HD-CONV-USB-100
HD to USB Video Converter
> Converts DVI or HDMI® video to USB 3.0
> Plug-and-play compatible with Crestron RL® 2
> Also compatible with Google® Chromebox® for Meetings
> Enables use of non-USB HD cameras
> Captures uncompressed 720p or 1080p at 30 or 60 fps
> Near-zero latency
> Includes a USB 3.0 cable
> USB powered
[1]
The HD-CONV-USB-100 is a USB video converter designed for use with the
Crestron RL® 2 Group Collaboration System or Google® Chromebox® for
Meetings. Its purpose is to expand the types of cameras that can be used
with either system by providing a DVI or HDMI® camera input. A single-link
DVI input is provided on the HD-CONV-USB-100. HDMI input is enabled
using an HDMI-to-DVI adapter (sold separately).
The HD-CONV-USB-100 captures uncompressed 720p or 1080p HD video
at up to 60 frames per second and converts it pixel-for-pixel to USB 3.0 for
connection to the Crestron RL 2 codec or Chromebox. The converter and
camera are automatically detected upon connection, and no configuration
is required.
Please note that HDCP sources are not supported.
SPECIFICATIONS
Video
Input Signal Types: DVI, HDMI
Output Signal Types: USB 3.0
Input/Output Resolutions: 1280x720@30/60Hz (720p),
1920x1080@30/60Hz (1080p)
Output Color Space: YUV 4:2:2
Connectors
Input: (1) DVI-I female;
Single-link DVI input;
Supports HDMI via a CBL-HD-DVI interface cable (sold separately)
USB: (1) USB Type B female;
USB 3.0 device port;
3 ft (0.9 m) cable included
Indicators
Status: (1) Tri-color LED, indicates power, readiness, and operation status
® [1]
Power Requirements
USB powered
Dimensions
Height: 0.91 in (23 mm)
Width: 2.36 in (60 mm)
Depth: 3.54 in (90 mm)
Weight
5.6 oz (159 g)
crestron.com | 800.237.2041
HD-CONV-USB-100 HD to USB Video Converter
MODELS & ACCESSORIES
Available Models
HD-CONV-USB-100: HD to USB Video Converter
Available Accessories
CBL-HD-DVI: Crestron® Certified HDMI® to DVI Interface Cable
CBL-DVI: Crestron® Certified DVI-D Interface Cable
Notes:
1. Requires an appropriate adapter or interface cable to accommodate an HDMI input signal.
CBL-HD-DVI interface cables are available separately. HDCP copy-protected sources are not
supported.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please
contact the Crestron sales representative for your area. A list of sales representatives is available
online at www.crestron.com/salesreps or by calling 800-237-2041.
The specific patents that cover Crestron products are listed online at: patents.crestron.com.
Certain Crestron products contain open source software. For specific information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, and Crestron RL are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Google and Chromebox
are either trademarks or registered trademarks of Google Inc. in the United States and/or other
countries. HDMI is either a trademark or registered trademark of HDMI Licensing LLC in the
United States and/or other countries. Other trademarks, registered trademarks, and trade names
may be used in this document to refer to either the entities claiming the marks and names or their
products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron
is not responsible for errors in typography or photography. Specifications are subject to change
without notice. ©2016 Crestron Electronics, Inc.
HD-CONV-USB-100 — Rear, Top, & Front Views
Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647
Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903
www.crestron.com
All brand names, product names and trademarks are the property of their respective owners.
Specifications subject to change without notice. Revised 04/06/16
©2016 Crestron Electronics, Inc.
