Introduction

Functions and Features

The Crestron rechargeable battery pack, ST-BTPN, is designed to supply
power to Crestron ST and STX Series (1550C and 1700C) wireless
touchpanels. The ST-BTPN offers the touchpanel user the freedom to
roam without being confined to a stationary power source (i.e., external
battery pack or docking station). The ST-BTPN can be charged when it is
mounted on the ST-DSN docking station. The ST-BTPN can also be
charged when mounted on the older ST-DS docking station.

NOTE: For related information on the docking stations, consult the ST­DSN and ST-DS Operations Guides (Doc. 6095 and Doc. 5738,
respectively) The latest versions of the guides can be obtained from the
Downloads | Product Manuals section of the Crestron website

(www.crestron.com)

Functional Summary

• Powers wireless touchpanels

• Unique design allows it to be installed only one way

• Fast charging Nickel Metal Hydride battery

.

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN • 1

Rechargeable Battery Pack Crestron ST-BTPN

NOTE: For related information on the wireless touchpanels, consult the
latest version of the ST-1550C Operations Guide (Doc. 6096), the STX­1550C and STX-1550CW Operations Guides (Doc. 5812 and Doc. 5849,
respectively), the ST-1700C Operations Guide (Doc. 6051) and the STX­1700C and STX-1700CW Operations Guides (Doc. 6049 and Doc. 6103,
respectively). The latest versions of the guides which includes their
respective international versions are available from the Downloads |
Product Manuals section of the Crestron website (www.crestron.com)

.

Specifications

The following table provides specifications for the ST-BTPN.

Specifications for the ST-BTPN

SPECIFICATION DETAILS

Output Voltage
Capacity 4.1 Ah, typical

Composition
Estimated Operating Time* Up to 5 hours of continuous use (20-22 hours in

Estimated life 500 charge/discharge cycles (min.)
Optimal Operating Temperature

4.8 VDC

Nickel Metal Hydride (NiMH)

standby)

o

Approximately 50

F to 104oF (10oC to 40oC)

Optimal Storage Temperature

Charging Temperature

Approximately -4oF to 113oF (-20oC to 45oC)

o

Approximately 50

F to 95oF (10oC to 35oC)

Weight 0.79 lb (0.36kg)

*Approximate battery operation for battery pack in touchpanels:

Worst case battery operation – 3.0 hours (STX -1700C at full backlight)

Best case battery operation – 4.3 hours (ST-1550 at full backlight)

Approximate battery charge times in touchpanels:

Worst case charge time – 6 hours (STX-1700C at full backlight)

Best case charge time – 2.7 hours (All units with power off)

2 • Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

NOTE: The battery will not charge when above maximum charging
temperature. To cool the battery, either turn off power to the touchpanel
by pressing the power down button on the touchscreen (or use the power
down timeout), or remove the battery from the touchpanel (refer to
“Removal” on page 8). The battery can also be mounted on the docking
station to cool and then charge. The docking station begins charging the
battery once the battery has cooled.

Physical Description

The ST-BTPN (refer to illustrations below and on the next page) is
housed in a black plastic enclosure with its electrical contacts on the top
and bottom of the unit.

Physical View

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN • 3

Rechargeable Battery Pack Crestron ST-BTPN

Physical View (continued)

2.280 in

(5.791 cm)

1.159 in

(2.944 cm)

BOTTOM VIEW

CRESTRON

Crestron Electronics, Inc.

Rockleigh, NJ 07647

Rechargeable

Power Pack

ST-BTPN

4.083 in

(10.371 cm)

4.245 in

(10.782 cm)

TOP VIEW

Z A 1 1 6 5 5

CRESTRON

ZA11655

ST-BTPN

C000000

EXTERNAL

FACE

INTERNAL

FAC E

RECHARGEABLE NICKEL

METAL HYDROXIDE BATTERY

MUST BE RECYCLED OR

DISPOSED OF PROPERLY

1

.

8

0

0

R

E

.

8

C

2

Y

2

C

.

L

8

E

8

3

7

Industry Compliance

As of the date of manufacture, the ST-BTPN has been tested and found to
comply with specifications for CE and C-Tick markings.

(N11785)

4 • Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

Handling

NOTE: The ST-BTPN contains a NiMH battery. When the unit can no
longer retain a charge, it must be recycled or disposed of properly. Refer
to the recycle label on the unit for disposal information.

To prevent short-circuiting, use care when handling the ST-BTPN.
NiMH cells have extremely low internal resistance and will discharge at
high current levels when shorted. As a result, the high temperatures can
damage the rechargeable battery pack and may cause personal injury.
Avoid accidental shorting from uninsulated workbenches, tools,
bracelets, rings, and coins.

Storage

The ST-BTPN can be stored in a temperate dry place (removed from the
touchpanel and docking station) indefinitely without significant
irreversible degradation in its performance. The self-discharge rate is a
function of temperature and internal resistance. High temperature storage
reduces charge retention. Best results occur if the ST-BTPN is stored at

an optimal temperature of 32° to 104°F (0° to 40°C). After an extended
storage, initiate a few charge/discharge cycles to restore full capacity.
Recharge the ST-BTPN after storage prior to use.

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN • 5

Rechargeable Battery Pack Crestron ST-BTPN

Charging

NOTE: Typically, the battery pack is good for 500 charge/discharge
cycles.

To charge the ST-BTPN:

• Use the powered ST-DSN docking station with battery guide; or

• Install the ST-BTPN in a ST-1550C or 1700C and mount

touchpanel on a powered ST-DSN docking station.

CAUTION: Internal damage to battery pack may occur if it is mounted
by itself on the ST-DSN without the battery guide.

NOTE: The battery pack may take up to 6 hours to charge in a powered
touchpanel. Refer to Specifications on page 2 for charging information.

For further information, consult the ST-DSN Operations Guide (Doc.

6095). The latest version of the guide is available from the Downloads |
Product Manuals section of the Crestron website (www.crestron.com)

Installation

The unique design of the ST-BTPN prevents it from being installed
improperly. The rechargeable battery pack fits only one way in the
battery compartment of the touchpanel.

Although the ST-BTPN can be installed in several Crestron wireless
touchpanel models, the ST-1700C and STX-1700C are the most common
models to use the battery pack. These models have the same shape and
battery compartment location. Therefore, as an example, the illustration
on the next page shows the ST-BTPN properly seated in the ST-1700C.
Complete the steps on the next page to install the battery.

.

6 • Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

ST-BTPN installed in a touchpanel (ST-1700C)

CRESTRON

Crestron Electronics, Inc.

Rockleigh, NJ 07647

FCC ID: EROST-1700C SEE MANUAL

NOTE: The ST-BTPN is shipped fully discharged. Charge the battery
pack in a well-ventilated area away from sparks, flames, or smoking.

1. Place touchpanel screen-side down on a clean and soft surface.

2. Place the designated end of the ST-BTPN into the touchpanel

battery compartment. Refer to illustration on next page.

3. Slowly rotate ST-BTPN in compartment so that external face is

visible.

4. Verify proper installation with audible click of rechargeable

battery pack into battery compartment. Touchpanel latch
secures the ST-BTPN and prevents the battery pack from
falling out.

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN • 7

Rechargeable Battery Pack Crestron ST-BTPN

ST-BTPN Orientation for Installation

Touchpanel latch

This side facing out

fits into this cutout

CRESTRON

Crestron Electronics, Inc.

Rockleigh, NJ 07647

Insert this end

of ST-BTPN in

touchpanel first

Removal

Complete the following steps to remove the ST-BTPN from a
touchpanel.

1. Place touchpanel screen-side down on a clean and soft surface.

2. Lift latch up so that one edge of ST-BTPN pops out of

touchpanel battery compartment.

3. Rotate battery pack out and remove.

8 • Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

Further Inquiries

If after reviewing this Operations and Installation Guide, you cannot
locate specific information or have questions, please take advantage of
Crestron's award winning customer service team by calling:

• In the US and Canada, call Crestron’s corporate headquarters at

1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400.

• In Europe, call Crestron International at [phone].

• In Asia, call Crestron Asia at [phone].

• In Latin America, call Crestron Latin America at

[phone].

• In Australia and New Zealand, call Creston Pacific at

[phone]

Future Updates

As Crestron improves functions, adds new features, and extends the
capabilities of the ST-BTPN, additional information may be made
available as manual updates. These updates are solely electronic and
serve as intermediary supplements prior to the release of a complete
technical documentation revision.

Check the Crestron website (www.crestron.com
update availability and its subjective value. Updates are available from
the Download | Product Manuals section and are identified as an
“Addendum” in the Download column.

) periodically for manual

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN • 9

Rechargeable Battery Pack Crestron ST-BTPN

Return and Warranty Policies

Merchandise Returns / Repair Service

1. No merchandise may be returned for credit, exchange, or service without prior

authorization from CRESTRON. To obtain warranty service for CRESTRON products,
contact the factory and request an RMA (Return Merchandise Authorization) number.
Enclose a note specifying the nature of the problem, name and phone number of contact
person, RMA number, and return address.

2. Products may be returned for credit, exchange, or service with a CRESTRON Return

Merchandise Authorization (RMA) number. Authorized returns must be shipped freight
prepaid to CRESTRON, Cresskill, N.J., or its authorized subsidiaries, with RMA number
clearly marked on the outside of all cartons. Shipments arriving freight collect or without
an RMA number shall be subject to refusal. CRESTRON reserves the right in its sole and
absolute discretion to charge a 15% restocking fee, plus shipping costs, on any products
returned with an RMA.

3. Return freight charges following repair of items under warranty shall be paid by

CRESTRON, shipping by standard ground carrier. In the event repairs are found to be
non-warranty, return freight costs shall be paid by the purchaser.

CRESTRON Limited Warranty

CRESTRON ELECTRONICS, Inc. warrants its products to be free from manufacturing defects in
materials and workmanship under normal use for a period of three (3) years from the date of
purchase from CRESTRON, with the following exceptions: disk drives and any other moving or
rotating mechanical parts, pan/tilt heads and power supplies are covered for a period of one (1)
year; touchscreen display and overlay components are covered for 90 days; batteries and
incandescent lamps are not covered.

This warranty extends to products purchased directly from CRESTRON or an authorized
CRESTRON dealer. Purchasers should inquire of the dealer regarding the nature and extent of the
dealer's warranty, if any.

CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in
any application other than that for which it was intended, or if it has been subjected to misuse,
accidental damage, modification, or improper installation procedures. Furthermore, this warranty
does not cover any product that has had the serial number altered, defaced, or removed.

This warranty shall be the sole and exclusive remedy to the original purchaser. In no event shall
CRESTRON be liable for incidental or consequential damages of any kind (property or economic
damages inclusive) arising from the sale or use of this equipment. CRESTRON is not liable for
any claim made by a third party or made by the purchaser for a third party.

CRESTRON shall, at its option, repair or replace any product found defective, without charge for
parts or labor. Repaired or replaced equipment and parts supplied under this warranty shall be
covered only by the unexpired portion of the warranty.

Except as expressly set forth in this warranty, CRESTRON makes no other warranties, expressed
or implied, nor authorizes any other party to offer any other party to offer any warranty, including
any implied warranties of merchantability or fitness for a particular purpose. Any implied
warranties that may be imposed by law are limited to the terms of this limited warranty. This
warranty statement supercedes all previous warranties.

Trademark Information

All brand names, product names, and trademarks are the sole property of their respective owners. Windows
is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP and WindowsNT/2000 are
trademarks of Microsoft Corporation.

10 • Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

This page intentionally left blank.

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN • 11

Crestron Electronics, Inc. Operations and Installation Guide – DOC. 6088

15 Volvo Drive Rockleigh, NJ 07647 06.02
Tel: 888.CRESTRON
Fax: [phone] Specifications subject to
www.crestron.com change without notice.
