CREST ELECTRONICS™

CRE 57076 CAPACITOR BOARD

www.crest-electronics.net

[e-mail]

201-565-6069

CRE 57076 CAPACITOR BOARD

FOR TRACK POWER USE ONLY

12000MF 35 V

THIS DEVICE PLUGS DIRECTLY INTO A SOCKET ON THE REVOLUTION
RECEIVER (CRE57002SD/SS) AND SUPPLIES CURRENT TO PROVIDE CONSTANT
VOLTAGE OVER DIRTY TRACK OR POOR CONNECTIVITY IN TRACK LAYOUTS.

BEFORE YOU INSTALL THE RECEIVER IN THE LOCOMOTIVE, PLUG IN THE MALE
PLUG FROM THE CAPACITOR BOARD MARK #1 TO THE FEMALE PLUG MARK #2
ON THE RECEIVER.

TO REMOVE THE PLUG FROM THE RECEIVER HOLD THE MALE PLUG FIRMLY
AND PULL OUTWARD. DO NOT PULL ON THE WIRES TO REMOVE THE MALE
PLUG FROM THE RECEIVER.

SERVICING:

Should your Craft Electronics Product require warranty service, please return it in the
original box, if possible protecting by a proper shipping carton. Craft is not responsible
for any loss or damage incurred during the shipping. Be sure to include a brief but
through explanation of the problem, with your name, shipping address, and phone
number so that we may contact you if necessary.

Payment for shipping and handling, in the US funds is $20.00 and should be included.
Check or money order should be payable to: Crest Electronics, Inc. Do not send cash.
If your item is not covered by warranty service, you will be contacted and a repair RA

Capacitor Board Page 1

2.4GHz

number will be given to you before any work commences. Warranty covers
manufactures defects, not normal wear and tear.
