Crestron TPMC-17-QM-L Operating Manual

Crestron Isys i/O™

TPMC-15/17-L Series

Wall Mount Touchpanel Media Centers Operations Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

Windows

, Windows® XP and Windows® Vista are registered trademarks of Microsoft Corporation in the United States and other countries.

All brand names, product names and trademarks are the property of their respective owners.

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Contents

Wall Mount Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................ 1

Applications.................................................................................................................6

Internal Block Diagram ............................................................................................... 8

Specifications ..............................................................................................................9

Physical Description.................................................................................................. 13

Industry Compliance .................................................................................................21

Setup ........................................................................................................................................ 22

Network Wiring......................................................................................................... 22

Ethernet .....................................................................................................................22

CAT5 Wiring (CH versions only) .............................................................................22

QuickMedia Wiring (QM versions only) ..................................................................22

Identity Code ............................................................................................................. 25

Configuring the Touchpanel...................................................................................... 25

Mounting Options......................................................................................................56

Hardware Hookup .....................................................................................................58

Recommended Cleaning............................................................................................ 61

Programming Software............................................................................................................62

Earliest Version Software Requirements for the PC .................................................62

Programming with Crestron SystemBuilder.............................................................. 62

Programming with SIMPL Windows........................................................................ 62

Programming with VisionTools Pro-e....................................................................... 65

Embedded Applications.............................................................................................68

Defaults for Embedded Windows Applications ........................................................ 69

Programming Embedded Windows Applications......................................................70

Example Program...................................................................................................... 71

Uploading and Upgrading........................................................................................................ 72

Establishing Communication.....................................................................................72

Programs, Projects and Firmware.............................................................................. 73

Program Checks ........................................................................................................74

Operation .................................................................................................................................75

MediaMarker............................................................................................................. 75

Security Infrastructure............................................................................................... 75

Problem Solving ......................................................................................................................77

Troubleshooting......................................................................................................... 77

Check Network Wiring..............................................................................................78

Reference Documents................................................................................................79

Further Inquiries........................................................................................................80

Future Updates ..........................................................................................................80

Appendix: TPMC-15/17 Multi-Language Pack...................................................................... 81

Software License Agreement................................................................................................... 82

Return and Warranty Policies.................................................................................................. 84

Merchandise Returns / Repair Service ......................................................................84

CRESTRON Limited Warranty.................................................................................84

Microsoft® Windows XP® Embedded End User License Agreement .....................................85

Operations Guide – DOC. 6354B Contents • i

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Wall Mount Touchpanel Media

Wall Mount Touchpanel Media Centers: Crestron Isys i/O™

Centers: Crestron Isys i/O™ TPMC-15/17-L Series

TPMC-15/17-L Series

Introduction Introduction

The Crestron Isys i/O™ TPMC-15/17-CH/QM-L Series of wall mounted

Touchpanel Media Centers (hereinafter referred to as TPMC-15/17-L) integrates

touchpanel control with embedded PC functionality, delivering a unified multimedia

presentation solution.

Both the TPMC-15-L and TPMC-17-L series are available in Crestron Home

(hereinafter referred to as CH) and QuickMedia™ (hereinafter referred to as QM)

versions.

Features and Functions

• 15 inch (4:3 aspect ratio) and 17 inch (widescreen 15:9 aspect ratio) active matrix touchscreen displays

• Screen resolutions: TPMC-15-L series 1024 x 768, TPMC-17-L series 1280 x 768

• 16.7 million colors, 24-bit Isys and Synapse™ image rendering algorithm

• Fast graphics performance: imported photographs, drawings and icons

• PNG image support enables translucent objects to be placed over still

images

• Dynamic Graphics enables the display of images (pictures, CD cover art, etc.) that are hosted externally on a flash memory card or media server

• Windows

• Onboard PC applications for Web browsing, streaming media,

videoconferencing, remote computer control and digital media presentation – no computer required!

XP Embedded operating system

i/O graphics with 8-bit alpha channel

(Continued on following page)

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 1

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

Features and Functions (Continued)

• Built-in real-time annotation using Crestron MediaMarker™ allows presenters to write or draw electronically on the touchscreen using a finger or stylus (QM versions only)

• High performance dual window video and RGB display enables simultaneous viewing of any two full-motion (scalable up to full screen) computer images (RGB on QM versions only)

• Built-in time base correction for stable video and graphics

• Two balanced video inputs can receive component, composite and

S-video inputs; supports NTSC/PAL formats from any Crestron CAT5 balanced video source (CH versions only)

• Two QM inputs can receive audio, microphone, NTSC/PAL composite video, S-video, component video and non-interlaced RGB computer signals over CresCAT-QM cable (QM versions only)

• QM output at native touchpanel resolution acts as transmitter for connection to a QM receiver or switcher (QM versions only)

• Built-in 10 watt biamplified speaker system and microphone (half duplex intercom capable)

• Balanced input for audio that can be connected to a Crestron CNX-BIPAD8 or any Crestron CAT5 balanced audio source (CH versions only)

• Balanced output for microphone audio that can be connected to a Crestron CNX-BIPAD8 or any Crestron CAT5 balanced audio device (CH versions only)

• Built-in mixer combines PC audio with selected audio input

• Stereo headphone jack

• Voltage monitor checks the voltage level supplied to the touchpanel

from the TPMC-L-IMC

• Auto compensation automatically recalls microphone EQ settings, source compensation settings and peak and boost preset values of multiple QM origination points when acting as an endpoint (QM versions only)

• Stores and transmits audio parameters for recall by a QM receiver when acting as a QM origination point (QM versions only)

• 10BaseT/100BaseTX high speed Ethernet, 802.3U compliant, full/half duplex, auto-negotiating

• High speed Cresnet

communications

• Two USB ports for connection with USB peripherals

• One RS-232 port for project upload, firmware upgrade and diagnostics

• Two PC Card slots for further expansion including installation of

wireless network card

• Up to 4,000 digital and 4,000 analog signals; up to 4000 serial signals

• Support for downloadable fonts – proportional

and non-proportional

• Foreign language text

• 512 MB of SDRAM, 512 MB internal Flash (expandable via external

card slot)

• Wall, lectern and rack mounting options

• Available in black or white

1. For QM versions, one or more QuickMedia devices are required to facilitate the input and output of audio, video and RGB signals.

2. With proportional fonts, the width of each character differs with the character’s shape, for example, the letter M is wider than the letter I. With non-proportional fonts, all characters are spaced equally.

2 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Isys®

Isys power and beauty are infused throughout Crestron’s entire touchpanel lineup. Under the hood, the TPMC-15/17-L offers vibrant 24-bit color depth with 8-bit alpha channel transparency to produce incredible 3D graphics using new dynamic menu objects, dynamic graphics, full motion animations, multi-mode objects, PNG translucence and exclusive Synapse™ image rendering - all with astonishing speed.

Synapse™

Crestron’s exclusive Synapse Image Rendering Algorithm enables system programmers to produce amazing graphics – faster and easier. Advanced antialiasing delivers crisper, sharper objects and text. Enhanced 3D effects add new depth and style. And because Synapse is native to the touchpanel, memory requirements and upload time are substantially reduced.

Enhanced Touchpanel Control and Presentation

More than a touchpanel, the TPMC-15/17-L is also a dynamic resource for managing routine online tasks and enjoying streaming music and video and a high-resolution video monitor with performance rivaling the best LCD flat panel displays available.

The QM version also provides a dynamic presentation source, delivering highresolution video and audio to any size audience via integrated QuickMedia transport technology.

Embedded PC

The power of Isys i/O™ is in its embedded PC engine, combining rock solid touchpanel performance with enhanced capabilities for surfing the Internet, streaming multimedia and desktop videoconferencing. Running the Microsoft Windows XP Embedded operating system, Isys i/O delivers a reliable and secure platform for touchpanel control with integrated PC functionality. Programmatic control erases the lines between control system and PC, allowing programmers to customize each application’s behavior within the touchpanel environment to create a truly powerful and user friendly interface.

With built-in Windows Media viewers for Word, Excel, PowerPoint provides everything needed for viewing Web pages, enjoying online music and movies and downloading documents without necessitating a separate computer. (The QM version also serves as a multimedia presentation source.) You can also access data and run applications on other computers over the network or Internet via Remote Desktop or use new VNC Viewer support for enhanced cross platform interaction with remote computers, allowing full control of desktop applications with live presentation capability. Onboard NetMeeting® and Skype™ VoIP applications enable duplex telephone and interactive conferencing right on the touchpanel.

Player, RealPlayer® and Internet Explorer, plus

and Adobe® Acrobat®, the TPMC-15/17-L

Touch-the-PC (QM version only)

In addition to its built-in PC, the TPMC-15/17-L is also enabled to display and control externally connected computers. Crestron’s exclusive “Touch-the-PC” technology allows real-time touchpanel navigation of any Windows PC through a direct high-speed serial connection.

MediaMarker™ Annotation

Built-in annotation allows presenters to write or draw electronically on the touchscreen using a finger or stylus. Whether drawing freehand or on a whiteboard

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 3

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

screen, highlighting points on a spreadsheet or making notes over motion video or still images, MediaMarker facilitates crystal clear visual communications.

NOTE: The TPMC-15/17-CH-L does not have video output capability. Therefore, annotation cannot be presented to an audience.

Dual Window HD Video1 and RGB2

In addition to its internal PC and streaming video applications, the TPMC-15/17-L can also simultaneously display two fully scalable, full-motion windows. Each window supports standard video, HDTV and high-resolution RGB (RGB on QM versions only) signals from external AV and computer sources. Discrete video scalers with motion adaptive deinterlacing bring out the finest detail, minimizing visible scan lines and motion artifacts for a truly remarkable picture. Advanced gamma correction and built-in time base correction ensure accurate color reproduction and a jitter-free image.

1. Additional CAT5 balanced AV equipment is required to facilitate the input of more than one external video signal.

2. One or more QuickMedia devices are required to facilitate the input and output of audio, video and

RGB signals.

High Quality Audio

An integrated microphone, biamplified speakers, stereo headphone output and PC audio output are all built into the touchpanel to support full AV, intercom, desktop conferencing and multimedia computer capabilities. Customized WAV files can be loaded on the touchpanel to add dimension to the touchscreen graphics with personalized sounds, button feedback and voice prompts.

Crestron Home® CAT5 AV (CH version only)

All audio and video connections are facilitated using inexpensive CAT5 wire, enabling direct connection to Crestron’s popular CAT5 balanced audio and video distribution switchers. Two video input ports are provided, each supporting composite, S-video and HDTV/component formats over wiring distances of up to 500 feet. A bidirectional audio port receives stereo program audio and intercom signals and outputs audio from the internal microphone and PC for intercom and whole-house audio distribution. An interface module is included to enable direct connection to conventional video and audio devices.

QuickMedia™ (QM version only)

All audio and video connections are facilitated using Crestron’s revolutionary QuickMedia transport, providing a flexible yet remarkably simple wiring solution. Through QuickMedia (QM), the TPMC-15/17-L interfaces directly with other QM-based products using inexpensive CAT5e type cable.

The two QM input ports each support non-interlaced RGB up to 1600 x 1200 pixels, as well as composite, S-video and component video signals. QM input #1 includes software adjustable compensation for cable runs up to 450 feet; input #2 supports up to 300 feet for video and HDTV and shorter distances for RGB computer signals. Both QM inputs receive audio signals from external microphone and stereo line level sources.

High-resolution RGB graphics and 24-bit digital audio are output from the internal PC and microphone via the QM output port for audience presentation and intercom purposes.

4 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Connectivity and Expansion

Both Cresnet and high-speed Ethernet are standard on the TPMC-15/17-L, providing for seamless communications with Crestron control systems, computers, digital media servers and other IP based devices. WiFi wireless networking and memory expansion are easily added through two PC card slots and two USB ports enable the connection of an external mouse and keyboard (not included), as well as CD ROM drives and memory devices.

NOTE: Contact Crestron for a current list of compatible devices and embedded applications. To ensure reliable performance, new device drivers and applications are available only from Crestron through firmware updates.

Cresnet®

Cresnet is the communications backbone for many Crestron touchpanels, keypads, lighting controls and other devices. The Cresnet bus is a simple, yet flexible 4-wire network that provides rock-solid bidirectional communication and power for up to 252 Cresnet devices.

Memory

The TPMC-15/17-L touchpanels feature 512 MB SDRAM and 512 MB Flash, with an external card slot that allows flash memory expansion.

Versatile Flush Mount Design

The TPMC-15/17-L is designed for flush-mount installation in a wall, lectern or similar flat surface. A variety of mounting accessories is offered including optional back box and 19” rack mount kit. Five backlit pushbuttons are also provided, allowing for quick access to commonly used functions such as volume, home and reset.

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 5

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

Applications

The TPMC-15-CH-L and TPMC-17-CH-L are integral to managing a residential audio/video distribution system. With built-in audio and video connectivity as well as Ethernet communications, the touchpanel can be used to control complex audio/video systems.

The following diagram shows a TPMC-15-CH-L in a residential audio/video distribution application.

TPMC-15-CH-L in Residential Audio/Video Distribution Application

The TPMC-15-QM-L and TPMC-17-QM-L are part of the Crestron MediaManager line of integrated presentation solutions. It is ideally suited to work with Crestron’s MediaManager wall plate media centers, FlipTop media centers, receivers and control processors to allow quick switching of multiple A/V sources in a presentation system. MediaManager devices are designed for conference room, auditorium and lecture hall applications or anywhere else where audio, video or computer equipment needs to be easily connected and disconnected from a presentation system or room control system.

6 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

The following diagram shows a TPMC-15/17-QM-L in a lecture hall application.

TPMC-15/17-QM-L in Lecture Hall Application

For more information on this and other QM applications, refer to the latest revision of the Crestron MediaManager Applications Guide (Doc. 6244), which is available from the Crestron website (www.crestron.com/manuals

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 7

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

Internal Block Diagram

The following diagrams represent the switching abilities of the TPMC-15/17-L. The diagrams depict the video, audio and connectivity paths available.

TPMC-15/17-CH-L Functional Diagram

TPMC-15/17-QM-L Functional Diagram

Up to 450 ft

From QuickMedia Transmitter

Up to 300 ft (~20 ft. for RGB)

From QuickMedia Transmitter

Built-In Microphone

QM IN 1

QM IN 2

Video/RGB

Audio

Video/RGB

Audio

2X1 Switcher

Skew/Bandwidth

Compensation

Graphics Engine

Embedded PC

Scaler

Annotator

Audio Mixer

Program

Mics

Touchpanel Display

Volume/Tone

Audio

RGB

QM OUT

MIC

Audio

Up to 450 ft

To QuickMedia Transmitter

Built-in Speakers

Headphone Jack

8 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Specifications

Specifications for the TPMC-15/17-L are listed in the following table.

TPMC-15/17-L Specifications

SPECIFICATION DETAILS

Touchscreen Display

Display Type TFT active matrix color LCD

Size

Aspect Ratio

Resolution

Brightness

Contrast

Color Depth 24-bit, 16.7M colors

Illumination Backlit fluorescent

Viewing Angle

Touchscreen Resistive membrane

Processor VIA Eden™ 667 MHz CPU

Memory

SDRAM 512 MB

Flash

PC Card

Maximum Project Size 190MB

Operating System Microsoft® Windows® XP Embedded

Graphic Engine

Embedded Software Applications3

TPMC-15-L: 15 inch (38.1 cm) diagonal TPMC-17-L: 17 inch (43.2 cm) diagonal

TPMC-15-L: 4:3 XGA TPMC-17-L: 15:9 WXGA

TPMC-15-L: 1024 x 768 pixels TPMC-17-L: 1280 x 768 pixels

TPMC-15-L: 400 nits TPMC-15-L: 350 nits1 TPMC-17-L: 450 nits

TPMC-15-L: 300:1 TPMC-15-L: 700:11 TPMC-17-L: 400:1

TPMC-15-L: ±85º horizontal and vertical TPMC-17-L: ±88º horizontal and vertical

512 MB internal flash memory, expandable via rear panel PC card slots

Accepts up to (2) 4 GB Type II PC Cards (not included)

Isys i/O engine, VIA Unichrome™ CLE266 chipset, 24 bit non-palette graphics + 8 bit alpha channel translucency, 16.7 million colors, Synapse image rendering algorithm, multi-mode objects, dynamic menu objects, dynamic graphics full-motion (60 fps) animation, transition effects, color key windowing.

Microsoft Internet Explorer w/Macromedia® Flash® plug-in, Windows Media® Player, RealPlayer®, Axis® Media Control, Crestron MediaMarker™, Remote Desktop, NetMeeting®, Skype™4, VNC Viewer5, Java™ Runtime, DirectX®, Crestron MJPEG Viewer and Axis ActiveX® control, Adobe® Acrobat® Reader, WordPad, plus viewers for MS Word, Excel and PowerPoint®6.

, PNG translucency,

(Continued on following page)

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 9

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

TPMC-15/17-L Specifications (Continued)

SPECIFICATION DETAILS

Ethernet

Wireless3

Video (CH7 and QM8 versions combined)

Signal Types

Formats

Color Depth 24-bit, 16.7M colors

Features

Streaming/File Formats

Audio (CH and QM8 versions combined)

Hardware Features

Streaming/File Formats

Audio Feedback (WAV)

D-A / A-D Conversion (via QM only)

Amplification

Power Requirements

Overall 8.4 Amps @ 12.5 Volts DC

External Power Supply (included)

Cresnet Power Usage Does not draw power from Cresnet

Default Net ID9 03

Control System Update Files

2-Series Control System

Environmental

Temperature 50° to 113°F (10° to 45°C)

Humidity 10% to 90% RH (non-condensing)

10, 11

10BaseT/100BaseTX, auto negotiating, auto discovery, full/half duplex TCP/IP, UDP/IP, CIP, DHCP, IEEE 802.3U compliant

Wireless Ethernet capable using third-party

802.11 PC card; (Wired connections required for power, audio, video and RGB)

RGB (QM only) and auto-detecting composite, S-video or component video

SDTV 480i (NTSC) & 576i (PAL), EDTV 480p & 576p, HDTV 720p & 1080i; RGB (VGA) (QM only) up to UXGA 1600 x 1200

Dual-window each scalable to full screen, time base correction, gamma correction, line doubling, motion adaptive deinterlacing, reverse 3:2/2:2 pulldown

MPEG4, MJPEG via Axis Media Control plus all formats supported by the embedded media player applications

Built-in microphone and biamplified speakers, stereo headphone output, internal volume control and audio mixer

All formats supported by the embedded media player applications

8 & 16 bit PCM, mono & stereo, 8 – 44 kHz sampling rates

Burr Brown 24-bit, 48 kHz

Biamplified, mono, 5 Watts for highfrequency, 5 Watts for low-frequency

2.2 Amps @ 100-250 Volts AC, 50/60 Hz

Version 3.137 or later

(Continued on following page)

10 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

TPMC-15/17-L Specifications (Continued)

SPECIFICATION DETAILS

Enclosure

Construction

Front Bezel

Dimensions

Height

Width

Depth

Weight

Available Models

TPMC-15-CH-LB

TPMC-15-CH-LW

TPMC-15-QM-LB

TPMC-15-QM-LW

TPMC-17-CH-LB

TPMC-17-CH-LW

TPMC-17-QM-LB

TPMC-17-QM-LW

Included Accessories

TPMC-CH-IMC12 CAT5 Balanced AV Interface Module

TPMC-L-IMC Power Interface Module

PW-1280RU Power Supply

TPMC-15-L: Metal, flush mountable, 8U 19” rack-mountable TPMC-17-L: Metal, flush mountable, 9U 19” rack-mountable

Injection molded plastic; black w/silver accent or white w/gray accent

TPMC-15-L: 13.59 in (34.52 cm) TPMC-17-L: 13.81 in (35.06 cm)

TPMC-15-L: 14.17 in (35.99 cm) TPMC-17-L: 16.98 in (43.11 cm)

TPMC-15-L: 3.80 in (9.66 cm) TPMC-17-L: 3.84 in (9.74 cm)

TPMC-15-L: 10 lbs (4.50 kg) TPMC-17-L: 13.4 lbs (6.10 kg)

Isys i/O 15” Wall Mount Touchpanel Media Center with Crestron Home CAT5 AV, Black

Isys i/O 15” Wall Mount Touchpanel Media Center with Crestron Home CAT5 AV, White

Isys i/O 15” Wall Mount Touchpanel Media Center with QuickMedia Transport Technology, Black

Isys i/O 15” Wall Mount Touchpanel Media Center with QuickMedia Transport Technology, White

Isys i/O 17” Wall Mount Touchpanel Media Center with Crestron Home CAT5 AV, Black

Isys i/O 17” Wall Mount Touchpanel Media Center with Crestron Home CAT5 AV, White

Isys i/O 17” Wall Mount Touchpanel Media Center with QuickMedia Transport Technology, Black

Isys i/O 17” Wall Mount Touchpanel Media Center with QuickMedia Transport Technology, White

(Continued on following page)

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 11

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

TPMC-15/17-L Specifications (Continued)

SPECIFICATION DETAILS

Available Accessories

BB-15L/17L Pre-Construction Wall Mount Back Box

PMK-15L/17L Pre-Construction Wall Mount Kit

TMK-15L/17L Trim Ring

MMK-15L/17L Mud Ring

WMKT-15L/17L

WMKM-15L

RMK-15L/17L Rack Mount Kit

TPMC-CH-IMW12 CAT5 Balanced AV Interface Wall Plate

QM-TX13 QuickMedia Transmitter

TPS/TPMC-CBL-T Triamese Interface Cables

CresCAT®Q12 Crestron Home CAT5 AV Cable

CresCAT QM13 QuickMedia Cable

CresCAT IM13 iMedia cable

1. Applies to part numbers 6500224 and 6501305 (in CH series) and 6500223 and 6501304 (in QM series) only.

2. By design, the panel will not load dynamic graphics if they are located on a password protected FTP or HTTP server.

3. Contact Crestron for a current list of compatible devices and embedded applications. To ensure reliable performance, new device drivers and applications are available only from Crestron through firmware updates.

4. The default minimum window size for Skype™ can not be overridden.

5. The supported VNC viewer is UltraVNC version 1.0.2. Other VNC viewers may work but are not guaranteed.

6. MS Office viewers are version 2003.

7. Additional CAT5 balanced AV equipment is required to facilitate the input of more than one external video signal.

8. One or more QuickMedia devices are required to facilitate the input and output of audio, video, and RGB signals.

9. Refer to “Identity Code” on page 25 for details.

10. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following these footnotes.

11. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product Catalog for a complete list of 2-Series control systems.

12. CH series only.

13. QM series only.

Lectern or Post-Construction Wall Mount Kit with Trim Ring

Post-Construction Wall Mount Kit with Mud Ring

NOTE: Crestron software and any files on the website are for Authorized Crestron dealers and Crestron Authorized Independent Programmers (CAIP) only. New users may be required to register to obtain access to certain areas of the site (including the FTP site).

12 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Physical Description

This section provides information on the connections, controls and indicators available on your TPMC-15/17-L.

TPMC-15-QM-L Physical View

TPMC-17-CH-L Physical View

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 13

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

TPMC-15-QM-L Overall Dimensions (Front, Bottom and Side Views)

14.17 in

(35.99 cm)

13.59 in

(34.52 cm)

0.58 in

(1.46 cm)

2.09 in

(5.31 cm)

3.80 in

(9.66 cm)

12.59 in

(31.98 cm)

13.26 in

(33.69 cm)

14 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

TPMC-17-QM-L Overall Dimensions (Front, Bottom and Side Views)

16.98 in

(43.11 cm)

16.07 in

(40.81 cm)

13.81 in

(35.06 cm)

0.61 in

(1.54 cm)

2.09 in

(5.31 cm)

3.84 in

(9.74 cm)

12.80 in

(32.51 cm)

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 15

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

TPMC-15/17-L Connectors (QM Version)

2 3 4 5 6

NOTE: Connectors on the TPMC-15/17-L CH version are identical to those on the QM version except for item number 9 above. The CH version, has Video IN and

Audio I/O ports instead of the QM IN and QM OUT ports.

NOTE: All connections to the TPS-15/17-L are made through the ports on the rear

panel. These ports are not accessible after the touchpanel is mounted in a wall or in a lectern.

Connectors, Controls & Indicators

CONNECTORS

CONTROLS &

INDICATORS

RS-232

(1) 6-pin RJ-11 female, computer console port; Bidirectional RS-232 up to 115.2k baud; Hardware and software handshaking support

PIN # DESCRIPTION

1 CTS

2 GND

3 RXD

4 TXD

5 RTS

6 N/C (Not connected)

DESCRIPTION

(Continued on following page)

16 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Connectors, Controls & Indicators (Continued)

CONNECTORS

CONTROLS &

INDICATORS

DESCRIPTION

RS-232

(Continued)

In the event that modular cables or an RJ-11 to DB9F adapter is not available, the following diagram provides information so that the cable can be fabricated on site. (Alternatively, Crestron cable number STCP-502PC is sold separately.)

GREEN LED

LAN

YELLOW LED

TO RS-232

PORT

Part #

641337

(1) 8-wire RJ-45 with two LED indicators; 10BaseT/100BaseTX Ethernet port;

Part #

AWC10152-A

COM PORT

CTS

GND RXD

TXD

RTS n/c

TO PC

1 2 3

7 8

Part #

748047-1

Green LED indicates link status;

PIN 1

Yellow LED indicates Ethernet activity.

PIN SIGNAL PIN SIGNAL

1 TX + 5 N/C 2 TX - 6 RC 3 RC+ 7 N/C 4 N/C 8 N/C

(1) 6-32 screw, chassis ground lug.

USB2

(2) USB Type A female, USB 1.1 ports for mouse, keyboard and storage devices.3

Pins 1 2 3 4

PIN DESCRIPTION

1 +5 VDC

2 Data -

3 Data +

4 Ground

PWR

(1) 4-pin DC power jack, 12.5V DC power input (external power supply included).

HEADPHONES

(1) 3.5 mm TRS mini phone jack; Output power: 105 mW per channel; Minimum impedance: 8 Ω.

PC CARD A - B

(2) Type II PC Card slots for memory expansion, project upload and wireless NIC.

(Continued on following page)

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 17

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

Connectors, Controls & Indicators (Continued)

CONNECTORS

CONTROLS &

INDICATORS

DESCRIPTION

NET

VIDEO IN 1 – 2

AUDIO I/O

Four-position terminal block connector for data and power. Connects to Cresnet control network.

Pin 1 (24) Power

4, 5

Pin 2 (Y) Data Pin 3 (Z) Data Pin 4 (G) Ground

(2) 8-wire RJ-45 female, CAT5 balanced video input port; Signal types: Auto-detecting component (YPbPr), S-video (Y/C) or composite video; Formats: SDTV 480i, (NTSC) & 576i (PAL), EDTV 480p & 576p, HDTV 720p & 1080i; Input impedance: 100 Ω balanced; Connects to any Crestron CAT5 balanced video source(s) or TPS/TPMC-CH-IMC Interface Module (included) via CresCAT cable or TPS/TPMC-CBL-T “triamese” cable (sold separately); Maximum cable length: 500 feet (component/HDTV), 750 feet (S-video or composite).

4, 6

(1) 8-wire RJ-45 female, bidirectional CAT5 balanced audio port; Signal types: receives (1) balanced stereo audio signal and transmits (1) balanced stereo audio signal from internal PC or microphone (dynamically selectable); Maximum input level: 4 V Maximum output level: 2 V

rms

;

; Input/output impedance: 600 Ω; Connects to any other Crestron CAT5 balanced audio port or TPMC-CH-IMC Interface Module (included) via CresCAT cable or TPS/TPMC-CBL-T “triamese” cable (sold separately); Maximum cable length: 1000 feet.

(Continued on following page)

18 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

Connectors, Controls & Indicators (Continued)

CONNECTORS

CONTROLS &

INDICATORS

QM OUT 1

QM IN 1 & 2

(1 each) 8-wire RJ-45 female, QuickMedia input port; Signal types: Dynamically configurable under system control as:

• One RGB (VGA) input with stereo

• One auto-detecting component

RGB format: RGBHV; RGB input resolution, non-interlaced: 640 x 480 minimum to 1600 x 1200 maximum (60 Hz limit at 1600 x 1200); Video/HDTV formats: 480i (NTSC), 576i (PAL), 480p, 576p, 720p and 1080i; Horizontal frequency: 15 - 100 kHz; Vertical frequency: 50 - 85 Hz; Delay skew compensation: 0 - 22 ns (QM IN 1 only, none on QM IN 2); Connects to QM output port of a QM-TX or other QuickMedia device (sold separately) via CresCAT-QM or CresCAT-IM cable; Maximum cable length: QM IN 1: 450 feet (aggregate distance from QM origination); QM IN 2: (Video/HDTV) 300 feet (aggregate distance from QM origination); (RGB @ 60 Hz) 216 feet for 640 x 480, 140 feet for 800 x 600, 84 feet for 1024 x 768, 70 feet for 1280 x 1024, 30 feet for 1600 x 1200 (using CresCAT-QM or CresCAT-IM cable)

(1) 8-wire RJ-45 female, QuickMedia output port containing RGB output with stereo audio from internal PC and two discrete channels from internal mic; RGB format: RGBHV; RGB output resolution, non-interlaced: 1024 x 768 pixels @ 60 Hz; Connects to QM input port of any QuickMedia device via CresCAT-QM or CresCAT-IM cable

DESCRIPTION

program audio and two mic channels or

(YP

), S-video (Y/C) or composite

bPr

video input with stereo program audio and two mic channels

(Continued on following page)

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 19

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

Connectors, Controls & Indicators (Continued)

CONNECTORS

CONTROLS &

INDICATORS

DESCRIPTION

PWR IN

(2) 2-pin detachable terminal blocks, paralleled; Used to extend power cabling up to 60 feet using 4 conductor, 14 AWG wire connected to a TPMC-L-IMC power interface module (included) at remote power supply location.

PWR OUT

(1) 4-pin DC power jack; Connects to PWR jack using 9-inch 4-pin DC power patch cable (included) when locating

UNDER & OVER

VOLTAGE LEDs

13 BUTTONS8

power supply remotely; passes 12.5 VDC power from PWR IN terminal blocks.

Indicate under or over voltage condition (refer to page 60 for details).

(4) Backlit “softkey” buttons, programmable (1) Backlit hard reset button, reboots the touchpanel

1. An interface connector for the NET port is provided with the unit.

2. Only generic USB devices (i.e. simple keyboard, mouse and external storage) should be used. Any complex USB devices (e.g. a storage device with a built-in fingerprint scanner) will not have the proper support on the panel.

3. Only standard Windows maximum length for a USB cable run is 16.4 feet (5.0 meters).

4. Use only the TPMC-CH-IMC Interface Module when connecting this port. Use of other “IMC” products could damage the panel.

5. This eight-pin RJ-45 port provides connectivity to the CNX-PVID or the TPMC-CH-IMC Interface Module. This port provides component, composite or S-video balanced input to the touchpanel over CAT5 wiring. Refer to the following table for connector pinouts.

1 WHITE/ORANGE WHITE/GREEN + Composite + Luminance + Y

2 ORANGE GREEN - Composite - Luminance - Y

3 WHITE/GREEN WHITE/ORANGE N/A + Chrominance + Pb

4 BLUE BLUE N/A N/A + Pr

5 WHITE/BLUE WHITE/BLUE N/A N/A - Pr

6 GREEN ORANGE N/A - Chrominance - Pb

7 WHITE/BROWN WHITE/BROWN N/A N/A N/A

8 BROWN BROWN N/A N/A N/A

6. This eight-pin RJ-45 port provides connectivity to the CNX-BIPAD or the TPMC-CH-IMC Interface

PIN WIRE COLORS (568B)

1 WHITE/ORANGE

2 ORANGE

3 WHITE/GREEN

4 BLUE

5 WHITE/BLUE

6 GREEN

7 WHITE/BROWN

8 BROWN

WIRE COLORS

(568B)

Module. This port uses CAT5 wiring and provides audio input to the touchpanel and output from the touchpanel’s built-in microphone. Refer to the following table for connector pinouts.

XP embedded drivers are included. You cannot load your own driver. The

WIRE COLORS

(568A)

WIRE COLORS

WHITE/GREEN

GREEN

WHITE/ORANGE

BLUE

WHITE/BLUE

ORANGE

WHITE/BROWN

BROWN

Composite S-Video Component

(568A)

Audio i/O

+ Mic Left Out

- Mic Left Out

+ Mic Right Out

+ Audio Left In

- Audio Left In

- Mic Right Out

+ Audio Right In

- Audio Right In

20 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

7. The eight-pin RJ-45 QuickMedia transport port accepts CAT5E/CAT6 carrying audio, video and microphone signals. The QM input port conforms to the 568B wiring standard. Refer to the following table for connector pinouts.

RJ-45 PIN

NUMBER

1 WHITE/ORANGE - RGB Red - CHROMINANCE (- Pr)

2 ORANGE + RGB Red + CHROMINANCE (+ Pr)

3 WHITE/GREEN - RGB Green - LUMINANCE (- Y)

4 BLUE + Digital Audio + AUDIO

5 WHITE/BLUE - Digital Audio - AUDIO

6 GREEN + RGB Green + LUMINANCE (+ Y)

7 WHITE/BROWN - RGB Blue - COMPOSITE (- Pb)

8 BROWN + RGB Blue + COMPOSITE (+ Pb)

8. Refer to “Hard Button Programming” on page 67 for details.

WIRE COLORS

(EIA 568B)

ASSIGNMENT:

RGB

QM ASSIGNMENT

COMPOSITE,

S-VIDEO, COMPONENT AND

AUDIO

Industry Compliance

As of the date of manufacture, the TPMC-15/17-L has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling.

NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 21

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

Setup

Network Wiring

When wiring the network, consider the following:

• Use Crestron Certified Wire.

• Use Crestron power supplies for Crestron equipment.

• Provide sufficient power to the system.

CAUTION: Insufficient power can lead to unpredictable results or damage to the equipment. Please use the Crestron Power Calculator to help calculate how much power is needed for the system (www.crestron.com/calculators

• For larger networks, use a Cresnet Hub/Repeater (CNXHUB) to maintain signal quality.

For more details, refer to “Check Network Wiring” on page 78.

Ethernet

The TPMC-15/17-L also uses high-speed Ethernet for communications between the device and a control system, computer, digital media server and other IP-based devices.

For information on connecting Ethernet devices in a Crestron system, refer to the latest version of the Crestron e-Control



Reference Guide (Doc. 6052).

CAT5 Wiring (CH versions only)

Category 5 (CAT5) wiring is a twisted pair cable designed for Ethernet networks. These networks operate at speeds of up to 100 Megabits per second (Mbps) using the 100BaseT standard. Crestron takes advantage of this specification for a variety of audio and video applications.

Crestron recommends using CresCAT-IM (or D) wire for transmitting video signals from the CH port.

When using a Creston wiring solution, the CresCAT-IM (or D) wire can carry audio and video signals up to 500 feet (observe distance limitations based upon power consumption for the device in use).

For more information, refer to the latest version of the Crestron CAT5 Wiring Reference Guide (Doc. 6137).

QuickMedia Wiring (QM versions only)

The Crestron QuickMedia cable (sold under the name “CresCAT-QM”) contains one CAT5E cable and one Cresnet cable in Siamese jackets. Installation of any QM device is as simple as installing CresCAT-QM wires from the output of one device to the input of another. Installations are flexible, affordable and fast. For more information, refer to the latest revision of the Crestron MediaManager Applications Guide (Doc. 6244).

22 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

Crestron Isys i/O™ TPMC-15/17-L Series Touchpanel Media Centers

CresCAT-QM Cable

CresCAT-QM

Cable

NOTE: Do not untwist the two wires in a single pair for more than 1/3-1/2” (0.84-1.27 cm) when making a connection. The twists are critical to canceling out interference between the wires.

The aggregate cable length of a signal path originating at a QM transmitter and terminating at the TPMC-15/17-L must not exceed 450 feet (137 meters). Video signals may experience a loss of quality over very long lengths of cable. This phenomenon is due to the added resistance and capacitance of longer cable lengths and is not peculiar to either Crestron and/or QuickMedia systems. To ensure sufficient bandwidth, the maximum aggregate cable length should not exceed 450 feet. The use of lower-resolution signals may allow increased cable length but must be tested by the installer with the sources to be used. The QM pin assignment is based on the EIA/TIA 568B RJ-45 Jack standard.

NOTE: QM IN 2 does not have delay skew compensation (as does QM IN 1), so the maximum cable length varies based upon resolution and should not exceed 300 feet (90 meters) for standard definition video. Refer to the QM Input #2 Maximum Cable Length table that follows.

QM Input # 2 Maximum Cable Length

SIGNAL TYPE RESOLUTION MAXIMUM CABLE

LENGTH* (FEET)

Video/S-video 480i 300

Component 480p 300 Component 720p 300 Component 1080i 300

RGB 1024 x 768 @ 75 Hz 69 RGB 1280 x 1024 @ 75 Hz 40 RGB 1600 x 1200 @ 60 Hz 30 RGB 640 x 480 @ 60 Hz 216 RGB 800 x 600 @ 60Hz 140 RGB 1024 x 768 @ 60Hz 84 RGB 1280 x 768 @ 60Hz 70

* With CresCAT-QM cable, available from Crestron. Using other may adversely affect performance and

is not recommended.

Operations Guide – DOC. 6354B Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series • 23

Touchpanel Media Centers Crestron Isys i/O™ TPMC-15/17-L Series

NOTE: When transmitting S-video, luminance uses the green video pathway and chrominance uses the red video pathway. When transmitting composite video, the signal is carried on the blue video pathway.

NOTE: When using CresCAT-QM wiring, four additional wires are included for making Cresnet connections.

When connecting multiple QM devices, the route between a QM origination point (transmitter) and a QM endpoint (receiver) cannot have more than two midpoints (e.g. QM-MD7x2 or other QM switchers). Refer to the following diagram when configuring a QM network.

NOTE: The aggregate length from transmitter to receiver cannot have a delay skew of more than 22 ns.

QM Network Topology

Origination Points Endpoints

Midpoints

QM-TX

QM-FTDC

QM-WMC

QM-MD7x2QM-MD7x2

The TPMC-15/17-QM-L is not a switcher, but a transmitter/endpoint. Therefore, even when designated as the endpoint from two midpoint switchers, the QM output of the TPMC-15/17-QM-L can become another transmitter sending RGB video at the touchpanel’s native resolution and aspect ratio. Refer to the following diagram.

QM Network Topology with TPMC-15/17-QM-L Acting as an Endpoint and a Transmitter

Origination Points

QM-WMC

Midpoints

TPMC-15/17-QM-L

This TPMC-15/17-QM-L acts as both an endpoint for signals from the QM-WMC origination points AND a QM transmitter to the QM-RMCRX-BA.

TPMC-15/17-QM-L

Endpoints

QM-RMCRX-BAQM-MD7x2 QM-MD7x2

This QM-RMCRX-BA does not violate the two-midpoint rule as it is receiving an RGB signal from the TPMC-15/17-QM-L transmitter.

24 • Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17-L Series Operations Guide – DOC. 6354B

+ 64 hidden pages

Crestron TPMC-17-QM-L Operating Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction Introduction

Features and Functions

Applications

Internal Block Diagram

Specifications

Physical Description

Industry Compliance

Setup

Network Wiring

Ethernet

CAT5 Wiring (CH versions only)

QuickMedia Wiring (QM versions only)
