CREST SUSPENSION FORK User Manual
USER MANUAL
CREST SUSPENSION FORK
EN
INTRODUCTION
Congratulations on the purchase of a new Giant Crest 34 suspension fork. The all-new Crest 34 brings
state-of-the-art features and premium performance to a broad range of riders. Featuring a Thixomolded
34mm stanchion chassis, engineered to balance stiffness, lightweight and strength, the Crest 34 has a
dedicated tuned damper with low speed compression and an ample rebound circuit tuned to help every
rider find the best setting. Plush and precise, the Crest 34 makes high-end suspension accessible to
everyone.
IMPORTANT: PLEASE READ BEFORE RIDING
This user manual contains important safety, performance and service information. Please keep it for
future reference. We strongly urge you to read the Crest 34 Fork Owner’s Manual in its entirety before
your first ride. If you have any questions about this manual or your Crest fork, please contact a Giant
authorized retailer.
! WARNING
• Do not use the suspension fork for the following types of riding: Free ride, downhill or
other types of extreme riding
• The suspension fork is not intended for use on E-bikes.
• Ignoring safety instructions can cause serious injury or death.
• Do NOT use a high pressure washer to clean the suspension fork. Non-compliance with the
user manual can cause product damage and will void your warranty.
！ CAUTION
• Please select the suspension fork which matches your bicycle’s specification.
• Maximum riding weight is 136kg (299lbs). This includes rider + accessories. For safety,
please do not exceed the specified weight limit.
• Modification of the product from its original condition is not covered by Giant limited
warranty. Disassembly or modification of any type to the Crest 34 fork WILL VOID the
warranty.
• Regularly maintain your Crest 34 fork through a Giant authorized retailer. Maintenance
and replacement of components by a non-authorized retailer WILL VOID the warranty. All
service and replacement parts must be Giant components only.
• Make sure to comply with setting, usage maintenance and service information instruction
to ensure your riding safety. Ignoring safety instructions can cause serious injury or death.
1
EN
SERVICE AND TECHNICAL SUPPORT
If you encounter difficulties or are uncertain about anything mentioned
in this user manual, please contact a Giant authorized retailer.
For more information, please visit:
www.giant-bicycles.com/global/manuals
To find a dealer or to learn more about Giant, please visit:
www.giant-bicycles.com
CHECK YOUR BIKE BEFORE RIDING
• Check the correct functioning of the braking system. For more information on various common brake
systems please visit:
• Shimano: https://si.shimano.com/#/
• SRAM: https://www.servicearchive.sram.com/service
• TRP: https://trpcycling.com/downloads/
• Tektro: https://www.tektro.com/download.php?t=7
• If you are unsure of which brake system your bike is equipped with, please visit your Giant
authorized retailer.
• Check the correct tire pressure for your tire type and riding experience.
• If you are unsure of which tire your bike is equipped with, please visit your Giant authorized
retailer.
• Check the correct tightness of the thru axle. For more information, please visit:
• Giant: https://www.giant-bicycles.com/global/manuals
• If you encounter difficulties, please contact a Giant authorized retailer.
• Check the surface of the suspension fork for bending, deformation, cracking, etc.
• Stop riding your bike immediately and contact a Giant authorized retailer if you encounter any
issues.
• Check the suspension fork for leaks.
• Stop riding your bike immediately and contact a Giant authorized retailer if you encounter any
issues.
• Check the correct air pressure setting of the suspension fork.
• If you encounter difficulties, please contact a Giant authorized retailer.
• Check the correct tightness of all bolts. For more information, please visit:
• Giant: https://www.giant-bicycles.com/global/manuals
2
EN
PRODUCT INTRODUCTION
F
K
G
A
B
C
A. Tapered steerer tube
B. Air spring cap
C. 34mm stanchion
D. Brake cable guide
J
E. Lower leg
F. Low speed compression cap
G. O-ring
H. Rebound adjustment knob
I. Thru axle
J. Crown
D
E
K. Lower leg arch
H
I
3
