c
Casing: IP30
Rigid: 1 x 4
1 x 11 AWG - 2 x 14 AWG
Flexible with ferrules: 1 x 2.5
1 x 14 AWG - 2 x 16 AWG
Emission EN 61000-6-4/EN 61000-6-3
IEC 61000-6-4/IEC 61000-6-3
Emission EN 55022 class B
2
- 2 x 2.52 mm2
➞ 1 Nm / 5.3 ➞ 8.8 Lbf.In
➞ +50°C
➞ +70°C
➞ 150 Hz, A = 0.035 mm
2
- 2 x 1.52 mm
pending
2
57
HSV
Speed control
Principles
Overview
The HSV relay controls the speed (or, more strictly speaking, the operating rate, or frequency) of a process (moving walkway, conveyor, etc.) using
discrete sensors:
- 3-wire PNP or NPN output proximity sensor
- voltage input 0 - 30 V
- NAMUR proximity sensor
- volt-free contact
It can be used to monitor under OR overspeed
Operating principle
Measurement
The monitored process cycle is the succession of pulses characterised by a signal with two states: high and low. The speed measurement is obtained by
measuring the duration of this signal, from the first detected change of state (either a rising or falling edge).
Digital signal processing avoids the problem of disparity of signals.
From energisation, or after the appearance (or reappearance) of the sensor signal, detection (characterisation) of the signal requires processing of one or
more periods (two maximum).
During this time, control is inoperative.
Operating mode
Using the selector switch, select one of four modes:
- Underspeed without latching
- Underspeed with latching
- Overspeed without latching
- Overspeed with latching
If, on energisation, the switch is placed in one of the three intermediate positions (between "underspeed with latching" and "overspeed with latching"), the
relay stays in the rest state ("alarm") and the error is signalled by all three LEDs flashing simultaneously.
The mode selector switch position is taken into account on energisation.
Modifications made during operation will have no effect: the active configuration may therefore be different from that indicated by the switch, the relay
operates normally but the change in configuration is signalled by all three LEDs flashing simultaneously.
Latching
In "memory" mode, when a fault has been recorded, the HSV relay latches in the rest position ("alarm" operational state). Once the speed is correct
again, the relay can be unlatched (reset) by closing contact S2 (for 50 ms minimum).
Irrespective of the speed of the controlled process, when S2 is closed the HSV relay is inhibited, the output is at the operating point ("normal" operational
state) ; if the speed is still not correct when contact S2 is reopened, the relay latches again in the rest position ("alarm" operational state).
The HSV can also be reset, by switching off and on again several times in succession (the power break must last at least 1500 ms).
If the process speed is incorrect, this method is limited by the same restriction as resetting using S2.
HSV - Control of underspeed without latching After the end of the inhibit delay on starting, "Ti", as soon as the measured speed drops below the
6
1
2
Ti Ti
3
4
5
Voltage (S1)
B
Threshold
C
Inhibit LED
D
Relay
E
Inhibit delay on starting (Ti)
F
1500 ms min.
G
Speed
H
threshold value, the output relay changes state, from operating point to rest position ("alarm"
operational state, 11-14 open and 11-12 closed).
It returns to the initial state when the speed rises above the threshold plus the hysteresis (fixed at
5% of the displayed threshold).
After the power supply returns, following a break that has lasted at least 1500 ms, the relay is in
the ("normal") operating state during the time delay and stays there until the speed is above the
7
threshold.
58
www.crouzet.com
Principles
HSV - Control of underspeed with latching When the HSV has been configured in "memory" mode, if underspeed is detected, the output
8
1
7
2
3
Ti
4
5
6
Voltage (S1)
B
Contact S2
C
Threshold
D
Inhibit LED
E
Relay
F
Inhibit delay on starting (Ti)
G
50 ms min.
H
1500 ms min.
I
Speed
J
Ti
relay stays in the rest state ("alarm") irrespective of any subsequent change in the speed of the
process.
It will not be able to revert to ("normal") operating state until contact S2 closes (50 ms minimum).
If, when S2 reopens, the speed is inadequate, the relay reverts to the rest latched state ("alarm").
The HSV can also be reset by a power break (1500 ms minimum) ; the relay then returns to the
("normal") operating state for at least the duration of the time delay, irrespective of the speed of
the process.
9
HSV - Underspeed with inhibition by S2 On energisation, to allow the controlled process to reach its nominal operating speed, the HSV
1
2
3
Ti
4
5
6
Voltage (S1)
B
Contact S2
C
Threshold
D
Inhibit LED
E
Relay
F
Inhibit delay on starting (Ti)
G
Speed
H
HSV - Control of overspeed without latching After the end of the inhibit delay on starting, "Ti", as soon as the measured speed rises above the
6
1
2
Ti
3
6
4
5
Voltage (S1)
B
Threshold
C
Inhibit LED
D
Relay
E
Inhibit delay on starting (Ti)
F
1500 ms min.
G
Speed
H
Ti
relay is inhibited for a period that is adjustable from 0.6 to 60 seconds.
This time delay can be modified during inhibition to be shorter or longer.
The HSV relay can also be inhibited by the closing of contact S2: on starting, for example, if the
process acceleration time is more than 60 s, or at any time during operation.
Irrespective of the origin (delay on starting or S2 closing), inhibition maintains the output relay in
7
the’’closed’ position’’ ("normal" operational state, contacts 11-14 closed and 11-12 open) and is
signalled by the Inhibit LED lighting up.
If, after removal of the inhibition (end of delay on starting or opening of contact S2), the signal
detection phase has not ended, the relay drops out after the expected time between two pulses
(measured from the end of inhibition).
Inhibition must last for as long as required for the product to detect at least 2 periods.
If the signal type has not been determined at the end of the inhibit period, the "inhibit" LED flashes
for as long as it is impossible to measure the speed.
Similarly, during operation, it is possible to inhibit the HSV relay at any time by closing S2.
threshold value, the output relay changes state, from operating point to rest position ("alarm"
operational state, 11-14 open and 11-12 closed).
It returns to the initial state when the speed falls back below the threshold minus the hysteresis
(fixed at 5% of the displayed threshold).
After a power break that has lasted at least 1500 ms, the relay is in the ("normal") operating state
during the time delay and stays there until the speed is below the threshold.
7
59
HSV - Control of overspeed with latching When the HSV has been configured in "memory" mode, if overspeed is detected, the output relay
Speed control
Principles
1
2
3
4
5
6
7
Ti
8
1
2
3
Ti
4
5
6
Voltage (S1)
B
Contact S2
C
Threshold
D
Inhibit LED
E
Relay
F
Inhibit delay on starting (Ti)
G
50 ms min.
H
1500 ms min.
I
Speed
J
HSV - Overspeed with inhibition by S2
7
Ti
stays in the rest state ("alarm") irrespective of any subsequent change in the speed of the
process. It will not be able to revert to ("normal") operating state until contact S2 closes (50 ms
minimum). If, when S2 reopens, the speed is too high, the relay reverts to the rest latched state
("alarm").
The HSV can also be reset by a power break (1500 ms minimum) ; the relay then returns to the
("normal") operating state for at least the duration of the time delay, irrespective of the speed of
the process.
9
It is possible to inhibit the HSV relay by closing external contact S2 until the process has reached
its nominal speed.
Voltage (S1)
B
Contact S2
C
Threshold
D
Inhibit LED
E
Relay
F
Inhibit delay on starting (Ti)
G
Speed
H
60
Dimensions (mm)
HSV
3,5
www.crouzet.com
60
44
23,2
35
45
67,5
Connections
HSV - Input circuits
1
Y1 12 V
12 V E1 E2 0 V
A1 A2
+/–
24…240 V
50/60 Hz
–/+
S2 Inhibit - Reset
B
Volt-free contact input 12 V, 9.5 kΩ
C
S1
2
12
5,5
11
14
1112 14
90
2,6
2
+–
1
Y1 12 V
R
A1 A2
+/–
24…240 V
50/60 Hz
–/+
B
C
S1
S2 Inhibit - Reset
NAMUR proximity sensor input 12 V, 1.5
k
Ω
12 V E1 E2 0 V
11
14
12
1112 14
R
1
Y1 12 V
12 V E1 E2 0 V
A1 A2
+/–
24…240 V
50/60 Hz
–/+
B
C
S1
S2 Inhibit - Reset
3-wire PNP/NPN proximity switch 12 V,
50 mA max.
2
BBU
BK
11
R
14
12
1112 14
1
Y1 12 V
A1 A2
+/–
24…240 V
50/60 Hz
–/+
B
C
S1
S2 Inhibit - Reset
Voltage input 0 V - 30 V
2
+–
℮
12 V E1 E2 0 V
11
R
14
12
1112 14
61
Loading...
