INSULATED STAINLESS STEEL
C US
®
SUPER DUTY HOT CABINET SERIES
FEATURES AND BENEFITS:
• Fully insulated hot cabinet keeps prepared
foods at safe serving temperatures.
• Available in Full Size, 3/4 Size or half size
units with locking universal transport angles
accommodate a variety of pan sizes on
adjustable 1-1/2" centers.
• Powerful, yet efcient, 1500 Watt heating
system maintains the right temperature to
properly hold products. Heats up to 200˚F
(93˚C).
• Standard solid state electronic control with
large, clear, easy-to-read and operate LED
digital display to ensure holding at precise food
temperature.
• Internal frame in body maintains structural
rigidity.
SANITATION
NSF/ANSI 4
JOB:
ITEM NO:
®
H-137-SUA-12D-SD
• Full perimeter bumper, rear push/pull handle
and dry erase panel come standard on all
models.
• Stainless steel construction throughout for ease
of cleaning. One piece extended base protects
cabinet body.
• Super duty composite side impact panel
protection with ergonomic grips on both sides
prevents damage to walls; allows for easy
maneuvering.
• Insulated Dutch doors prevent temperature
loss. Standard with right hand hinging; left hand
hinging available upon request.
• Lockable slide bolt door latches ensure the
doors stay closed even during the roughest
transport.
• Smooth interior coved corners prevent food
particle/grease buildup.
• Heavy duty 6" modulus casters, two with
brakes. Provides mobility when fully loaded.
Standard solid state electronic control with large,
clear, easy-to-read and operate LED digital display
to ensure holding at precise food temperature
ACCESSORIES and OPTIONS
(Available at extra cost):
q Extra Transport Angles
q 208 or 240 Volt Service
q Upgrade to 2000 Watt Power Unit
See page B-30 for accessory details.
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
Gold indicates our Best Insulated
Hot Cabinets with the best warranty
in the industry.
3-Year Parts / 1-Year Labor.
Page B-5.7
Jan., 2017
C
B
A
B
A
70"
G
Scan QR code to view Spec Sheet,
Operating Manual, Wiring Diagram or
to call Cres Cor
®
Customer Service.
If you need a QR reader, visit your
App Store on your Smartphone or
Tablet.
Model
H-137-SUA-12DSD
8400-025
HOLDS 18 X 26 PAN
HOLDS 12 X 20 PAN
PAN SLIDE
2.213
DETAIL OF
A
C
B
H-137-SD SERIES
G
W
5-15P
CRES COR
MODEL NO.
ANGLES
H-137-SUA-12D-SD 12 SETS
H-137-SUA-9D-SD 9 SETS
H-137-SUA-6D-SD 6 SETS
CAPACITY/
PAN SIZE
(12) 18 x 26 or
(24) 12 x 20
(9) 18 x 26 or
(18) 12 x 20
(6) 18 x 26 or
(12) 12 x 20
CABINET:
• Body: 22 ga. stainless steel.
• Reinforcement: Internal framework of 18 ga. 304 stainless steel.
• Insulation: Fiberglass, thermal conductivity (K factor) is .23 at
75˚F. 1-1/2" in doors, base top; 2" in sidewalls.
• Air tunnels: 22 ga. stainless steel; lift-out type, mounted on sides.
• Push/pull handle: Welded stainless steel with end bumpers; rear
mounted.
• Interior coved corners.
• Super Duty composite side impact panel with ergonomic grips.
• Supplied with magnetic white erasable board, 12" x 12".
BASE:
• One piece construction, .125 aluminum; extended in rear for toe kick.
• Casters: 6" dia., modulus tires, 2" wide, load cap. 450 lbs. each,
temp. range -40˚/+180˚F. Sealed ball bearings; permanently
lubricated. Front casters equipped with brakes.
• Perimeter bumper: 1" non-marking gray rubber.
DIM "A" DIM "B" DIM "C" INSIDE DIMENSIONS
WIDTH DEPTH HEIGHT WIDTH DEPTH HEIGHT
WEIGHT
ACT.
IN 30-1/2 34-7/8 74-3/8 22 26-7/8 58 LBS 283
MM 775 885 1890 560 685 1475 KG 128
IN 30-1/2 34-7/8 58-5/8 22 26-7/8 42 LBS 295
MM 775 885 1490 560 685 1070 KG 134
IN 30-1/2 34-7/8 44-3/8 22 26-7/8 28 LBS 280
MM 775 885 1130 560 685 715 KG 127
Gold indicates our Best Insulated
Hot Cabinets with the best warranty
in the industry.
3-Year Parts / 1-Year Labor.
TRANSPORT PAN SLIDES:
• Extruded aluminum; mounted on locking lift-off posts.
• Spaced on 4-1/2" centers; adjustable on 1-1/2" centers.
HOT UNIT COMPONENTS:
• Thermostat: Solid state digital display control, room ambient to
200˚F (93˚C).
• Switch: ON-OFF push button type.
• Power cord: Permanent, 10 ft., 14/3 ga.
• Heater: 1470 Watts (960 Watts for -UA6D)
• Blower motor.
• Vent Fan.
• Thermometer: Digital.
POWER REQUIREMENTS:
• For H137SUA9D and H137SUA12D: 1500 Watts, 120 Volts, 60
Hz., single phase, 12 Amps., 15 Amp. service.
• For H137SUA6D: 1000 Watts, 120 Volts, 60 Hz., single phase,
8.3 Amps., 15 Amp. service.
DUTCH DOORS:
• Formed 22 ga. stainless steel.
• Hinges: 11 ga. stainless steel, butt type.
• Gaskets: Perimeter type, silicone.
• Pan stop: Embossed.
• Latches: Polished stainless steel, slam type; ush mounted.
• Transport Latch: 12 ga. stainless steel slide with lockable hasp.
Cres Cor Insulated Hot Cabinet Model H-137-SUA-___D.
Solid state electronic controlled time and temperatures.
Cabinet 22 ga. stainless steel; stainless steel internal
frame. (__) sets locking transport angles for multiple
SHORT FORM SPECIFICATIONS
pan sizes, adjust able spacing every 1-1/2". Dutch doors,
22 ga. stainless steel. Fiberglass insulation in sides, 2";
Scan QR code to view Spec Sheet,
Operating Manual, Wiring Diagram
or to call Customer Service.
If you need a QR reader visit your App
Store on your Smartphone or Tablet.
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
© Crescent Metal Products, Inc. 2017 All rights reserved. Made in America Since 1936
doors, base, top 1-1/2". Interior coved corners. 1500
or 1000 Watt, 120 Volt power unit. One piece insulated
base, .125 aluminum. 6" modulus casters, ball bearings.
Load capacity 450 lbs. each. 3-Year Parts / 1-Year
Labor warranty. Provide the following accessories: ____
_____ _____ NSF, CSA-US, CSA-C listed. Energy Star
Qualied.
In line with its policy to continually improve its products,
CRES COR reserves the right to change materials and
specications without notice.
