Crosley CRG3480HQQB, CRG3480HQQA, CRG3480GWWD, CRG3480GWBD, CRG3480GWBB Owner’s Manual
...
Use & Care Manual
s....
Welcome .......................................... 2
important Safety instructions ..... 3=5
Features at a Glance ...................... 6
Before Setting Oven Controls ....... 7
Setting Surface Controls ............... 8
Oven Control Functions ................ 9
Setting Oven Controls ............ 10=12
Self Cleaning ........................... 13=14
General Care & Cleaning ....... 15=18
Gas Range
ES200 Control, Self-Cleaning Oven
with Sealed Bas Burners
READ AND SAVE THESE INSTRUCTIONS pin 316417144 (0707)
Adjusting Oven Temperature ....... 18
Before You Call
Solutions to Common Problems .................... 19
Warranty ......................... Back Page
Welcome&Congratulations
Congratulations on your purchase of anew range! At Crosley Corporation, we are very proud of our product and are completely
committed to providing you with the best service possible. Your satisfaction is our number one priority.
We know you'll enjoy your new range and Thank You for choosing our product. We hope you consider us for future purchases.
PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating instructionsfor your model. Use your range only as instructed in this
manual. These instructionsare not meant to cover every possible condition and situation that may occur. Common sense and
caution must be practiced when installing, operating and maintaining any appliance.
Please record your model and serial numbers below for future reference.
Model Number:
Serial Number:
Purchase Date:
Product Registration
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should befilled
in completely, signed and returned to Crosley Corporation.
This Use & Care Manual contains general operating instructions for
your range and feature information for several models. Your range may
not have all the described features. The graphics shown are
representational. The graphics on your range may not look exactly like
those shown.
Serial plate location;
Open storage drawer (some models)
or remove outer lower panel (some models).
Important Safety Instructions
Read all instructions before using this appliance. Save these instructions for future reference.
This manual conta ns important safety symbols a_dinstructions. Please payattention tothese symbols and follow a instructions gwen.
This symbol will help alert you to situations that may cause serious bodily harm. death or property damage.
_[_ This symbol will help alert you to situations that may cause bodily injury or property damage.
if the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FORYOURSAFETY:
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
-- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
-- Installation and service must be performed by a
qualified installer, servicer or the gas supplier.
• Remove all tape and packaging before using the range.
Destroy the carton and plastic bags after unpacking the
range. Never allow children to play with packaging material.
• Proper Installation--Be sure your appliance is properly
installed and grounded by a qualified technician in
accordance with the National Fuel Gas Code ANSi
Z223.- latest edition, orin Canada CAN/CGA B149.1, and
CAN/CGA B149.2, and the the National Electrical Code
ANSI/NFPA No.70-1atest edition, or in Canada CSA
Standard C22.1, Canadian Electrical Code, Part 1, and
local code requirements. Install only per installation
instructions provided in the literature package for this range.
Ask your dealer to recommend a qualified technician and an
authorized repair service. Know how to disconnect the power
to the range at the circuit breaker or fuse box in case of an
emergency.
User servicing--Do not repair or replace any part of the
appliance unless specifically recommended in the
manuals. All other servicing should be done only by a
qualified technician, This may reduce the risk of personal
injuryand damage to the range.
• Never modify or alter the construction of a range by
removing leveling legs, panels, wire covers, anti=tip
bracketslscrews, or any other part of the product.
• Storage in or on Appliance--Flammable materials
should not be stored in an oven, warmer drawer, near
surface burners or in the storage drawer. This includes
paper, plastic and cloth items, suchas cookbooks, plasticware
and towels, as well as flammable liquids. Do not store
explosives, such as aerosol cans, on or near the range.
• All ranges can tip.
, Injury to persons could result.
• Install anti-tip device packed with range.
, See Installation Instructions.
_To reduce the risk of
tipping, the rangemust be secured by
properly installed anti-tip bracket provided
with the range. To check if the bracket is
installed properly, visually check that rear
leveling leg is inserted into and fully
secured by the anti-tip bracket by
removing lower panel or storage drawer.
For models with a warmer drawer, grasp
the top rear edge of the range and
carefully attempt to tilt it forward. Refer to
the installation instructions for proper anti-
tip bracket installation.
Stepping, leaning or sitting on the doors or
drawers of this range can result in serious injuries and
also cause damage to the range. Do not allow children to
climb or play around the range. The weight of a child on an
open door may cause the range to tip, resulting in serious
burns or other injury.
Do not use the oven or warmer drawer (if
equipped) for storage.
Do not store items of interest to children in
the cabinets above a range or on the backguard of a
range. Children climbing on the range to reach items could be
seriously injured.
Never Use Your Appliance for Warming or
Heating the Room.
NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning.
NEVER cover any slots, holes or passages in
the oven bottom or cover an entire rack with materials such as
aluminum foil. Doing so blocks air flow through the oven and
may cause carbon monoxide poisoning. Aluminum foil linings
may trap heat, causing afire hazard.
3
J
``Do Not Leave Children Alone--Children should not be left
alone or unattended in the area where appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
``DO NOT TOUCH SURFACE BURNERS, AREAS NEAR THESE
BURNERS, OVEN BURNERS OR iNTERiOR SURFACES OF
THE OVEN. Both surface and oven burners may be hot even
though flames are not visible. Areas near surface burners may
become hot enough to cause burns. During and after use, do not
touch, or let clothing or other flammable materials touch these
areas until they have had sufficient time to cool. Among these
areas are the cook top, surfaces facing the cook top, the oven vent
openings and surfaces near these openings, oven door and
window.
Wear Proper Apparel--Loose-fitting or hanging garments
should never be worn while using the appliance. Do not let
clothing or other flammable materials contact hot surfaces.
``Do Not Use Water or Flour on Grease Fires--Smother the fire
with a pan lid, or use baking soda, a dry chemical or foam-type
extinguisher.
``When heating fat or grease, watch it closely. Fat or grease may
catch fire if allowed to become too hot.
Use Only Dry Potholders--Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let potholders
touch hot heating burners. Do not use a towel or other bulky cloth
instead of a potholder.
Do Not Heat Unopened Food Containers--Buildup of pressure
may cause container to burst and result in injury.
Remove the oven door from any unused range if it is to be
stored or discarded.
IMPORTANT--ELECTRIC IGNITION MODELS ONLY: Do not
attempt to operate the oven during a power failure. If the power fails,
always turn off the oven. Ifthe oven is not turned off and the power
resumes, the oven will begin to operate again. Once the power
resumes, reset the clock and oven function.
iMPORTANT iNSTRUCTiONS FOR USINGYOUR
COOKTOP
Use Proper Flame Size--Adjust flame size so it
does not extend beyond the edge of the utensil. The use of
undersized utensils will expose a portion of the burner flame to
direct contact and may result in ignition of clothing. Proper
relationship of utensil to flame will also improve efficiency.
,,Know which knob controls each surface burner. Place a pan of
food on the burner before turning it on, and turn the burner off
before removing the pan.
,,Always turn knob to the full LITE position when igniting top
burners, Visually check that burner has lit. Then adjust the flame
so it does not extend beyond the edge of the utensil.
Utensil Handles Should Be Turned inward and Not Extend Over
Adjacent Surface Burners--To reduce the risk of burns, ignition
of flammable materials, and spillage due to unintentional contact
with the utensil, the handle of the utensil should be positioned so
that it is turned inward, and does not extend over adjacent surface
burners.
``Never Leave Surface Burners Unattended at High Heat
Settings--Believers cause smoking and greasy spillovers that
may ignite, or a pan that has boiled dry may melt.
* Protective Liners--Do not use aluminum foil to line surface
burner pans, or oven bottom, except as suggested in this manual.
Improper installation of these liners may result in risk of electric
shock, or fire.
* Glazed Cooking Utensils--Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed utensils are
suitable for cooktop service without breaking due to the sudden
change in temperature. Check the manufacturer's
recommendations for cooktop use.
IMPORTANT INSTRUCTIONS FOR USING YOUR OVEN
* Use Care When Opening Oven Door or Warmer Drawer--
Stand to the side ofthe range when opening the door of a hot oven.
Let hot air or steam escape before you remove or replace food in
the oven.
,,Keep Oven Vent Ducts Unobstructed. The oven vent is located
below the backguard. Touching the surfaces in this area when the
oven is operating may cause severe burns. Also, do not place
plastic or heat-sensitive items on or near the oven vent. These
items could melt or ignite.
Placement of Oven Racks. Always place oven racks in desired
location while oven is cool. If rack must be moved while oven is
hot use extreme caution. Use potholders and grasp the rack with
both hands to reposition. Do not let potholders contact the hot
heating elements in the oven. Remove all utensils from the rack
before moving.
,,Do not use the broiler pan without its insert. The broiler pan and
its insert allow dripping fat to drain and be kept away from the high
heat of the broiler.
* Do not cover the broiler insert with aluminum foil. Exposed fat
and grease could ignite.
, Cold temperatures can damage the electronic control. When
using the appliance for the first time, or when the appliance has
not been used for an extended period of time, be certain the unit
has been in temperatures above 32°F (0°C) for at least 3 hours
before turning on the power to the appliance.
iMPORTANT INSTRUCTIONS FOR CLEANING
YOUR RANGE
Clean the range regularly to keep all parts free of grease that
could catch fire. Pay particular attention to the area underneath
each surface element. Do not allow grease to accumulate. Refer
to the range manufacturer's instructions for cleaning.
*Kitchen cleaners and aerosols--Always follow the
manufacturer's recommended directions for use. Be aware
that excess residue from cleaners and aerosols may ignite
causing damage and injury.
SELF CLEANING OVENS
* Clean in the self-cleaning cycle only the parts listed in this
Owner's Guide. Before self cleaning the oven, remove the broiler
pan and any utensils or foods from the oven.
* Do Not Use Oven Cleaners--No commercial oven cleaner or
oven liner protective coating of any kind should be used in or
around any part of the oven.
,,Do Not Clean Door Gasket--The door gasket is essential for a
good seal. Care should be taken not to rub, damage or move the
gasket.
important Safety Notice
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn
customers of potential exposure to such substances.
Grounding type
wall receptacle
k
Do not, under any }
circumstance, cut,
remove, or bypass
the grounding prong.
Power supply cord
with 3-prong
grounding plug
See the INSTALLATION INSTRUCTIONS packaged with this range
for complete installation and grounding instructions.
GROUNDING INSTRUCTIONS
(electric ignition models only)
an adapter plug, an extension cord, or remove grounding prong
from electrical power cord. Failure to follow this warning can cause
serious injury, fire or death.
grounding plug for your protection against shock hazard and
should be plugged directly into a properly grounded receptacle.
DO NOT cut or remove the grounding prong from this plug.
For personal safety, the range must be properly grounded. For
maximum safety, the power cord must be plugged into an electrical
outlet that is correctly polarized and properly grounded.
If a 2-prong wall receptacle is the only available outlet, it is the
personal responsibility of the consumer to have it replaced with a
properly grounded 3-prong wall receptacle installed by a qualified
electrician.
Conversion to Liquefied Petroleum Gas (or L.P. Gas)
The natural gas range is designed to allow for conversion to
Liquefied Petroleum (L.P.) Gas.
If L.P. conversion is needed, contact your local appliance
dealer for assistance. The L.P. Conversion Kit may be
obtained from your appliance dealer and should be installed
by a qualified service technician. Before installing the kit be
sure to follow the L.P. Installation Instructions carefully.
shock may occur if the range is not installed by a qualified
installer or electrician.
required in order for this appliance to satisfactorily meet the
application needs must be made by a qualified technician.
Avoid fire hazard or electrical shock. Do not use
This appliance is equipped with a 3-prong
Personal injury or death from electrical
Any additions, changes or conversions
...... J
YourGas Range Features include:
1. Electronic Oven Control with Kitchen Timer.
2. Left Front Burner Valve & Knob.
3. Left Rear Burner Valve & Knob.
4. Right Rear Burner Valve & Knob.
5. Right Front Burner Valve & Knob.
6. Center Burner Valve & Knob.
7. Easy to clean Upswept Cooktop
8. Dishwasher safe Burner Grates (colors vary).
9. Self-Clean Oven Door Latch.
10. Manual Oven Light Switch (some models).
11. Automatic Oven Door Light Switch (some models).
12. Oven Interior Light with Shield (some models).
13. Self-Cleaning Oven interior.
14. Adjustable Oven Rack(s).
15. Large 1 piece Oven Door Handle.
16. Full width Oven Door (styles vary with model).
17. Storage Drawer with integrated Handle (some models) or lower
cover panel (some models).
18. 5,000 BTU Simmer Burner (some models).
19. 9,500 BTU Burner (some models).
20. 12,000 BTU Quick Boil Burner (some models).
21. 14,000 BTU Quick Boil Burner (some models).
22. Broil Pan (some models).
23. Broil Pan insert (some models).
24. Leveling Legs and Anti-tip Bracket (included).
o r
u
NOTE: The features of your range may
vary according to model type & color.
Loading...
