Crestron SMK-8T Operating Manual

Crestron SMK-8T
Swivel Mount Kit for TPMC-8T
Installation Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names and trademarks are the property of their respective owners.

©2007 Crestron Electronics, Inc.

Crestron SMK-8T Swivel Mount Kit for TPMC-8T

Contents

Swivel Mount Kit for TPMC-8T: SMK-8T 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................ 1

Specifications ..............................................................................................................1

Physical Description.................................................................................................... 2

Setup .......................................................................................................................................... 3

Supplied Hardware...................................................................................................... 3

Installation................................................................................................................... 3

Contact Information and Updates.............................................................................................. 6

Further Inquiries..........................................................................................................6

Future Updates ............................................................................................................6

Return and Warranty Policies....................................................................................................7

Merchandise Returns / Repair Service ........................................................................7

CRESTRON Limited Warranty...................................................................................7

Installation Guide – DOC. 6573A Contents • i

Crestron SMK-8T Swivel Mount Kit for TPMC-8T

Swivel Mount Kit for TPMC-8T:
SMK-8T

Introduction

Features and Functions

• Designed for attachment to the Crestron TPMC-8T Isys i/O™

• Swivel mount increases security by reducing the chance of

theft, while improving viewing convenience

• Base rotates 330 degrees

• Mounts on the desktop, in a lectern or on a conference table

• Accommodates surface thicknesses from ¾ inch (1.91 cm)

minimum to 1 3/8 inches (3.50 cm) maximum, using the
hardware provided

• Cables route down through center of assembly, keeping cables
completely hidden from work surface

touchpanel

Specifications

Specifications for the SMK-8T are listed in the following table.

SMK-8T Specifications

SPECIFICATION DETAILS

Dimensions
Height 0.88 in (2.22 cm)
Width 4.50 in (11.43 cm)
Depth 6.38 in (16.20 cm)
Weight 14.7 oz (417 g)

Installation Guide – DOC. 6573A Swivel Mount Kit for TPMC-8T: SMK-8T • 1

Swivel Mount Kit for TPMC-8T Crestron SMK-8T

Physical Description

SMK-8T Overall Dimensions

4.50 in

(11.43 cm)

6.38 in

(16.20 cm)

0.88 in

(2.22 cm)

0.69 in

(1.76 cm)

2 • Swivel Mount Kit for TPMC-8T: SMK-8T Installation Guide – DOC. 6473A

Crestron SMK-8T Swivel Mount Kit for TPMC-8T

Setup

Supplied Hardware

The hardware supplied in the kit is listed in the following table.

Supplied Hardware for the SMK-8T (Swivel Mount Kit for TPMC-8T)*

DESCRIPTION PART NUMBER QUANTITY

Metal Plate 2004821 1
Screws
6-32 x ½ inch 2007240 4
8-32 x 5/8 inch 2007274 4
8-32 x 1 inch 2007276 4

* The SMK-8T Swivel Mount Kit includes a template for preparing the mounting

surface.

Installation

To attach the SMK-8T Swivel Mount Kit to the TPMC-8T touchpanel
and install the assembly on a suitable mounting surface, refer to the
follow procedures and the illustration on page 5.

1. Prepare the mounting surface using the template provided with the
kit. The center hole for the swivel assembly should be 2.5 inches
minimum, 2.6 inches maximum. Position the template so the edge
indicated as “front” aligns with the desired front position of the
touchpanel. Observe the dashed line indicating the front edge of
the touchpanel base to ensure the touchpanel will not overhang the
mounting surface.

2. If necessary, to prevent errors when reconnecting, label and
disconnect any cables connected to the touchpanel.

3. Refer to the illustration on page 5 and route the cables from the
interface box up through the metal plate, through the mounting
surface and through the swivel assembly, then through the hole in
the base of the touchpanel. Route the cables carefully to avoid
chafing.

Installation Guide – DOC. 6573A Swivel Mount Kit for TPMC-8T: SMK-8T • 3

Swivel Mount Kit for TPMC-8T Crestron SMK-8T

4. Being careful to avoid damage to the cables, attach the swivel
assembly to the base of the touchpanel, using the supplied four #6­32 x ½ inch screws A through the swivel assembly standoff posts
into the threaded holes in the touchpanel base. Make certain the
cables are not twisted or crimped and have sufficient slack at the
port connections before fully tightening screws.

5. Make certain tab B is positioned toward the front of the swivel
assembly and that it is directly opposite bent tab D. Place the
touchpanel and swivel mount assembly down on the mounting
surface.

6. Hold the metal plate in position under the mounting surface and
secure the assembly in place using the #8-32 screws E provided.
Use the 5/8 inch screws for surfaces ¾ inch to 1 1/8 inches thick.
Use the 1 inch screws for surfaces 1 1/8 – 1 3/8 inches thick. Use
screws C to adjust tension of the swivel assembly.

4 • Swivel Mount Kit for TPMC-8T: SMK-8T Installation Guide – DOC. 6473A

Crestron SMK-8T Swivel Mount Kit for TPMC-8T

SMK-8T Swivel Mount Kit Assembly Diagram

Swivel Mount

Assembly

A

Mounting Surface

B

C

D

Front

Metal Plate

E

Cables from Interface Box

Installation Guide – DOC. 6573A Swivel Mount Kit for TPMC-8T: SMK-8T • 5

Swivel Mount Kit for TPMC-8T Crestron SMK-8T

Contact Information and Updates

Further Inquiries

If you cannot locate specific information or have questions after
reviewing this guide, please take advantage of Crestron's award winning
customer service team by calling the Crestron corporate headquarters at
1-888-CRESTRON [1-888-273-7876]. For assistance in your local time
zone, refer to the Crestron website (http://www.crestron.com/offices
a listing of Crestron worldwide offices.

You can also log onto the online help section of the Crestron website
(http://www.crestron.com/onlinehelp
products. First-time users will need to establish a user account to fully
benefit from all available features.

) to ask questions about Crestron

) for

As of the date of manufacture, the SMK-8T has been tested and found to
comply with specifications for CE marking.

Future Updates

As Crestron improves functions, adds new features and extends the
capabilities of the SMK-8T, additional information may be made
available as manual updates. These updates are solely electronic and
serve as intermediary supplements prior to the release of a complete
technical documentation revision.

Check the Crestron website periodically for manual update availability
and its relevance. Updates are identified as an “Addendum” in the
Download column.

6 • Swivel Mount Kit for TPMC-8T: SMK-8T Installation Guide – DOC. 6473A

Crestron SMK-8T Swivel Mount Kit for TPMC-8T

Return and Warranty Policies

Merchandise Returns / Repair Service

1. No merchandise may be returned for credit, exchange or service without prior authorization
from CRESTRON. To obtain warranty service for CRESTRON products, contact an
authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory
and request an RMA (Return Merchandise Authorization) number. Enclose a note specifying
the nature of the problem, name and phone number of contact person, RMA number and
return address.

2. Products may be returned for credit, exchange or service with a CRESTRON Return
Merchandise Authorization (RMA) number. Authorized returns must be shipped freight
prepaid to CRESTRON, 6 Volvo Drive, Rockleigh, N.J. or its authorized subsidiaries, with
RMA number clearly marked on the outside of all cartons. Shipments arriving freight collect
or without an RMA number shall be subject to refusal. CRESTRON reserves the right in its
sole and absolute discretion to charge a 15% restocking fee plus shipping costs on any
products returned with an RMA.

3. Return freight charges following repair of items under warranty shall be paid by CRESTRON,
shipping by standard ground carrier. In the event repairs are found to be non-warranty, return
freight costs shall be paid by the purchaser.

CRESTRON Limited Warranty

CRESTRON ELECTRONICS, Inc. warrants its products to be free from manufacturing defects in materials
and workmanship under normal use for a period of three (3) years from the date of purchase from
CRESTRON, with the following exceptions: disk drives and any other moving or rotating mechanical
parts, pan/tilt heads and power supplies are covered for a period of one (1) year; touchscreen display and
overlay components are covered for 90 days; batteries and incandescent lamps are not covered.

This warranty extends to products purchased directly from CRESTRON or an authorized CRESTRON
dealer. Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if
any.

CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any
application other than that for which it was intended or if it has been subjected to misuse, accidental
damage, modification or improper installation procedures. Furthermore, this warranty does not cover any
product that has had the serial number altered, defaced or removed.

This warranty shall be the sole and exclusive remedy to the original purchaser. In no event shall
CRESTRON be liable for incidental or consequential damages of any kind (property or economic damages
inclusive) arising from the sale or use of this equipment. CRESTRON is not liable for any claim made by a
third party or made by the purchaser for a third party.

CRESTRON shall, at its option, repair or replace any product found defective, without charge for parts or
labor. Repaired or replaced equipment and parts supplied under this warranty shall be covered only by the
unexpired portion of the warranty.

Except as expressly set forth in this warranty, CRESTRON makes no other warranties, expressed or
implied, nor authorizes any other party to offer any warranty, including any implied warranties of
merchantability or fitness for a particular purpose. Any implied warranties that may be imposed by law are
limited to the terms of this limited warranty. This warranty statement supersedes all previous warranties.
