Crimsco USTC-48-HR, IMC-48-1014, IMC-72-1014, IMC-120-912-HA, IMC-120-912-HH Specifications
...Page 1
is
Foodservice equipment
designed for the unique
needs of correctional facilities
Corrections
Page 2
Precision performance. State-of-the-art design. For over 30
years Crimsco has been recognized by food service managers
across the country for top quality correctional meal delivery
systems that are built to last.
Your environment is tough.
Our standards are even tougher.
When we say, “Crimsco is corrections”, that’s not a
statement we make lightly. For over 30 years, Crimsco
has served the corrections market-getting to know
your needs literally from the inside out.
The result? Products that are as inmate-proof as
possible: heavy-duty stainless steel
construction…unique tamper resistant, mechanically
attached bumpers…double pan reinforced doors…12
gauge welded hinges…a minimal number of moving
parts to minimize breakage and wear…top mounted
heating systems and much, much more. Our
equipment is also designed with the many structural
needs of your facility in mind. Our products can easily
move through “sally ports” and navigate narrow door
openings and bottle necks. Crimsco products are
designed with flexibility in mind. Where you may
have needed a cumbersome two or three door
product you will be able to use a Crimsco one door
product. Most of our products can utilize multiple tray
sizes, giving you more options.
Our top mounted forced air heating system
helps keep foods at HACCP compliant
temperature levels, and also meets your
needs for security and sanitation.
Along with the built-in challenges of your environment
- an inmate population that is both growing and aging,
new facilities construction, adequate staffing and
budget cuts – you also face increasing demands for
HACCP-compliance. Because more facilities are
going to cell block feeding, there’s an even greater
need to monitor temperatures to reduce the
possibility of food-borne illness. Crimsco helps you
stay HACCP-compliant with equipment that when
properly used, works to help maintain proper food
temperature at the point of service.
Durability. Flexibility. Reliability.
That’s a lot to ask of any equipment. But at Crimsco,
we work hard to deliver in each of those areas. After
all, we don’t consider corrections equipment just
something we do. We know your needs so well, it’s
who we are.
Top mounted-away from damage and food spillage
Tunnel distribution system insures even heat flow
Recessed thermostat and thermometer safely
protected behind tamper-proof covers
Simple on/off switch
Page 3
Count on Crimsco for maximum
security and durability.
Security is our top priority.
Making our equipment as close to inmate-proof as
possible drives the development of every feature of
our carts. It’s not enough to take an existing
product tack on a few bolts and call it secure. Our
equipment is designed primarily for the maximum
security environment. Which is why you’ll find
everything available from Lexan ™ covers for
thermometers, to tamper-proof fasteners, to 12
gauge welded hinges to 12 gauge lockable
transport latches to magnetic door closures to fully
welded shelving that prevent exposed parts getting
banged up or tampered with – all standard on
Crimsco’s carts.
The strength and toughness of Crimsco carts start with
our heavy-duty double pan reinforced base
Crimsco carts are extra strong and avoid cabinet torque
with our unique four corner integral c-channel design
Crimsco carts feature heavy gauge stainless steel
construction
Tray slides are welded in place to removable frames
Fully welded stainless steel tubular handles are standard
12 gauge stainless steel hinges
Durable Construction, Efficient Design, Reliable Performance
Page 4
Crimsco’s Corrections Solutions
Heated and
Refrigerated Cart
HACCP compliance
requirements are
becoming mandatory for
more and more
corrections facilities.
Crimsco can help you
meet those demanding
regulations while handling
the growing prison
population with our
heated/refrigerated meal
delivery system.
USTC-48-HR
Heated/Refrigerated Cart
USTC-48-HR accepts dual 8 x 10 hot and cold
compartmentalized trays; or dual 6 x 8 hot and
cold food boxes with lids: or 9 x 11 hot and cold
food boxes with lids.
Each hot and cold section has an independent
air convection system for uniform temperature
distribution
Hot and cold sections are provided with a
louvered panel to send air to each individual tray
slide
USTC-48-HR
Automatic overload protection helps prevent
shock and fire hazards
The cold section refrigerates using a finned
coil tubular evaporator with blower fan and
expansion valve which improves energy
efficiency and provides longer life
Tray slides are welded to removable uprights
for easy cleaning
Page 5
Crimsco’s Corrections Solutions
Heated Carts
Exceptionally even heating
is the key benefit of
Crimsco’s IMC series carts.
But what makes these carts
the clear choice is the
durability and reliability of
our “High n’ Dry” top
mounted heating system.
IMC-1014 Series
Heated Carts
Carries 48 to 72
compartmentalized 10 x 14 trays.
Higher volumes of 6 x 8 and 9 x 11
trays can also be carried
Rear mounted “tunnel”
distribution system insures even
heating
Fully insulated using high density
foam insulation
Low profile design provides good
visibility and easy maneuverability
IMC-48-1014
IMC-912 Series
Heated and Ambient Carts
Carries up to 96 9 x 11 food boxes with lids or 144
6 x 8 food boxes with lids
Rear mounted “tunnel” distribution system insures
even heating
Fully insulated using high density foam insulation
Can be configured as Heated/Ambient,
Heated/Heated or Ambient only
* heated/heated unit is not Energy Star rated
Page 6
Crimsco’s Corrections Solutions
Bulk Food Cabinets
They’re the workhorses
you shouldn’t do without!
Versatile BFT cabinets can
serve as holding or
transport units for bulk
steam and sheet pans.
IMC-BFT Series
Heated Bulk Food Transport
IMC-BFT and IMC-BFT-HS accommodate 24
bulk pans or 12 bun pans
Universal shelving is welded to removable
uprights
IMC-BFTIMC-BFT-HS
Insulated Tray Delivery Cart
These carts are designed to
transport insulated stackable
trays. They are setup to
receive just about any brand
available.
IMC-COR Series
Insulated tray delivery cart
Center hinged doors for ease of operation
Heavy-duty welded tubular divider helps
keep trays in place
Page 7
is
Corrections
WHAT’S BEHIND THE NAME ?
- PRIDE,COMMITMENT, INTEGRITY AND SKILL -
Testimonials:
It’s a war out there, I want the tank that lasts, that’s why I use Crimsco.
Bill M, Corrections Maintenance Manager
Southern California
Ventura County Sheriff’s Dept. has used Crimsco carts for at least 25 years,
I stand behind their product.
Henk Van Der Kraan, Manager-Sheriff’s Food Services
Ventura County Sheriff’s Department
Call 414-702-8972 or 800-367-8413 ext. 231 today to discuss the
models that are just right for your foodservice needs and receive a quote .
Or set-up an on-site consultation with our professional team.
Your job is tough, our standards are even tougher!
Page 8
Model
Tray Size
Tray Capacity
Width
Depth
Height
USTC-48-HR
6 x 8
72 hot / 72 cold
50.5”
32.5”
55” (to top of deck)
9 x 11
48 hot / 48 cold
Heated and Refrigerated Carts
Model
Tray Size
Tray Capacity
Width
Depth
Height
IMC-48-1014
10 x 14
48
28”
34.5”
53”
IMC-72-1014
10 x 14
72
28”
34.5”
65”
Model
Tray Size
Tray Capacity
Width
Depth
Height
IMC-120-912-HA
6 x 8
72 hot / 72 ambient
50.5”
29”
63”
9 x 12
48 hot / 48 ambient
IMC-120-912-HH
6 x 8
144 hot
50.5”
29”
63”
9 x 12
96 hot
Model
Tray Size
Tray Capacity
Width
Depth
Height
IMC-BFT
18 x 26
12
28”
34.5”
72”
12 x 20 x 4
24
IMC-BFT-HS
18 x 26
6
28”
34.5”
45”
12 x 20 x 4
12
Model
Tray Size
Tray Capacity
Width
Depth
Height
IMC-COR-48
Max tray size
14 x 18 x 2.75
48
46”
32.5”
50.5”
IMC-COR-72
Max tray size
14 x 18 x 2.75
72
46”
32.5”
62.5”
Heated Carts
Heated / Ambient Carts
Bulk Food Carts
Insulated Tray Carts
A Division of
7737 N 81stStreet, Milwaukee, WI 53223 USA / 414-702-8972 / 800-367-8413 ext. 231 / www.crimsco .com
Form# 41197 (8/10)
