DMC-4K-HD-HDCP2
4K HDMI® Input Card for DM® Switchers
> Modular input card for a DM-MD8X8, DM-MD16X16, or
DM-MD32X32 switcher
> Provides a single 4K HDMI® input
> Handles video resolutions up to 4K and Ultra HD
> Handles 3D video and Deep Color
> Handles Dolby® TrueHD, Dolby Atmos®, DTS-HD®, and
uncompressed 7.1 linear PCM audio
> HDCP 2.2 compliant
> Includes an HDMI output for pass-through of the input signal
> Includes a stereo analog line-level audio output with
volume control
> Allows de-embedding of stereo 2-channel audio signals
> Enables device control via CEC
> Enables USB HID signal extension for a local computer
> Compatible with Crestron USB over Ethernet Extenders
> Occupies a single DM® switcher input card slot
> Provides an HDMI problem solving solution using the optional
DMCI card interface
[2]
[3]
[4]
The DMC-4K-HD-HDCP2 is an input card designed for use with any cardbased Crestron® DigitalMedia™ Switcher. It provides one HDMI® input, with
complementary HDMI pass-through and analog audio outputs. A USB HID
port is also provided. The HDMI input handles Full HD 1080p, Ultra HD,
2K, and 4K video signals with support for HDCP 2.2, Deep Color, 3D, and
high-bitrate 7.1 audio. The HDMI input can also handle DVI and Dual-Mode
DisplayPort signals using an appropriate adapter or interface cable.
[1]
NOTE: Refer to model DMC-4K-HD-DSP-HDCP2 for use with surround sound
sources.
4K Ultra HD
The DMC-4K-HD-HDCP2 is capable of handling video resolutions up to
4K and Ultra HD. Support for 4K video also ensures support for the latest
generation of computers and monitors with native resolutions beyond
1080p and WUXGA.
HDMI® Pass-Through
Every DM switcher input card includes an HDMI output port, which can be
used to pass the input signal through to a local audio processor or video
monitor, or to feed a second DM switcher for output expansion purposes.
Audio De-embedding
The DMC-4K-HD-HDCP2 also includes an unbalanced analog audio output,
allowing stereo audio signals to be extracted from the digital input and fed
to a multiroom audio distribution system. The output volume is adjustable
via a control system using a keypad, touch screen, handheld remote, or
mobile device.
[2]
USB Signal Extension
Built-in USB HID signal routing allows a connected computer (or other
USB HID-compliant host) to be controlled by a mouse and/or keyboard
located at a presentation lectern, conference table, or some other remote
location. Additional USB devices of virtually any type can be supported
using Crestron USB over Ethernet Extenders (USB-EXT-DM)
[3]
.
CEC Embedded Device Control
DigitalMedia offers an alternative to conventional IR and RS-232 device
control by harnessing the CEC (Consumer Electronics Control) signal
embedded in HDMI. Through its connection to a Crestron control system
(via the DM switcher), the DMC-4K-HD-HDCP2 provides a gateway for
controlling the connected source device right through the HDMI
connection, potentially eliminating the need for any dedicated control
wires or IR emitters.
Standalone HDMI Problem Solver
In addition to its use as an input card for DM switchers, the DMC-4K-HDHDCP2 may also be used with the DMCI DigitalMedia Card Interface
[4]
to
provide a handy problem-solving tool with many useful functions. It can be
used to extract an analog audio signal from an HDMI stream, to provide a
gateway for CEC device control, and to extend a USB HID mouse/keyboard
signal over Ethernet. It can also be used to detect a deviceís video and
audio information, manage its EDID, and assess its HDCP capabilities.
To configure a DM switcher complete with input and output cards,
cables, and other peripherals, please use the online DigitalMedia
Switcher Configuration Tool.
NOTE: For applications requiring the simultaneous distribution of
multichannel surround sound and 2-channel stereo audio signals, use
model DMC-4K-HD-DSP-HDCP2.
crestron.com | 800.237.2041
Please refer to the DigitalMedia Resources Webpage at
http://www.crestron.com/dmresources/ for additional design tools and
reference documents.
DMC-4K-HD-HDCP2 4K HDMI
®
Input Card for DM® Switchers
SPECIFICATIONS
Video
Input Signal Types: HDMI w/Deep Color, 3D, & 4K (DVI & Dual-Mode
DisplayPort compatible
Output Signal Types: HDMI w/Deep Color, 3D, & 4K (DVI compatible
Maximum Resolutions:
Scan
Type
Progressive
Interlaced 1920x1080 HD1080i 30 Hz 4:4:4 36 bit
NOTE: Common resolutions are shown; other custom resolutions are
supported at pixel clock rates up to 300 MHz
Audio
Input Signal Types: HDMI (Dual-Mode DisplayPort compatible
Output Signal Types: HDMI (multichannel pass-through from input),
analog stereo (2-channel pass-through from input
Digital Formats: Dolby Digital®, Dolby Digital EX, Dolby Digital Plus,
Dolby® TrueHD, Dolby Atmos®, DTS®, DTS-ES, DTS 96/24, DTS-HD High
Res, DTS-HD Master Audio™, LPCM up to 8 channels
Analog Format: Stereo 2-channel
Digital-To-Analog Conversion: 24-bit 48 kHz
Analog Performance: Frequency Response: 20 Hz to 20 kHz ±0.5 dB;
Analog Volume Adjustment: -80 to 0 dB
Communications
USB: Supports signal extension of USB HID class devices, expandable to
support virtually any USB 1.1 or 2.0 device using Crestron USB-EXT-DM
USB over Ethernet Extenders
HDMI: HDCP 2.2, EDID, CEC
NOTE: Supports management of HDCP and EDID; supports management
of CEC between the connected HDMI devices and a control system
Connectors
HDMI OUT: (1) 19-pin Type A HDMI female;
HDMI digital video/audio output;
(DVI compatible
HDMI IN: (1) 19-pin Type A HDMI female;
HDMI digital video/audio input;
(DVI and Dual-Mode DisplayPort compatible
[1]
)
Resolution
Frame
Rate
Color
Sampling
Color
Depth
24 Hz 4:4:4 30 bit
4096x2160 DCI 4K
&
3840x2160 4K UHD
30 Hz 4:4:4 24 bit
30 Hz 4:2:2 36 bit
60 Hz 4:2:0 24 bit
2560x1600 WQXGA 60 Hz 4:4:4 36 bit
1920x1080 HD1080p 60 Hz 4:4:4 36 bit
[1]
)
[2]
)
S/N Ratio: >95 dB, 20 Hz to 20 kHz A-weighted;
THD+N: <0.005% @ 1 kHz;
Stereo Separation: >90 dB
[3]
[1]
)
[1]
)
[1]
)
USB HID: (1) USB Type B female;
USB device port for connection to the USB host interface of a computer or
other USB HID-compliant host
AUDIO OUT: (2) RCA female;
Unbalanced stereo line-level audio output
[2]
;
Output Impedance: 100 Ohms nominal;
Maximum Output Level: 2 Vrms
Construction
Plug-in card, occupies (1) DM switcher input card slot, includes metal
faceplate w/black finish
Weight
8.0 oz (227 g)
MODELS & ACCESSORIES
Available Models
DMC-4K-HD-HDCP2: 4K HDMI® Input Card for DM® Switchers
Available Accessories
CBL Series: Crestron® Certified Interface Cables
MP-WP Series: Media Presentation Wall Plates
MPI-WP Series: Media Presentation Wall Plates - International Version
USB-EXT-DM: USB over Ethernet Extender with Routing
DMCI: DigitalMedia™ Card Interface
Notes:
1. HDMI requires an appropriate adapter or interface cable to accommodate a DVI or Dual-Mode
DisplayPort signal. CBL-HD-DVI interface cables are available separately.
2. The analog stereo audio output is only active when the input source is outputting a
2-channel stereo signal. For applications using a multichannel surround sound source, use
model DMC-4K-HD-DSP-HDCP2 which provides simultaneous surround sound and stereo
downmix output signals.
3. USB-EXT-DM USB over Ethernet Extender Modules are sold separately. Refer to the
USB-EXT-DM spec sheet for more information.
4. Item(s) sold separately.
