CLW-DIM, DIMS, & SLVD(W/A/B)
Introduction
Features and Functions
The CLW-DIM (-DIM) is a stand-alone wall box dimmer
that can also act as a Cresnet
Crestron® control processor. The CLW-DIM has four
preset lighting levels that can be adjusted (refer to note
below). The CLW-DIM also includes two isolated, nonpolarized Cresnet wires (plus a ground wire) for
connecting to the Cresnet network over a twisted pair
wire with shield.
NOTE: The four preset levels are noted as Button 1High, Button 1-Low, Button Preset 2, and Button Preset
3. Preset “Button 1-High” is usually used for turning
lights on to full brightness while preset “Button 1-Low” is
usually used for turning the lights off. Although “1-High”
and “1-Low” are usually used for “On” and “Off”
respectively, the light level for each preset can be
customized by the user. Refer to “Operating Buttons and
Switches” on page 5 for more information on customizing
light levels.
The CLW-DIM features a three-position mode selection
switch. Refer to “Operating Buttons and Switches” on
page 5 for more information. In the absence of Cresnet
communications, the dimmer can still be used to control
lighting.
The CLW-DIMS (-DIMS) is similar to the -DIM with the
added capability of working with a slave unit
(CLW-SLVD) in a multi-switch / single circuit
application.
The CLW-SLVD (-SLVD) is a slave unit that when used
in conjunction with the -DIMS acts as an additional
dimmer control point in a multi-dimmer / single circuit
application. It does not connect to a Cresnet system and
cannot be used without a -DIMS. The -SLVD does not
have a mode selection switch and is not programmable. It
emulates the operation of the -DIMS to which it is
connected.
The -DIM, -DIMS, and -SLVD are available in white,
almond, and black. White units are designated by part
numbers ending in “W”. Almond units are designated by
part numbers ending in “A”. Black units are designated by
part numbers ending in “B”. Each dimmer can be covered
with a decorative faceplate (not supplied).
®
device that reports to a
Specifications
Following are specifications for the -DIM, -DIMS, and
-SLVD.
CLW-DIM, CLW-DIMS, & CLS-SLVD Specifications
SPECIFICATION DETAILS
Power Requirements Line Power, 120 VAC, 60 Hz
Default Net ID -DIM: 6D
-DIMS: 6E
Switch Type Dimmer
Load Type Incandescent, Tungsten-Halogen,
2-Series Control System
Update File
Load Ratings3
Incandescent/Tungsten
Halogen
Magnetic Low Voltage4 -DIM: 1000VA/750W
Operating Temperature
and Humidity
Dimensions and Weight -DIM and -DIMS:
1. The latest software versions can be obtained from the Crestron
2. Crestron 2-Series control systems include the AV2 and PRO2.
3. Refer to Derating Charts for Multigang Installations on page 3.
4. VA ratings are for input power to the transformer. If you do not
1,2
website. Refer to the NOTE following these footnotes.
Consult the latest Crestron Product Catalog for a complete list of
2-Series control systems.
know the input power requirement of the transformer, use the
bulb’s wattage rating to determine proper rating.
NOTE: Crestron software and any files on the website
are for Authorized Crestron dealers and Crestron
Authorized Independent Programmers (CAIP) only. New
users may be required to register to obtain access to
certain areas of the site (including the FTP site).
Magnetic Low Voltage
Version 3.093 or later
-DIM: 1000W
-DIMS: 1000W
-SLVD: N/A
-DIMS: 1000VA/750W
-SLVD: N/A
32°F to 104°F (0°C to 40°C)
10 to 90% Relative Humidity
(Non-Condensing)
Height: 4.13 in (10.48 cm)
Width: 2.38 in (6.03 cm)
Depth: 1.91 in (4.85 cm)
Weight: 4.9 oz (0.67 kg)
-SLVD:
Height: 4.13 in (10.48 cm)
Width: 1.75 in (4.45 cm)
Depth: 1.91 in (4.85 cm)
Weight: 3.6 oz (0.50 kg)
Crestron Electronics, Inc. Installation Guide – DOC. 5995B
15 Volvo Drive Rockleigh, NJ 07647 (2002077)
Tel: 888.CRESTRON 06.05
Fax: 201.767.7576 Specifications subject to
www.crestron.com change without notice.
CLW-DIM, DIMS, & SLVD(W/A/B)
Physical Description
The -DIM and -DIMS contain three buttons (one large,
two small), a light emitting diode (LED), and a threeposition slider-switch, shown after this paragraph. The
-SLVD is similar to the -DIM and -DIMS but does not
have the slider-switch. Line voltage connections are made
at the rear of the dimmer. Three Class 2 low voltage
wires, located on the front of the switch provide a Cresnet
connection to a control system. The wires are routed to
the bottom of the unit for placement outside of the wall
box.
CLW-DIM/DIMS (L) and CLW-SLVD (R) shown in white
Physical view of CLW-DIM/ DIMS (clockwise from top; Top,
Side, and Front)
Physical view of CLW-SLVD (clockwise from top; Top, Side,
and Front)
The -DIM, -DIMS, and -SLVD mount in a standard
wallbox and are covered using a decorative faceplate (not
included).
Industry Compliance
This product is Listed to applicable UL Standards and
requirements by Underwriters Laboratories Inc.
Important Notes
Read before installation.
• Codes: Install in accordance with all local and
national electrical codes.
Alternate wiring methods may be used for the
Class 2 wiring connection. The 2002 National
Electrical Code (Article 725-55) prohibits Class
2 conductors of the -DIM, -DIMS, and -SLVD to
occupy the same outlet box as the power
conductors. The exception is Part D of Section
725.55 of the 2002 National Electrical Code,
which allows a device’s power conductors to be
installed near (0.25 inch minimum spacing)
associated Class 2 conductors in the same outlet
box. Consult the 2002 National Electrical Code
Handbook and your local electrical inspector
before proceeding.
Do not use the supplied butt-splice connectors if
the Class 2 conductors are to be installed in the
wallbox with the power conductors. Use
2 • Stand Alone Wall Box Dimmer : CLW-DIM, DIMS, & SLVD Installation Guide – DOC. 5995B
