DM-TXRX-100-STR
Quick Start
The Crestron® DM-TXRX-100-STR provides a compact, high-definition
H.264 streaming transmitter or receiver for use with a DigitalMedia™
system or other application.
In the Box
1 DM-TXRX-100-STR, HD Streaming Transmitter/Receiver
Additional Items
1 Connector, 4-Pin (2003576)
1 Connector, 5-Pin (2003577)
1 Power Pack, 24 VDC 0.75 A, 100-240 VAC (2045865)
Install the Device
The DM-TXRX-100-STR can be mounted onto a flat surface or onto a
rack rail.
Mounting onto a Flat Surface
Using four mounting screws (not included), mount the device onto a flat
surface such as a wall or the underside of a table.
Mounting onto a Wall
1
DM-TXRX-100-STR
Mounting onto a Rack Rail
Quick Start
Using two mounting screws (not included), mount the left or right
mounting flange of the device onto the front or rear rail of a rack.
Mounting onto a Rack Rail
Connect the Device
Connect the device as required for the application.
Front Panel Connections
Rear Panel Connections
2
DM-TXRX-100-STR
NOTES:
Quick Start
l The LAN PoE (Power over Ethernet) port is a PoE PD (Powered
Device) port. To receive PoE, the DM-TXRX-100-STR requires
connection to a PoE PSE (Power Sourcing Equipment) port of a
PoE switch. Wiring that connects to a PoE PSE port is for
intrabuilding use only.
l Connection to the included power pack is not required when PoE
is used to power the device.
Configure the Device
Before configuring the DM-TXRX-100-STR, refer to the IP Considerations
Guidelines for the IT Professional Design Guide (Doc. 4579) at
www.crestron.com/manuals. The manual provides information about
proper configuration of the network to support the DM-TXRX-100-STR.
Configure the DM-TXRX-100-STR using the web interface. To access the
web interface, open a web browser and then go to the IP address of the
device.
NOTE: By default, DHCP is enabled. To display the IP address on the
connected display, press the SETUP button on the front panel of the
device.
Visit the Product Page
Scan the QR code to visit the product page.
www.crestron.com/model/6507122
To log in to the user interface, enter the user name and password. The
default user name and password are both admin. For additional
information, refer to the DM-TXRX-100-STR Supplemental Guide
(Doc. 7845) at www.crestron.com/manuals.
3
DM-TXRX-100-STR
Additional Information
Original Instructions
The U.S. English version of this document is the original instructions.
All other languages are a translation of the original instructions.
