CR66
ROCHESTER
www.crosleyradio.com
IMPORTANT SAFETY INSTRUCTION
PLEASE READ CAREFULLY ALL THE FOLLOWING IMPORTANT SAFEGUARDS
THAT ARE APPLICABLE TO YOUR EQUIPMENT
1. Read Instructions - All the safety and operating instructions should be read before the product is operated.
2. Retain instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating Instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.Use
a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
8. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination to overturn.
9. Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be blocked
or covered, The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in a built - in installation such as a bookcase
or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
10. Power Sources - This product should be operated only from the type of power source indicated on the marking label,
if you are not sure of the type of power supply to your home. Consult your product dealer or local power company.For
products intended to operate from battery power, or other sources, refer to the operating instructions.
11. Grounding or Polarization - This product may be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet try reversing the plug, If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12. Power - Cord Protection - Power - supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they exit from the product.
13. Lightning - For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the product due to lightning and power - line surges.
14. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
15. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
16. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short - out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
17. Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel
under the following conditions;
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance - this indicates a need for service.
19. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
20. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
21. Wall or ceiling Mounting - The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
22. Heat - The product should be situated away from heat sources such as radiators. Heat registers, stoves, or other
products (including amplifiers) that produce heat.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful intereference to radio or
television reception, which can be determined by turning the equipment off and on , the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio TV technician for help.
AC
Polarized Plug
WARNING:
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION:
Use of controls or adjustments or performance of procedures other than those specified
may result in hazardous radiation exposure.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER - SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, within an equilateral
triangle, is intended to alert user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be
of sufficient magnitude to constitute risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended
to alert user to the presence of important operating and
maintenance (servicing) instruction in the literature accompanying
the appliance.
CAUTION
For Compact Disc Units Only:
INVISBLE LASER RADIATION WHEN OPEN AND INTERLOCK
FAILED OR DEFEATED. AVOID DIRECT EXPORSURE TO LASER
BEAM.
Marking plate was located on bottom enclosure
Specification
Frequency Range : AM 525 - 1710 KHz
: FM 87.5 - 108.5 MHz
Power Supply : AC 120V ~ 60Hz
Power Consumption : 18W
Antennas : External antenna for FM
: Built-in ferrite bar for AM
Speaker : 4” Dynamic type x 2
Replacement Needle : NP1
* DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
2
Welcome Table of Contents
Thank you for purchasing the Crosley Rochester
(CR66). Before operating this unit, please read this
manual thoroughly and retain it for future reference.
About This Manual
Instructions in this manual describe the control
functions of the CR66.
Getting Started
Control Locators....................... 4,5
Unpacking................................. 6
Power Source........................... 6
Base Operation
Turntable Operation.................. 7
Accessory: Adapter for 45 rpm
.................................................. 7
Cassette Operation.................. 8
Radio Operation....................... 8
CD Operation
Playing a CD............................. 9,10
Programmed Playback............. 10
Connecting Optional Equipment
Auxiliary Input ......................... 11
General
Troubleshooting Guide.......... 11
Warranty.............................. 12
3
Control Locators
Unit Controls
1. SPEAKER
2. FUNCTION SWITCH
3. TUNING KNOB
4. DIAL SCALE
5. ON/OFF-VOLUME ROTARY KNOB
6. AM/FM BAND SWITCH
7. PROGRAM INDICATOR
8. PROGRAM BUTTON
9. REPEAT INDICATOR
10. REPEAT BUTTON
11. BACKWARD SKIP BUTTON
12. LED DISPLAY
13. FORWARD SKIP BUTTON
14. STOP BUTTON
15. PLAY INDICATOR
16. PLAY/PAUSE BUTTON
17. CD DOOR
18. OPEN/CLOSE BUTTON
1
CD
TAPE
RADIO
PHONO
AM FM
B.SKIPPROG.
REPEAT
8.
8.
2
RADIO
3 4
CD
TAPE
PHONO
F.SKIP PLAYSTOP
VOLUME
ON
MAX.
OFF
OPEN/CLOSE
5
VOLUME
AM FM
7
6 8910
REPEAT
B.SKIPPROG.
11
8.
8.
12
F.SKIP
13
ON
OFF
STOP
15
14 16
MAX.
PLAY
OPEN/CLOSE
17
18
4
Unit Controls
Control Locators
19. TURNTABLE
20. SPINDLE
21. ADAPTER FOR
45 RPM RECORD
22. CUE LEVER
23. TONE ARM
24. SPEED CONTROL SWITCH
(331/3, 45, 78 RPM)
25. TONE ARM REST
26. SECURITY HOOK
27. EXTERNAL ANTENNA
28. AC POWER PLUG CORD
29. LINE IN JACK
30. LINE IN SWITCH
31. CASSETTE EJECT / FAST FORWARD
32. CASSETTE DOOR
19
20
29 30
21
22
23
24
25
26
LINE IN
LINE IN
OFFON
31 32
27
28
5
Getting Started
Unpacking
1 Remove packing materials from unit.
Note: Save all packing materials.
2 Remove plastic bag covering radio.
3 Remove plastic safety cover from A/C plug.
4 Remove tie from A/C cord and untie antenna
wire on back of radio.
5 Open lid and remove styrofoam shipping
material from turntable.
6 Remove black tie-wrap from under the tone
arm.
7 Remove white protective needle cover by gently
pulling towards the front of the unit.
Power Source
1
Unwind the AC POWER CORD (28) at the back
of the unit and connect it to a power outlet.
2 Plug A/C cord into appropriate outlet.
AC
Polarized Plug
3 This product is equipped with a polarized
alternating current line plug (a plug having one
blade wider than the other). This plug will fit into
the power outlet only one way. This is a safety
feature, If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug
should still fail to fit, contact you electrician to
replace your obsolete outlet. Do not defeat the
purpose of the polarized plug.
8 Untie the FM antenna and allow it to hang down
in a straight line for optimum FM reception. If
you have trouble tuning in an FM station, move
the external FM antenna for best reception. Do
no connect FM antenna to outside antenna.
6
Turntable Operation
Turntable Operation
Turn the unit on by rotating the ON/OFF-VOLUME
ROTARY KNOB (5) located on the front panel to
the ON position.
1 Rotate the FUNCTION SWITCH (2) to select
PHONO mode.
2 Set the SPEED CONTROL SWITCH (24) to
desire speed (33 1/3,45 or 78 rpm). Place the
record on the turntable.
3 Use the CUE LEVER (22) to raise the tone
arm off its rest. Pull the TONE ARM (23) slightly
to the right side until hear the “click” sound to
activate the turnatable.
4 Move the tone arm over the record and use the
cue lever to lower it to the point you want the
record to start. Adjust the ON/OFF-VOLUME
ROTARY KNOB (5) to the desired listening
level.
Accessory: ADAPTER FOR 45 RPM
This adaptor allows you to play 45 RPM records.
1 Place the 45 RPM adaptor over the spindle.
2 Gently place your 45 RPM record onto the
turntable.
3 Follow the steps under turntable operation to
play your record.
5 At the end of the record, the TONE ARM (23)
will stop automatically . You must return to TONE
ARM to arm rest by hand.
7
Cassette & Radio Operation
Cassette Operation
1 Rotate the FUNCTION SWITCH (2) to TAPE
position.
2 Insert a prerecorded tape through
DOOR (32). Tape will slide into the cassette
mechanism and start playing.
3 Adjust the volume level by turning the VOLUME
KNOB (5).
4 For fast forwarding, press the CASSETTE
EJECT/F.F (31) half way in. Pressing again,
will stop the fast forwarding and return the
cassette to the playing mode.
5 To stop and eject the cassette, press the
CASSETTE EJECT/F.F (31) in completely.
6 When one side of the tape finishes playing, the
cassette will automatically stop.
NOTE: Remove the tape from the unit when it is not
in use or stopped.
the CASSETTE
Radio Operation
1 Rotate the FUNCTION SWITCH (2) to select
RADIO mode.
2 Set the AM/FM BAND SWITCH (6) to the desired
band (AM or FM).
3 Select the desired radio station by rotating
TUNING KNOB (3)
4 Adjust the ON/OFF-VOLUME ROTARY KNOB
(5) to the desired sound level.
Antenna
Antenna: for FM reception, the unit is provided with
a FM WIRE ANTENNA (27) , move the wire until
the reception is clear and with no interferences. For
AM reception, the unit is provided with a directional
build-in ferrite antenna. Rotate the set to find the
position in which the best reception is obtained. Do
not connect the EXTERNAL FM ANTENNA (27) to
any outside antenna.
8
CD Operation
Playing A CD
1 Rotate the FUNCTION SWITCH (2) to CD mode.
2 Press the OPEN/CLOSE BUTTON (18) to open
the CD DOOR (17). Place a disc in the tray
with the labeled side of the disc facing up.
3 Press the OPEN/CLOSE BUTTON (18) again
close the CD DOOR (17). The display will
show “— —“ for a few seconds, then the total
number of tracks on the disc will be displayed.
“00” will be shown when there is no disc inside
the unit.
4 Press the PLAY BUTTON (16) to start playback.
The PLAY INDICATOR (15) will light up.
5 Adjust the VOLUME ROTARY KNOB (2) to the
desired volume level.
6 To pause playback, press the PLAY/PAUSE
BUTTON (16). The PLAY INDICA T OR (15) will
flash. Press the PLAY BUTTON (16) again to
resume playback.
Skip Forward And Skip Reverse
1 Press the FORWARD SKIP BUTTON (13) or
the BACKWARD SKIP BUTTON (11) to select
a track.
2 Press the PLAY BUTTON (16) to start playing
the selected track
Search Forward And Reverse During Play
PLAYBACK
1 Press and hold the FORWARD SKIP BUTTON
(13) or the BACKWARD SKIP BUTTON (11) to
search forward or backward though the selected
track.
2 Release the button at the desired point, playback
will resume automatically.
7 To stop playback, press the STOP BUTTON
(14). The PLAY INDICATOR (15) will go off.
9
CD Operation
Repeat Playback
1 To repeat a single track, choose the track that
you want to repeat, then press the PLA Y BUTT ON
to start the track. Press the REPEAT BUTTON
once to repeat this track.The REPEA T INDICATOR
will flash.
2
To repeat all tracks, press the PLAY BUTT ON
to start the CD. Press the REPEA T BUTTON (10)
twice to repeat all tracks. Once the CD ends, it
will start over again from the beginning of the
CD. The REPEAT INDICATOR (9) will remain
on.
3 T o erase the repeat function, press the REPEAT
BUTTON(10) again until the REPEA T INDICATOR
is off.
(16)
(10)
(9)
(16)
(9)
Programmed Playback
1 Press the PROGRAM BUTTON (8). " 01" will
shown on the display and the PROGRAM
INDICATOR (7) will flash.
2 Press the FORWARD SKIP BUTTON (13) or
the BACKWARD SKIP BUTTON (11) to select
a track.
3 Press the PROGRAM BUTTON (8) again to
store the selected track number.
4 Repeat steps 2 and 3 above to program other
tracks.
5 Press the PLAY BUTTON (16) to start
Programmed playback. The PROGRAM
INDICATOR (7) will be on.
6 T o erase the programmed sequence, press the
STOP BUTTON (14) twice or until the
PROGRAM INDICA TOR (7) is of f. Programmed
tracks will also erase when the
is opened.
CD DOOR
(17)
NOTE: Maximum of 20 tracks can be programmed
to play in any order.
10
Connecting Optional Equipment
Auxiliary Input
1 You can connect external components to your
unit by using the Auxiliary Input.
2 Plug Auxiliary cable into the LINE IN JACK (29)
on the back of your unit.
3 Switch the LINE IN SWITCH (30) to the ON
position.
4 Plug the other end of the Auxililary cable into
the output jack on your desired external
component.
5 Check the volume level of your external
component.
6 See operators manual for correct operation of
the external component.
NOTE: When not using the Auxiliary Input, make
sure the LINE IN SWITCH (30) is in the
OFF position.
Troubleshooting
There is no Power
1 The AC plugged is not well connected.
2 Check to see that the ON/OFF volume knob is
in the on position.
There is no Sound
1 Check the volume level by turning the volume
knob.
2 Make sure the LINE IN SWITCH is in the OFF
position if the LINE IN JACK is not being used.
Turntable will not work
1 Make sure the function switch is set to phono.
2 Try moving the tone arm to the right until you
hear a click.
3 Make sure the protective needle cover is
removed.
CD does not play
1 Check to make sure CD is inserted correctly
(label side facing up).
2 Check that the surface of the CD is clean
3 Make sure function switch is set to CD.
11
LIMITED MANUFACTURERS WARRANTY
Crosley Radio, Inc. warrants the product to be free from defects in material and
workmanship under normal use for a period of one year from the original date of
purchase. This warranty is not transferable. If the product is determined to be defective
during the warranty period, the unit will be repaired or replaced at Crosley Radio’s sole
discretion. This warranty covers manufacturing defects and normal consumer use and
does NOT cover damage or failure as a result of abuse, accident, alterations, misuse,
neglect, abnormal wear and tear , inadequate maintenance, commercial or unreasonable
use, damage caused by power surges, mishandling, accident, acts of God or attempted
repair by an unauthorized service agent. Also not covered are cosmetic damages,
cords and antennas.
Should this product fail to function in a satisfactory manner, it is best to first return it
to the store or retailer where it was originally purchased. If additional service is still
needed, the original purchaser must FIRST contact our offices to obtain an RA (Return
Authorization) Number.
TO OBTAIN AN RA NUMBER
CALL: 1.888.CROSLEY
(1.888.276.7539)
Send the unit prepaid to the address below in the original packaging (or reasonable
substitute to prevent damage). Clearly mark your RA number on the outside packaging
and include the original sales receipt (or a copy) indicating date of purchase, amount
paid, and place of purchase. You must also include your full name, shipping address
and daytime contact number. Please include a check or money order in the amount
of $19.95, made payable to Crosley Radio, to cover handling and return shipping
charges. Returned products will not be shipped to PO Boxes. Crosley Radio will not
be responsible for delays or unprocessed claims resulting from a purchaser’s failure
to provide any or all of the necessary information.
CROSLEY RADIO
ATTN: RETURNS DEPT
2001 PRODUCTION DRIVE
Louisville, KY 40299
For additional support: Crosley Radio Consumer Service Department
24 hours a day / 7 days a week
Telephone: 1.888.CROSLEY (1.888.276.7539)
There are no express warranties except as listed above.
The purchaser’s bill of sale is the only proof of warranty entitlement.
This warranty gives the purchaser specified legal rights in addition to any rights which
may vary from state to state.
In accordance with the “Moss-Magnuson Warranty Act” of July 10, 1975, this is termed
a “limited warranty” which in no way compromises Crosley Radio’s high standards of
quality and workmanship.
910-245000-0160-200
Loading...
