All about the

Use & Care

of your Refrigerator

TABLE OF CONTENTS

Welcome & Congratulations ........................2

Important Safety Instructions ......................3

Features At A Glance ..................................5

Installation ................................................6

Door Removal Instructions ..........................8

Handle Installation ...................................11

Connecting Water Supply ..........................13

www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352

Ice Service ...............................................15

Controls ...................................................16

Optional Features .....................................17

Normal Operating Sounds and Sights .........19

Care and Cleaning ....................................20

Before you Call .........................................22

Major Appliance Warranty .........................23

A04720102 (September 2017)

WELCOME & CONGRATULATIONS

Congratulations on your purchase of a new refrigerator! We here at Crosley Corporation are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority.

Please read this Use & Care Manual very carefully. It contains valuable information on how to properly maintain your new refrigerator.

We know you’ll enjoy your new refrigerator and Thank You for choosing our product. We hope you consider us for future purchases.

Please Read and Save these Instructions

This Use & Care Manual provides specic operating

instructions for your model. Use your refrigerator only as instructed in this manual. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance.

Please record your model and serial numbers below for future reference. This information is found on the serial plate located inside the refrigerator compartment.

Model Number:

Serial Number:

Purchase Date:

For product information contact:

704-956-2523

Crosley Corporation

952 Coppereld Blvd NE

Concord, NC 28025

www.crosley.com

Please attach sales receipt

here for future reference.

NOTE



Use only soap and water to clean serial plate.

Serial Plate

Please complete and mail in the

Product Registration Card

included with your refrigerator.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

Please read all instructions before using this refrigerator.

For your Safety

• DO NOT store or use gasoline, or other

ammable liquids in the vicinity of this or

any other appliance. Read product labels

for warnings regarding ammability and

other hazards.

• DO NOT operate the refrigerator in the presence of explosive fumes.

• Avoid contact with any moving parts of automatic ice maker.

• Remove all staples from the carton. Staples can cause severe cuts, and also destroy

nishes if they come in contact with other

appliances or furniture.

Denitions

This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

DANGER

DANGER indicates an imminently hazardous

situation which, if not avoided, will result in death or serious injury.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

IMPORTANT

IMPORTANT indicates installation, operation or maintenance information which is important but not hazard-related.

Installation Checklist

Doors

 Handles are secure and tight  Door seals completely to cabinet on all sides  Freezer door is level across the top

Leveling

 Refrigerator is level, side-to-side and

tilted ¼” (6mm) front-to-back  Toe grille is properly attached to refrigerator  Cabinet is setting solid on all corners

Electrical Power

 House power turned on  Refrigerator plugged in

Ice Maker

 House water supply connected to refrigerator  No water leaks present at all connections

- recheck in 24 hours  Ice maker is turned ON  Ice & water dispenser operates correctly  Front lter must be ush with lter

housing (select models)

Final Checks

 Shipping material removed  Fresh food and freezer temperatures set  Crisper humidity controls set  Registration card sent in

Child Safety

Destroy or recycle the carton, plastic bags, and any exterior wrapping material immediately after the refrigerator is unpacked. Children should never use these items to play. Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may become airtight

chambers, and can quickly cause suffocation.

Proper Disposal of your Refrigerator or Freezer

Risk of child entrapment

Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators or freezers are still dangerous – even if they will sit for “just a few days”. If you are getting rid of your old refrigerator or freezer, please follow the instructions below to help prevent accidents.

IMPORTANT SAFETY INSTRUCTIONS

Grounding type wall receptacle

Power cord with 3-prong grounded plug

Do not, under any circumstances, cut, remove, or bypass the grounding prong.

Proper Disposal of Refrigerators/Freezers

We strongly encourage responsible appliance recycling/disposal methods. Check with your utility company or visit www.energystar.gov/recycle for more information on recycling your old refrigerator.

Before you throw away your old refrigerator/ freezer:

• Remove doors.

• Leave shelves in place so children may not easily climb inside.

• Have refrigerant removed by a

qualied service technician.

WARNING

These guidelines must be followed to ensure that safety mechanisms in this refrigerator will operate properly.

Electrical information

• The refrigerator must be plugged into its own dedicated 115 Volt, 60 Hz., 15 Amp, AC only electrical outlet. The power cord of

the appliance is equipped with a three-

prong grounding plug for your protection against electrical shock hazards. It must be plugged directly into a properly grounded three prong receptacle. The receptacle must be installed in accordance with local

codes and ordinances. Consult a qualied

electrician. Avoid connecting refrigerator to a Ground Fault Interrupter (GFI) circuit. Do not use an extension cord or adapter plug.

• If the power cord is damaged, it should be replaced by an authorized service technician to prevent any risk.

• Never unplug the refrigerator by pulling on

the power cord. Always grip the plug rmly,

and pull straight out from the receptacle to prevent damaging the power cord.

• Unplug the refrigerator before cleaning and before replacing a light bulb to avoid electrical shock.

• Performance may be affected if the voltage

• Do not plug the unit into an electrical outlet

varies by 10% or more. Operating the

refrigerator with insufcient power can

damage the compressor. Such damage is not covered under your warranty.

controlled by a wall switch or pull cord to prevent the refrigerator from being turned off accidentally.

IMPORTANT

Turning the Refrigerator controls to “0” will disable your refrigerator’s cooling system, but does not disconnect the power to the light bulb and other electrical components. To turn off power to your refrigerator you must unplug the power cord from the electrical outlet.

CAUTION

To avoid personal injury or property damage, handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change.

IMPORTANT

CFC/HCFC Disposal

Your old refrigerator may have a cooling system that used CFCs

or HCFCs (chlorouorocarbons or hydrochlorouorocarbons). CFCs and

HCFCs are believed to harm stratospheric ozone if released to the atmosphere. Other refrigerants may also cause harm to the environment if released to the atmosphere.

If you are throwing away your old refrigerator, make sure the refrigerant is

removed for proper disposal by a qualied

technician. If you intentionally release

refrigerant, you may be subject to nes

and imprisonment under provisions of environmental legislation.

FEATURES AT A GLANCE

Ice Maker

Ice Tray

Features may vary according to model

Ice Bucket

Freezer Shelf

Auxiliary Freezer

Control

Fixed Door Bin

Door Rack

Refrigerator

Control

Dairy Door

Deli Drawer

Cover

Deli Drawer

(Some Models)

Upper Door Rack

Full Shelf

Deli Drawer

Cover

Full Width Deli

(Some Models)

Crisper

Cover

Crisper

Drawers

Toe Grille

Fixed Door Bin

Door Rack

IMPORTANT

Cleaning your Refrigerator Remove tape and glue residue from surfaces before turning on the refrigerator. Rub a small

amount of liquid dish soap over the adhesive with your ngers. Rinse with warm water and

dry with a soft cloth.

Do not use sharp instruments, rubbing alcohol, ammable uids, or abrasive cleaners to

remove tape or glue. These products can damage the surface of your refrigerator. After you remove all of the package materials, clean the inside of your refrigerator before

using it. See the “Care & Cleaning” section in this manual. See important information about cleaning glass shelves and covers in the “Optional Features”

section of this manual.

IMPORTANT

Moving your Refrigerator Your refrigerator is heavy. When moving the refrigerator for cleaning or service, be sure

to cover the oor with cardboard or hardboard to avoid oor damage. Always pull the

refrigerator straight out when moving it. Do not wiggle or “walk” the refrigerator when trying

to move it as oor damage could occur.

INSTALLATION

This Use & Care Guide provides general operating instructions for your model. Use the refrigerator only as instructed in this Use & Care Guide. Before starting the refrigerator,

follow these important rst steps.

Location

• Choose a place that is near a grounded electrical outlet. Do Not use an extension cord or an adapter plug.

• If possible, place the refrigerator out of direct sunlight and away from the range, dishwasher or other heat sources.

• The refrigerator must be installed on a oor that is level and strong enough to support a fully loaded refrigerator.

• Consider water supply availability for

models equipped with an automatic ice

maker. If you do not hook up water to the refrigerator, remember to turn the ice maker off.

CAUTION

Do not install the refrigerator where the temperature will drop below 55°F (13°C) or rise above 110°F (43°C). The compressor will not be able to maintain proper temperatures inside the refrigerator.

Do not block the toe grille on the lower front

of your refrigerator. Sufcient air circulation

is essential for the proper operation of your refrigerator.

Guidelines for nal positioning of your

refrigerator:

• All four corners of the cabinet must rest

rmly on the oor.

• The cabinet should be level at the front and rear.

• The sides should tilt ¼-inch (6 mm) from front-to-back (to ensure that doors close and seal properly).

• Doors should align with each other and be level.

NOTE



For additional instructions on garage installation, refer to “Controls” section.

Installation

Installation clearances

• Allow the following clearances for ease of installation, proper air circulation, and plumbing and electrical connections:

Sides & Top ⅜ inch

Back 1 inch

NOTE



If your refrigerator is placed with the door hinge side against a wall, you may have to allow additional space for the handle so the door can be opened wider.

INSTALLATION

9/16"

(14 mm)

Max

Raise

To level the cabinet using the front rollers:

1 Remove the toe grille.

2 Use a at-blade screwdriver or ⅜ inch

socket wrench to raise or lower the front rollers (Figure 2). Do not raise the cabinet more than 9/16 inch.

3 Use adjustable wrench to adjust leveling

screws. Lower the leveling screws on each

side clockwise until they contact the oor

(Figure 3). Do not raise the cabinet more than 9/16 inch.

9/16"

(14 mm)

Max

Raise

Figure 3

NOTE



Raise the front of the refrigerator enough so the doors close freely when opened halfway. The refrigerator should slope ¼ inch to ½ inch from front-to-back. Then level the refrigerator from side-to-side.

Figure 2

DOOR REMOVAL INSTRUCTIONS

Top Hinge

Cover Front

Screw

Top Hinge

Cover Rear

Screw

Bottom

Hinge

Screw

Top Hinge Screw

Door

Bottom

Door Stop

Door

Tools Necessary:

Phillips Head

3/8" (10mm)

Fixed

Wrench

Socket

Wrench Set

Door removal and reversal instructions:

1. Remove toe grille.

2. Remove top hinge cover. Trace around the hinge with a soft lead pencil. This makes reinstallation easier. Remove top hinge and lift door off center hinge pin. Set door aside.

Top Hinge Cover

Adjustable

Wrench

NOTE



The direction in which your refrigerator doors open (door swing) can be reversed, from left to right or right to left, by moving the door hinges from one side to the other. Reversing the door swing should be performed by a

qualied person.

IMPORTANT

Before you begin, turn the refrigerator temperature control to “0” and remove the electrical power cord from the wall outlet. Remove any food from door shelves.

Stop Screw

Shim

Hinge Hole Plug

Stop

Washer

Hinge

Center Hinge

Screws

Handle Hole Plug

Top

Hinge

3. Unscrew center hinge pin using adjustable

wrench and save for reassembly. Ensure

plastic washer stays on hinge pin.

4. Lift refrigerator door off of bottom hinge and set aside.

5. Remove center hinge and shim by removing inside screw and loosening two outside screws enough to allow hinge and shim to slide out. Tighten screws.

6. Loosen two outside screws on opposite side of refrigerator, remove inside screw and install center hinge.

7. Remove two screws on bottom hinge with ⅜”

socket wrench.

8. Install bottom hinge on opposite side with the two screws removed from step 7.

Screw

Stop

Washer

Hinge Pin

Hinge

Screws

Toe Grille

DOOR REMOVAL INSTRUCTIONS

cabinet all the way around including top

and bottom

9. Unscrew bottom hinge pin using adjustable wrench. Move hinge pin to other hole in hinge and tighten with adjustable wrench.

10. Reverse door handles (see instruction on next page).

11. Move freezer and refrigerator door stops to opposite side. Before starting screws, use an awl to puncture the foam.

12. Position refrigerator door onto bottom hinge pin and screw center hinge pin through center hinge into top of door. Close refrigerator door to help align hinge hole.

13. Tighten center hinge pin with adjustable wrench.

14. Remove cabinet and hinge hole plugs and move to opposite side.

15. Lower freezer door onto center hinge pin.

16. Close freezer door. Lift up on handle side of door and grasp the thinnest part of the top hinge cover (which was removed in Step 2) and insert the thickest part between the doors on the handle side approximately 3 inches from the outside edge. This will ensure proper spacing.

17. Tighten the top hinge screws and check door gasket for open seal condition (gap

between gasket and cabinet ange).

Look for open areas between the

gasket and the cabinet flange.

Gasket should seal against the

DOOR REMOVAL/REVERSAL INSTRUCTIONS

18. Should open seal condition exist, try to massage the gasket to make sure it is seated into the channel.

IMPORTANT

If the condition still exists, try heating the gasket with a hair dryer with the door closed. Use Caution and be careful not to damage the interior door panel or gasket by applying too much heat.

19. If the open seal condition still exists, it

may be necessary to ip the gasket. In

this case, remove the gasket from the door by pulling it out. Rotate the gasket half a turn (180 degrees). Reinstall the

gasket by inserting the corners rst then

work towards the middle assuring that it is fully seated in the channel.

20. Flip toe grille and reinstall.

21. Plug in electrical power cord and turn refrigerator temperature control to center position. Adjust setting as necessary.

HANDLE INSTALLATION

CAUTION

Wear gloves and use extreme CAUTION when installing these handles. The rounded end of the handles may be sharp.

IMPORTANT

To ensure proper installation of handles, please review these instructions and illustrations thoroughly prior to installing the handles.

Additionally, before installing the door handles, make sure the door swing is correct. Your model will have either a right hand or left hand door swing. Follow instructions in the Use & Care Guide to reverse the doors, if necessary.

To attach metal refrigerator handle:

1. Place rounded part of handle onto shoulder screw on face of door and align the two holes in top of handle with the two holes in top of door. Do not tighten the set screw yet.

2. Install the two screws into the top of the handle.

3. Tighten the set screw on the rounded part

of the handle until the handle is ush with

the door, then tighten another ½ turn.

Screw

3. Tighten the set screw on the rounded part

of the handle until the handle is ush with

the door, then tighten another ½ turn.

Shoulder Screw

Nameplate

Set

Screw

Handle

Stainless Steel Models

Screw

Handle

Shoulder

Screw

Handle

Shoulder

Screw

Set

Screw

To attach metal freezer handle:

1. Place rounded part of handle onto shoulder screw on face of door and align the two holes in bottom of handle with the two holes in bottom of door. Do not tighten the set screw yet.

2. Install the two screws into the bottom of the handle.

Button

Plug

Screw

Handle

Set

Screw

Shoulder Screw

Set Screw

HANDLE INSTALLATION

To attach plastic refrigerator handle:

1. Place bottom of handle over dovetail screw and rotate or pull handle straight up until handle is aligned with screw holes on top of door.

2. Secure top of handle with two screws.

Screw

Handle

Dovetail Screw

Lock Handle

over

Dovetail Screw

To attach plastic freezer handle:

1. Place top of handle over dovetail screw and rotate or pull handle straight down until handle is aligned with screw holes on bottom of door.

2. Secure bottom of handle with two screws.

Button

Plug

To reverse refrigerator/freezer handles:

Handles may be easier to reverse while doors are off. Reverse freezer and refrigerator handles as shown.

CAUTION

Be sure doors are set aside in a secure position where they cannot fall and cause personal injury.

Handle

Screw

Dovetail Screw

Nameplate

Lock Handle

over

Dovetail Screw

CONNECTING THE WATER SUPPLY

WARNING

To avoid electric shock, which can cause death or severe personal injury, disconnect the refrigerator from electrical power before connecting a water supply line to the refrigerator.

CAUTION

To Avoid Property Damage:

• Copper or Stainless Steel braided tubing is recommended for the water supply line. Water supply tubing made of ¼ inch plastic is not recommended to be used. Plastic tubing greatly increases the potential for water leaks, and the manufacturer will not be responsible for any damage if plastic tubing is used for the supply line.

• DO NOT install water supply tubing in areas where temperatures fall below freezing.

• Chemicals from a malfunctioning softener can damage the ice maker. If the ice maker is connected to soft water, ensure that the softener is maintained and working properly.

IMPORTANT

Ensure that your water supply line

connections comply with all local plumbing codes.

Before Installing The Water Supply Line, You Will Need:

• Basic Tools: adjustable wrench, at-blade screwdriver, and PhillipsTM screwdriver

• Access to a household cold water line with water pressure between 30 and 100 psi.

• A water supply line made of ¼ inch (6.4 mm) OD, copper or stainless steel tubing. To determine the length of tubing needed, measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water pipe. Then add approximately 7 feet (2.1 meters), so the refrigerator can be moved out for cleaning (as shown).

• A shutoff valve to connect the water supply line to your household water system. DO NOT use a self-piercing type shutoff valve.

• Do not re-use compression tting or use thread seal tape.

• A compression nut and ferrule (sleeve) for connecting a copper water supply line to the ice maker inlet valve.



NOTE

Check with your local building authority for recommendations on water lines and associated materials prior to installing your new refrigerator. Depending on your local/ state building codes, Frigidaire recommends for homes with existing valves its Smart

Choice® water line kit 5305513409 (with

a 6 ft. Stainless Steel Water Line) and for homes without an existing valve, Frigidaire recommends its Smart Choice® water line kit 5305510264 (with a 20 ft. Copper Water Line with self-tapping saddle valve). Please refer to www.frigidaire.com/store for more information.

CONNECTING THE WATER SUPPLY

Steel

To Connect Water Supply Line To Ice Maker Inlet Valve

1. Disconnect refrigerator from electric power source.

2. Place end of water supply line into sink or

bucket. Turn ON water supply and ush

supply line until water is clear. Turn OFF water supply at shutoff valve.

3. Remove plastic cap from water valve inlet and discard cap.

4. If you use copper tubing - Slide brass compression nut, then ferrule (sleeve) onto water supply line. Push water supply line into water valve inlet as far as it will go (¼ inch / 6.4 mm). Slide ferrule

(sleeve) into valve inlet and nger tighten

compression nut onto valve. Tighten another half turn with a wrench; DO NOT over tighten. See Figure 1.

If you use braided exible stainless

steel tubing - The nut is already assembled on the tubing. Slide nut onto

valve inlet and nger tighten nut onto

valve. Tighten another half turn with a wrench; DO NOT over tighten. See Figure

5. With steel clamp and screw, secure water supply line (copper tubing only) to rear panel of refrigerator as shown.

6. Coil excess water supply line (copper tubing only), about 2½ turns, behind refrigerator as shown and arrange coils so they do not vibrate or wear against any other surface.

7. Turn ON water supply at shutoff valve and tighten any connections that leak.

8. Reconnect refrigerator to electrical power source.

9. To turn ice maker on, lower wire signal arm (side mounted) or set the ice maker’s On/Off power switch to the “I” position (rear mounted).

Plastic Water Tubing to Ice Maker Fill Tube

Copper water line

from household

(Include enough tubing in loop to allow

moving refrigerator out for cleaning.)

Figure 1

Plastic Water Tubing

to Ice Maker

Fill Tube

6 ft (1.8 Meters) Braided flexible

stainless steel water line from

household water supply.

Clamp

Brass

Compression

Water Valve

water supply

Nut

Ferrule

(Sleeve)

Copper

water line

Bracket

Valve Inlet

Steel

Clamp

Braided Flexible

Stainless

Steel

Water Line

Water Valve

Bracket

Valve Inlet

Water Valve

NOTE



These instructions do not cover after market ice maker installation. Instructions in after market ice maker kit should be used.

(Include enough tubing in loop to allow

moving refrigerator out for cleaning.)

Figure 2

ICE SERVICE

If your refrigerator has an automatic ice maker,

minimal ice will be produced during the rst 24

hours of operation. Air in new plumbing lines may cause the ice maker to cycle two or three times before making a full tray of ice. With no usage, it will take approximately one to two

days to ll the ice container.

New plumbing connections may cause the rst

production of ice cubes to be discolored or

have an odd avor. Discard ice made during the rst 24 hours.

NOTE



Automatic ice makers are also optional accessories that may be installed in most models at any time. Call your local dealer for information.

Turning your Ice Maker On

After the plumbing connections have been completed, the water supply valve must be opened. Place the ice container under the ice maker, pushing it as far back as possible. Lower the wire signal arm to its “down” or ON position.

Turning your Ice Maker Off

To stop the ice maker, lift the wire signal arm until it clicks and locks in the “up” or OFF position. The ice maker also turns off automatically when the ice container is full.

IMPORTANT

Your ice maker is shipped from the factory with the wire signal arm in the ON position. To ensure proper function for your ice maker, hook up water supply immediately or turn ice maker OFF by lifting the wire signal arm until it clicks and locks in the UP position. If the ice maker is on and the water supply is not connected, the water valve will make a loud chattering noise.

ICE PRODUCTION: WHAT TO EXPECT

The ice maker will produce 2.5 to 3 pounds of ice every 24 hours depending on usage conditions. Ice is produced at a rate of 8 cubes every 80 to 160 minutes.

CAUTION

Do Not place the ice container in your dishwasher.

OFF

Wire Signal Arm

CONTROLS

Allow 24 hrs for adjustments

Cool Down Period

To ensure safe food storage, allow the refrigerator to operate with the doors closed for at least 8 hours before loading it with food.

Refrigerator & Freezer Controls

NOTE



When rst turning refrigerator on, adjust

control to recommended. This is the recommended initial setting. After 24 hours, adjust the controls as needed.

Refrigerator Control

IMPORTANT

Adjusting the refrigerator temperature control to “0” turns off the compressor and prevents the refrigerator from cooling, but does not disconnect the power to the light bulb and other electrical components. To turn off power to your refrigerator, you must unplug the power cord from the wall outlet.

CAUTION

IMPORTANT

If you install your refrigerator in a garage or other unheated area, you may experience freezer temperature problems during the winter months when temperatures dip below 55° F.

Upgrading your refrigerator with a Garage Kit will lower the minimum operating temperature of your unit to 34° F. This kit can be ordered by calling the phone number listed at the bottom of the warranty page or back cover at an additional cost.

Temperature Adjustment

• Adjust temperature gradually: adjust the knob in small increments, allowing the temperature to stabilize.

• For colder temperatures, adjust the knob towards coldest.

• For warmer temperatures, adjust the knob towards cold.

Adjusting the refrigerator control will change temperatures in both compartments. The auxiliary freezer control can be left at the factory pre-set (mid position) or adjusted as desired; it has no effect on electrical power to the refrigerator.

To maintain temperatures, a fan circulates air in the refrigerator and freezer compartments. For good circulation, do not block cold air vents with food items.

Auxiliary Freezer Control

OPTIONAL FEATURES

CAUTION

Do not clean glass shelves or covers with warm water when they are cold. Shelves and covers may break if exposed to sudden temperature changes or impact, such as bumping. Tempered glass is designed to shatter into many small, pebble-size pieces. This is normal. Glass shelves and covers are heavy. Use both hands when removing them to avoid dropping.

Shelf Adjustment

Refrigerator shelves are easily adjusted to suit individual needs. Before adjusting the shelves, remove all food.

To adjust sliding shelves:

1. Remove shelf by pulling forward to stop position.

2. Lift front edge up and pull out.

To replace shelf, rest side edges on any pair of shelf rails and carefully push shelf back into position.

Door storage

Door bins, shelves, and racks are provided for convenient storage of jars, bottles, and cans.

Frequently used items can be quickly selected.

The dairy compartment, which is warmer than the general food storage section, is intended for short term storage of cheese, spreads, or butter.

Door rack

Some models have door racks or bins that can accommodate gallon-sized plastic drink containers and economy-sized jars and containers.

To remove door rack:

1. Push on rack sides to release from locking tabs.

2. Pull straight out.

To install door rack:

1. Push rack straight ahead.

2. You will hear the sides lock into the tabs.

Sliding Glass Shelf

Sliding Wire Shelf

Door Rack

OPTIONAL FEATURES

Crisper Humidity Control (some models)

The crisper humidity control, present on the crisper drawers of some models, allows you to adjust the humidity within the crisper. This can extend the life of fresh vegetables that keep best in high humidity.

Low Humidity

High Humidity

Higher Humidity Lower Humidity

NOTE



Leafy vegetables keep best when stored with the Humidity Control set on High Humidity, or in a drawer without a Humidity Control. This keeps incoming air to a minimum and maintains maximum moisture content. Store non-leafy vegetables and fruits still in their skins at the low humidity setting.

Crispers (some models)

The crispers, located under the bottom refrigerator shelf, are designed for storing fruits, vegetables, and other fresh produce. Wash items in clear water and remove excess water before placing them in the crispers. Items with strong odors or high moisture content should be wrapped before storing.

NORMAL OPERATING SOUNDS AND SIGHTS

Understanding the sounds you may hear

Your new, high-efciency refrigerator may

introduce unfamiliar sounds. These sounds normally indicate your refrigerator is operating

correctly. Some surfaces on oors, walls, and

kitchen cabinets may make these sounds more noticeable.

NOTE



Rigid foam insulation is very energy efcient,

but is not a sound insulator.

Following is a list of major components in your refrigerator and the sounds they can cause:

A Evaporator Refrigerant through the

evaporator may create a boiling or gurgling sound.

B Evaporator fan You may hear air being

forced through the refrigerator by the evaporator fan.

C Defrost heater During defrost cycles,

water dripping onto the defrost heater may cause a hissing or sizzling sound. After defrosting, a popping sound may occur.

IMPORTANT

During the automatic defrost cycle, you may notice a red glow in the vents on the back wall of your freezer compartment. This is normal during the defrost cycle.

D Automatic ice maker When ice has

been produced, you will hear ice cubes falling into the ice bin.

E Automatic Defrost control These parts

can produce a snapping or clicking sound when turning the cooling system on and off.

F Condenser fan You may hear air being

forced through the condenser.

G Compressor Modern, high-efciency

compressors run much faster than in the past. The compressor may have a highpitched hum or pulsating sound.

H Water valve If your refrigerator is

equipped with an automatic ice maker,

you will hear a buzzing sound as the water

valve opens to ll the ice maker during

each cycle.

I Drain pan (not removable) You may hear

water dripping into the drain pan during the defrost cycle.

J Condenser May create minimal sounds

from forced air.

CARE & CLEANING

Protecting your investment

Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year. When cleaning, take the following precautions:

• Never use CHLORIDE or cleaners with bleach to clean stainless steel.

• Do not wash any removable parts in a dishwasher.

• Always unplug the electrical power cord from the wall outlet before cleaning.

• Remove adhesive labels by hand. Do not use razor blades or other sharp instruments which can scratch the appliance surface.

• Do not remove the serial plate.

Do not use abrasive cleaners such as window sprays, scouring cleansers, brushes,

ammable uids, cleaning waxes, concentrated

detergents, bleaches or cleansers containing petroleum products on plastic parts, interior doors, gaskets or cabinet liners. Do not use paper towels, metallic scouring pads, or other abrasive cleaning materials or strong alkaline solutions.

NOTE



If you set your temperature controls to turn off cooling, power to lights and other electrical components will continue until you unplug the power cord from the wall outlet.

IMPORTANT

If you store or move your refrigerator in freezing temperatures, be sure to completely drain the water supply system. Failure to do so could result in water leaks when the refrigerator is put back into service. Contact a service representative to perform this operation.

CAUTION

• Pull the refrigerator straight out to move it. Shifting it from side to side may

damage ooring. Be careful not to move

the refrigerator beyond the plumbing connections.

• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces with wet or damp hands.

CARE & CLEANING

Care & Cleaning Tips

Part What To Use Tips and Precautions

Interior & Door Liners

Door Gaskets

Drawers & Bins

Glass Shelves

Toe Grille • Soap and water

Exterior &

Handles

Exterior &

Handles

(Stainless Steel Models Only)

Replacing Light Bulbs

• Soap and water

• Baking soda and water

• Soap and water Wipe gaskets with a clean soft cloth.

• Soap and water Use a soft cloth to clean drawer runners and tracks.

• Soap and water

• Glass cleaner

• Mild liquid sprays

• Vacuum attachment

• Soap and water

• Non Abrasive Glass Cleaner

• Soap and water

• Stainless Steel Cleaners

• Unplug refrigerator

• Wear gloves

• Remove light cover (some models)

• Replace old bulb

• Replace light cover (some models)

• Plug in the refrigerator

Use 2 tablespoons of baking soda in 1 quart of warm

water. Be sure to wring excess water out of sponge or cloth before cleaning around controls, light bulb or any electrical part.

Allow glass to warm to room temperature before immersing in warm water.

Vacuum dust from front of toe grille. Remove toe grille (see Installation Instructions). Vacuum backside, wipe with sudsy cloth or sponge. Rinse and dry.

Do not use commercial household cleaners containing ammonia, bleach or alcohol to clean handles. Use a soft cloth to clean smooth handles. DO NOT use a dry cloth to clean smooth doors.

Never use CHLORIDE or cleaners with bleach to

clean stainless steel.

Clean stainless steel front and handles with nonabrasive soapy water and a dishcloth. Rinse with clean water and a soft cloth. Use a non-abrasive stainless steel cleaner. These cleaners can be purchased at most home improvement or major department stores. Always follow manufacturer’s instructions. Do not use household cleaners containing ammonia or bleach.

NOTE: Always clean, wipe and dry with the grain

to prevent scratching. Wash the rest of the cabinet

with warm water and mild liquid detergent. Rinse

well, and wipe dry with a clean soft cloth.

CAUTION: Wear gloves when replacing light bulbs to avoid getting cut. Use same wattage when replacing bulb

BEFORE YOU CALL

1-800-944-9044 (United States)

1-800-265-8352 (Canada)

Common Occurrences

Refrigerator does not run. • Ensure plug is tightly pushed into electrical outlet.

Freezer temperature is colder than preferred. Refrigerator temperature is satisfactory.

Refrigerator temperature is too cold. Freezer temperature is satisfactory.

Freezer temperature is warmer than preferred. Refrigerator temperature is satisfactory.

Refrigerator temperature is too warm. Freezer temperature is satisfactory.

Refrigerator is noisy or vibrates. • The cabinet is not level.

Odors in refrigerator. • Interior needs to be cleaned.

Cabinet light not working. • Replace light bulb.

Automatic ice maker not working (some models)

Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance.

• Check/replace fuse with a 15 amp time-delay fuse. Reset circuit breaker.

• The refrigerator/freezer control is turned to “0”

• Refrigerator may be in defrost cycle. Wait 20 minutes and check again.

• Set auxiliary freezer control to a warmer setting until freezer temperature is satisfactory. Allow 24 hours for the temperature to stabilize.

• Set refrigerator/freezer control to a warmer setting. Allow 24 hours for temperature to stabilize. Then check freezer temperatures and adjust as needed.

• Set auxiliary freezer control to a colder setting until freezer temperature is satisfactory. Allow 24 hours for the temperature to stabilize.

• Set refrigerator/freezer control to a colder setting. Allow 24 hours for temperature to stabilize. Then check refrigerator temperatures and adjust as needed.

• Floor is weak.

• See Normal Operating Sounds and Sights section.

• Foods that produce odors should be covered or wrapped.

• Ensure plug is tightly pushed into electrical outlet.

• Light switch may be stuck. Push in light switch, located on the refrigerator control box, to release.

• Ensure the wire signal arm is not in UP position.

• Ice maker should produce 2.5 to 3 pounds of ice in a 24 hour period.

• Water supply is turned off.

• Water pressure is too low.

• The freezer is not cold enough.

Visit our web site at

www.frigidaire.com.

MAJOR APPLIANCE WARRANTY

Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux Home Products, Inc., “Electrolux,” will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions. *In addition to warranty shown above, ask your dealer about a Crosley Extended Limited Warranty that comes to you at no extra charge for the 2nd through 10th years.

Exclusions

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be readily determined.

2. Product that has been transferred from its original owner to another party or removed outside the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any refrigerator or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in ordinary household use or used other than in accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not a part of the appliance when it is shipped from the factory.

10. Servicecallstorepairorreplaceappliancelightbulbs,airlters,waterlters,other

consumables, or knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service calls to remote areas, including the state of Alaska.

12.Damagestothenishofapplianceorhomeincurredduringinstallation,includingbutnot

limitedtooors,cabinets,walls,etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts other than genuine Crosley parts or parts obtained from persons other than authorized service companies; or

externalcausessuchasabuse,misuse,inadequatepowersupply,accidents,res,oractsofGod.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,

INCLUDINGWARRANTIESOFMERCHANTABILITYORFITNESSFORAPARTICULARPURPOSE,ARE

LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUXSHALLNOTBELIABLEFORCONSEQUENTIALORINCIDENTALDAMAGESSUCH

ASPROPERTYDAMAGEANDINCIDENTALEXPENSESRESULTINGFROMANYBREACHOFTHIS

WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO

NOTALLOWTHEEXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,

OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR

EXCLUSIONSMAYNOTAPPLYTOYOU.THISWRITTENWARRANTYGIVESYOUSPECIFICLEGAL RIGHTS.YOUMAYALSOHAVEOTHERRIGHTSTHATVARYFROMSTATETOSTATE.

If You Need Service

Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under this warranty must be obtained by contacting Electrolux at the addresses or phone numbers below.

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Home Products, Inc. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under this warranty must be performed by

Electroluxoranauthorizedservicecompany.Productfeaturesorspecicationsasdescribedor

illustrated are subject to change without notice.

FOR WARRANTY INFORMATION CONTACT: USA 855.224.4987 Canada 800.265.8352

FOR PRODUCT INFORMATION CONTACT:

704-956-2523

Crosley Corporation

952CoppereldBlvdNE

Concord, NC 28025

www.crosley.com

Crosley CRTE182TB1, CRTE182TB2, CRTE182TS1, CRTE182TW2, CRTE206TW1 Owner’s Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
