Crouse Hinds N2MV Dimensional Sheet

3L

50-175W N2MV Series

Champ®H.I.D. Luminaires
Non-Metallic

N2MV Dimensions

Dimensions and Weights

Ceiling Mount

25° Angle Stanchion Mount

Ceiling Mount – Top View

Pendant Mount

772

Net Luminaire Weights (lbs.)

Wall Arm Mount

US: 1-866-764-5454 CAN: 1-800-265-0502 Copyright©2006 Cooper Crouse-Hinds

Luminaire
Series

N2MVS 50 23 70 231⁄16

N2MVC 100 211⁄16 175 221⁄4

N2MVM 70 21 100 21

Add for mounting modules (lbs.):

Pendant 11⁄4 Flexible Pendant 11⁄2
Ceiling 23⁄4 Wall 41⁄2
Quad Mount 31⁄2 Angle Stanchion 31⁄2
Straight Stanchion 41⁄2

Add for reflectors (lbs.):

Dome 11⁄4 30° Angle 13⁄4

Deduct: 1 lb. for luminaire without P33 Guard.
Add: 5

Lamp
Watts

100 241⁄16 150 261⁄8

250 24

175 221⁄4 250 24

1

⁄2 lbs. for luminaire with GR305 refractor.

Luminaire with
Globe, Guard
(lbs.)

Lamp
Watts

Luminaire with
Globe, Guard
(lbs.)

1

⁄16
