INSULATED
STAINLESS STEEL HOT CABINET
MODEL H-137-SUA-12D
FEATURES AND BENEFITS:
• Fully insulated hot cabinet keeps prepared
foods at serving temperatures.
• Powerful, yet efcient, 1500 Watt heating
system maintains the right temperature to
properly hold products. Heats up to 200˚F
(93˚C).
• Standard solid state electronic control with
large, clear, easy-to-read and operate LED
digital display to ensure holding at precise food
temperature.
• Internal frame in body maintains structural
rigidity.
• Stainless steel construction throughout for ease
of cleaning. One piece extended base protects
cabinet body.
• Smooth interior coved corners prevent food
particle/grease buildup.
JOB:
ITEM NO:
®
®
C US
H-137-SUA-12D
• Safety-conscious anti-microbial latches protect
against spreading germs.
• Field reversible insulated Dutch doors prevent
temperature loss. Silicone door gaskets for
proper seal.
• Standard with right hand hinging; left hand
hinging available upon request.
• High temperature ceramic magnetic latches
for “easy open”; twist-lock catch secures door
during transport.
• Recessed push/pull handles on both sides
prevent damage to walls; allows easy
maneuvering.
• Twelve sets of chrome plated wire universal
angles accommodate a large variety of pan
sizes on adjustable 1-1/2" centers.
• Heavy duty 5" swivel casters, two with brakes.
Provides mobility when fully loaded.
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
Standard solid state electronic control with large,
clear, easy-to-read and operate LED digital display
to ensure holding at precise food temperature
ACCESSORIES and OPTIONS
(Available at extra cost):
q Tempered Glass Door Windows
q Key Lock Handles
q Lock Hasp
q Extra Universal Angles
q Change from standard chrome plated wire
angles to angles designed for transporting
q Corner Bumpers
q Perimeter Bumper
q Rear Push Handle
q Bail Handles
q Various Caster Options
q Removable Cord Set
q 208 or 240 Volt Service
q Upgrade to 2000 Watts Power Unit
q HACCP Documentation (Built-in USB port)
See page B-20 for accessory details.
Gold indicates our Best Insulated
Hot Cabinets with the best warranty
in the industry.
3-Year Parts / 1-Year Labor.
Page B-5.1
Feb., 2014
5-1/8
5-15P
4-1/2
9"
H-137-SUA-12D
A
B
A
B
C
70"
DETAIL OF
PAN SLIDE
CRES COR
MODEL NO.
ANGLES
H-137-SUA-12D
NOTES: 1. Pan sizes 22" x 20" (560 x 510) Roast & Bake Pans, 10" x 20" (255 x 510) Roast & Bake Pans, 18" x 26" (460 x 660)
Bun Pans, 14" x 18" (355 x 460) Service Trays, 12" x 20" (305 x 510) Steam Table Pans.
Refer to Pan Size Chart at end of section.
2. When ordering bumpers, add 2" to overall dimensions.
CABINET:
• Body: 22 ga. stainless steel.
• Reinforcement: Internal framework of 18 ga. stainless steel.
• Insulation: Fiberglass, thermal conductivity (K factor) is .23 at
75˚F. 1-1/2" in doors, base top; 2" in sidewalls.
• Air tunnels: 22 ga. stainless steel; lift-out type, mounted on sides.
• Push/pull handles (2): 5” vertical; recessed.
• Interior coved corners.
BASE:
• One piece construction, .125 aluminum.
• Casters: 5" dia., swivel, modulus tires, 1-1/4 wide, load cap.
250 lbs. each, temp. range -45˚/+180˚F. Delrin bearings. Front
casters equipped with brakes.
DUTCH DOORS:
• Field reversible.
• Formed 22 ga. stainless steel.
• Latches: Chrome plated zinc, high temperature ceramic
magnetic type, mounted inboard.
• Transport Latches.
• Hinges: Heavy duty chrome plated zinc.
• Gaskets: Perimeter type, silicone.
• Pan stops: Embossed.
PAN SLIDES:
• Wire angles (.306 dia.), nickel chrome plated steel, mounted on
lift-off posts.
• Spaced on 4-1/2" centers; adjustable on 1-1/2" centers.
PAN DIM "A" DIM "B" DIM "C" INSIDE DIMENSIONS
CAP/
12
SETS
SIZE WIDTH DEPTH HEIGHT WIDTH DEPTH HEIGHT
SEE NOTE
BELOW
IN 28-3/4 32-3/4 73 22 26-7/8 58 LBS 283
MM 730 835 1855 560 685 1475 KG 128
HOT UNIT COMPONENTS:
• Thermostat: Solid state digital display control, room ambient to
200˚F (93˚C).
• Switch: ON-OFF push button type.
• Power cord: Permanent, 10 ft., 14/3 ga.
• Heater: 1470 Watts.
• Blower motor.
• Vent Fan.
• Thermometer: Digital.
POWER REQUIREMENTS:
• 1500 Watts, 120 Volts, 60 Hz., single phase, 12 Amps., 15 Amp.
service.
SHORT FORM SPECIFICATIONS
Cres Cor Insulated Hot Cabinet Model H-137-SUA-12D.
Solid state electronic controlled time and temperatures.
Cabinet 22 ga. stainless steel; stainless steel internal
frame. (12) sets wire universal angles for multiple pan
sizes, adjust able spacing every 1-1/2". Field reversible
Dutch doors, 22 ga. stainless steel. Fiberglass insulation
in sides, 2"; doors, base, top 1-1/2". Interior coved
corners. 1500 Watt, 120 Volt power unit. One piece
insulated base, .125 aluminum. 5" swivel modulus
casters, Delrin bearings. Load capacity 250 lbs. each.
3-Year Parts / 1-Year Labor warranty. Provide the
following accessories: . NSF, CSA-US,
CSA-C listed. Energy Star Qualied.
Gold indicates our Best Insulated
Hot Cabinets with the best warranty
in the industry.
3-Year Parts / 1-Year Labor.
G
W
WEIGHT
ACT.
In line with its policy to continually improve its products,
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
© Crescent Metal Products, Inc. 2013 All rights reserved. Litho in U.S.A.
CRES COR reserves the right to change materials and
specications without notice.
