Crock-Pot 4865 User Manual

4865

Owner’s Guide

READ AND SAVE THESE INSTRUCTIONS

Pre-Programmed Recipes

Programmable

The Original and America’s #1 Brand of Slow Cookers

SAVE THESE INSTRUCTIONS

This appliance is for HOUSEHOLD USE ONLY. No user-serviceable parts
inside. Do not attempt to service this product. Do not immerse base in water
or other liquid. A short power-supply cord is provided to reduce the hazards
resulting from entanglement or tripping over a longer cord. AN EXTENSION

CORD MAY BE USED WITH CARE; HOWEVER, THE MARKED ELECTRICAL
RATING SHOULD BE AT LEAST AS GREAT AS THE ELECTRICAL RATING OF
THE RECIPE SMART-POT™. The extension cord should not be allowed to

drape over the counter or tabletop where it can be pulled on by children or
tripped over.
NOTE: During initial use of this appliance, some slight smoke and/or odor
may be detected. This is normal with many heating appliances and will not
recur after a few uses.

-2-

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be
followed, including the following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock, do not immerse cord, plug, or cooking

unit in water or other liquid. CAUTION: Never submerge the heating unit
in water or other liquid.

4. Close supervision is necessary when any appliance is used by or
near children.

5. Unplug from outlet when not in use and before cleaning. Allow unit to
cool before putting on or taking off parts.

6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner. Return
appliance to Rival®(see warranty) for examination, repair or adjustment.

7. The use of accessory attachments not recommended by Rival

®

may cause

fire, electrical shock or injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch
heated surfaces.

10. Do not place on or near a hot gas or electric burner, or in a
heated oven.

11. Extreme caution must be used when moving an appliance containing hot
oil or other hot liquids. Always use hot pads when moving your heated
Recipe Smart-Pot™.

12. Do not use appliance for other than intended use.

13. Avoid sudden temperature changes, such as adding refrigerated foods into
a heated pot.

14. To disconnect, press the OFF button, then remove plug from
wall outlet.

-3-

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the

other). To reduce the risk of electric shock, this plug is

intended to fit into a polarized outlet only one way. If the
plug does not fit fully into the outlet, reverse the plug. If it

still does not fit, contact a qualified electrician. Do not attempt
to modify the plug in any way. If the plug fits loosely into the AC outlet or if
the AC outlet feels warm do not use that outlet.

-5-

HOW TO USE YOUR RECIPE SMART-POT

™

1. Always cook with the lid on, for the recommended time.

2. Follow recommended cooking times.

3. Do not use the slow cooker stoneware for storage of foods.

4. Do not reheat foods in your Recipe Smart-Pot

™

.

5. Do not set heated unit filled with food on a finished wood table.

6. Unplug when cooking is done and before cleaning.

7. Do not use plastic lids in microwave or conventional oven. Do not use
removable stoneware on gas or electric burner or under broiler.

CAUTION: Always place protective padding under stoneware before setting
on table or countertop.

HOW TO PROGRAM YOUR RECIPE SMART-POT

™

To turn the unit on, press either the COOK/TIME or the RECIPE
key pads. You can either use a programmed recipe or if you want
to use your own favorite recipe then skip to the section titled
“How to Program Using the Cook /Time Key Pad.”

HOW TO REVIEW RECIPES OR PROGRAM:

Over two hundred recipes are stored in the Rival®Recipe
Smart-Pot™. It is possible to review as many categories and recipes
as you like before making your choice. To review
and/or choose specific recipes proceed as directed below.
NOTE: A list of the recipes have been included on pages 14-17 of this manual.

Press RECIPE key pad:

The Display Shows: Navigating

RIVAL

®

A signal will sound and the word Rival

®

appears briefly on the screen. (This will
happen only the first time the unit is
powered on)

Main Menu The MAIN MENU option will appear on
Choose/Press ENTER the screen. It contains a list of four
Starters categories of recipes that are available.
Soups and Stews Use arrow key pad and Press DOWN
Main Dishes until you reach the desired category.
Desserts To return to previous category Press

UP arrow key pad. When you have chosen
a category Press ENTER.

(Selected setting) Each main category is divided into sub
Ex. Starters categories which narrows your choices
Choose/Press ENTER into more specific types of recipes, within
Previous Menu the category. To view the choices, use
Appetizers / Sides arrow key pad and Press DOWN until you
Dips reach desired category. Press UP
Beverages arrow key pad to return to previous

category choices or Previous Menu. When
you have chosen a category Press ENTER.

-4-

KNOW YOUR RECIPE SMART-POT

™

REMOVABLE LID

CONTROL PANEL

REMOVABLE STONEWARE

BASE/ HEATING UNIT

HANDLES

SCREEN – Digital
screen to display
menus and recipes

COOK/TIME – Sets
the time and
cooking temperature

RECIPE – Finds
the desired recipe

UP & DOWN ARROWS – Up and down

buttons to scroll through menus and recipes

OFF – Turns Power off
ENTER - Selects

highlighted menu
choice

GO – Starts the
cooking cycle once
cook temperature and
time has been set

COOKING LED – Illuminates
during cooking cycle

HOW TO PROGRAM YOUR RECIPE SMART-POT™(CONT.)

The Display Shows: Navigating

HEAT SETTING The Heat Setting options will appear on

the screen. This is used to set the desired
cooking temperature (which is given in
the recipe).

Choose/Press Enter Machine is set on High. If Low is desired,
High

use

the arrow key pad and Press DOWN once
Low for Low setting. When you have chosen
Keep Warm

the desired temperature setting Press ENTER.
(Note: Keep Warm setting should not be
used for cooking.)

ENTER TIME: Press UP or DOWN arrow on key pads to
04:00 increase or decrease the time. Click once

for each half-hour that you want to add or
subtract until you reach the desired time
from one-half hour to twenty hours. When
the display shows desired time, press ENTER.

PRESS GO To start cooking, Press GO. A single beep

will sound. This beep signals that cooking
has begun.* The COOKING LED will
illuminate and indicates the cooking cycle
is active. The screen will show the cook
time remaining and heat setting.

(Selected setting) Time counts down in minutes until the
Ex. High timer reaches 00:00. (ex. 04:00 is four
04:00 hours, 03:59 is 3 hours, 59 minutes, etc.)

At 00:00, the cooking ends and a beep
will sound. At any time during a cooking
cycle, recipes can be browsed without
interrupting the cooking cycle. If recipes
are browsed during a cooking cycle,
the screen will default back to the cook
time/heat setting screen after 30 seconds

HOW TO PROGRAM YOUR RECIPE SMART-POT™(CONT.)

The Display Shows: Navigating

(Selected setting) All of the available recipes in each chosen
Ex. APPETIZERS/SIDES

category are listed. To view possible choices

Choose/Press ENTER Use arrow key pad and Press DOWN until

Previous Menu you reach the desired recipe. Press UP
Alphabetical listing arrow key to return to previous recipe
of available recipes choices or Previous Menu option. When
Ex. Appetizer Ribs you have made your recipe choice
(etc.) Press ENTER.

Push ENTER To view the complete recipe chosen
to go back Press DOWN arrow key. Press once to stop

Chosen recipe title on each line or hold the arrow key pad
list of ingredients down to scroll down . Press UP arrow key
and cooking pad to return to previous ingredients or
instructions instructions. When you have chosen a

recipe, scroll down and follow instructions.
To view a different recipe Press ENTER to
go back. To program cooking temperature
and time Press COOK/TIME keypad.
Continue programming by following the
navigating instructions below.

HOW TO PROGRAM USING THE COOK / TIME KEY PAD.

When you have finished filling the stoneware with the recipe
ingredients, cover your Recipe Smart-Pot™and proceed as
directed below:

Press COOK/TIME key pad:

The Display Shows: Navigating

RIVAL

®

A signal will sound. The word RIVAL

®

appears briefly on the screen. (This will
happen only the first time the unit is
powered on)

-7-
