HD-CONV-USB-100
LED OPERATION
DESCRIPTION
Solid red
Device is initializing.
Solid blue
USB 3.0 connection is active.
Blinking blue
Video is transferring
successfully.
HD to USB Converter
Installation Guide
Description
The HD-CONV-USB-100 captures non-HDCP video
and turns it into a DirectShow compatible stream via a
USB 3.0 connection.
Additional Resources
Visit the product page on the
Crestron website (www.crestron.com)
for additional information and the
latest rmware updates. Use a QR
reader application on your mobile
device to scan the QR image.
Hardware Hookup
Connect the HD-CONV-USB-100 as shown in the
following diagram.
HD Video
Source
USB 3.0
Video Device
HD-CONV-USB-100
NOTE: The HD-CONV-USB-100 can also accept
®
HDMI
video with an appropriate adapter (not
supplied).
NOTE: The HD-CONV-USB-100 requires a USB 3.0
connection to function.
USB 3.0DVI
LED Behavior
Once the device is connected and a video signal is
supplied, the LED on the HD-CONV-USB-100 lights as
shown in the following table.
