All-in-one Kiosk
KFP249 & KFP255 Series
Specially designed for commercial market, this product features high luminance
panel, professional DCPI color adjustment tecchnology and your choice of
®
built-in media player, Android or BrightSign
All-In-One kiosks offer non=touch and 10-point IR touch options
•
in 49” & 55” displays
Ultra slim design allowing for small footprint installations
•
Choose from models standard with Android media player or add
•
a BrightSign® as an added accessory
Built in storage for housing media players and other integrated
•
hardware
Can be secured to the oor using pre-drilled holes in the base
•
for added security
.
SMALL FOOTPRINT
Ultra Slim Design
A sleek, stylish and rugged design,
with simple installation and
maintenance, oering a perfect
all- in-one solution for today’s
marketplace.
MULTIMEDIA
Built in Speakers
Vents positioned in top and bottom
compartment to direct airow over
compoents and display.
OPTIONAL MEDIA
BrightSign
Add an optional Brightsign® Media
player.
®
SECURE
Steel Keyed Locks
Steel keyed locks secure the back
door compartment.
OPTIONAL 10-POINT
IR TOUCH SCREEN
Fast respoonse, high accuracy and
high reliability it supports multi-touch
operantion and gesture recognition
SECURE
Pre-drilled Base Holes
Can be secured to the oor using
pre-drilled holes in the base for
added security.
4 5
ph: 866.668.6888
BUILT-IN ANDROID
MEDIA PLAYER
Secure Organized Storage
Easily attach components to shelf for
secure ventilated placement.
fax: 847.919.3483
SUPERIOR COOLING
Engineered Venting
Vents positioned in top and bottom
compartment to direct airow over
components and display.
[email protected]www.crimsonav.com
Superior Product
Superior Service
Superior Value
Page 4
K20 Series
Floor standing portrait kiosk compatible with
displays 46”-65”.
14 gauge steel construction
•
3/16” high impact acrylic front for a seamless
•
appearance
Sliding display shelf eliminates VESA pattern
•
concerns
Built in storage for housing components
•
Can be secured to the oor using pre-drilled
•
holes in the base
Equipped with heat exhaust fans to eliminate
•
heat buildup caused by the display and/or
integrated electronics
Can be hard wired to a junction box or
•
simply plugged into a wall socket
Custom colors and custom screen printing
•
available
Fully Customizable Solutions
Fully Customizable Solutions
Kiosks-IndoorKiosks-Indoor
K20F
Bottom plate
K20P
No bottom plate
K35 Series
Fully integrated wall mounted enclosure compatible with displays 46”-65” is rated for indoor use. Constructed with 14 gauge steel and 3/16”
high impact acrylic front present a durable and seamless appearance. Easy assist gas shocks make opening the kiosk and accessing the
display a cinch.
KT300 Series
Floor standing tablet kiosk
Holds tablet in portrait or
•
landscape and can be easily
switched between the 2 without
removing the tablet
Removable access panel allows
•
for easy access to built in storage
for housing power cords, external
batteries and other accessories
Lockable storage compartment
•
Can be secured to the oor using
•
pre-drilled holes in the base
Available in a variety of standard
•
and custom color congurations
Custom colors and custom
•
screen printing available
K30 Series
Floor standing kiosk in landscape orientation compatible
with displays 46”-55”. Ideal for touch applications. 14
gauge steel construction, with 3/16” high impact acrylic
face. Easy assist gas shocks and prop bars make
opening the kiosk and accessing the inputs a cinch.
6 7
ph: 866.668.6888
fax: 847.919.3483
[email protected]www.crimsonav.com
KT300 Series
Compatible with most tablets on the market today. Customizable colors and screen printing to tailor the project look to your client’s
specications. Solid steel construction with ability to bolt to the oor make the KT300 ideal for high trafc applications. Lockable storage
compartment neatly stores batteries and manages power cords.
Superior Product
Superior Service
Superior Value
Page 5
Outdoor Displays
QSR Outdoor Menu Boards
QSR Outdoor EnclosuresSEALOC
Single, Double and Triple CongurationsFully Weatherproof Outdoor Display
Smart TV features to improve your lifestyle
•
Thin & lightweight design
•
Crystal clear audio that delivers rich highs, mids and
•
low frequencies
Exclusive Nano-Coating enabling our displays to
•
become weatherproof
4K UHD
Built in Speakers
Stunning true 4K Ultra High
Denition resolution, specically
calibrated for outdoor use.
SMART TV
WIFI Enabled
Features such as shows, movies,
streaming, video games, aps, web
surng, social media and much
more.
THIN EXTERIOR
Weatherproofed in a certain way to
make sure we retain its thin design.
Floor standing kiosk in portrait orientation compatible with
•
SEALOC 4k UHD display
IP56 rated
•
Wind load rated to 90, 120, 150 mile per hour wind loads
•
under soil classes 4 and 5
4mm AR coated tempered safety glass
•
Built in storage for housing media players and other
•
integrated electronics
Slotted base plate for securing to foundation
•
Custom colors available
•
QSR Outdoor Enclosures for 55” SEALOC 4K UDH Display
NANO TECHNOLOGY
Exclusive Nano-Coating
Conforms to every facet, chip and
component on delicate electronics,
providing a tough, weatherproof
barrier.
Model Display Size Description
CST-SLV-LG43
CST-SLV-LG50
CST-SLV-LG55
CST-SLV-LG65
CST-SLV-LG75
8 9
43” Fully weatherproofed 43” 4K UHD outdoor display 200x200mm 18.3 lb
50” Fully weatherproofed 50” 4K UHD outdoor display 200x200mm 23.6 lb
55” Fully weatherproofed 55” 4K UHD outdoor display 300x300mm 30.2 lb
65” Fully weatherproofed 65” 4K UHD outdoor display 300x300mm 46.3 lb
75” Fully weatherproofed 75” 4K UHD outdoor display 600x400mm 76.3 lb
ph: 866.668.6888
fax: 847.919.3483
LIGHTWEIGHT DESIGN
Easy to handle weight for moving and
mounting.
Mounting
Pattern
[email protected]www.crimsonav.com
Display Weight
Single
QSR155
CFM rated exhaust system maintains temperature no greater than 10º
•
above ambient
