Crossroads XRD-BC Series User Manual

User Guide & Important Information

XRD-BC Series

1

The XRD-BC wireless Bluetooth acoustics design combines fashion element and new wireless technologies;
Their sophisticated design is fully compliant with the fashionable life needs.Clear sound, deep bass and better
performance as standard configuration, it than just a Shapes to lovable acoustics of the ordinary, it uses
Bluetooth 3.0 technology, get rid of the shackles of the cable, as a unique ornaments, when you any corner of
the place and then the house, but when you play the wonderful music of the ultra-high quality, how make people
enjoy. As a wireless Bluetooth acoustics, it is designed to become more humane, facial designs, you can easily
be used to enjoy music, a wireless Bluetooth connection to mobile phones, computers Bluetooth audio devices.

2

The purpose of this guide is to help you get started
using your new XRD-BC Series Bluetooth
Speaker.

This booklet also provides you with information
abo ut the added fea t ures and imp ortan t
information regarding this product.

Page

What’s Inside..........................................................3

Button Controls.......................................................4

Quick Start..............................................................5

Getting Started....................................................... 6

How to Connect......................................................7

LED Indicators........................................................8

Basic Operation......................................................9

Pairing With Bluetooth Devices............................13

Making Voice Calls...............................................15

Helpful Tips...........................................................16

Low Battery Alert and Charging Instructions........17

Battery Tips...........................................................18

PURPOSE CONTENTS

3

Crossroads XRD-BC

BluetoothSpeaker

USB to Micro-USB

Charging Cable

3.5 to 3.5mm
Audio Cable

WHAT’S INSIDE

4

BUTTON
CONTROLS

3.5mm
Audio in

Micro-USB
Charging Port

Power
On/Off

Volume Up

Volume Down

Multi-Function

c

5

1. Power ON Power on by sliding the Power switch” “ to ON position.

2. To pair, press and hold the “ “ For 8 seconds the LED flash BLUE/RED enable Your
Device Bluetooth and Scan and Connect the “XRD-BC”.

3. Enjoy your music or anuswer a Phonecall by XRD-BC.

QUICK START

or

6

TWO WAYS TO CONNECT

Connect your Crossroads
Speaker to your mobile
devic e via Bl u etoot h
Wireless.

Or connected directly to
your device via a 3.5mm
Audio Cable. (included)

GETTING STARTED

After you are finished charging your
device, power on by find the ON/OFF
switch “ “and Slide the switch into
the ON position.

POWERING UP

7

Using your 3.5mm cable:

Insert one 3.5mm end into the speaker and the other 3.5mm end in to the device you want
to use with your speaker.

Using Bluetooth is easy:

1. Go to your settings and enable Bluetooth.

2. Next, search for devices.

3. Then, press and hold the Multi-function for 8 seconds.

4. Select “XRD-BC” and enjoy.

HOW TO CONNECT

BLUE

RED

BLUE
& RED

8

●

Blue Flashing means it’s On and Ready to be paired.

●

Once paired the Blue light will fast every 5 seconds.

●

Red Flashing light means the battery is low.

●

Red Solid light means that the battery is charging.

●

Both Red and Blue Flashing lights means that the Speaker is searching
for a device to pair with.

LED INDICATORS
